2007 MERCEDES-BENZ GL320CDI snow chains

Contents
Emission control .......................... 373
Coolant temperature .................... 374
At the gas station .............................. 375
Refueling ...................................... 375
Check regularly and
before a long trip.......................... 377
Engine compartment ......................... 379
Hood ............................................ 379
Engine oil ..................................... 381
Transmission fluid level ................ 382
Coolant level ................................ 382
Windshield/rear window
washer system and
headlamp cleaning system* ........ 384
Tires and wheels ................................ 385
Important guidelines .................... 385
Tire care and maintenance........... 386
Direction of rotation ..................... 388
Loading the vehicle ...................... 388
Recommended tire
inflation pressure ......................... 394
Checking tire inflation pressure ... 396
Tire labeling.................................. 406
Load identification ....................... 410
DOT, Tire Identification
Number (TIN) ............................... 410Maximum tire load ........................ 412
Maximum tire inflation pressure ... 412
Uniform Tire Quality Grading
Standards (U.S. vehicles) .............. 413
Tire ply material ............................ 415
Tire and loading terminology......... 415
Rotating tires ................................ 418
Winter driving ..................................... 420
Winter tires ................................... 420
Snow chains.................................. 421
Maintenance....................................... 422
Maintenance service indicator
message ....................................... 422
Calling up the maintenance
service indicator display ............... 424
Resetting the maintenance
service indicator ........................... 424
Vehicle care........................................ 425
Cleaning and care of the vehicle ... 425
Practical hints.................................. 435
What to do if … ................................... 436
Lamps in instrument cluster ......... 436
Lamp in center console ................ 448
Vehicle status messages in
the multifunction display .............. 451
Where will I find ...? ............................ 495
First aid kit.................................... 495
Vehicle tool kit.............................. 495
Spare wheel .................................. 499
Unlocking/locking in an emergency .. 500
Unlocking the vehicle ................... 500
Locking the vehicle ....................... 501
Fuel filler flap ................................ 501
Opening/closing in an emergency ..... 503
Power tilt/sliding sunroof* ........... 503
Resetting activated head restraints.... 504
Replacing SmartKey batteries ............ 506
Replacing bulbs .................................. 508
Bulbs............................................. 508
Replacing bulbs for front lamps .... 511
Replacing bulbs for rear lamps ..... 515
Adjusting headlamp aim ............... 518

103 Safety and Security
Driving safety systems
Driving safety systems
In this section you will find information on
the following driving safety systems:

ABS (Antilock Brake System)

BAS (Brake Assist System)

ESP® (Electronic Stability Program)

EBP (Electronic Brake Proportioning)

4-ETS (Electronic Traction System)
ABS
The Antilock Brake System (ABS) regulates
the brake pressure so that the wheels do
not lock during braking. This allows you to
maintain the ability to steer your vehicle.
The ABS is functional above a speed of ap-
proximately 5 mph (8 km/h) independent
of road surface conditions.
On slippery road surfaces, the ABS will
respond even to light brake pressure.
The -indicator lamp in the instrument
cluster (
page 26) comes on when you
switch on the ignition. It goes out when the
engine is running.
Warning!G
The following factors increase the risk of
accidents:

Excessive speed, especially in turns

Wet and slippery road surfaces

Following another vehicle too closely
The driving safety systems described in this
section cannot reduce these risks or pre-
vent the natural laws of physics from acting
on the vehicle.
Always adapt your driving style to the pre-
vailing road and weather conditions and
keep a safe distance to other road users and
objects in the street.
iIn winter operation, the maximum effective-
ness of the ABS, the BAS, the ESP®, the EBP, and
the 4-ETS is only achieved with winter tires
(
page 420) or snow chains as required.
Warning!G
Do not pump the brake pedal. Use firm,
steady brake pedal pressure instead. Pump-
ing the brake pedal defeats the purpose of
the ABS and significantly reduces braking
effectiveness.

107 Safety and Security
Driving safety systems
Switching off the ESP®
To improve the vehicle’s traction, switch
off the ESP® in driving situations where it
would be advantageous to have the drive
wheels spin and thus cut into surfaces for
better grip such as:

when driving with snow chains

in deep snow

in sand or gravelWhen you switch off the ESP
®

the ESP® does not stabilize the vehicle

the engine output is not limited, which
allows the drive wheels to spin and
thus cut into surfaces for better grip

the 4-ETS will still apply the brake to a
spinning wheel

the ESP® continues to operate when
you are braking

you cannot activate the cruise control
or the Distronic* system

the cruise control or the Distronic*
system switch off if currently activatedThe ESP
® switch is located on the upper
part of the center console.
1ESP
® switch
With the engine running, press ESP®
switch1.
The ESP
®warning lampv in the
instrument cluster comes on.
The ESP
® is deactivated.
Warning!G
The ESP® should not be switched off during
normal driving other than in the circum-
stances described below. Disabling of the
system will reduce vehicle stability in stan-
dard driving maneuvers.
Do not switch off the ESP
® when a spare
wheel is mounted.
Warning!G
Switch on the ESP® immediately if the afore-
mentioned circumstances do not apply any-
more. Otherwise the ESP
® will not stabilize
the vehicle when it is starting to skid or a
wheel is spinning.
iWhen the ESP® is switched off and one or
more drive wheels are spinning, the ESP®
warning lampv in the instrument cluster
flashes. However, the ESP
® will then not
stabilize the vehicle.

355 Operation
Driving instructions
GL 320 CDI, GL 450
Your vehicle is factory equipped with
“H”-rated tires, which have a speed rating
of 130 mph (210 km/h).
An electronic speed limiter prevents your
vehicle from exceeding a speed of
130 mph (210 km/h).
GL 450*
Your vehicle is factory equipped with
“W”-rated tires, which have a speed rating
of 168 mph (270 km/h).
An electronic speed limiter prevents your
vehicle from exceeding a speed of
130 mph (210 km/h).Winter driving instructions
The most important rule for slippery or icy
roads is to drive sensibly and to avoid
abrupt acceleration, braking and steering
maneuvers. Do not use the cruise control
system under such conditions.
When the vehicle is in danger of skidding,
shift the automatic transmission to
positionN. Try to keep the vehicle under
control by corrective steering action.
Road salts and chemicals can adversely af-
fect braking efficiency. Increased pedal
force may become necessary to produce
the normal brake effect.
Depressing the brake pedal periodically
when traveling at length on salt-strewn
roads can bring road-salt-impaired braking
efficiency back to normal.
iFor information on speed ratings for winter
tires, see “Winter tires” (
page 420).
For additional general information on tire speed
markings on the tire sidewall, see “Tire speed
rating” (
page 418).
iFor information on driving with snow chains,
see “Snow chains” (
page 421).
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of control loss.
Do not engage the transfer case in position
LOW when driving on ice or packed snow. At
speeds below 18 mph (30 km/h) vehicle
steering is adversely affected by the
Off-road – ABS (
page 104).

397 Operation
Tires and wheels
Install the valve cap.
Repeat this procedure for each tire.Run Flat Indicator (Canada only)
While the vehicle is being driven, the Run
Flat Indicator monitors the set tire inflation
pressures by evaluating each wheel’s rota-
tional speed. This allows the system to de-
tect a significant loss of pressure in a tire.
If a wheel’s rotational speed changes due
to falling tire inflation pressure, you will
see a corresponding warning message in
the multifunction display.
The Run Flat Indicator may function in a
restricted manner or with a delay

if snow chains are mounted to the
vehicle

in presence of ice and snow

if you are driving on a loose surface
(e.g. sand or gravel)

if you are driving in a very sporty man-
ner (involving rapid acceleration or high
speeds in curves)
iIf you have overfilled the tire, release tire in-
flation pressure by pushing the metal stem of the
valve with e.g. a tip of a pen. Then recheck the
tire inflation pressure with the tire gauge.Warning!G
When the multifunction display shows the
message
Tire pressure Check tires,
one or more of your tires is significantly un-
derinflated. You should stop and check your
tires as soon as possible, and inflate them to
the proper tire inflation pressure as indicat-
ed on the vehicle’s Tire and Loading
Information placard or, if available, on the
tire inflation pressure label. Driving on a sig-
nificantly under-inflated tire causes the tire
to overheat and can lead to tire failure. Un-
derinflation also reduces fuel efficiency and
tire tread life, and may affect the vehicle’s
handling and stopping ability. Each tire, in-
cluding the spare, should be checked
monthly when cold and set to the recom-
mended tire inflation pressure as specified
on the Tire and Loading Information placard
on the driver’s door B-pillar (
page 389) or,
if available, on the tire inflation pressure la-
bel located on the inside of the fuel filler flap
(
page 375).

421 Operation
Winter driving
Snow chains
Snow chains should only be driven on
snow-covered roads at speeds not to
exceed 30 mph (50 km/h). Remove chains
as soon as possible when driving on roads
without snow.Please observe the following guidelines
when using snow chains:

Use of snow chains is not permissible
with all wheel/tire combinations
(
page 554).

Snow chains should only be used on
the rear wheels. Follow the manufac-
turer’s mounting instructions.

Only use snow chains that are
approved by Mercedes-Benz. Your
authorized Mercedes-Benz Light Truck
Center will be glad to advise you on this
subject.

Use of snow chains may be prohibited
depending on location. Always check
local and state laws before installing
snow chains.

Do not use snow chains on the spare
wheel (
page 556).
Warning!G
If you use your spare tire when winter tires
are fitted on the other wheels, be aware that
the difference in tire characteristics may
very well impair turning stability and that
overall driving stability may be reduced.
Adapt your driving style accordingly.
Have the spare tire replaced with a winter
tire at the nearest authorized
Mercedes-Benz Light Truck Center.!Even on vehicles with all-wheel-drive use
snow chains on rear tires only.
Some tire sizes do not leave adequate clearance
for snow chains. To help avoid serious damage to
your vehicle or tires, use of snow chains is not
permissible with the spare wheel.
!Vehicles with ADS*:
When driving with snow chains, do not select
SPORT mode (
page 281).
iWhen driving with snow chains, you may
wish to deactivate the ESP® (page 107)
before setting the vehicle in motion. This will
improve the vehicle’s traction.

556 Technical data
Rims and tires
Minispare wheel
ModelGL 320 CDI,
GL 450
Rim4.5B x 19 H2
Wheel offset1.58 in (40 mm)
TireT 165/90D-19 119M1
1Must not be used with snow chains.
!Please compare the recommended tire
inflation pressure for your vehicle with the tire
inflation pressure on the yellow label located on
the Minispare wheel rim.
If the tire inflation pressure on the yellow label
on the Minispare wheel rim differs from the
values given in this Operator’s Manual, inflate
the tire to the recommended tire inflation pres-
sure given on the yellow label on the Minispare
wheel rim.
iPlease note that the tire inflation pressure of
the Minispare tire differs from the tire inflation
pressure of the road tires.
Inflate the Minispare tire to approximately 61 psi
(4.2 bar).

587 Index
Vehicle level control 281
Shifting
Automatic transmission 58, 192
Side impact air bags 80
Side marker lamps
Cleaning lenses 429
Messages in the
multifunction display 484
Replacing bulbs 514, 517
Side windows see Power windows
Sidewall 417
SmartKey see Key, SmartKey
SmartKey see Key, SmartKey with
KEYLESS-GO*
Snow chains 421
Snow tires see Winter tires
Spare fuses 495
Spare wheel 499
Mounting 524
Wheel bolts 496, 526
Speed settings
Cruise control 259
Distronic* 268
Speedometer 27, 265Spinning see Tires, Direction of rotation
SRS 90
Indicator lamp 29, 445
Messages in the
multifunction display 445
Standing lamps 145
Replacing bulbs 508, 509, 513, 515,
517
Standing water, Driving through 362
Starter switch 25, 42
Positions 42
Starting difficulties, Engine 60
Starting, Engine 57
Steep terrain, Driving 360
Steering column 50, 51
Steering wheel 49
Adjustment, Electrically* 51
Adjustment, Manually 50
Buttons 30, 158
Cleaning 433
Steering wheel gearshift control,
Automatic transmission 201
Stolen Vehicle Recovery services 339Storage compartments 36, 316
Armrest, Front 318
Cup holder 321
Cup holders 321
Door pockets 36
Front center console 318
Glove box 316
Parcel net, Front passenger
footwell 320
Parcel nets, Front seat backrest 320
Rear seats, In front of 319
Storing tires 387
Stranded vehicle 543
Submenus see Control system submenus
Sun visors 213
Sunroof see Power tilt/sliding sunroof*
Sunshade
Rear panorama roof 214
Suspension tuning see Air suspension
package
Symbols used in this Operator’s
Manual 16
