2007 DODGE DAKOTA power steering fluid

When you are in a severe braking condition involving
use of the Anti-lock Brake System, you will experience
some pedal drop as the vehicle comes to a stop. This is
the result of the system reverting to the base brake
system.
Engagement of the Anti-lock Brake System may be
accompanied by a pulsing sensation. You may also hear a
clicking noise. These occurrences are normal, and indi-
cate that the system is functioning properly.
POWER STEERING
The standard power steering system will give you good
vehicle response and increased ease of maneuverability
in tight spaces. The system will provide mechanical
steering capability if power assist is lost.If for some reason, the power assist is interrupted, it will
still be possible to steer your vehicle. Under these condi-
tions you will observe a substantial increase in steering
effort, especially at very low vehicle speeds and during
parking maneuvers.
NOTE:Increased noise levels at the end of the steering
wheel travel are considered normal and does not indicate
that there is a problem with the power steering system.
Upon initial start-up in cold weather, the power steering
pump may make noise for a short period of time. This is
due to the cold, thick fluid in the steering system. This
noise should be considered normal, and does not in any
way damage the steering system.
216 STARTING AND OPERATING

WARNING!
Continued operation with reduced power steering
assist could pose a safety risk to yourself and others.
Service should be obtained as soon as possible.
CAUTION!
Prolonged operation of the steering system at the
end of the steering wheel travel will increase the
steering fluid temperature and should be avoided
when possible. Damage to the power steering pump
may occur.
ROCKING THE VEHICLE
If vehicle becomes stuck in snow, sand, or mud, it can
often be moved by a rocking motion. Move the gear
selector rhythmically between FIRST and REVERSE,
while applying slight pressure to the accelerator.
The least amount of accelerator pedal pressure to main-
tain the rocking motion without spinning the wheels or
racing the engine is most effective. Allow the engine to
idle with the transmission selector in NEUTRAL for at
least one minute after every five rocking-motion cycles.
This will minimize overheating and reduce the risk of
transmission failure during prolonged efforts to free a
stuck vehicle.
STARTING AND OPERATING 217
5

MAINTAINING YOUR VEHICLE
CONTENTS

3.7L/4.7L Engine Compartment.............292

Onboard Diagnostic System — OBD II........293
▫Loose Fuel Filler Cap Message............293

Emissions Inspection And Maintenance
Programs............................294

Replacement Parts......................295

Dealer Service.........................296

Maintenance Procedures..................296
▫Engine Oil..........................297▫Engine Oil Filter......................300
▫Drive Belts — Check Condition And Tension . . 301
▫Spark Plugs.........................301
▫Engine Air Cleaner Filter................302
▫Engine Fuel Filter.....................302
▫Catalytic Converter....................302
▫Maintenance Free Battery................304
▫Air Conditioner Maintenance.............305
▫Power Steering — Fluid Check............306
7

Refrigerant Recovery and Recycling
R-134a Air Conditioning Refrigerant is a hydrofluorocar-
bon (HFC) that is endorsed by the Environmental Pro-
tection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by dealers or other service facilities
using recovery and recycling equipment.
Power Steering — Fluid Check
Checking the power steering fluid level at a defined
service interval is not required. The fluid should only be
checked if a leak is suspected, abnormal noises are
apparent, and/or the system is not functioning as antici-
pated. Coordinate inspection efforts through a certified
DaimlerChrysler Dealership.
WARNING!
Fluid level should be checked on a level surface and
with the engine off to prevent injury from moving
parts and to insure accurate fluid level reading. Do
not overfill. Use only manufacturers recommended
power steering fluid.
If necessary, add fluid to restore to the proper indicated
level. With a clean cloth, wipe any spilled fluid from all
surfaces. Refer to Fluids, Lubricants, and Genuine Parts
for correct fluid type.
Front Suspension Ball Joints
The ball joints and seals should be inspected whenever
the vehicle is serviced for other reasons. Damaged seals
should be replaced to prevent leakage or contamination
of the grease.
306 MAINTAINING YOUR VEHICLE

Chassis
Component Fluids, Lubricants and Genuine Parts.
Automatic Transmission MoparATF+4, Automatic Transmission Fluid.
Manual Transmission (Getrag 238) MoparATF+4, Automatic Transmission Fluid.
Transfer Case MoparATF+4, Automatic Transmission Fluid.
Front Axle SAE 75W-90 Multipurpose Type, GL-5 Gear Lubricant (MS-9763).
Rear Axle SAE 75W-140 Synthetic Gear Lubricant (MS-8985). Limited-slip rear axles
require Moparlimited-slip additive (MS-10111). Four ounces (118 ml)
should be added to the gear lubricant whenever a fluid change is made.
Brake Master Cylinder MoparDOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not
available, then DOT 4 is acceptable. Use only recommended brake fluids.
Power Steering Reservoir MoparATF+4, Automatic Transmission Fluid.
MAINTAINING YOUR VEHICLE 347
7

Axle Lubrication (Axle Fluid)............... 321
BallJoints ............................. 306
Battery............................... 304
Charging............................ 283
Emergency Starting..................... 283
Gas Caution.......................... 283
Keyless Transmitter Replacement (RKE)....... 25
Saving Feature (Protection)................ 91
Belts,Drive ............................ 301
Belts, Seat.............................. 35
Body Mechanism Lubrication............... 307
B-Pillar Location........................ 222
Brake Fluid............................ 347
Brake System........................213,316
Anti-Lock (ABS)....................213,214
Disc Brakes.......................... 316
Fluid Check.......................... 316
Hoses.............................. 317Master Cylinder....................... 316
Parking............................. 212
Warning Light.....................139,141
Brake/Transmission Interlock............... 191
Break-In Recommendations, New Vehicle........ 71
Bulb Replacement....................... 333
Bulbs,Light ............................ 332
Calibration, Compass..................... 107
Camper............................... 128
Capacities, Fluid........................ 345
Caps, Filler
Oil (Engine).......................... 299
Power Steering........................ 306
Radiator (Coolant Pressure)............... 312
Car Washes............................ 323
Carbon Monoxide Warning..............129,242
CargoLight ............................ 94
Cargo (Vehicle Loading)................... 247
INDEX 379
10

Maintenance.......................... 247
Replacement Parts..................... 247
Starting............................. 246
Flooded Engine Starting................... 188
Floor Console.......................... 121
Fluid, Brake........................... 347
Fluid Capacities......................... 345
Fluid Level Checks
Automatic Transmission................. 318
Brake............................... 316
Engine Oil........................... 297
Power Steering........................ 306
Transfer Case......................... 321
Fluids, Lubricants and Genuine Parts.......... 346
Fog Lights........................... 93,345
Four Wheel Drive....................... 199
Operation........................... 199
Four-Way Hazard Flasher.................. 272
Freeing A Stuck Vehicle................... 217FrontAxle(Differential) ................... 322
Fuel................................. 238
Adding............................. 243
Filter ............................... 302
Gauge.............................. 136
Octane Rating......................238,346
Requirements......................238,345
Tank Capacity........................ 345
Fuel, Flexible.............See Flexible Fuel Vehicles
Fueling ............................... 243
Fuses................................ 327
Garage Door Opener (HomeLink) ........... 110
Gas Cap (Fuel Filler Cap)...............244,293
Gas Gauge (Fuel Gauge)................... 136
Gasoline (Fuel)......................... 238
Gasoline, Reformulated................... 239
Gauges
Coolant Temperature.................... 136
INDEX 383
10

Overheating, Engine...................... 138
Owner’s Manual (Operator Manual).......... 374
Panic Alarm............................ 22
Parking Brake.......................... 212
Parking On Hill......................... 212
Passenger Airbag On/Off Switch............. 54
Passing Light........................... 95
Pets.................................. 71
Pets, Transporting........................ 71
Pickup Box............................ 126
Placard, Tire and Loading Information......... 222
Positive Crankcase Valve.................. 315
Power
Brakes.............................. 316
Distribution Center (Fuses)............... 327
Door Locks......................... 19,28
Mirrors .............................. 81
Outlet (Auxiliary Electrical Outlet).......... 119Steering..........................216,306
Sunroof............................. 116
Windows............................. 32
Power Steering Fluid..................... 347
Pregnant Women and Seat Belts.............. 43
Preparation for Jacking.................... 278
Pretensioners
Seat Belts............................. 41
Programmable Electronic Features......... 112,115
Programming Transmitters
(Remote Keyless Entry)............... 23,112,115
Quad Cab.............................. 87
Radial Ply Tires......................... 229
Radiator Cap (Coolant Pressure Cap).......310,312
Radio Broadcast Signals................... 144
Radio Operation...................146,154,175
Radio, Satellite.......................... 167
388 INDEX
