2007 Lancia Musa sensor

210
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
EBD SYSTEM FAILURE - SYSTEM
UNAVAILABLE ..................................................... 239
EXTERNAL LIGHT FAILURE.............................. 240
BRAKE LIGHT FUSE FAILURE ........................... 242
PARKING SENSOR FAILURE ............................... 242
ANTIPINCH SYSTEM
FAILURE............................................................... 243
AIR BAG FAILURE ............................................... 244
TWILIGHT SENSOR FAILURE ............................ 245
INJECTION SYSTEM FAILURE............................ 245
ENGINE CONTROL SYSTEM FAILURE
(EOBD) ................................................................. 246
GENERIC FAILURE INDICATION........................ 247
“DUAL FUNCTION SYSTEM”
TRANSMIS. FAIL. ................................................. 248
ESP SYSTEM FAILURE -
SYSTEM NOT AVAILABLE .................................. 249
HILL HOLDER FAILURE -
SYSTEM NOT AVAILABLE .................................. 250

233
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
Warning
light on
dial Message on
multifunction
display
SIDELIGHTS AND LOW BEAMS
The warning light on the dial turns on when sidelights, parking lights
or low beams are turned on. The warning light on the dial will also
turn on when the daylight sensor (where provided) turns the lights
on.
FOLLOW ME HOME
The warning light on the dial comes on (on certain versions, together
with the message on the display) when the “Follow me home” device
is activated (see “Follow me home” in section “Dashboard and
controls”).
MAIN BEAM HEADLIGHTS
The warning light on the dial turns on when the main beams are
turned on.3
1
3
green
green
blue

237
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
“DUALDRIVE” ELECTRIC POWER STEERING FAILURE
(where provided)
Turning the ignition key to MAR the warning light on the dial turns
on, but it should go off after few seconds.
If the warning light stays on (together with the message on the
display), you will not have steering assistance and the effort on the
steering wheel will be increased, steering is however possible. Contact
Lancia Dealership.
DIESEL FUEL FILTER SENSOR FAILURE
The warning light on the dial comes on (together with the message on
the display) when diesel fuel filter sensor failure is detected. Contact
Lancia Dealership as soon as possible to have the fault removed.
GLOW PLUG WARMING FAILURE (Multijet versions)
The warning light on the instrument panel flashes for about 30
seconds after starting the engine (together with the message on the
display) when there is a failure in the glow plug warming system.
Contact Lancia Dealership to have the fault eliminated.
g
red
amber
amber
è
m
Warning
light on
dial Message on
multifunction
display

238
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
ABS SYSTEM FAILURE - System unavailable
Turning the ignition key to MAR the warning light on the dial turns
on, but it should go off after few seconds.
The warning light turns on (together with the message on the display)
when the system is inefficient or unavailable.
In this case the braking system keeps its effectiveness unchanged, but
without the potential offered by the ABS system. Drive carefully and
contact Lancia Dealership as soon as possible.
RAIN SENSOR FAILURE
The warning light on the dial turns on (together with the message on
the display) when the rain sensor is faulty. Contact Lancia
Dealership.
>
amber
amber
è
Warning
light on
dialMessage on
multifunction
display

242
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
BRAKE LIGHT FUSE FAILURE
The warning light on the dial turns on (together with the message on
the display) when the brake light fuse is faulty (blown fuse).
W
T.P.M.S. FAULT WARNING LIGHT (where provided)
The warning light comes on (together with the message on the display
and the buzzer), when T.P.M.S. (where provided) fault is detected.
Contact Lancia Dealership as soon as possible.
Should one or more wheels without sensor be fitted, the instrument
panel warning light will come on (together with the message on the
display) and stay on until restoring initial conditions.
è
amber
amber
Warning
light on
dialMessage on
multifunction
display

243
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
ANTIPINCH SYSTEM PARKING SENSOR FAILURE
(where provided)
The warning light on the dial turns on (together with the message on
the display) when failure is detected in parking sensors.
Contact Lancia Dealership.
è
è
ANTIPINCH SYSTEM FAILURE (where provided)
The warning light on the dial turns on (together with the message on
the display) when failure is detected in the antipinch system.
Contact Lancia Dealership.amber
amber
(*)
(*) Or rear
Warning
light on
dial Message on
multifunction
display

245
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
TWILIGHT SENSOR FAILURE (where provided)
The warning light on the dial turns on (together with the message on
the display) when failure is detected in twilight sensor (adjusting
headlight sensitivity).
è
INJECTION SYSTEM FAILURE (Multijet versions)
The warning light stays on or comes on glowing steadily when
travelling (together with the message on the display) when there is a
failure in the injection/ignition system that could cause an increase in
exhaust gas emissions, loss of performance, poor driveability and high
consumption.U
amber
amber
Warning
light on
dial Message on
multifunction
display

247
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
❒flashing- indicates the possibility of damage to the catalyst (see
“EOBD system” in section “Dashboard and controls”).
If the light flashes, it is necessary to release the accelerator pedal to
lower the speed of the engine until the warning light stops flashing;
continue the journey at moderate speed, trying to avoid driving
conditions that may cause further flashing and contact Lancia
Dealership as soon as possible.U
amber
amber
8:30
continued from previous page
If with ignition key at MAR, the
Uwarning light does not turn on or if it turns on with fixed light
or flashing when the car is travelling (on certain versions together with the message on the display),
contact Lancia Dealership as soon as possible. Warning light
Uoperation can by checked by traf-
fic agents by proper equipment therefore, comply with laws and regulations in force in the country
where you are driving.
GENERIC FAILURE INDICATION
The warning light on the dial comes on when the engine oil pressure
sensor is faulty and, for Multijet versions with modal instrument
panel, also when a failure is detected in diesel fuel sensor. Contact
Lancia Dealership as soon as possible.
è
Warning
light on
dial Message on
multifunction
display
