2007 INFINITI M35 component

EC-13
C
D
E
F
G
H
I
J
K
L
M
ECA
Revision: 2007 April2007 M35/M45 (FPCM) ...................................................................1225
Description ..........................................................1225
CONSULT-II Reference Value in Data Monitor Mode
1225
On Board Diagnosis Logic ..................................1225
DTC Confirmation Procedure ..............................1226
Wiring Diagram ...................................................1227
Diagnostic Procedure ..........................................1228
Component Inspection ........................................1232
DTC P1225 TP SENSOR .......................................1233
Component Description .......................................1233
On Board Diagnosis Logic ..................................1233
DTC Confirmation Procedure ..............................1233
Diagnostic Procedure ..........................................1234
Removal and Installation .....................................1234
DTC P1226 TP SENSOR .......................................1235
Component Description .......................................1235
On Board Diagnosis Logic ..................................1235
DTC Confirmation Procedure ..............................1235
Diagnostic Procedure ..........................................1236
Removal and Installation .....................................1236
DTC P1550 BATTERY CURRENT SENSOR ........1237
Component Description .......................................1237
CONSULT-II Reference Value in Data Monitor Mode
1237
On Board Diagnosis Logic ..................................1237
DTC Confirmation Procedure ..............................1238
Wiring Diagram ...................................................1239
Diagnostic Procedure ..........................................1240
Component Inspection ........................................1242
DTC P1551, P1552 BATTERY CURRENT SENSOR 1244
Component Description .......................................1244
CONSULT-II Reference Value in Data Monitor Mode
1244
On Board Diagnosis Logic ..................................1244
DTC Confirmation Procedure ..............................1245
Wiring Diagram ...................................................1246
Diagnostic Procedure ..........................................1247
Component Inspection ........................................1249
DTC P1553 BATTERY CURRENT SENSOR ........1251
Component Description .......................................1251
CONSULT-II Reference Value in Data Monitor Mode
1251
On Board Diagnosis Logic ..................................1251
DTC Confirmation Procedure ..............................1252
Wiring Diagram ...................................................1253
Diagnostic Procedure ..........................................1254
Component Inspection ........................................1256
DTC P1554 BATTERY CURRENT SENSOR ........1258
Component Description .......................................1258
CONSULT-II Reference Value in Data Monitor Mode
1258
On Board Diagnosis Logic ..................................1258
Overall Function Check .......................................1259
Wiring Diagram ...................................................1260
Diagnostic Procedure ..........................................1261
Component Inspection ........................................1263
DTC P1564 ICC STEERING SWITCH ...................1265
Component Description .......................................1265CONSULT-II Reference Value in Data Monitor Mode
1265
On Board Diagnosis Logic ...................................1265
DTC Confirmation Procedure ..............................1266
Wiring Diagram ....................................................1267
Diagnostic Procedure ..........................................1268
Component Inspection .........................................1271
DTC P1564 ASCD STEERING SWITCH ...............1272
Component Description .......................................1272
CONSULT-II Reference Value in Data Monitor Mode
1272
On Board Diagnosis Logic ...................................1272
DTC Confirmation Procedure ..............................1273
Wiring Diagram ....................................................1274
Diagnostic Procedure ..........................................1275
Component Inspection .........................................1278
DTC P1568 ICC FUNCTION ..................................1279
On Board Diagnosis Logic ...................................1279
DTC Confirmation Procedure ..............................1279
Diagnostic Procedure ..........................................1279
DTC P1572 ICC BRAKE SWITCH .........................1280
Component Description .......................................1280
CONSULT-II Reference Value in Data Monitor Mode
1280
On Board Diagnosis Logic ...................................1280
DTC Confirmation Procedure ..............................1281
Wiring Diagram ....................................................1282
Diagnostic Procedure ..........................................1283
Component Inspection .........................................1288
DTC P1572 ASCD BRAKE SWITCH .....................1289
Component Description .......................................1289
CONSULT-II Reference Value in Data Monitor Mode
1289
On Board Diagnosis Logic ...................................1289
DTC Confirmation Procedure ..............................1290
Wiring Diagram ....................................................1291
Diagnostic Procedure ..........................................1292
Component Inspection .........................................1296
DTC P1574 ICC VEHICLE SPEED SENSOR ........1297
Component Description .......................................1297
On Board Diagnosis Logic ...................................1297
DTC Confirmation Procedure ..............................1297
Diagnostic Procedure ..........................................1298
DTC P1574 ASCD VEHICLE SPEED SENSOR ....1299
Component Description .......................................1299
On Board Diagnosis Logic ...................................1299
DTC Confirmation Procedure ..............................1299
Diagnostic Procedure ..........................................1300
DTC P1715 INPUT SPEED SENSOR (TURBINE
REVOLUTION SENSOR) .......................................1301
Description ...........................................................1301
CONSULT-II Reference Value in Data Monitor Mode
1301
On Board Diagnosis Logic ...................................1301
Diagnostic Procedure ..........................................1301
DTC P1800 VIAS CONTROL SOLENOID VALVE 1302
Component Description .......................................1302
CONSULT-II Reference Value in Data Monitor Mode
1302

EC-14Revision: 2007 April2007 M35/M45 On Board Diagnosis Logic ...................................1302
DTC Confirmation Procedure ..............................1302
Wiring Diagram ....................................................1303
Diagnostic Procedure ..........................................1304
Component Inspection .........................................1305
Removal and Installation .....................................1306
DTC P1805 BRAKE SWITCH ................................1307
Component Description .......................................1307
CONSULT-II Reference Value in Data Monitor Mode
1307
On Board Diagnosis Logic ...................................1307
DTC Confirmation Procedure ..............................1308
Wiring Diagram ....................................................1309
Diagnostic Procedure ..........................................1310
Component Inspection .........................................1315
DTC P2100, P2103 THROTTLE CONTROL MOTOR
RELAY ....................................................................1316
Component Description .......................................1316
CONSULT-II Reference Value in Data Monitor Mode
1316
On Board Diagnosis Logic ...................................1316
DTC Confirmation Procedure ..............................1316
Wiring Diagram ....................................................1318
Diagnostic Procedure ..........................................1319
DTC P2101 ELECTRIC THROTTLE CONTROL
FUNCTION .............................................................1322
Description ...........................................................1322
On Board Diagnosis Logic ...................................1322
DTC Confirmation Procedure ..............................1322
Wiring Diagram ....................................................1323
Diagnostic Procedure ..........................................1324
Component Inspection .........................................1328
Removal and Installation .....................................1328
DTC P2118 THROTTLE CONTROL MOTOR ........1329
Component Description .......................................1329
On Board Diagnosis Logic ...................................1329
DTC Confirmation Procedure ..............................1329
Wiring Diagram ....................................................1330
Diagnostic Procedure ..........................................1331
Component Inspection .........................................1332
Removal and Installation .....................................1333
DTC P2119 ELECTRIC THROTTLE CONTROL
ACTUATOR ............................................................1334
Component Description .......................................1334
On Board Diagnosis Logic ...................................1334
DTC Confirmation Procedure ..............................1334
Diagnostic Procedure ..........................................1335
DTC P2122, P2123 APP SENSOR ........................1336
Component Description .......................................1336
CONSULT-II Reference Value in Data Monitor Mode
1336
On Board Diagnosis Logic ...................................1336
DTC Confirmation Procedure ..............................1337
Wiring Diagram ....................................................1338
Diagnostic Procedure ..........................................1339
Component Inspection .........................................1341
Removal and Installation .....................................1342
DTC P2127, P2128 APP SENSOR ........................1343
Component Description .......................................1343CONSULT-II Reference Value in Data Monitor Mode
1343
On Board Diagnosis Logic ...................................1343
DTC Confirmation Procedure ...............................1344
Wiring Diagram ....................................................1345
Diagnostic Procedure ...........................................1346
Component Inspection .........................................1349
Removal and Installation ......................................1349
DTC P2135 TP SENSOR .......................................1350
Component Description .......................................1350
CONSULT-II Reference Value in Data Monitor Mode
1350
On Board Diagnosis Logic ...................................1350
DTC Confirmation Procedure ...............................1351
Wiring Diagram ....................................................1352
Diagnostic Procedure ...........................................1353
Component Inspection .........................................1356
Removal and Installation ......................................1356
DTC P2138 APP SENSOR .....................................1357
Component Description .......................................1357
CONSULT-II Reference Value in Data Monitor Mode
1357
On Board Diagnosis Logic ...................................1357
DTC Confirmation Procedure ...............................1358
Wiring Diagram ....................................................1359
Diagnostic Procedure ...........................................1360
Component Inspection .........................................1364
Removal and Installation ......................................1364
DTC P2A00, P2A03 A/F SENSOR 1 ......................1365
Component Description .......................................1365
CONSULT-II Reference Value in Data Monitor Mode
1365
On Board Diagnosis Logic ...................................1365
DTC Confirmation Procedure ...............................1365
Wiring Diagram ....................................................1367
Diagnostic Procedure ...........................................1370
Removal and Installation ......................................1376
ASCD BRAKE SWITCH .........................................1377
Component Description .......................................1377
CONSULT-II Reference Value in Data Monitor Mode
1377
Wiring Diagram ....................................................1378
Diagnostic Procedure ...........................................1379
Component Inspection .........................................1383
ASCD INDICATOR .................................................1384
Component Description .......................................1384
CONSULT-II Reference Value in Data Monitor Mode
1384
Wiring Diagram ....................................................1385
Diagnostic Procedure ...........................................1386
ELECTRICAL LOAD SIGNAL ...............................1387
Description ...........................................................1387
CONSULT-II Reference Value in Data Monitor Mode
1387
Diagnostic Procedure ...........................................1387
FUEL INJECTOR ....................................................1389
Component Description .......................................1389
CONSULT-II Reference Value in Data Monitor Mode
1389

EC-15
C
D
E
F
G
H
I
J
K
L
M
ECA
Revision: 2007 April2007 M35/M45 Wiring Diagram ...................................................1390
Diagnostic Procedure ..........................................1391
Component Inspection ........................................1394
Removal and Installation .....................................1394
FUEL PUMP ..........................................................1395
Description ..........................................................1395
CONSULT-II Reference Value in Data Monitor Mode
1395
Wiring Diagram ...................................................1396
Diagnostic Procedure ..........................................1397
Component Inspection ........................................1401
Removal and Installation .....................................1402
ICC BRAKE SWITCH ............................................1403
Component Description .......................................1403
CONSULT-II Reference Value in Data Monitor Mode
1403
Wiring Diagram ...................................................1404
Diagnostic Procedure ..........................................1405
Component Inspection ........................................1410
IGNITION SIGNAL .................................................1411
Component Description .......................................1411
Wiring Diagram ...................................................1412
Diagnostic Procedure ..........................................1417
Component Inspection ........................................1421
Removal and Installation .....................................1423
REFRIGERANT PRESSURE SENSOR ................1424
Component Description .......................................1424
Wiring Diagram ...................................................1425Diagnostic Procedure ..........................................1426
Removal and Installation .....................................1428
VIAS .......................................................................1429
Description ...........................................................1429
CONSULT-II Reference Value in Data Monitor Mode
1430
Wiring Diagram ....................................................1431
Diagnostic Procedure ..........................................1433
Component Inspection .........................................1436
Removal and Installation .....................................1437
MIL AND DATA LINK CONNECTOR .....................1438
Wiring Diagram ....................................................1438
SERVICE DATA AND SPECIFICATIONS (SDS) ...1440
Fuel Pressure ......................................................1440
Idle Speed and Ignition Timing ............................1440
Calculated Load Value .........................................1440
Mass Air Flow Sensor ..........................................1440
Intake Air Temperature Sensor ............................1440
Engine Coolant Temperature Sensor ..................1440
Fuel Tank Temperature Sensor ...........................1440
Crankshaft Position Sensor (POS) ......................1440
Camshaft Position Sensor (PHASE) ...................1440
A/F Sensor 1 Heater ............................................1440
Heated Oxygen Sensor 2 Heater ........................1441
Throttle Control Motor ..........................................1441
Fuel Injector .........................................................1441
Fuel Pump ...........................................................1441

EC-24
[VQ35DE]
PRECAUTIONS
Revision: 2007 April2007 M35/M45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NBS004RW
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Procedures without Cowl Top CoverNBS004RX
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
On Board Diagnostic (OBD) System of Engine and A/TNBS004RY
The ECM has an on board diagnostic system. It will light up the malfunction indicator lamp (MIL) to warn the
driver of a malfunction causing emission deterioration.
CAUTION:

Be sure to turn the ignition switch OFF and disconnect the negative battery cable before any
repair or inspection work. The open/short circuit of related switches, sensors, solenoid valves,
etc. will cause the MIL to light up.

Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MIL to light up due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)

Certain systems and components, especially those related to OBD, may use a new style slide-
locking type harness connector. For description and how to disconnect, refer to PG-104, "
HAR-
NESS CONNECTOR" .

Be sure to route and secure the harnesses properly after work. The interference of the harness
with a bracket, etc. may cause the MIL to light up due to the short circuit.

Be sure to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MIL to light up due to the malfunction of the EVAP system or fuel injection system,
etc.

Be sure to erase the unnecessary malfunction information (repairs completed) from the ECM and
TCM (Transmission control module) before returning the vehicle to the customer.
PIIB3706J

AUTOMATIC SPEED CONTROL DEVICE (ASCD)
EC-37
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
COAST OPERATION
When the SET/COAST switch is pressed during cruise control driving, decrease vehicle set speed until the
switch is released. And then ASCD will keep the new set speed.
RESUME OPERATION
When the RESUME/ACCELERATE switch is pressed after cancel operation other than pressing MAIN switch
is performed, vehicle speed will return to last set speed. To resume vehicle set speed, vehicle condition must
meet following conditions.

Brake pedal is released

A/T selector lever is in other than P and N positions

Vehicle speed is greater than 40 km/h (25 MPH) and less than 144 km/h (89 MPH)
Component DescriptionNBS004S9
ASCD STEERING SWITCH
Refer to EC-559 .
ASCD BRAKE SWITCH
Refer to EC-576 and EC-657 .
STOP LAMP SWITCH
Refer to EC-576 , EC-589 and EC-657
ELECTRIC THROTTLE CONTROL ACTUATOR
Refer to EC-598 , EC-604 , EC-610 and EC-615 .
ASCD INDICATOR
Refer to EC-664 .

EC-42
[VQ35DE]
EVAPORATIVE EMISSION SYSTEM
Revision: 2007 April2007 M35/M45
Component InspectionNBS004SC
EVAP CANISTER
Check EVAP canister as follows:
1. Block port (B).
2. Blow air into port (A) and check that it flows freely out of port (C).
3. Release blocked port (B).
4. Apply vacuum pressure to port (B) and check that vacuum pres-
sure exists at the ports (A) and (C).
5. Block port (A) and (B).
6. Apply pressure to port (C) and check that there is no leakage.
FUEL TANK VACUUM RELIEF VALVE (BUILT INTO FUEL FULLER CAP)
1. Wipe clean valve housing.
2. Check valve opening pressure and vacuum.
3. If out of specification, replace fuel filler cap as an assembly.
CAUTION:
Use only a genuine fuel filler cap as a replacement. If an incor-
rect fuel filler cap is used, the MIL may come on.
EVAP CANISTER PURGE VOLUME CONTROL SOLENOID VALVE
Refer to EC-407 .
FUEL TANK TEMPERATURE SENSOR
Refer to EC-336 .
EVAP CANISTER VENT CONTROL VALVE
Refer to EC-420 .
EVAP CONTROL SYSTEM PRESSURE SENSOR
Refer to EC-430 .
PBIB2728E
SEF445Y
Pressure:
15.3 - 20.0 kPa (0.156 - 0.204 kg/cm2 , 2.22
- 2.90 psi)
Va c u u m :
−6.0 to −3.3 kPa (−0.061 to −0.034 kg/cm
2 ,
−0.87 to −0.48 psi)
SEF943S

ON BOARD REFUELING VAPOR RECOVERY (ORVR)
EC-47
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
Diagnostic ProcedureNBS004SG
SYMPTOM: FUEL ODOR FROM EVAP CANISTER IS STRONG.
1. CHECK EVAP CANISTER
1. Remove EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
2. Weigh the EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
The weight should be less than 2.0 kg (4.4 lb).
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
2. CHECK IF EVAP CANISTER SATURATED WITH WATER
Does water drain from the EVAP canister?

EVAP canister (1)

EVAP canister vent control valve (2)
Ye s o r N o
Ye s > > G O T O 3 .
No >> GO TO 5.
3. REPLACE EVAP CANISTER
Replace EVAP canister with a new one.
>> GO TO 4.
4. DETECT MALFUNCTIONING PART
Check the EVAP hose between EVAP canister and vehicle frame for clogging or poor connection.
>> Repair or replace EVAP hose.
5. CHECK REFUELING EVAP VAPOR CUT VALVE
Refer to EC-49, "
Component Inspection" .
OK or NG
OK >>INSPECTION END
NG >> Replace refueling EVAP vapor cut valve with fuel tank.
PBIB2731E

ON BOARD REFUELING VAPOR RECOVERY (ORVR)
EC-49
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2007 April2007 M35/M45
7. CHECK REFUELING EVAP VAPOR CUT VALVE
Refer to EC-49, "
Component Inspection" .
OK or NG
OK >> GO TO 8.
NG >> Replace refueling EVAP vapor cut valve with fuel tank.
8. CHECK FUEL FILLER TUBE
Check filler neck tube and hose connected to the fuel tank for clogging, dents and cracks.
OK or NG
OK >> GO TO 9.
NG >> Replace fuel filler tube.
9. CHECK ONE-WAY FUEL VALVE-I
Check one-way valve for clogging.
OK or NG
OK >> GO TO 10.
NG >> Repair or replace one-way fuel valve with fuel tank.
10. CHECK ONE-WAY FUEL VALVE-II
1. Make sure that fuel is drained from the tank.
2. Remove fuel filler tube and hose.
3. Check one-way fuel valve for operation as follows.
When a stick is inserted, the valve should open, when removing
stick it should close.
Do not drop any material into the tank.
OK or NG
OK >>INSPECTION END
NG >> Replace fuel filler tube or replace one-way fuel valve
with fuel tank.
Component InspectionNBS004SH
REFUELING EVAP VAPOR CUT VALVE
With CONSULT-II
1. Remove fuel tank. Refer to FL-10, "FUEL TANK" .
2. Drain fuel from the tank as follows:
a. Remove fuel feed hose located on the fuel gauge retainer.
b. Connect a spare fuel hose, one side to fuel gauge retainer where the hose was removed and the other
side to a fuel container.
c. Drain fuel using “FUEL PUMP RELAY” in “ACTIVE TEST” mode with CONSULT-II.
3. Check refueling EVAP vapor cut valve for being stuck to close as follows.
Blow air into the refueling EVAP vapor cut valve (from the end of EVAP/ORVR line hose), and check that
the air flows freely into the tank.
4. Check refueling EVAP vapor cut valve for being stuck to open as follows.
a. Connect vacuum pump to hose end.
b. Remove fuel gauge retainer with fuel gauge unit.
Always replace O-ring with new one.
c. Put fuel tank upside down.
SEF665U
