2007 CHEVROLET OPTRA 5 Owners Manual

Door Ajar Reminder
If one of the doors on is
not closed properly
while the ignition is on,
the door ajar light
on the instrument panel
cluster comes on
and stays on until the
doors are closed.
SeeDoor Ajar Light on page 177for additional
information.
Rear Door Security Locks
Your vehicle has rear
door security locks
on each rear door that
prevent passengers
from opening the
rear doors from
the inside.
97

Using the Rear Door Security Lock
1. Move the lever up to lock.
2. Close the door.
3. Do the same thing to the other rear door lock.
Notice:Pulling the inside door handle while
the rear door security locks are engaged could
damage your vehicle. Do not pull the inside
door handle while the rear door security locks
are engaged.
The rear doors on your vehicle cannot be opened
from the inside while this feature is in use.
Opening a Rear Door When the
Security Lock is On
1. Unlock the door from the inside.
2. Open the door from the outside.
If you do not cancel the security lock, adults or
older children who ride in the rear will not be able
to open the rear door from the inside. You
should let adults and older children know how to
cancel the locks.
Canceling the Rear Door Security Lock
1. Unlock the door from the inside and open
the door from the outside.
2. Move the lever down to unlock.
3. Do the same for the other rear door.
The rear door locks can now be locked and
unlocked normally.
Lockout Protection
This feature helps prevent locking the key in the
car. The driver’s door can only be locked with
the door closed. From the outside of the vehicle,
close the driver’s door and lock it using the key
or the Remote Keyless Entry transmitter.
This feature cannot guarantee that you will never
be locked out of your vehicle. Always remember
to take your key with you.
98

Liftgate
{CAUTION:
It can be dangerous to drive with the
liftgate open because carbon monoxide
(CO) gas can come into your vehicle.
You cannot see or smell CO. It can cause
unconsciousness and even death. If you
must drive with the liftgate open or if
electrical wiring or other cable connections
must pass through the seal between the
body and the liftgate:
Make sure all other windows are shut.
Turn the fan on your heating or cooling
system to its highest speed and select
the control setting that will force
outside air into your vehicle. See
Climate Control System on page 155.
If you have air outlets on or under the
instrument panel, open them all the
way. SeeEngine Exhaust on page 121.The liftgate on a hatchback or wagon can be
locked and unlocked from outside of the vehicle
by inserting the key into the lock and turning it.
The Remote Keyless Entry transmitter, if the
vehicle has one, can also be used. Then pull up
the handle above the license plate to open
the liftgate.
When closing the liftgate, close it from the center
to make sure it fully latches.
99

Windows
{CAUTION:
Leaving children, helpless adults, or pets
in a vehicle with the windows closed is
dangerous. They can be overcome by the
extreme heat and suffer permanent
injuries or even death from heat stroke.
Never leave a child, a helpless adult, or a
pet alone in a vehicle, especially with the
windows closed in warm or hot weather.
Manual Windows
Use the window crank to open and close each
window.
The rear windows do not open fully.
100

Power Windows
{CAUTION:
Leaving children, helpless adults, or pets
in a vehicle with the windows closed is
dangerous. They can be overcome from
extreme heat in warm or hot weather and
suffer permanent injuries or even death
from heat stroke.
Leaving children in a vehicle with the
ignition key is dangerous for many
reasons, children or others could be badly
injured or even killed. They could operate
the power windows or other controls or
even make the vehicle move. The windows
will function with the keys in the ignition
and they could be seriously injured or
killed if caught in the path of a closing
window. Do not leave keys in a vehicle with
children.
CAUTION: (Continued)
CAUTION: (Continued)
When there are children in the rear seat
use the window lockout button to prevent
unintentional operation of the windows.
If your vehicle has this
feature, the power
window switches are
located on the driver’s
door armrest.
In addition, each passenger door has a switch for
its own window. The ignition must be turned to
ON to use the power windows. To lower a window,
press the switch. To raise a window, lift up on
the switch.
Uplevel shown, Base
similar
101

Express-Down Window
The driver’s window may also have an
express-down feature. This switch is labeled
AUTO. Press the switch then release it and the
driver’s window goes all the way down.
To stop the window while it is lowering, press the
switch again. To raise the window, pull up and
hold the switch.
Window Lockout
The driver’s power
window controls may
also include a lockout
button.Press the lockout button to stop the front and rear
passengers from using their window switches.
The driver can still operate all the windows with the
lock on. Press the lockout button again to return
to normal window operation.
Sun Visors
To block out glare you can pull the visors down.
They can also be removed from the center
mount and moved to the side.
Visor Vanity Mirror
Your vehicle has vanity mirrors located on the
back of the sun visors. Pull the sun visor down and
lift the cover to expose the vanity mirror.
102

Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing we
put on it can make it impossible to steal.
Theft-Deterrent System
Your vehicle may have a theft-deterrent system.
The theft-deterrent system will not arm when
you lock the doors using the key or the manual
door lock. It activates only when you use the
optional remote keyless entry transmitter.
Arming the System
To arm the system, do the following:
1. Turn the ignition to LOCK and remove the key
from the ignition.
If the key is inserted in the ignition, the
transmitter will not operate the theft-deterrent
system.2. Close the doors, the windows, the hood, and
the trunk or liftgate.
Make sure the windows are closed, as the
system can be activated even if the windows
are open.
3. Lock the door using the remote keyless entry
transmitter. The transmitter must be used to
activate the theft-deterrent system.
•The LED light on the transmitter will
flash once.
•All of the doors will lock.
•The hazard warning lamps will flash once
and the horn will chirp.
•The theft-deterrent mode will activate.
•The security light will flash once every
second to indicate that the theft-deterrent
system is armed. The security light is located
on the base of the driver’s door lock.
103

To avoid activating the alarm by accident, use
one of the following methods:
•Unlock the driver’s or passenger’s door using
the key.
•Press the unlock button on the remote keyless
entry transmitter.
Unlocking a door any other way will activate the
alarm when a door, the trunk or liftgate is opened.
If you do not want to arm the theft-deterrent
system, lock the vehicle using the key or the
manual door locks.
Disarming the System
To disarm the system, use one of the following
methods:
•Unlock the driver’s or passenger’s door using
the key.
•Press the unlock button on the transmitter.
- The LED light on the transmitter will
flash once.
- All of the doors will unlock.
- The hazard warning lamps will flash
twice.
- The theft-deterrent mode will deactivate.
If the door is not opened or if the engine is not
started within 30 seconds after disarming the
system with the transmitter, all of the doors will
automatically lock and the theft-deterrent mode
will reactivate.
104
