2007 HUMMER H3 key

Shifting Out of Park (P)
(Automatic Transmission)
Your vehicle has an automatic transmission shift
lock control system. You have to apply your
regular brake before you can shift from PARK (P)
when the ignition is in ON. SeeAutomatic
Transmission Operation on page 106.
If you cannot shift out of PARK (P), ease pressure
on the shift lever and push the shift lever all the way
into PARK (P) as you maintain brake application.
Then move the shift lever into the gear you wish.
Press the shift lever button before moving the
shift lever.
Parking Your Vehicle
(Manual Transmission)
Your vehicle has a manual transmission. Before
you get out of your vehicle, move the shift
lever into REVERSE (R), and rmly apply the
parking brake. Once the shift lever has been
placed into REVERSE (R) with the clutch pedal
pressed in, turn the ignition key to LOCK, remove
the key and release the clutch.
If you are parking on a hill, or if your vehicle is
pulling a trailer, seeTowing a Trailer on page 297.
Parking Over Things That Burn
{CAUTION:
Things that can burn could touch hot
exhaust parts under your vehicle and
ignite. Do not park over papers, leaves,
dry grass, or other things that can burn.
119

OnStar®System
OnStar®uses several innovative technologies and
live advisors to provide you with a wide range
of safety, security, information, and convenience
services. If your airbags deploy, the system is
designed to make an automatic call to OnStar
®
Emergency advisors who can request emergency
services be sent to your location. If you lock
your keys in the vehicle, call OnStar
®at
1-888-4-ONSTAR and they can send a signal to
unlock your doors. If you need roadside
assistance, press the OnStar
®button and they
can contact Roadside Service for you.
OnStar
®service is provided to you subject to the
OnStar®Terms and Conditions. You may cancel
your OnStar®service at any time by contacting
OnStar®as provided below. A complete OnStar®
Owner’s Guide and the OnStar®Terms andConditions are included in the vehicle’s OnStar
®
Subscriber glove box literature. For more
information, visit onstar.com or onstar.ca, contact
OnStar
®at 1–888–4–ONSTAR (1–888–466–7827)
or TTY 1–877–248–2080, or press the OnStar®
button to speak with an OnStar®advisor 24 hours a
day, 7 days a week.
Not all OnStar
®features are available on all
vehicles. To check if your vehicle is equipped to
provide the services described below, or for a
full description of OnStar
®services and system
limitations, see the OnStar®Owner’s Guide in your
glove box or visit onstar.com.
OnStar®Services
For new vehicles equipped with OnStar®, the Safe
& Sound Plan, or the Directions & Connections®
Plan is included for one year from the date of
purchase. You can extend this plan beyond the rst
year, or upgrade to the Directions & Connections
®
Plan. For more information, press the OnStar®
button to speak with an advisor. Some OnStar®
services (such as Remote Door Unlock or Stolen
Vehicle Location Assistance) may not be available
until you register with OnStar
®.
129

Luggage Carrier
If your vehicle has this feature, you can load cargo
on your vehicle.
The luggage carrier consists of siderails attached
to the roof. The crossrails attach into the
siderails and can be moved back and forth to
accommodate various cargo sizes.
Notice:Loading cargo on the luggage carrier
that weighs more than 250 lbs. (113 kg) or
hangs over the rear or sides of the vehicle may
damage your vehicle. Load cargo only on
top of the crossrails and tie the cargo down to
the crossrail support cargo tie-down loops,
making sure to fasten it securely
Do not exceed the maximum vehicle capacity
when loading your vehicle. For more information
on vehicle capacity and loading, seeLoading Your
Vehicle on page 289.
Adjusting the Crossrails
Adjust the crossrails to t your load by doing the
following:
1. Use the provided crossrail key to unlock the
crossrail end cap by turning it
counterclockwise.
144

2. Remove the end cap. 3. Pull the lever labeled “PULL” from left to right
to loosen the crossrail.
4. Repeat Steps 1 through 3 to the opposite end
of the crossrail.
5. Once both sides of the crossrail are loose,
adjust the crossrail to the desired position.
6. Push the lever labeled “PULL” from right to
left to lock the crossrail in place.
7. Reinstall end cap and lock by turning the key
clockwise.
8. Repeat Steps 5 through 7 to the opposite end
of the crossrail.
145

Hazard Warning Flashers
Your hazard warning ashers let you warn others.
They also let police know you have a problem.
Your front and rear turn signal lamps will ash
on and off.
The hazard warning
asher button is located
in the center of the
instrument panel.
Your hazard warning ashers work no matter
what position your key is in, and even if the key
is not in the ignition switch.
Press the button to make the front and rear turn
signal lamps ash on and off. Press the button
again to turn the ashers off.
When the hazard warning ashers are on, your
turn signals will not work.
Other Warning Devices
If you carry reective triangles, you can set one
up at the side of the road about 300 feet (100 m)
behind your vehicle.
Horn
To sound the horn, press the horn symbol on the
steering wheel pad.
Tilt Wheel
A tilt wheel allows the steering wheel to be adjusted
before driving. It can be raised to allow more room
for the driver to enter and exit the vehicle.
154

Vehicles rst sold in Canada with an automatic
transmission cannot turn off automatic headlamps
unless the gear position is in PARK (P) and
the headlamp switch is turned to the Off position.
Vehicles rst sold in Canada with a manual
transmission can turn off the automatic headlamps
with the headlamp control; however, the parking
lamps will remain on.
;(Parking Lamps):Turn the knob to this
position to turn on the parking lamps, together
with the following:
Sidemarker Lamps
Taillamps
License Plate Lamps
Instrument Panel Lights
2(Headlamps):Turn the knob to this position
to turn on the headlamps, together with the
previously listed lamps and lights.
You can switch your headlamps from low to high
beam by pushing the turn signal/multifunction
lever toward the instrument panel.
Headlamps on Reminder
A headlamp reminder chime will sound if the
following conditions are met:
The driver door is open.
Parking lamps or headlamps are manually
turned on.
The key is either not in the ignition switch, or it
is in the LOCK position of the ignition switch.
The headlamp reminder cannot be turned off if
the conditions listed above are met.
In the automatic mode, the headlamps turn off
once the ignition is in ACC.
Daytime Running Lamps (DRL)
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during
the day. DRL can be helpful in many different
driving conditions, but they can be especially
helpful in the short periods after dawn and before
sunset. Fully functional daytime running lamps
are required on all vehicles rst sold in Canada.
164

Dome Lamp Override
E(Dome Lamp Override):You can use the
dome override button, located below the exterior
lamps control, to set the dome and footwell
lamps to come on automatically when a door is
opened, or to remain off. To turn the lamps
off, press the button into the in position. With the
button in this position, the dome lamps will
remain off when the doors are open. To return
the lamps to automatic operation, press the
button again and return it to the out position.
With the button in this position, the dome lamps
will come on when you open a door.
Exit Lighting
With exit lighting, the interior lamps will come
on when you remove the key from the ignition.
The lamps will not come on if the dome override
button is pressed in.
Reading Lamps
Your vehicle has reading lamps. Press the button
located next to the lamp to turn them on or off.
These lamps will not come on with the dome lamps.
Electric Power Management
The vehicle has Electric Power Management (EPM)
that estimates the battery’s temperature and state
of charge. It then adjusts the voltage for best
performance and extended life of the battery.
When the battery’s state of charge is low, the
voltage is raised slightly to quickly put the charge
back in. When the state of charge is high, the
voltage is lowered slightly to prevent overcharging.
If the vehicle has a voltmeter gage, you may
see the voltage move up or down. This is normal.
If there is a problem, an alert will be displayed.
The battery can be discharged at idle if the
electrical loads are very high. This is true for all
vehicles. This is because the generator (alternator)
may not be spinning fast enough at idle to
produce all the power that is needed for very
high electrical loads.
A high electrical load occurs when several of the
following loads are on: headlamps, high beams,
fog lamps, rear window defogger, climate
control fan at high speed, heated seats, engine
cooling fans, trailer loads, and loads plugged into
accessory power outlets.
168

0(Defrost):Turn the right knob on the control
panel to this mode to direct most of the air to the
windshield, and the side window outlets. When
you select this mode, the system runs the air
conditioning system unless the outside temperature
is near or below freezing. Recirculation is not
available in this mode.
Do not drive the vehicle until all the windows
are clear.
Rear Window Defogger
The rear window defogger uses a warming grid to
remove fog or frost from the rear window when
the key is in the ignition and turned to ON.
=(Rear Defogger):Press the right knob on the
control panel to turn the rear window defogger
on or off. First press of this button will activate
the rear window defogger for 15 minutes and
each subsequent activation lasts seven and
one-half minutes.
Notice:Do not use anything sharp on the
inside of the rear window. If you do, you could
cut or damage the warming grid, and the repairs
would not be covered by your warranty. Do not
attach a temporary vehicle license, tape, a decal
or anything similar to the defogger grid.
Outlet Adjustment
Use the air outlets located in the center and
on the side of your instrument panel to direct
the airow.
Your vehicle has air outlets that allow you to
adjust the direction and amount of airow inside
the vehicle. Move the louvers up or down to
change the direction of the airow. Use the
thumbwheel under the outlets to change the
direction of the airow from left to right.
Operation Tips

Enable recirculation mode for maximum
air conditioning performance.
Clear away any ice, snow or leaves from the
air inlets at the base of the windshield that
may block the ow of air into your vehicle.
Use of non-GM approved hood deectors
may adversely affect the performance of
the system.
Keep the path under the front seats clear
of objects to help circulate the air inside
of your vehicle more effectively.
173
