LAN-46
[CAN]
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
Intelligent Key Unit
0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
LDW Camera Unit
0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.
Unified Meter and A/C Amp.
0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF →ON)
*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased. SELECT SYS-
TEM CAN DIAG SUP-
PORT MNTR Description Normal Error
PRSNT PAST PRSNT PAST
INTELLIGENT
KEY TRANSMIT DIAG Signal transmission status
OK OK
or
1 – 39
*UNKWN 0
ECM Signal receiving status from the ECM
METER/M&A Signal receiving status from the unified
meter and A/C amp.
BCM/SEC Signal receiving status from the BCM
SELECT SYS- TEM CAN DIAG SUP-
PORT MNTR Description Normal Error
PRSNT PAST PRSNT PAST
LDW TRANSMIT DIAG Not used even though indicated
ECM Signal receiving status from the ECM
OK OK
or
1 – 39
*UNKWN 0
VDC/TCS/ABS
Signal receiving status from the ABS actu-
ator and electric unit (control unit)
BCM/SEC Signal receiving status from the BCM
TCM Signal receiving status from the TCM
SELECT SYS- TEM CAN DIAG SUP-
PORT MNTR Description Normal Error
PRSNT PAST PRSNT PAST
METER A/C AMP TRANSMIT DIAG Signal transmission status
OK OK
or
1 – 39
*UNKWN 0
ECM Signal receiving status from the ECM
TCM Signal receiving status from the TCM
BCM/SEC Signal receiving status from the BCM
VDC/TCS/ABS Signal receiving status from the ABS actu-
ator and electric unit (control unit)
IPDM E/R Not used even though indicated
DISPLAY Signal receiving status from the display
control unit OK OK
or
1 – 39
*UNKWN 0
I-KEY Signal receiving status from the Intelligent
Key unit
EPS Not used even though indicated
AW D/4 WD Signal receiving status from the AWD con-
trol unit OK OK
or
1 – 39
*UNKWN 0
e4WD Not used even though indicated
ICC Signal receiving status from the Intelligent
Key unit OK OK
or
1 – 39
*UNKWN 0
LANE KEEP Not used even though indicated
TIRE-P

LAN-48
[CAN]
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
MONITOR ITEM LIST (ON-BOARD DIAGNOSIS)
Display Control Unit
NOTE:
CAN diagnostic support monitor of the display control unit is indicated on the vehicle display. Refer to AV- 8 1 ,
"CAN DIAG SUPPORT MONITOR" .
*: The error counter stops counting when it reaches “50” and holds “50” until it is deleted.
PKIB6080E
Unit name Diagnosis item Description Indicated items on CAN DIAG SUPPORT MONITOR
Normal Error
Result indi- cated Error
counter
(Reference) Result indi-
cated Error
counter
(Reference)
Display control
unit CAN_COMM Status of CAN controller
OK 0
or
1 – 50* NG
1 – 50*
CAN_CIRC_1 Signal transmission status
UNKWN
CAN_CIRC_2
Signal receiving status from the
BCM
CAN_CIRC_3 Signal receiving status from the
ECM
CAN_CIRC_4 Not used even though indicated
CAN_CIRC_5 Signal receiving status from the
unified meter and A/C amp. OK 0
or
1 – 50* UNKWN 1 – 50*
CAN_CIRC_6 Not used even though indicated
CAN_CIRC_7 Signal receiving status from the
IPDM E/R OK 0
or
1 – 50* UNKWN 1 – 50*
CAN_CIRC_8 Not used even though indicated
CAN_CIRC_9

TROUBLE DIAGNOSIS LAN-53
[CAN]
C
D E
F
G H
I
J
L
M A
B
LAN
Revision: 2006 July 2007 FX35/FX45
ICC operation signal R T
ICC system display signal T R
ICC warning lamp signal T R
A/T CHECK indicator lamp signal T R
A/T self-diagnosis signal R T
Current gear position signal R T R
Manual mode indicator signal R T R
Output shaft revolution signal R R T R
P range signal R T R R
Shift position indicator signal R T R
Turbine revolution signal R R T
A/C switch signal R T
Blower fan motor switch signal R T
Day time running light request signal T R
Door lock/unlock status signal T R
Door switch signal R T R R R R
Front fog light request signal T R
Front wiper request signal R T R
High beam request signal T R R
Horn chirp signal T R
Ignition switch signal T R R
Key fob door unlock signal T R
Key fob ID signal T R
Key switch signal T R
Low beam request signal T R
Oil pressure switch signal RT
TR
Position light request signal T R R
Rear window defogger switch signal T R
Run flat tire warning lamp signal T R
Sleep wake up signal TRRR
RT
Theft warning horn request signal T R
Tire pressure warning lamp signal T R
Turn indicator signal T R R
Alarm request signal R T
Back door open request signal R T
Door lock/unlock request signal R T
Ignition knob switch signal R T
Key warning signal T R
Power window open request signal R T
Steering angle sensor signal T R
Distance to empty signal R T Signals
ECM
DISP ICC
TCM
BCM
I-KEY
LANE
STRG M&AABS
LASER ADP
IPDM-E

TROUBLE DIAGNOSIS LAN-57
[CAN]
C
D E
F
G H
I
J
L
M A
B
LAN
Revision: 2006 July 2007 FX35/FX45
TYPE 6
NOTE:
Refer to LAN-41, "
Abbreviation List" for the abbreviations of the connecting units.
T: Transmit R: Receive
Signals
ECM
4WD
DISP
ICC
TCM
BCM
I-KEY
LANE
STRG M&AABS
LASER ADP
IPDM-E
A/C compressor feedback signal T R
A/C compressor request signal T R
Accelerator pedal position signal T R R R R
ASCD OD cancel request signal T R
ASCD operation signal T R
Battery voltage signal T R
Closed throttle position signal T R R
Cooling fan speed request signal T R
Engine coolant temperature signal T R
Engine speed signal T R R R R R R
Engine status signal T R
Fuel consumption monitor signal TR
RT
ICC steering switch signal T R
Malfunction indicator lamp signal T R
Snow mode switch signal RT
TR
Wide open throttle position signal T R
AWD warning lamp signal T R
A/C switch/indicator signal TR
RT
System setting signal TR R
RT T
Buzzer output signal TR
TR
TR
ICC OD cancel request signal T R
ICC operation signal R T
ICC system display signal T R
ICC warning lamp signal T R
A/T CHECK indicator lamp signal T R
A/T self-diagnosis signal R T
Current gear position signal R T R
Manual mode indicator signal R T R
Output shaft revolution signal R R T R
P range signal R T R R
Shift position indicator signal R T R
Turbine revolution signal R R T
A/C switch signal R T
Blower fan motor switch signal R T

LAN-68
[CAN]
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
ON-BOARD DIAGNOSIS COPY SHEET
NOTE:
CAN diagnostic support monitor of the display control unit is indicated on the vehicle display. Refer to AV- 8 1 ,
"CAN DIAG SUPPORT MONITOR" .
SKIB8871E

TROUBLE DIAGNOSIS LAN-75
[CAN]
C
D E
F
G H
I
J
L
M A
B
LAN
Revision: 2006 July 2007 FX35/FX45
Component Parts LocationNKS004NV
Harness LayoutNKS004NW
Refer to PG-43, "Harness Layout" .
1. AWD control unit M92 2. ICC unit M88 3. ECM M90
4. IPDM E/R E9 5. ICC sensor E39 6. Display control unit M76
7. Unified meter and A/C amp. M55 8. Steering angle sensor M14 9. Intelligent Key unit M34
10. ABS actuator and electric unit (con- trol unit) E56 11. BCM M3 12. Data link connector M5
13. LDW camera unit R9 14. Driver seat control unit B152 15. A/T assembly F44
16. Air bag diagnosis sensor unit M72
PKID0616E

LAN-76
[CAN]
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
Malfunction Area ChartNKS004NX
MAIN LINE
BRANCH LINE
SHORT CIRCUIT
Malfunction Area Reference
Main line between TCM and data link connector LAN-77, "
Main Line Between TCM and Data Link Connector"
Main line between data link connector and unified meter and A/
C amp. LAN-77, "Main Line Between Data Link Connector and Unified
Meter and A/C Amp."
Main line between unified meter and A/C amp. and ABS actua-
tor and electric unit (control unit) LAN-78, "Main Line Between Unified Meter and A/C Amp. and
ABS Actuator and Electric Unit (Control Unit)"
Main line between ABS actuator and electric unit (control unit)
and driver seat control unit LAN-79, "Main Line Between ABS Actuator and Electric Unit
(Control Unit) and Driver Seat Control Unit"
Malfunction Area Reference
ECM branch line circuit LAN-80, "
ECM Branch Line Circuit"
AWD control unit branch line circuit LAN-80, "AWD Control Unit Branch Line Circuit"
Display control unit branch line circuit LAN-81, "Display Control Unit Branch Line Circuit"
ICC unit branch line circuitLAN-82, "ICC Unit Branch Line Circuit"
TCM branch line circuit LAN-82, "TCM Branch Line Circuit"
BCM branch line circuit LAN-83, "BCM Branch Line Circuit"
Data link connector branch line circuit LAN-84, "Data Link Connector Branch Line Circuit"
Intelligent Key unit branch line circuitLAN-84, "Intelligent Key Unit Branch Line Circuit"
LDW camera unit branch line circuitLAN-85, "LDW Camera Unit Branch Line Circuit"
Steering angle sensor branch line circuit LAN-86, "Steering Angle Sensor Branch Line Circuit"
Unified meter and A/C amp. branch line circuit LAN-86, "Unified Meter and A/C Amp. Branch Line Circuit"
ABS actuator and electric unit (control unit) branch line circuit LAN-87, "ABS Actuator and Electric Unit (Control Unit) Branch
Line Circuit"
ICC sensor branch line circuit
LAN-88, "ICC Sensor Branch Line Circuit"
Driver seat control unit branch line circuitLAN-89, "Driver Seat Control Unit Branch Line Circuit"
IPDM E/R branch line circuit LAN-89, "IPDM E/R Branch Line Circuit"
Malfunction Area Reference
CAN communication circuit LAN-90, "
CAN Communication Circuit"

TROUBLE DIAGNOSIS LAN-81
[CAN]
C
D E
F
G H
I
J
L
M A
B
LAN
Revision: 2006 July 2007 FX35/FX45
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of AWD control unit.
2. Check the resistance between the AWD control unit harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the AWD control unit branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the AWD control unit. Refer to TF-16, "
Circuit Diagram" .
OK or NG
OK >>
Present error: Replace the AWD control unit. Refer to TF-39, "AWD CONTROL UNIT" .

Past error: Error was detected in the AWD control unit branch line.
NG >> Repair the power supply and the ground circuit.
Display Control Unit Branch Line CircuitNKS004O4
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the display control unit for damage, bend and loose connection (unit side and connector side).
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of display control unit.
2. Check the resistance between the display control unit harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the display control unit branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the display control unit. Refer to AV- 5 6 , "
Schematic — INF/D
—" .
OK or NG
OK >>
Present error: Replace the display control unit. Refer to AV- 9 2 , "Removal and Installation of
Display Control Unit" .

Past error: Error was detected in the display control unit branch line.
NG >> Repair the power supply and the ground circuit.
AWD control unit harness connector Resistance ( Ω)
Connector No. Terminal No.
M92 8 16 Approx. 54 – 66
Display control unit harness connector Resistance ( Ω)
Connector No. Terminal No.
M76 25 26 Approx. 54 – 66
