2007 DODGE DAKOTA wipers

To Open And Close The Hood..............88

Lights................................90
▫Interior Lights........................90
▫Battery Saver.........................91
▫Headlamp Delay.......................92
▫Headlights, Parking Lights, Panel Lights......92
▫Daytime Running Lights (Canada Only)......93
▫Lights-On Reminder....................93
▫Fog Lights — If Equipped................93
▫Cargo Light — If Equipped...............94
▫Multifunction Control Lever...............94

Windshield Wipers And Washers.............96
▫Windshield Wipers.....................96▫Windshield Washers....................97

Tilt Steering Column.....................98

Electronic Speed Control — If Equipped.......99
▫ToActivate ...........................99
▫To Set At A Desired Speed...............100
▫To Deactivate........................100
▫To Resume Speed.....................100
▫To Vary The Speed Setting...............100
▫To Accelerate For Passing...............102

Overhead Console......................103
▫Courtesy/Reading Lights................103

Compass/Temperature Mini-Trip Computer....104
▫US/M Button........................104
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

High Beam / Low Beam Select Switch
Pull the multifunction control lever fully toward the
steering wheel to switch the headlights from HIGH or
LOW beam.
WINDSHIELD WIPERS AND WASHERS
The multifunction control lever is located on the left side
of the steering column.
Windshield Wipers
The wipers and washers are operated by a switch in the
multifunction control lever. Turn the end of the handle to
select the desired wiper speed.
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Intermittent Wiper System
The intermittent feature of this system was designed for
use when weather conditions make a single wiping cycle,
with a variable pause between cycles, desirable. For
maximum delay between cycles, rotate the control knob
into the upper end of the delay range.
The delay interval decreases as you rotate the knob until
it enters the LO continual speed position. The delay can
be regulated from a maximum of about 18 seconds
between cycles, to a cycle every 2 seconds. The delay
intervals will double in duration when the vehicle speed
is 10 mph (16 km) or less.WARNING!
Sudden loss of visibility through the windshield
could lead to an accident. You might not see other
vehicles or other obstacles. To avoid sudden icing of
the windshield during freezing weather, warm the
windshield with defroster before and during wind-
shield washer use.
NOTE:If the front wiper is operating when the ignition
is turned off, the wiper will automatically return to the
Parkposition. When the vehicle is restarted, the wipers
will resume operation.
Windshield Washers
To use the washer, push in on the washer knob on the end
of the multifunction control lever and hold while spray is
desired. If the washer knob is depressed while in the
delay range, the wiper will operate for several seconds
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97
3

Drive Shaft Constant Velocity Joints
All four wheel drive models are equipped with four
constant velocity joints. Periodic lubrication of these
joints is not required. However, the joint boot should be
inspected for external leakage or damage periodically. If
external leakage or damage is evident, the joint boot and
grease should be replaced immediately. Continued op-
eration could result in failure of the joint due to water
and dirt contamination of the grease. This would require
complete replacement of the joint assembly. Refer to the
Service Manual for the detailed replacement procedure.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, doors and hood hinges, should be lubricated
periodically to assure quiet, easy operation and to protect
against rust and wear. Prior to the application of any
lubricant, the parts concerned should be wiped clean to
remove dust and grit; after lubricating excess oil and
grease should be removed. Particular attention shouldalso be given to hood latching components to insure
proper function. When performing other underhood ser-
vices, the hood latch, release mechanism and safety catch
should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the fall and spring. Apply a small
amount of a high quality lubricant such as MoparLock
Cylinder Lubricant directly into the lock cylinder.
Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner. This will remove accu-
mulations of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
MAINTAINING YOUR VEHICLE 307
7

CavityCartridge
FuseMini
FuseDescription
16 20 Amp
YellowHorn
17 20 Amp
YellowABS Feed (Valves)
18 20 Amp
YellowFuel Pump
19 15 Amp
BlueCenter High Mounted
Stop Lamp (CHMSL)
20 20 Amp
YellowCabin Compartment
Node (CCN) Door
Locks/Brake Transmis-
sion Shift Interlock
(BTSI)
21 25 Amp
NaturalAudio Amp
22 20 Amp
YellowPower Outlet (Switch-
able)
23 20 Amp
YellowFog LampsCavityCartridge
FuseMini
FuseDescription
24 20 Amp
YellowPowertrain Control Mod-
ule (PCM) B+
25 15 Amp
BlueCabin Compartment
Node (CCN) Illumina-
tion
26 Spare
27 10 Amp
RedPower Mirror
28 20 Amp
YellowPower Outlet
29 20 Amp
YellowFront Control Module
(FCM) 4 (Wipers)
30 Spare
31 Spare
32 30 Amp
PinkFront Control Module
(FCM) 1 (Ext. Lights # 1)
33 30 Amp
PinkAuto Shut Down (ASD)
MAINTAINING YOUR VEHICLE 329
7

Selection of Coolant (Antifreeze)...... 311,345,346
Temperature Gauge..................... 136
Cruise Control (Speed Control)............... 99
CupHolder ............................ 123
Customer Assistance..................... 370
Data Recorder, Event...................... 56
Daytime Running Lights................... 93
Dealer Service.......................... 296
Defroster, Rear Window................... 124
Defroster, Windshield................... 73,177
Delay (Intermittent) Wipers................. 97
Diagnostic System, Onboard................ 293
Differential, Limited-Slip.................. 210
Dimmer Switch, Headlight................. 137
Dipsticks
Automatic Transmission................. 318
Oil (Engine).......................... 297
Power Steering........................ 306Disarming, Theft System................... 18
Disc Brakes............................ 316
Disposal
Antifreeze (Engine Coolant)............... 313
Door Locks............................. 27
Door Opener, Garage..................... 110
DriveBelts ............................ 301
Drive Shaft Universal Joints................ 307
E-85 Fuel............................. 245
Electric Remote Mirrors.................... 81
Electrical Power Outlets................... 119
Electronic Speed Control (Cruise Control)....... 99
Emergency, In Case of
FreeingVehicleWhenStuck ............... 217
Jacking............................. 278
Tow Hooks.......................... 285
Towing ............................. 286
Emission Control System Maintenance......... 350
INDEX 381
10

Inflation Pressure Tires.................... 235
Inside Rearview Mirror.................... 79
Instrument Cluster....................... 136
Instrument Panel and Controls.............. 134
Instrument Panel Lens Cleaning............. 326
Interior Appearance Care.................. 325
Interior Lights........................... 90
Intermittent Wipers (Delay Wipers)............ 97
Introduction............................. 4
Jack Operation.......................273,278
Jacking Instructions...................... 279
Key, Replacement........................ 16
Key, Sentry (Immobilizer)................... 15
Keyless Entry System...................... 20
Keys................................. 12
Knee Bolster............................ 44Lane Change and Turn Signals......... 94,136,338
Lap/Shoulder Belts....................... 35
LATCH (Lower Anchors and Tether for CHildren) . 61
LifeofTires ............................ 233
Lights ............................... 74,90
Airbag............................ 54,142
Anti-Lock Warning..................... 139
Back-Up............................. 338
Brake Warning........................ 141
Bulb Replacement...................332,333
Cargo ............................... 94
Center Mounted Stop................... 341
Courtesy/Reading..................... 103
Cruise .............................. 143
Daytime Running....................... 93
Fog ........................... 93,137,345
Hazard Warning Flasher................. 272
Headlights............................ 92
High Beam........................... 96
INDEX 385
10

Weight Load Carrying.................... 247
Wheel Alignment and Balance............... 234
Wheel and Wheel Trim.................... 325
Wheel and Wheel Trim Care................ 325
Wheel Changing........................ 273
Wheel Mounting........................ 278
Wheel Nut Torque....................... 281
Wind Buffeting.......................... 33
Window Fogging........................ 179
Windows.............................. 32
Power............................... 32Rear Sliding.......................... 124
Windshield Defroster..................... 177
Windshield Washers.................. 96,97,308
Fluid ............................. 96,308
Windshield Wiper Blades.................. 307
Windshield Wipers....................... 96
Wiper Blade Replacement.................. 307
Wipers, Intermittent....................... 97
Wrecker Towing......................... 286
YES EssentialsFabric Cleaning Procedure...... 325
394 INDEX
