2007 Lancia Musa Owner handbook (in English)

ENGINE OIL CHANGE COLD TYRE INFLATION PRESSURE (bar)
STANDARD TYRES
Size Medium load Full load
Front Rear Front Rear
FUEL CAPACITIES (litres)
1.48V - 1.416V1.3 Multijet 1.9 Multijet
Tank capacity 47 47 47
Reserve 5 - 7 5 - 7 5 - 7
Refuel petrol engines with unleaded petrol with an octane rating (RON) no lower than 95 only.
Refuel diesel engines with diesel fuel for motor vehicles (EN590 specifications) only.
Fiat Auto S.p.A.
Quality - Assistenza Tecnica - Ingegneria Assistenziale
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print no. 603.81.169 - 01/2007 - 1
stedition
1.418V1.416V1.3 Multijet 1.9 Multijet
litres kg litres kg litres kg litres kg
Engine sump 2.4 2.1 2.5 2.2 2.85 2.5 4.2 3.75
Engine sump and filter 2.62.25 2.7 2.35 3.0 2.6 4.4 3.9
185/65 R14 86T 2,2 2,1 2,3 2,3
195/60 R15 88T 2,2 2,1 2,3 2,3
205/50 R16 87V 2,2 2,1 2,3 2,3
135/80 B14 84M 2,8SPARE WHEEL
125/80 R15 95M 4,2
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
