2007 NISSAN 350Z remote control

AUDIO
AV-31
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 November2007 350Z

*1: With M/T without navigation system and VDC system

*2: Except *1

*3: With navigation system 20 (L/B) 19 (R/B)Voice guidance
signal
*3Input ON Press “VOICE” button
21 (R/G) 23 (Y/G)Remote control signal
AInput ONPress and hold MODE
switchApprox. 0 V
Press and hold SEEK UP
switchApprox. 1.7 V
Press and hold VOLUME
UP switchApprox. 3.3 V
Except for above Approx. 5 V
22 (OR) 23 (Y/G)Remote control signal
BInput ONPress and hold POWER
switchApprox. 0 V
Press and hold SEEK
DOWN switchApprox. 1.7 V
Press and hold VOLUME
DOWN switchApprox. 3.3 V
Except for above Approx. 5 V
23 (Y/G) GroundRemote control
ground— ON — Approx. 0 V Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
SKIB3597E

AUDIO
AV-33
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 November2007 350Z
22 (R/G)25
(GR)*1
(Y/G)*2
Remote control signal
AInput ONPress and hold MODE
switchApprox. 0 V
Press and hold SEEK UP
switchApprox. 1.7 V
Press and hold VOLUME
UP switchApprox. 3.3 V
Except for above Approx. 5 V
23 (OR)25
(GR)
*1
(Y/G)*2
Remote control signal
BInput ONPress and hold POWER
switchApprox. 0 V
Press and hold SEEK
DOWN switchApprox. 1.7 V
Press and hold VOLUME
DOWN switchApprox. 3.3 V
Except for above Approx. 5 V
24 (R/B)31
(B/OR)Voice guidance ON
signal
*3Input ON Press “VOICE” button
25
(GR)
*1
(Y/G)*2GroundRemote control
ground— ON — Approx. 0 V
27 (L) 26 (P)
TEL voice signal
*1Input ONReceiving the party's voice
while using the hands-free
phone system.
28 (W/G) Ground
TEL ON signal
*1Input ONWhen using hands-free
phone systemApprox. 0 V
Except while using hands-
free phone systemApprox. 5 V
29 —
Shield
*1—— — —
32 (L/B) 30 (W/B)Voice guidance
signal
*3Input ON Press “VOICE” button
34 (B/R) GroundCommunication signal
Tx (AUDIO-SAT)
*4Output ONWhen setting to satellite
radio mode Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
SKIB0232E
SKIB3609E
SKIB3597E
SKIB7336E

AV-110
TELEPHONE
Revision: 2006 November2007 350Z
Terminals and Reference Value for TEL Adapter UnitNKS0056H
Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
1 (Y) Ground Battery power supply Input OFF — Battery voltage
2 (LG) Ground ACC power supply Input ACC — Battery voltage
3 (Y/G) Ground Ignition signal Input ON — Battery voltage
4 (B) Ground Ground — ON — Approx. 0 V
5 — Shield — — — —
6 — Shield — — — —
7 (R) 8 (B)TEL microphone sig-
nalInput ONUttering in front of the
microphone while using the
hands-free phone system.
9 (L) 10 (P) TEL voice signal Output ONReceiving the party's voice
while using the hands-free
phone system.
11 (W/G) Ground TEL ON signal Output ONWhile using hands-free
phone systemApprox. 0 V
Except while using hands-
free phone systemApprox. 5 V
12 (SB) 14 (PU)Remote control signal
AInput ONPress and hold switchApprox. 0 V
Press and hold SEEK UP
switchApprox. 1.7 V
Press and hold VOLUME
UP switchApprox. 3.3 V
Except for above Approx. 5 V
13 (G) 14 (PU)Remote control signal
BInput ONPress and hold switchApprox. 0 V
Press and hold SEEK
DOWN switchApprox. 1.7 V
Press and hold VOLUME
DOWN switchApprox. 3.3 V
Except for above Approx. 5 V
14 (PU) GroundRemote cntrol signal
ground— ON — Approx. 0 V
15
(L/Y)Ground Indicator signal Output ONMicrophone indicator ON Approx. 1 V
Microphone indicator OFF Approx. 10 V
17 (R/G) 19 (GR)Remote control signal
AOutput ONPress and hold SEEK UP
switchApprox. 1.7 V
Press and hold VOLUME
UP switchApprox. 3.3 V
Except for above Approx. 5 V
SKIB3609E
SKIB3609E

TELEPHONE
AV-111
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 November2007 350ZSelf-Diagnosis FunctionNKS0056J

During on board diagnosis the diagnosis function of TEL adapter unit starts with the operation of the steer-
ing switch and performs the diagnosis when ignition switch ACC.

The on board diagnosis has 3 modes: the self-diagnosis mode that performs the trouble diagnosis, the
speaker adaptation data deleting mode and the hands free phone system initialization mode.
NOTE:

Perform the diagnosis with the vehicle stopped.

Perform STEP 2 if necessary.
18 (OR) 19 (GR)Remote control signal
BOutput ONPress and hold switchApprox. 0 V (Audio mode)
Approx. 5 V (TEL mode)
Press and hold SEEK
DOWN switchApprox. 1.7 V
Press and hold VOLUME
DOWN switchApprox. 3.3 V
Except for above Approx. 5 V
19 (GR) GroundRemote control signal
ground— ON — Approx. 0 V
20 (B) Ground Control signal 1 — ON — Approx. 0 V
22 (B) Ground Control signal 3 — ON — Approx. 0 V
23 (B) Ground Control signal 4 — ON — Approx. 0 V
28 (W) GroundVehicle speed signal
(2-pulse)Input ONWhen vehicle speed is
approx. 40 km/h (25 MPH)NOTE:
Maximum voltage may be 12 V
due to specifications (connected
units).
29 (W) Ground TEL Microphone VCC Output ON — Approx. 5 V
33 — TEL antenna signal Input ONNot connected to Blue-
tooth
® antenna connectorApprox. 3 V Te r m i n a l
(Wire color)
ItemSignal
input/
outputCondition
Reference value
+–Ignition
switchOperation
ELF1080D
STEP Mode Contents
STEP 1 Self-diagnosisThe self-diagnosis mode perform the following.

Diagnosis of TEL adapter unit, Bluetooth antenna and steering switch.

Vehicle speed pulse count.

Microphone test.
Then reads out the results with the sound.
STEP 2Speaker adaptation data deletingThe speaker adaptation data deleting mode can delete the speaker adapta-
tion data.
Hands free phone system initializationHands free phone system initialization mode can perform the initialization
of hands free phone system.

AV-114
TELEPHONE
Revision: 2006 November2007 350Z
Symptom ChartNKS0056K
Indicator
statusSymptom Check item Diagnosis procedure
ON
(Normal)Voice is not heard on the
other end.—

Check the TEL microphone signal circuit
between TEL adapter unit to the TEL
microphone.

Check the TEL microphone power sup-
ply circuit between TEL adapter unit to
the microphone.
Voice guidance does not
activate, or the volume of
voice guidance is too low
when pressing switch.
(“PHONE” is indicated on
LCD screen of the audio
unit)—Check TEL voice signal circuit between
TEL adapter unit to the audio unit.
Voice guidance does not
activate, when pressing
switch. (“PHONE” is not indi-
cated on LCD screen of the
audio unit)Dial the cellular phone. The front speaker
RH outputs a dial tone.1. Check “VOLUME UP” and “SEEK UP”
switches function.
2. Replace steering switch, if “VOLUME
UP” and “SEEK UP” switches function is
normal. If not, go to 3.
3. Check if remote control signal A circuit
between steering switch and TEL
adapter unit is not open or short.
4. Check voltage of remote control signal A
between steering switch and TEL
adapter unit when operating steering
switch.
Dial the cellular phone. The front speaker
RH does not outputs a dial tone.1. Check TEL ON signal circuit. Go to the
next step if normal.
2. Disconnect TEL adapter unit connector.
Measure audio unit #28 terminal volt-
age. Replace TEL adapter unit if the
voltage approx. 5 V. Replace audio unit
if the voltage approx. 0 V.
None of the steering switch
operations work.—

Check control signal 1circuit.

Check steering switch signal ground cir-
cuit.
OFFBluetooth
® communication
does not perform.The indicator blinks for approx. 5 sec.
when pressing switch.Perform the error history mode with self-
diagnosis. Refer to AV- 111 , "
Self-Diagno-
sis Function" .
The indicator continue turning OFF when
pressing switch.Check TEL adapter unit power supply, and
ground circuit.
