2007 DODGE DAKOTA Owners Manual

CavityCartridge
FuseMini
FuseDescription
16 20 Amp
YellowHorn
17 20 Amp
YellowABS Feed (Valves)
18 20 Amp
YellowFuel Pump
19 15 Amp
BlueCenter High Mounted
Stop Lamp (CHMSL)
20 20 Amp
YellowCabin Compartment
Node (CCN) Door
Locks/Brake Transmis-
sion Shift Interlock
(BTSI)
21 25 Amp
NaturalAudio Amp
22 20 Amp
YellowPower Outlet (Switch-
able)
23 20 Amp
YellowFog LampsCavityCartridge
FuseMini
FuseDescription
24 20 Amp
YellowPowertrain Control Mod-
ule (PCM) B+
25 15 Amp
BlueCabin Compartment
Node (CCN) Illumina-
tion
26 Spare
27 10 Amp
RedPower Mirror
28 20 Amp
YellowPower Outlet
29 20 Amp
YellowFront Control Module
(FCM) 4 (Wipers)
30 Spare
31 Spare
32 30 Amp
PinkFront Control Module
(FCM) 1 (Ext. Lights # 1)
33 30 Amp
PinkAuto Shut Down (ASD)
MAINTAINING YOUR VEHICLE 329
7

CavityCartridge
FuseMini
FuseDescription
34 30 Amp
PinkFront Control Module
(FCM) 2 (Ext. Light # 2)
35 40 Amp
GreenHVAC Blower Motor
36 10 Amp
RedIgnition UNLK/RN/ST
37 10 Amp
RedCrank
38 20 Amp
BlueRun/Start
39 30 Amp
PinkStarter Solenoid
40 Spare
41 30 Amp
PinkWiper Motor
42 25 Amp
NaturalFront Control Module
(FCM) 5 (T-Case)
43 10 Amp
RedLt Park LampsCavityCartridge
FuseMini
FuseDescription
44 10 Amp
RedRt Park Lamps
45 20 Amp
YellowTrailer Tow Park Lamps
46 10 Amp
RedAirbag System # 2
47 40 Amp
GreenIgnition Run/Accessory
(Acc)
48 20 Amp
BlueSunroof/Sound Box
49 30 Amp
PinkTrailer Tow B+
50 40 Amp
GreenAnti-Lock Brake System
(ABS) Module (Pump)
51 40 Amp
GreenPark Lamps
52 Spare
53 40 Amp
GreenRear Defogger
330 MAINTAINING YOUR VEHICLE

CavityCartridge
FuseMini
FuseDescription
54 Spare
55 10 Amp
RedCabin Compartment
Node (CCN) Accessory
(ACC) Feed
56 10 Amp
RedHeated Seats
57 20 Amp
YellowAirbag System # 2
58 20 Amp
YellowHeated Seats
59 10 Amp
RedHVAC Module
60 10 Amp
RedABS Module
61 20 Amp
YellowFront Control Module
(FCM) 3 (Reverse
Lamps)CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it suggests a
problem in the circuit that must be corrected.
NOTE:If you are leaving your vehicle dormant for
longer than 21 days you may want to take steps to protect
your battery. You may do this by disconnecting the
battery or by disconnecting the two ignition-off draw
(I.O.D.) fuses located in the Auxiliary Power Distribution
Center (PDC) located in the engine compartment. The
I.O.D. cavities include a snap-in retainer that allows the
fuse to be disconnected, without removing it from the
fuse block. Pressing the I.O.D. fuse back into the cavity
reconnects it.
MAINTAINING YOUR VEHICLE 331
7

VEHICLE STORAGE
If you are storing your vehicle for more than 21 days, we
recommend that you take the following steps to mini-
mize the drain on your vehicle’s battery:
•Disconnect the Ignition-Off Draw fuse (I.O.D.) fuse
located in the Power Distribution Center (PDC). The
I.O.D. cavity includes a snap-in retainer that allows the
fuse to be disconnected, without removing it from the
fuse block.
•The transfer case should be placed in the 4HI mode
and kept in this position to minimize the battery drain.
•As an alternative to the above steps you may discon-
nect the negative cable from the battery.
REPLACEMENT LIGHT BULBS
LIGHT BULBS — Interior Bulb No.
Dome Light........................ WL212–2
Cargo Light............................ 567
Overhead Console Lights................... 192
Reading Light....................... WL212–2
LIGHT BULBS — Outside Bulb No.
Headlight............................. H13
Front Park/Turn/Sidemarker.............3157NA
Back-Up..............................3157
Center High Mounted Stoplight.............. 921
Fog Lamp.............................9145
Rear Sidemarker......................... 168
License Plate Light....................... 168
Rear Tail, Stop, Turn Signal.................3057
332 MAINTAINING YOUR VEHICLE

BULB REPLACEMENT
Headlamps
Removing Attaching Screw
Removing Headlamp Assembly
MAINTAINING YOUR VEHICLE 333
7

1. Open the hood.
2. Remove the 3 screws attaching the headlamp housing
to the inner panel.
3. Grasp the headlamp and pull firmly to disengage the
headlamp housing from the fender panel.4. While firmly holding the headlamp housing in your
hands unlock and disconnect Headlamp bulb connector.
5. Twist 1/4 turn and remove headlamp bulb and socket
from housing and replace.
Removing Headlamp Assembly
Removing Headlamp Bulb
334 MAINTAINING YOUR VEHICLE

Unlocking ConnectorRemoving Headlamp from Assembly
MAINTAINING YOUR VEHICLE 335
7

6. Reverse procedure to install new Headlamp bulb into
the headlamp assembly.
NOTE:These are Halogen bulbs. Take care not to touch
the bulb with your fingers. Body oils from your fingers
could cause excessive heat buildup which reduces bulb
life.
Removing Headlamp BulbDisconnecting Headlamp Bulb Connector
336 MAINTAINING YOUR VEHICLE
