2007 NISSAN 350Z reverse

AT-76
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
45
Slips/Will
Not
EngageWith selector lever in
“D” position, driving is
not possible.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. PNP switchAT- 1 0 2
4. A/T positionAT- 2 0 6
5. Control valve with TCMAT- 2 1 5
OFF vehicle6. Torque converterAT- 2 5 5
7. Oil pump assembly AT- 2 7 1
8. 1st one-way clutchAT- 2 8 1
9. Gear systemAT- 2 4 6
10. Reverse brakeAT- 2 5 5
11. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-17, "
Cross-sectional View" .)AT- 2 5 5
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT- 2 5 5
46With selector lever in
“R” position, driving is
not possible.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. PNP switchAT- 1 0 2
4. A/T positionAT- 2 0 6
5. Control valve with TCMAT- 2 1 5
OFF vehicle6. Gear systemAT- 2 4 67. Output shaftAT- 2 5 5
8. Reverse brakeAT- 2 5 5
47
Does Not
ChangeDoes not change M
5
→ M
4 .
Refer to AT-196, "
A/T
Does Not Shift: 5th
Gear → 4th Gear" .ON vehicle1. PNP switchAT- 1 0 2
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT- 2 0 6
4. Manual mode switchAT- 1 5 7
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT- 2 1 5
OFF vehicle 7. Front brake (brake band)AT- 2 5 5
48Does not change M
4
→ M
3 .
Refer to AT-198, "
A/T
Does Not Shift: 4th
Gear → 3rd Gear" .ON vehicle1. PNP switchAT- 1 0 2
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT- 2 0 6
4. Manual mode switchAT- 1 5 7
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT- 2 1 5
OFF vehicle7. Front brake (brake band)AT- 2 5 58. Input clutchAT- 2 7 6
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-77
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z49
Does Not
ChangeDoes not change M
3
→ M
2 .
Refer to AT-199, "
A/T
Does Not Shift: 3rd
Gear → 2nd Gear" .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Front brake (brake band)AT-2558. Input clutchAT-276
9. High and low reverse clutchAT-286
50Does not change M
2
→ M
1 .
Refer to AT-201, "
A/T
Does Not Shift: 2nd
Gear → 1st Gear" .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Input clutchAT-2768. High and low reverse clutchAT-286
9. Direct clutchAT-288
51Cannot be changed to
manual mode.
Refer to AT-196,
"Cannot Be Changed
to Manual Mode" .ON vehicle1. Manual mode switchAT-157
2. Turbine revolution sensorAT-106
3. CAN communication lineAT- 9 4
52
OthersShift point is high in
“D” position.ON vehicle1. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108
,
AT-139
2. Accelerator pedal position sensorAT-131
3. CAN communication lineAT- 9 4
4. A/T fluid temperature sensorAT-134
5. Control valve with TCMAT-215
53Shift point is low in “D”
position.ON vehicle1. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108
,
AT-139
2. Accelerator pedal position sensorAT-131
3. CAN communication lineAT- 9 4
4. Control valve with TCMAT-215
No. Items Symptom Condition Diagnostic ItemReference
page

AT-78
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
54
OthersJudder occurs during
lock-up.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. Turbine revolution sensorAT- 1 0 6
4. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 8,
AT- 1 3 9
5. Accelerator pedal position sensorAT- 1 3 1
6. CAN communication lineAT- 9 4
7. Torque converter clutch solenoid valveAT- 1 2 5
8. Control valve with TCMAT- 2 1 5
OFF vehicle 9. Torque converterAT- 2 5 5
55Strange noise in “R”
position.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. CAN communication lineAT- 9 4
4. Control valve with TCMAT- 2 1 5
OFF vehicle5. Torque converterAT- 2 5 5
6. Oil pump assemblyAT- 2 7 1
7. Gear systemAT- 2 4 6
8. High and low reverse clutchAT- 2 8 6
9. Reverse brakeAT- 2 5 5
56Strange noise in “N”
position.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. CAN communication lineAT- 9 4
4. Control valve with TCMAT- 2 1 5
OFF vehicle5. Torque converterAT- 2 5 56. Oil pump assemblyAT- 2 7 1
7. Gear systemAT- 2 4 6
57Strange noise in “D”
position.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. CAN communication lineAT- 9 4
4. Control valve with TCMAT- 2 1 5
OFF vehicle5. Torque converterAT- 2 5 5
6. Oil pump assemblyAT- 2 7 1
7. Gear systemAT- 2 4 6
8. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT- 2 5 5
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-79
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z58
OthersVehicle does not
decelerate by engine
brake.
Refer to AT-202,
"Vehicle Does Not
Decelerate by Engine
Brake" .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Input clutchAT-2768. High and low reverse clutchAT-286
9. Direct clutchAT-288
59Engine brake does
not work M5 → M4 .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle 7. Front brake (brake band)AT-255
60Engine brake does
not work M4 → M3 .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Front brake (brake band)AT-2558. Input clutchAT-276
61Engine brake does
not work M3 → M2 .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Manual mode switchAT-157
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle7. Front brake (brake band)AT-2558. Input clutchAT-276
9. High and low reverse clutchAT-286
No. Items Symptom Condition Diagnostic ItemReference
page

AT-80
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
62
OthersEngine brake does
not work M2 → M1 .ON vehicle1. PNP switchAT- 1 0 2
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT- 2 0 6
4. Manual mode switchAT- 1 5 7
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT- 2 1 5
OFF vehicle7. Input clutchAT- 2 7 68. High and low reverse clutchAT- 2 8 6
9. Direct clutchAT- 2 8 8
63 Maximum speed low.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Line pressure testAT- 5 0
3. Accelerator pedal position sensorAT- 1 3 1
4. CAN communication lineAT- 9 4
5. Direct clutch solenoid valveAT- 1 4 9
6. Control valve with TCMAT- 2 1 5
OFF vehicle7. Torque converterAT- 2 5 5
8. Oil pump assemblyAT- 2 7 1
9. Input clutchAT- 2 7 6
10. Gear systemAT- 2 4 6
11. High and low reverse clutchAT- 2 8 6
12. Direct clutchAT- 2 8 8
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-17, "
Cross-sectional View" .)AT- 2 5 5
14 Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT- 2 5 5
64Extremely large
creep.ON vehicle1. Engine idle speed EC-76

2. CAN communication lineAT- 9 4
OFF vehicle 3. Torque converterAT- 2 5 5
65With selector lever in
“P” position, vehicle
does not enter parking
condition or, with
selector lever in
another position, park-
ing condition is not
cancelled.ON vehicle1. PNP switchAT- 1 0 2
2. A/T positionAT- 2 0 6
3. Parking pawl componentsAT- 2 4 6
66Vehicle runs with A/T
in “P” position.ON vehicle1. PNP switchAT- 1 0 2
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT- 2 0 6
4. Control valve with TCMAT- 2 1 5
5. Parking pawl componentsAT- 2 4 6
OFF vehicle 6. Gear systemAT- 2 4 6
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-81
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
67
OthersVehicle runs with A/T
in “N” position.
Refer to AT-174, "In
“N” Position, Vehicle
Moves" .ON vehicle1. PNP switchAT-102
2. A/T fluid level and stateAT- 4 9
3. A/T positionAT-206
4. Control valve with TCMAT-215
OFF vehicle5. Input clutchAT-276
6. Gear systemAT-246
7. Direct clutchAT-288
8. Reverse brakeAT-255
9. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 7 , "
Cross-sectional View" .)AT-255
10. Low coast brake (Parts behind drum support is impossi-
ble to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT-255
68Engine does not start
in “N” or “P” position.
Refer to AT-173, "Engine Cannot Be
Started in “P” or “N”
Position" .ON vehicle1. Ignition switch and starterPG-4
,
SC-8
2. A/T positionAT-206
3. PNP switchAT-102
69Engine starts in posi-
tions other than “N” or
“P”.ON vehicle1. Ignition switch and starterPG-4
,
SC-8
2. A/T positionAT-206
3. PNP switchAT-102
70 Engine stall.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. Turbine revolution sensorAT-106
4. Torque converter clutch solenoid valveAT-125
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle 7. Torque converterAT-255
71Engine stalls when
selector lever shifted
“N” → “D”, “R”.ON vehicle1. A/T fluid level and stateAT- 4 9
2. Engine speed signalAT- 11 3
3. Turbine revolution sensorAT-106
4. Torque converter clutch solenoid valveAT-125
5. CAN communication lineAT- 9 4
6. Control valve with TCMAT-215
OFF vehicle 7. Torque converterAT-255
No. Items Symptom Condition Diagnostic ItemReference
page

TROUBLE DIAGNOSIS
AT-85
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
I/C SOLENOIDInput clutch disengaged. Refer to AT- 1 9 . 0.6 – 0.8 A
Input clutch engaged. Refer to AT- 1 9
. 0 – 0.05 A
FR/B SOLENOIDFront brake engaged. Refer to AT- 1 9
. 0.6 – 0.8 A
Front brake disengaged. Refer to AT- 1 9
. 0 – 0.05 A
D/C SOLENOIDDirect clutch disengaged. Refer to AT- 1 9
. 0.6 – 0.8 A
Direct clutch engaged. Refer to AT- 1 9
. 0 – 0.05 A
HLR/C SOLHigh and low reverse clutch disengaged. Refer to AT- 1 9
. 0.6 – 0.8 A
High and low reverse clutch engaged. Refer to AT- 1 9
. 0 – 0.05 A
ON OFF SOLLow coast brake engaged. Refer to AT- 1 9
.ON
Low coast brake disengaged. Refer to AT- 1 9
.OFF
MANU MODE SWManual shift gate position (neutral) ON
Other than the above OFF
NON M-MODE SWManual shift gate position OFF
Other than the above ON
UP SW LEVERSelector lever: + side ON
Other than the above OFF
DOWN SW LEVERSelector lever: - side ON
Other than the above OFF
STARTER RELAYSelector lever in “N” and “P” positions. ON
Selector lever in other positions. OFF
ACCELE POSIReleased accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8.0/8
CLSD THL POSReleased accelerator pedal. ON
Fully depressed accelerator pedal. OFF
W/O THL POSFully depressed accelerator pedal. ON
Released accelerator pedal. OFF
BRAKE SWDepressed brake pedal. ON
Released brake pedal. OFF
GEAR During driving 1, 2, 3, 4, 5 Item name Condition Display value (Approx.)

TROUBLE DIAGNOSIS
AT-91
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
DTC WORK SUPPORT MODE
Display Items List
Frequency (Hz) — —
The value measured by the pulse probe is dis-
played. DUTY-HI (high) (%) — —
DUTY-LOW (low) (%) — —
PLS WIDTH-HI (ms) — —
PLS WIDTH-LOW (ms) — —Monitored item (Unit)Monitor Item Selection
Remarks
ECU INPUT
SIGNALSMAIN SIG-
NALSSELEC-
TION FROM
MENU
DTC work support item Description Check item
1ST GR FUNCTN P0731Following items for “1st gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)

Input clutch solenoid
valve

Front brake solenoid
valve

Direct clutch solenoid
valve

High and low reverse
clutch solenoid valve

Each clutch

Hydraulic control circuit 2ND GR FUNCTN P0732Following items for “2nd gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)
3RD GR FUNCTN P0733Following items for “3rd gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)
4TH GR FUNCTN P0734Following items for “4th gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)
5TH GR FUNCTN P0735Following items for “5th gear function” can be confirmed.

Self-diagnosis status (whether the diagnosis is being performed or not)

Self-diagnostic results (OK or NG)
