2007 DODGE CALIBER Owners Manual

Air Conditioning
Use this button to engage the
Air Conditioning. A lamp will
illuminate when the Air Con-
ditioning System is engaged.
NOTE:The air conditioning compressor will not en-
gage until the engine has been running for about 10
seconds.
MAX A/C
For maximum cooling use the
A/C and recirculate buttons
at the same time.
UNDERSTANDING YOUR INSTRUMENT PANEL 201
4

Circulation Control
Use this button to choose be-
tween outside air intake or
recirculation of the air inside
the vehicle. A lamp will illu-
minate when you are in recir-
culate mode. Only use the re-
circulate mode to temporarily
block out any outside odors,
smoke, or dust and to cool the
interior rapidly upon initial
start up in very hot or humid weather.
NOTE:Continuous use of the recirculate mode may
make the inside air stuffy and window fogging may
occur. Extended use of this mode is not recommended.In cold or damp weather, the use of the Recirculate
position will cause windows to fog on the inside because
of moisture build up inside the vehicle. For maximum
defogging, select the Outside Air position.
NOTE:Recirculation Mode will not operate in floor,
mix or defrost modes.
Air Filtration System – If Equipped
An air filter is included in the optional Security Group.
Filter media includes a particle filtration layer and a
charcoal layer. The filter will reduce, but not eliminate,
diesel and agricultural smells. The filter acts only on air
coming from outside the vehicle; it does not filter air
inside the passenger compartment. The filter ’s normal
service life is 12,000 miles (20,000 km) or one year. The air
filter change schedule coincides with that for engine oil
and filter. As with oil changes, the interval is shorter for
heavy duty service or dusty conditions. See your autho-
rized dealer for service.
202 UNDERSTANDING YOUR INSTRUMENT PANEL

Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 203
4

Window Fogging
Vehicle side windows tend to fog on the inside in mild
rainy or humid weather. To clear the windows, set mode
to the mix or defrost position. Direct the panel outlets
toward the side windows. Do not use recirculate without
A/C for long periods as fogging may occur.
Interior fogging on the windshield can be quickly re-
moved by using the defrost position.
If the fogging problem persists, clean the inside window
surfaces. The cause of undue fogging may be dirt collect-
ing on the inside surface of the glass
NOTE:In cold weather, the use of the recircu-
late position will cause windows to fog on the
inside because of moisture build up inside the
vehicle. For maximum defogging, press the
recirculation button until recirculate is off.
Summer Operation
Air conditioned vehicles must be protected with a high-
quality antifreeze coolant to provide proper corrosionprotection and to raise the boiling point of the coolant for
protection against overheating. A 50% concentration is
recommended.
Outside Air Intake
When operating the system during the winter months,
make sure the air intake, directly in front of the wind-
shield, is free of ice, slush, snow or other obstructions
such as leaves. Leaves collected in the air-intake plenum
may reduce air flow and plug the plenum water drains.
The blower air will heat faster in cold weather if you use
only a low blower speed for the first few minutes of
vehicle operation.
Side Window Demisters
A side window demister outlet is at each end of the
instrument panel. These nonadjustable outlets direct air
toward the side windows when the system is in either the
FLOOR, MIX, or DEFROST mode. The air is directed at
the area of the windows through which you view the
outside mirrors.
204 UNDERSTANDING YOUR INSTRUMENT PANEL

STARTING AND OPERATING
CONTENTS

Starting Procedures....................208
▫Automatic Transaxle...................208
▫Manual Transaxle.....................208
▫Normal Starting......................208
▫Extremely Cold Weather
(Below
20°F Or
29°C)................209
▫If Engine Fails To Start.................209
▫After Starting........................210

Automatic Transaxle — If Equipped........210
▫Brake/Transmission Interlock System.......211
▫Automatic Transaxle Ignition
Interlock System......................212▫Gear Ranges For Continuously Variable
Automatic Transaxle (Cvt)...............212
▫Fuel Economy/Performance
Operation Feature.....................213

AutoStick — If Equipped................214
▫AutoStick Operation...................214
▫AutoStick General Information............215

Manual Transaxle Operation..............215
▫Recommended Shift Speeds..............216
▫Downshifting........................217

All Wheel Drive System — If Equipped.....217

Parking Brake.........................218
5

Brake System.........................219
▫Anti-Lock Brake System (ABS) —
If Equipped.........................220

Power Steering........................223

Driving On Slippery Surfaces.............224
▫Acceleration.........................224
▫Traction............................224

Tire Safety Information..................225
▫Tire Markings........................225
▫Tire Identification Number (TIN)..........228
▫Tire Loading And Tire Pressure...........229

Tires — General Information..............233
▫Tire Pressure.........................233
▫Tire Inflation Pressures.................234
▫Radial-Ply Tires......................236
▫Compact Spare Tire — If Equipped.........236▫Limited Use Spare — If Equipped.........237
▫Tire Spinning........................237
▫Tread Wear Indicators..................238
▫LifeOfTire .........................239
▫Replacement Tires.....................239
▫Alignment And Balance.................240

Tire Pressure Monitoring System (TPMS) —
If Equipped
..........................241
▫Base Tire Pressure Monitoring System
(TPMS) Operation – If Equipped..........241
▫Premium System – If Equipped...........242
▫General Information...................246

Tire Chains...........................247

Snow Tires...........................247

Tire Rotation Recommendations...........247

Fuel Requirements.....................248
206 STARTING AND OPERATING

▫Gasoline Engines.....................248
▫Reformulated Gasoline.................249
▫Gasoline/Oxygenate Blends..............249
▫MMT In Gasoline.....................249
▫Materials Added To Fuel................250
▫Fuel System Cautions..................250
▫Carbon Monoxide Warnings..............251

Adding Fuel..........................252
▫Fuel Filler Cap (Gas Cap)...............252
▫Loose Fuel Filler Cap Message............253

Vehicle Loading.......................254
▫Gross Vehicle Weight Rating (GVWR).......254

Trailer Towing........................255
▫Common Towing Definitions.............255
▫Trailer Hitch Classification...............256
▫Trailer Towing Weights
(Maximum Trailer Weight Ratings).........257
▫Trailer And Tongue Weight..............258
▫Towing Requirements..................259
▫TowingTips .........................263

Recreational Towing
(Behind Motorhome, Etc.)
................264
▫Towing This Vehicle Behind
Another Vehicle (Flat Towing With All Four
Wheels On The Ground)................264
STARTING AND OPERATING 207
5

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust both
inside and outside mirrors, and fasten your seat belts.
WARNING!
Never leave children alone in a vehicle. Leaving
children in a vehicle unattended is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Don’t leave the keys in
the ignition. A child could operate power windows,
other controls, or move the vehicle.
WARNING!
Be sure to turn off the engine if you want to rest or
sleep in your car. Accidents can be caused by inad-
vertently moving the gear selection lever or by
pressing the accelerator pedal. This may cause exces-
sive heat in the exhaust system, resulting in over-
heating and vehicle fire which may cause serious or
fatal injuries.
Automatic Transaxle
The gear selector must be in the PARK or NEUTRAL
position before you can start the engine. Apply the brakes
before shifting to any driving gear.
NOTE:You must press the brake pedal before shifting
out of Park.
Manual Transaxle
Before starting the engine fully apply the parking brake,
press the clutch pedal to the floor and place the gear
selector in NEUTRAL.
NOTE:The engine will not start unless the clutch pedal
is pressed to the floor.
NOTE:If key won’t turn and steering wheel is locked,
rotate the wheel in either direction to relieve pressure on
the locking mechanism and then turn the key.
Normal Starting
Normal Starting of either a cold or a warm engine does
not require pumping or depressing the accelerator pedal.
Simply turn the ignition switch to the “START’” position
and release when the engine starts. If the engine fails to
208 STARTING AND OPERATING
