2007 DODGE CALIBER odometer

off for 60 seconds when a system fault is detected. The
flash cycle will repeat every ten minutes or until the fault
condition is removed and reset.
If this indicator comes on, the entire PRNDL/odometer
display will brighten to FULL DAYTIME INTENSITY
and will not be dimmable.
CAUTION!
The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures and
warning have been established for the tire size
equipped on your vehicle. Undesirable system op-
eration or sensor damage may result when using
replacement equipment that is not of the same size,
type, and/or style. Aftermarket wheels can cause
sensor damage. Do not use tire sealant from a can, or
balance beads if your vehicle is equipped with a
TPMS, as damage to the sensors may result.
15. Odometer/Trip Odometer
A vacuum fluorescent display indicates the total distance
the vehicle has been driven. Also, the cluster will display,
replacing the odometer/trip odometer, vehicle warning
messages such as: door/gate ajar and loose gas cap.
Loose gas cap will be displayed from the Odometer/Trip
Odometer on all models.
NOTE:If vehicle is equipped with the optional Elec-
tronic Vehicle Information Center (EVIC) in the instru-
ment cluster, all warnings including “door”, and “gATE”
will only be displayed in the EVIC display. For additional
information, refer to “Electronic Vehicle Information Cen-
ter — If Equipped” in Section 3.
U.S. federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. There-
fore, if the odometer reading is changed during repair or
replacement, be sure to keep a record of the reading
before and after the service so that the correct mileage can
be determined.
UNDERSTANDING YOUR INSTRUMENT PANEL 147
4

16. Malfunction Indicator Light
This light is part of an onboard diagnostic
system called OBD that monitors emissions,
engine, and automatic transmission control
systems. The light will illuminate when the key is in
the ON/RUN position before engine start. If the bulb
does not come on when turning the key from OFF to
ON/RUN, have the condition checked promptly.
Certain conditions such as a loose or missing gas cap,
poor fuel quality, etc. may illuminate the light after
engine start. The vehicle should be serviced if the light
stays on through several of your typical driving cycles. In
most situations the vehicle will drive normally and will
not require towing.
If the Malfunction Indicator Light flashes when the
engine is running, serious conditions may exist that
could lead to immediate loss of power or severe catalytic
converter damage. The vehicle should be serviced as
soon as possible if this occurs.
If this indicator comes on, the entire PRNDL/odometer
display will brighten to FULL DAYTIME INTENSITY
and will not be dimmable.
17. Cruise Indicator — If Equipped
This indicator shows that the Speed Control
System is ON.
18. Odometer/Trip Odometer Reset Knob
Press this button to change the display from odometer to
either of the two trip odometer settings. Trip A or Trip B
will appear when in the trip odometer mode. Push in and
hold the button for two seconds to reset the trip odometer
to 0 miles or kilometers. The odometer must be in trip
mode to reset.
19. Electronic Throttle Control Indicator Light
This light informs you of a problem with the
Electronic Throttle Control system. If a prob-
lem is detected, the light will come on while
the engine is running. If the light remains lit
with the engine running your vehicle will usually be
drivable and not need towing, however see your
dealer for service as soon as possible.
If the light is flashing when the engine is running you
may experience power loss, an elevated/rough idle, and
increased brake pedal effort, and your vehicle may
require towing. Immediate service is required.
148 UNDERSTANDING YOUR INSTRUMENT PANEL

Confirmation of Voice Commands — If Equipped
When ON is selected all voice commands from the
U-Connect system are confirmed. Press and hold the
EVIC button when in this display until “ON” or “OFF”
appears to make your selection.
Display English or Metric
The EVIC, odometer, and navigation system units can be
changed between English and Metric.
Press and hold the EVIC button when in this display until
“US” or “METRIC” appears to make your selection.
Setting The Compass Variance And Compass
Calibration
Compass Variance
Compass Variance is the difference between magnetic
North and Geographic North. In some areas of the
country, the difference between magnetic and geographic
North is great enough to cause the compass to give false
readings. In order to ensure compass accuracy, the com-
pass variance should be set to the zone number on the
compass variance map that corresponds to the current
location of the vehicle.
NOTE:Magnetic materials should be kept away from
the Instrument Panel. This is where the compass sensor is
located.
158 UNDERSTANDING YOUR INSTRUMENT PANEL

WARNING!
•Do not use a tire, wheel size or rating other than
that specified for your vehicle. Some combina-
tions of unapproved tires and wheels may change
suspension dimensions and performance charac-
teristics, resulting in changes to steering, han-
dling, and braking of your vehicle. This can cause
unpredictable handling and stress to steering and
suspension components. You could lose control
and have an accident resulting in serious injury or
death. Use only the tire and wheel sizes with load
ratings approved for your vehicle.
•Never use a tire with a smaller load index or
capacity, other than what was originally equipped
on your vehicle. Using a tire with a smaller load
index could result in tire overloading and failure.
You could lose control and have an accident.
•Failure to equip your vehicle with tires having
adequate speed capability can result in sudden
tire failure and loss of vehicle control.
CAUTION!
Replacing original tires with tires of a different size
may result in false speedometer and odometer read-
ings.
Alignment And Balance
Poor suspension alignment may result in:
•Fast tire wear.
•Uneven tire wear, such as feathering and one-sided
wear.
•Vehicle pull to right or left.
Tires may also cause the vehicle to pull to the left or right.
Alignment will not correct this condition. See your dealer
for proper diagnosis.
Improper alignment will not cause vehicle vibration.
Vibration may be a result of tire and wheel out-of-
balance. Proper balancing will reduce vibration and
avoid tire cupping and spotty wear.
240 STARTING AND OPERATING

WARNING!
•Never have any smoking materials lit in or near
the vehicle when the gas cap is removed or the
tank filled.
•Never add fuel when the engine is running. This
is in violation of most state and federal fire
regulations and will cause the malfunction indi-
cator light to turn on.
NOTE:Tighten the gas cap about 1/4 turn until you
hear one click. This is an indication that cap is properly
tightened.
If the gas cap is not tighten properly, the Malfunction
Indicator Light will come on. Be sure the gas cap is
tightened every time the vehicle is refueled.
WARNING!
A fire may result if gasoline is pumped into a
portable container that is inside of a vehicle. You
could be burned. Always place gas containers on the
ground while filling.
Loose Fuel Filler Cap Message
If the vehicle diagnostic system determines that the fuel
filler cap is loose or improperly installed, a “GASCAP”
message will be displayed in the Odometer/Trip Odom-
eter in the instrument cluster. Refer to “Instrument
Cluster Description” in Section 4 of this manual. Tighten
the fuel filler cap properly and press the odometer/trip
odometer reset button to turn the message off. If the
problem continues, the message will appear the next time
the vehicle is started. Refer to “Onboard Diagnostic
System — OBDII” in Section 7 of this manual for more
information.
STARTING AND OPERATING 253
5

ONBOARD DIAGNOSTIC SYSTEM — OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transaxle control systems. When these systems are oper-
ating properly, your vehicle will provide excellent per-
formance and fuel economy, as well as engine emissions
well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light.” It will
also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your dealer for service as soon as
possible.CAUTION!
•Prolonged driving with the “Malfunction Indica-
tor Light” on could cause further damage to the
emission control system. It could also affect fuel
economy and driveability. The vehicle must be
serviced before any emissions tests can be per-
formed.
•If the “Malfunction Indicator Light” is flashing
while the engine is running, severe catalytic con-
verter damage and power loss will soon occur.
Immediate service is required.
Loose Fuel Filler Cap Message
After fuel is added, the vehicle diagnostic system can
determine if the fuel filler cap is loose or improperly
installed. A GASCAP message will be displayed in the
instrument cluster. Tighten the gas cap until aclicking
sound is heard. This is an indication that the gas cap is
properly tightened. Press the trip odometer reset button
to turn off the message. If the problem persists, the
message will appear the next time the vehicle is started.
280 MAINTAINING YOUR VEHICLE

Gasoline (Fuel).....................248,316
Gasoline, Reformulated.................. 249
Gauges
Coolant Temperature.................. 144
Fuel............................... 144
Odometer........................... 147
Tachometer.......................... 144
Gearshift............................. 212
General Information................. 13,93,246
General Maintenance.................... 283
Glass Cleaning......................... 306
Glove Compartment..................... 134
GrossAxleWeightRating ................. 255
GrossVehicleWeightRating ............254,255
Hands-Free Phone (UConnect™)............ 72
Hazard Warning Flasher.................. 266
Head Restraints......................... 96
Headlights............................ 311
Cleaning............................ 306
High Beam.......................105,150
High Beam/Low Beam Select Switch...... 105
Passing............................. 106Replacing........................... 311
Switch ............................. 103
Heated Seats........................... 97
Hitches
TrailerTowing ....................... 256
HomeLink
(Garage Door Opener) Transmitter.......... 112
Hood Release.......................... 101
Hoses............................... 298
Ignition................................ 9
Key ................................. 9
Ignition Key Removal..................... 9
Immobilizer (Sentry Key)................ 11,25
InfantRestraint ......................... 54
Information Center, Vehicle............... 152
Inside Rearview Mirror................... 69
Instrument Cluster...................142,144
Instrument Panel and Controls............. 141
Instrument Panel Cover.................. 307
Instrument Panel Lens Cleaning............ 307
Integrated Power Module (Fuses)........... 307
Interior Appearance Care................. 305
INDEX 351
10

Navigation Radio....................... 192
Navigation System...................... 192
New Vehicle Break-In Period............... 61
Occupant Classification System (OCS)........ 44
Occupant Restraints (Sedan)................ 28
Octane Rating, Gasoline (Fuel)............. 248
Odometer............................ 147
Trip ............................147,148
Oil, Engine.........................283,316
Capacity............................ 316
Change Interval...................... 284
Checking........................... 283
Disposal............................ 286
Filter.............................. 286
Identification Logo.................... 285
Materials Added to.................... 286
Recommendation..................285,316
Synthetic........................... 285
Viscosity............................ 285
Oil Pressure Light...................... 145
Onboard Diagnostic System............280,281
Opener, Garage Door (HomeLink) ......... 112Operator Manual (Owner’s Manual).......... 4
OutsideAirIntake ...................... 204
Overdrive............................ 213
Overheating, Engine..................... 266
Owner’s Manual (Operator Manual)....... 4,341
PaintCare ............................ 303
Panic Alarm........................... 21
Parking Brake......................... 218
Passing Light.......................... 106
Performance........................... 213
Personal Settings....................... 155
Pets .................................. 60
Phone, Cellular......................... 72
Phone, Hands-Free (UConnect™)............ 72
Placard, Tire and Loading Information....... 229
Power
Distribution Center (Fuses).............. 307
Door Locks.......................... 15
Mirrors ............................. 70
Outlet (Auxiliary Electrical Outlet)........ 124
Steering .........................223,291
Steering, Checking.................... 291
354 INDEX
