2007 DODGE DAKOTA Owners Manual

FLOOR CONSOLE — IF EQUIPPED
Floor Console Features
The Floor Console between the driver’s and front pas-
senger’s seat has the following features:
•Miscellaneous storage compartments
•Flexible cup holder inserts
•Portable phone storage bin
•Portable phone cord routing between lid and base on
forward edge
•12 Volt power outlet inside storage compartment
•Side open armrest lid
•Tissue holder & pen holder
•Coin slotsThe coin slots are located under the instrument panel
center stack.
Storage Compartments
Some miscellaneous storage compartments and cup
holders have rubber mats at the bottom, the mats are
both removable and dishwasher safe for cleaning pur-
poses. Various storage compartments provide versatile
and useful storage. A coin holder is also provided inside
the console storage compartment.
Cup Holders
The cup holders fit a wide variety of cup and bottle sizes.
To use the adjustable cup holders (only in automatic
transmission vehicles), place your beverage in the cup
holder, then adjust the movable arms to tightly hold the
beverage.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121
3

Power Outlet and Portable Phone Storage
The console is equipped with a power outlet, portable
phone storage bin, and phone cord routing. The phone
storage bin can be used when easy access to the phone is
needed. Also, the power outlet inside console compart-
ment can be used to charge the phone while it is being
stored in the bin. To use plug in the portable power
recharge cord and place the cord along the slot provided
in the left side of the console. Close the console armrest
lid and plug the power cord into the phone while resting
the phone in the bin. The power outlet may be used for
any portable item with a standard 12 volt power plug.
Side Open Armrest Lid
Pressing the button on the left side of the console opens
the console armrest lid. The armrest lid will remain open
until armrest lid is closed manually by pressing the lid
back into place. A penholder is provided on the inside ofthe armrest lid. A tissue holder is also provided on the
inside of the armrest lid, which holds a pocket size soft
pack of tissue.
CENTER STORAGE COMPARTMENT — IF
EQUIPPED
The center portion of the seat folds down to provide an
armrest with unique storage compartments under the lid.
Push the button on the armrest to raise the lid. Compart-
ments include a holder which will accommodate five
compact disks with finger notches for easier access, a
pencil tray, a coin holder, and a large open area for
miscellaneous items.
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CUP HOLDERS
If your vehicle has bucket seats with a center console,
there are three cup holders located on the console. Refer
to the section on floor console.
A two-cavity cup holder is available on all Quad Cab
with rear seats mounted on the floor.
Front Cup Holders – Double Cab with Automatic
Rear Cup Holders – Double Cab with Automatic
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123
3

REAR WINDOW FEATURES
Rear Window Defroster – If Equipped
CAUTION!
Use care when washing the inside of the rear win-
dow to prevent damage to heating elements. Use a
soft cloth and a mild washing solution, wiping
parallel to the heating elements. Also, keep all
objects a safe distance from the window to prevent
damaging the heating elements.
A push-button type switch is located on the right
side of the control below the A/C (Snowflake)
button. Pressing the switch will turn on the Rear Window
Defroster and heated mirrors, if equipped. A light above
the Rear Window Defroster symbol will illuminate to
indicate the Rear Window Defroster is On. Pushing thebutton again will turn the Rear Window Defroster Off
prior to the time-out. The Rear Window Defroster will
turn off automatically after 15 minutes after the first
push, 10 minutes after the second push and 5 minutes
after the third push and all subsequent pushes of the
button (all within the same ignition cycle). To prevent
excessive battery drain, use the rear defroster only when
the engine is running.
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Sliding Rear Window – If Equipped
A locking device in the center of the window helps to
prevent entry from the rear of the vehicle. Squeeze the
lock to release the window.
TAILGATE
Tailgate Removal
To simplify mounting a camper unit with an overhang,
the tailgate can be removed quickly. Follow these steps:
1. Open the tailgate to a 45° angle.
2. Unclip and remove the cables from the box while
maintaining a 45° angle.
Sliding Rear Window Latch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125
3

3. Lift the tailgate off of the pivot on the passenger side
by pulling upward and rearward at the same time.
4. Slide the tailgate to the passenger side while making
sure clearance from the box and taillight is maintained.
To reinstall the tailgate, do the following:
1. Slide the tailgate onto the driver’s side pivot.2. Hold the tailgate at a 45° angle and insert it into the
passenger side pivot.
3. Clip the cables to the box.
Two Position Tailgate / Upper Load Platform
Your tailgate can be opened to the full open or the partial
open position. The partial open position is for loading
objects longer than the length of the bed (sheets of
plywood, etc.) by creating an upper load platform:
1. Install lumber
•Place lumber across the box in the indentations
provided above the wheel housings and in the
bulkhead dividers to form the floor. There are
indents in the sheet metal (or bed liner if equipped)
on the inner side of the box in front (Club Cab only)
and behind both wheel housings.
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Secure the tailgate in the partially open position:
•Open the tailgate slightly.
•Snap the tailgate support cable between the cable
guide and the tailgate bumper. Do this on both sides
of the tailgate.
To return the tailgate to the full open position:
•Lift up on the tailgate.
1 — Bulkhead Divider
2 — Upper Load Floor Indent
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127
3

•Remove both cables from between the cable guides
and the tailgate bumpers and lower the tailgate.
CAUTION!
•Care should always be exercised when operating a
vehicle with cargo. Vehicle speeds may need to be
reduced. Severe turns or rough roads may cause
shifting or bouncing of the cargo that may result
in vehicle damage.
•Insure the load is securely tied down and is
properly identified according to local laws if it
extends beyond the taillamps.
•LOADING should not exceed 400 lbs (181 kg) of
material suspended above the wheelhouse and
partially open tailgate or vehicle damage may
result.
SLIDE-IN CAMPERS
Camper Applications
Certain truck models are not recommended for slide-in
campers. To determine if your vehicle is excluded, please
refer to the Consumer Information Truck-Camper Load-
ing document located in your Owner’s Manual packet or
available from your dealer. For safety reasons, follow all
instructions on this important document.
General Information
The Manufacturer’s Warranty does not apply to body
modifications and special equipment, such as a camper
unit, heaters, stoves, refrigerators, etc., supplied by
manufacturers other than the manufacturer. For warranty
coverage and service on these items, contact the appli-
cable manufacturer.
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
