range (PRND21). If the PRNDL displays only the char-
acters PRND21 (no boxes), have the system checked by
an authorized dealer.
16. Trip Odometer
The trip odometer shows individual trip mileage. To
toggle between the odometer and the trip odometer,
press the Odometer/Trip Odometer Button. To reset the
Trip Odometer, press and hold the button while in trip
mode, until the Trip Odometer resets.
Also the cluster will display, replacing the odometer,
vehicle warning messages such as: door ajar, low wash,
No-fuse, and the outside temperature on vehicles that are
not equipped with the Overhead Console with
Compass/Temperature Mini-Trip Computer. For addi-
tional information, refer to “Compass/Temperature
Mini-Trip Computer” in section 3.
If the vehicle diagnostic system determines that the fuel
filler cap is loose, improperly installed, or damaged,GASCAP will be displayed in the instrument cluster.
Tighten the fuel filler cap properly and press the odom-
eter reset button to turn the GASCAP message off. If the
problem continues, the message will appear the next time
the vehicle is started.
17. Odometer
The odometer shows the total distance the vehicle has
been driven.
U.S. federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. There-
fore, if the odometer reading is changed during repair or
replacement, be sure to keep a record of the reading
before and after the service so that the correct mileage can
be determined.
140 INSTRUMENT PANEL AND CONTROLS
CavityCartridge
FuseMini
FuseDescription
34 30 Amp
PinkFront Control Module
(FCM) 2 (Ext. Light # 2)
35 40 Amp
GreenHVAC Blower Motor
36 10 Amp
RedIgnition UNLK/RN/ST
37 10 Amp
RedCrank
38 20 Amp
BlueRun/Start
39 30 Amp
PinkStarter Solenoid
40 Spare
41 30 Amp
PinkWiper Motor
42 25 Amp
NaturalFront Control Module
(FCM) 5 (T-Case)
43 10 Amp
RedLt Park LampsCavityCartridge
FuseMini
FuseDescription
44 10 Amp
RedRt Park Lamps
45 20 Amp
YellowTrailer Tow Park Lamps
46 10 Amp
RedAirbag System # 2
47 40 Amp
GreenIgnition Run/Accessory
(Acc)
48 20 Amp
BlueSunroof/Sound Box
49 30 Amp
PinkTrailer Tow B+
50 40 Amp
GreenAnti-Lock Brake System
(ABS) Module (Pump)
51 40 Amp
GreenPark Lamps
52 Spare
53 40 Amp
GreenRear Defogger
330 MAINTAINING YOUR VEHICLE
