2007 JEEP LIBERTY service

and the narrower track, if this vehicle is out of control it
may roll over when some other vehicles may not.
Do not attempt sharp turns or abrupt maneuvers or other
unsafe driving actions that can cause loss of vehicle
control. Failure to operate this vehicle safely may result
in an accident, roll over of the vehicle, and severe or fatal
injury. Drive carefully.Failure to use driver and passenger seat beltsprovided
is a major cause of severe or fatal injury. In fact, the U.S.
government notes that the universal use of existing seat
belts could cut the highway death toll by 10,000 or more
each year, and could reduce disabling injuries by 2
million annually. In a roll over crash an unbelted person
is significantly more likely to die than a person wearing
a seat belt. Always buckle up.
This manual has been prepared with the assistance of
service and engineering specialists to acquaint you with
the operation and maintenance of your new vehicle. It is
supplemented by a Warranty Information Booklet and
various customer oriented documents. You are urged to
read these publications carefully. Following the instruc-
tions and recommendations in this manual will help
assure safe and enjoyable operation of your vehicle.
Roll Over Warning Label
INTRODUCTION 5
1

NOTE: After you read the manual, it should be stored
in the vehicle for convenient reference and remain with
the vehicle when sold so that the new owner will be
aware of all safety warnings.
When it comes to service, remember that the manufac-
turer knows your vehicle best, has the factory-trained
technicians and genuine Moparparts, and is interested
in your satisfaction.
WARNING!
Engine exhaust, some of its constituents, and certain
vehicle components contain or emit chemicals
known to the State of California to cause cancer and
birth defects or other reproductive harm. In addition,
certain fluids contained in vehicles and certain prod-
ucts of component wear contain or emit chemicals
known to the State of California to cause cancer and
birth defects or other reproductive harm.
HOW TO USE THIS MANUAL
Consult the table of contents to determine which section
contains the information you desire.
The detailed index, at the rear of this manual, contains a
complete listing of all subjects.
Consult the following table for a description of the
symbols that may be used on your vehicle or throughout
this owner’s manual:
6 INTRODUCTION

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS

A Word About Your Keys..................14
▫Ignition Key Removal...................14
▫Key-In-Ignition Reminder................16

Steering Wheel Lock — If Equipped..........16
▫To Manually Lock The Steering Wheel.......16
▫To Release The Steering Wheel Lock.........16

Sentry Key Immobilizer System..............16
▫Important Note About Service.............18
▫Replacement Keys......................18▫Customer Key Programming..............18
▫General Information....................19

Security Alarm System — If Equipped.........19
▫ToSetTheAlarm ......................20
▫To Disarm The System...................20

Illuminated Entry........................21

Remote Keyless Entry.....................21
▫To Unlock The Doors...................21
▫To Lock The Doors.....................22
2

▫To Unlatch The Swing Gate Flip-Up Window . .23
▫Panic Alarm..........................24
▫To Use The Panic Alarm.................24
▫To Program Additional Transmitters.........24
▫General Information....................25
▫Transmitter Battery Service...............26

Door Locks............................26
▫Manual Door Locks.....................28
▫Power Door Locks — If Equipped..........29
▫Automatic Door Locks — If Equipped.......29
▫Child Protection Door Lock...............30

Windows.............................31
▫Power Front Windows...................31▫Power Rear Windows...................32
▫Wind Buffeting........................32

Rear Swing Gate........................33

Occupant Restraints......................36
▫Lap/Shoulder Belts.....................37
▫Lap/Shoulder Belt Operating Instructions.....39
▫Rear Center Lap/Shoulder Belt
Retractor Lock-Out.....................43
▫Adjustable Upper Shoulder Belt Anchorage....43
▫Automatic Locking Mode — If Equipped.....44
▫Energy Management Feature..............45
▫Seat Belt Pretensioners...................46
▫Enhanced Seat Belt Use Reminder System
(BeltAlert)...........................47
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The Sentry Key Immobilizer System does not need to be
armed or activated. Operation of the system is automatic
regardless of whether or not the vehicle is locked or
unlocked. During normal operation, the SKIM indicator
light will come on for 3 seconds immediately after the
ignition switch is turned on for a bulb check. Afterwards,
if the bulb remains on, this indicates a malfunction in the
electronics. If the bulb begins to flash immediately after
the ignition switch is turned on, this indicates that an
invalid key is being used to start the vehicle. Both of these
conditions will result in the engine being shut down after
2 seconds of running. Keep in mind that a key which has
not been programmed is also considered an invalid key
even if it is cut to fit the ignition for that vehicle.
If the SKIM indicator light comes on during normal
vehicle operation (it has been running for longer than 10
seconds) a fault has been detected in the electronics and
the vehicle should be serviced as soon as possible.NOTE:
•The Sentry Key Immobilizer System is not compatible
with remote starting systems. Use of these systems
may result in vehicle starting problems and loss of
security protection.
•Mobil Speedpass™, additional Sentry Keys, or any
other transponder equipped components on the same
keychain will not cause a key-related (Transponder)
fault unless the additional part isphysically held
against the ignition keybeing used when starting the
vehicle. Also, cell phones, pagers, or other RF electron-
ics will not cause interference with this system.
All of the keys provided with your new vehicle have
been programmed to the vehicle electronics.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17
2

Important Note About Service
A four digit PIN number is needed to service the Sentry
Key Immobilizer System. This number can be obtained
from your authorized dealer. However, this number can
also be found on your customer invoice that you were
given upon receipt of your vehicle.
Replacement Keys
NOTE:Only keys that have been programmed to the
vehicle electronics can be used to start the vehicle. Once
a Sentry Key has been programmed to a vehicle, it cannot
be programmed to any other vehicle.
At the time of purchase, the original owner is provided
with a four digit PIN number. This number is required for
dealer replacement of keys. Duplication of keys may be
performed at an authorized dealer or by using the Cus-
tomer Key Programming procedure. This procedure con-
sists of programming a blank key to the vehicle electron-
ics. A blank key is one which has never been programmed.
NOTE:When having the Sentry Key System serviced,
bring all vehicle keys to the dealer.
Customer Key Programming
You can program new keys to the system if you have two
valid keys by doing the following:
1. Cut the additional Sentry Key Transponder blank(s) to
match the ignition switch lock cylinder key code.
2. Insert the first valid key into the ignition switch and
turn the ignition switch ON for at least 3 seconds but no
longer than 15 seconds. Turn the ignition switch OFF and
remove the first key.
3. Insert the second valid key and turn the ignition
switch ON within 15 seconds. After ten seconds, a chime
will sound and the SKIM indicator light will begin to
flash. Turn the ignition switch OFF and remove the
second key.
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Transmitter Battery Service
The recommended replacement battery is the Panasonic
CR2032 or equivalent.
1. Pry the transmitter halves apart with a dime or similar
object. Make sure not to damage the rubber gasket
material during removal.2. Remove and replace the batteries. Avoid touching the
new batteries with your fingers. Skin oils may cause
battery deterioration. If you touch the battery, clean it
with rubbing alcohol.
3. Reassemble the transmitter case. Snap the halves
together and test transmitter operation.
DOOR LOCKS
The vacuum fluorescent (VF) display located in the
odometer area displays the word “door” as an indication
of a door ajar or door not completely closed. When the
vehicle is not moving and the door is ajar or not
completely closed, the VF display will show the word
“door” and then show the odometer/trip odometer
mileage (each for 2 seconds). The display will continue to
cycle.
Separating Transmitter
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Rear Center Lap/Shoulder Belt Retractor
Lock-Out
This feature is designed to lock the retractor whenever
the 65% rear seat back is not fully latched. This prevents
someone from wearing the rear center lap/shoulder belt
when the rear seat back is not fully latched.
NOTE:
•If the rear center lap/shoulder belt cannot be pulled
out, check that the rear seat back is fully latched.
•If the rear seat back is properly latched and the rear
center lap/shoulder belt still cannot be pulled out, the
Automatic-Locking Retractor (ALR) system may be
activated. To reset this feature you must let all of the
belt webbing return into the retractor. You will not be
able to pull out more webbing until all of the webbing
has been returned back into the retractor.
WARNING!
The rear center lap/shoulder belt is equipped with a
lock-out feature to ensure that the rear seat back is in
the fully upright and locked position when occu-
pied. If the rear seat back is not fully upright and
locked and the rear center lap/shoulder belt can be
pulled out of the retractor, the vehicle should imme-
diately be taken to your dealer for service. Failure to
follow this warning could result in serious or fatal
injury.
Adjustable Upper Shoulder Belt Anchorage
In the front seat positions, the shoulder belt can be
adjusted upward or downward to position the belt away
from your neck. To lower the shoulder belt height, push
the button and slide the height adjuster down. To raise
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43
