2007 DODGE CALIBER Owners Manual

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instrument Panel Features...............141

Instrument Cluster—Base................142

Instrument Cluster—Premium............143

Instrument Cluster Descriptions...........144

Electronic Vehicle Information Center
(EVIC) – If Equipped
...................152
▫EVIC Functions.......................154
▫Compass/Temperature/Audio............154
▫Average Fuel Economy.................155
▫Distance To Empty (DTE)...............155
▫Elapsed Time........................155
▫Tire Pressure Monitor (TPM).............155▫Personal Settings
(Customer Programmable Features)........155

Setting The Compass Variance And
Compass Calibration
...................158
▫Compass Variance.....................158
▫Compass Calibration...................160

Radio General Information...............160
▫Radio Broadcast Signals.................160
▫Two Types Of Signals..................161
▫Electrical Disturbances..................161
▫AM Reception.......................161
▫FM Reception........................161
4

Electronic Digital Clock.................161
▫Clock Setting Procedure.................162

Sales Code REF — AM/FM/CD
(Single Disc) Radio With Optional Satellite
Radio And Hands Free Phone Capability
....162
▫Operating Instructions - Radio Mode.......163
▫Operation Instructions - CD Mode.........166
▫Operation Instructions - Auxiliary Mode.....167
▫Operating Instructions - Hands Free Phone —
If Equipped.........................168
▫Operating Instructions - Satellite Radio —
If Equipped.........................168

Sales Code RAQ – AM/FM/CD (6-Disc)
Radio With Optional Satellite Radio, Hands
Free Phone, And Vehicle
Entertainment Systems (VES) Capabilities
....169
▫Operating Instructions - Radio Mode.......169▫Operation Instructions -
(CD Mode For CD Audio Play)...........173
▫Load/Eject Button
(CD Mode For CD Audio Play)...........174
▫NotesOnPlayingMP3Files .............176
▫Operation Instructions -
(CD Mode For MP3 Audio Play)..........178
▫Load/Eject Button
(CD Mode For MP3 Play)...............178

Sales Code RAK – AM/FM/Cassette/CD
(6-Disc) Radio With Optional Satellite Radio,
Hands Free Phone, Video, MP3, And
WMA Capabilities
.....................180
▫Operating Instructions - Radio Mode.......180
▫Operating Instructions — Tape Player.......184
▫Seek Button.........................184
▫Fast Forward (FF).....................184
▫Rewind (RW)........................184
138 UNDERSTANDING YOUR INSTRUMENT PANEL

▫TapeEject...........................184
▫Scan Button.........................185
▫Changing Tape Direction................185
▫Metal Tape Selection...................185
▫Pinch Roller Release...................185
▫Noise Reduction......................185
▫Operation Instructions -
(CD Mode For CD Audio Play)...........185
▫Load/Eject Button
(CD Mode For CD Audio Play)...........186
▫Notes On Playing MP3 Files.............188
▫Operation Instructions - (CD Mode For MP3
And WMA Audio Play).................190
▫Load/Eject Button (CD Mode For MP3
AndWMAPlay) ......................190

Sales Code REC — AM/FM/CD
(6–Disc) Radio With Navigation System
.....192▫Operating Instructions — Satellite Radio
(If Equipped)........................192
▫Clock Setting Procedure.................192

Satellite Radio — If Equipped.............193
▫System Activation.....................193
▫Electronic Serial Number/Sirius
Identification Number (ESN/SID)..........193
▫Selecting Satellite Mode In REF,
And RAQ, Radios.....................194
▫Selecting a Channel....................194
▫Storing And Selecting Pre-Set Channels......195
▫Using The PTY (Program Type) Button
(If Equipped)........................195
▫PTY ButtonScan.....................195
▫PTY ButtonSeek.....................195
▫Satellite Antenna......................195
▫Reception Quality.....................195
UNDERSTANDING YOUR INSTRUMENT PANEL 139
4

Remote Sound System Controls —
If Equipped
..........................196
▫Radio Operation......................196
▫CD Player..........................197

CD/DVD Disc Maintenance..............197

Radio Operation And Cellular Phones.......198

Climate Controls......................198
▫Climate Controls......................198
▫Air Filtration System – If Equipped........202
▫Operating Tips.......................203
140 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT PANEL FEATURES
UNDERSTANDING YOUR INSTRUMENT PANEL 141
4

INSTRUMENT CLUSTER—BASE
142 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER—PREMIUM
UNDERSTANDING YOUR INSTRUMENT PANEL 143
4

INSTRUMENT CLUSTER DESCRIPTIONS
1. Fuel Gauge
When the ignition switch is in the ON position,
the pointer will show the level of fuel remaining
in the fuel tank.
2. Fuel Door Reminder
This is a reminder that the Fuel Filler Door is
located on the left side of the vehicle.
3. Temperature Gauge
The temperature gauge shows engine coolant
temperature. Any reading below the red area of
the gauge shows that the engine cooling system
is operating properly. The gauge pointer may show a
higher than normal temperature when driving in hot
weather, up mountain grades, in heavy stop and go
traffic, or when towing a trailer.
If the pointer rises to theH(red) mark, the instrument
cluster will sound a chime. Pull over and stop the vehicle.
Idle the vehicle with the air conditioner turned off untilthe pointer drops back into the normal range. If the
pointer remains on theH(red) mark, turn the engine off
immediately and call for service.
There are steps that you can take to slow down an
impending overheat condition. If your air conditioning is
on, turn it off. The air conditioning system adds heat to
the engine cooling system and turning off the A/C
removes this heat. You can also turn the Temperature
control to maximum heat, the Mode control to Floor and
the Fan control to High. This allows the heater core to act
as a supplement to the radiator and aids in removing heat
from the engine cooling system.
4. Speedometer
Indicates vehicle speed.
5. Tachometer
The white area of the scale shows the permissible engine
revolutions-per-minute (rpm x 1000) for each gear range.
Before reaching the red area, ease up on the accelerator to
prevent engine damage.
