2007 CHEVROLET IMPALA tow

Seats and Restraint Systems
........................ 7
Front Seats
.............................................. 9
Rear Seats
............................................. 15
Safety Belts
............................................ 18
Child Restraints
...................................... 41
Airbag System
........................................ 68
Restraint System Check
......................... 84
Features and Controls
................................. 87
Keys
....................................................... 89
Doors and Locks
.................................... 98
Windows
............................................... 104
Theft-Deterrent Systems
....................... 107
Starting and Operating Your Vehicle
..... 111
Mirrors
.................................................. 126
OnStar
®System
................................... 128
Universal Home Remote System
.......... 132
Storage Areas
...................................... 144
Sunroof
................................................ 145Instrument Panel
........................................ 147
Instrument Panel Overview
................... 150
Climate Controls
................................... 168
Warning Lights, Gages,
and Indicators
................................... 174
Driver Information Center (DIC)
............ 190
Audio System(s)
................................... 215
Driving Your Vehicle
.................................. 247
Your Driving, the Road, and
Your Vehicle
..................................... 248
Towing
................................................. 282
Service and Appearance Care
................... 293
Service
................................................. 296
Fuel
...................................................... 298
Checking Things Under the Hood
......... 304
Headlamp Aiming
................................. 343
Bulb Replacement
................................ 343
Windshield Wiper Blade Replacement
... 349
2007 Chevrolet Impala Owner ManualM
1

Rear Seats
Split Folding Rear Seat
Flip and Fold Feature
If your vehicle has this feature, you can ip the
bottom seat cushion(s) forward and fold the
seatback(s) down for an extended at cargo area.
To use this feature, do the following:
Notice:Folding a rear seat with the safety
belts still fastened may cause damage to the
seat or the safety belts. Always unbuckle
the safety belts and return them to their normal
stowed position before folding a rear seat.
1. Disconnect the rear
center safety belt
latch from the
mini buckle, if your
vehicle has this,
by using an object
such as a car key.Insert the key into the slot in the mini buckle
and press the release button.
2. Flip the bottom seat cushion forward by
pulling up on the tab located in the center
of the seat cushion where the seatback meets
the seat cushion. There is a tab on both
rear seats.
Make sure the front seats are not reclined.
If they are, the seat cushion will not ip
forward completely.
15

{CAUTION:
A safety belt that is improperly routed,
not properly attached, or twisted will not
provide the protection needed in a crash.
The person wearing the belt could be
seriously injured. After raising the rear
seatback, always check to be sure that
the safety belts are properly routed and
attached, and are not twisted.
2. Ensure that the safety belts are properly
stowed over the seatback in all three positions.
3. Reconnect the
rear center safety
belt latch plate
to the mini buckle,
if your vehicle
has this.Make sure the safety belt label is facing the
same direction as the release button of
the mini buckle. Make sure the belt is not
twisted. Push and pull on the latch plate to
be sure it is secure.
4. Flip the bottom seat cushion back into place.
Push rmly on the seat cushion to make sure
it is secure.
When the seat is not in use, the seatback should
be placed in upright, locked position, and the
seat cushion should be in the down position.
Under Seat Storage
Your vehicle has under seat storage.
To get to the storage area, lift up on the tab
located in the center of the bottom seat cushion
where the seat cushion meets the seatback.
SeeRear Storage Area on page 144for more
information.
17

{CAUTION:
Never do this.
Here two children are wearing the same
belt. The belt cannot properly spread the
impact forces. In a crash, the two children
can be crushed together and seriously
injured. A belt must be used by only
one person at a time.
Q:What if a child is wearing a lap-shoulder
belt, but the child is so small that the
shoulder belt is very close to the child’s
face or neck?
A:If the child is sitting in a seat next to a window,
move the child toward the center of the vehicle.
Also seeRear Safety Belt Comfort Guides on
page 37. If the child is sitting in the center rear
seat passenger position, move the child toward
the safety belt buckle. In either case, be sure
that the shoulder belt still is on the child’s
shoulder, so that in a crash the child’s upper
body would have the restraint that belts provide.
{CAUTION:
Never do this.
Here a child is sitting in a seat that has a
lap-shoulder belt, but the shoulder part is
behind the child. If the child wears the belt
in this way, in a crash the child might slide
under the belt. The belt’s force would then
be applied right on the child’s abdomen.
That could cause serious or fatal injuries.
42

{CAUTION:
The body structure of a young child is
quite unlike that of an adult or older child,
for whom the safety belts are designed. A
young child’s hip bones are still so small
that the vehicle’s regular safety belt may
not remain low on the hip bones, as it
should. Instead, it may settle up around
the child’s abdomen. In a crash, the belt
would apply force on a body area that is
unprotected by any bony structure. This
alone could cause serious or fatal injuries.
Young children always should be secured
in appropriate child restraints.
Child Restraint Systems
An infant car bed (A), a special bed made for use
in a motor vehicle, is an infant restraint system
designed to restrain or position a child on a
continuous at surface. Make sure that the infant’s
head rests toward the center of the vehicle.
47

{CAUTION:
Children can be seriously injured or
strangled if a shoulder belt is wrapped
around their neck and the safety belt
continues to tighten. Secure any unused
safety belts behind the child restraint so
children cannot reach them. Pull the
shoulder belt all the way out of the
retractor to set the lock, if your vehicle
has one, after the child restraint has
been installed. Be sure to follow the
instructions of the child restraint
manufacturer.
Notice:Contact between the child restraint or
the LATCH attachment parts and the vehicle’s
safety belt assembly may cause damage to
these parts. Make sure when securing unused
safety belts behind the child restraint that
there is no contact between the child restraint
or the LATCH attachment parts and the
vehicle’s safety belt assembly.Folding an empty rear seat with the safety
belts secured may cause damage to the safety
belt or the seat. When removing the child
restraint, always remember to return the safety
belts to their normal, stowed position before
folding the rear seat.
1. Attach and tighten the lower attachments to
the lower anchors. If the child restraint does
not have lower attachments or the desired
seating position does not have lower anchors,
secure the child restraint with the top tether
and the safety belts. Refer to your child
restraint manufacturer instructions and the
instructions in this manual.
1.1. Find the lower anchors for the desired
seating position.
1.2. Put the child restraint on the seat.
1.3. Attach and tighten the lower
attachments on the child restraint to
the lower anchors.
59

What Makes an Airbag Inate?
In an impact of sufficient severity, the airbag
sensing system detects that the vehicle is
in a crash. The sensing system triggers a
release of gas from the inator, which inates
the airbag. The inator, airbag, and related
hardware are all part of the airbag modules
inside the steering wheel and in the instrument
panel in front of the right front passenger.
For vehicles with roof-mounted side impact
airbags, there are also airbag modules in the
ceiling of the vehicle, near the side windows.
How Does an Airbag Restrain?
In moderate to severe frontal or near frontal
collisions, even belted occupants can contact
the steering wheel or the instrument panel.
In moderate to severe side collisions, even belted
occupants can contact the inside of the vehicle.
Airbags supplement the protection provided
by safety belts. Airbags distribute the force of the
impact more evenly over the occupant’s upper
body, stopping the occupant more gradually.
But the frontal airbags would not help you in
many types of collisions, including rollovers, rear
impacts, and many side impacts, primarily because
an occupant’s motion is not toward the airbag.
Side impact airbags would not help you in many
types of collisions, including many frontal or
near frontal collisions, rollovers, and rear impacts.
Airbags should never be regarded as anything
more than a supplement to safety belts, and
then only in moderate to severe frontal or
near-frontal collisions for the driver’s and
right front passenger’s frontal airbags, and
only in moderate to severe side collisions for
vehicles with side impact airbags.
75

SeeAdding Equipment to Your Airbag-Equipped
Vehicle on page 83for more information about
modications that can affect how the system
operates.
{CAUTION:
Stowing of articles under the passenger’s
seat or between the passenger’s seat
cushion and seatback may interfere with
the proper operation of the passenger
sensing system.
Servicing Your Airbag-Equipped
Vehicle
Airbags affect how your vehicle should be
serviced. There are parts of the airbag
system in several places around your vehicle.You do not want the system to inate while
someone is working on your vehicle. Your dealer/
retailer and the service manual have information
about servicing your vehicle and the airbag system.
To purchase a service manual, seeService
Publications Ordering Information on page 441.
{CAUTION:
For up to 10 seconds, after the ignition is
turned off and the battery is disconnected,
an airbag can still inate during improper
service. You can be injured if you are
close to an airbag when it inates. Avoid
yellow connectors. They are probably part
of the airbag system. Be sure to follow
proper service procedures, and make
sure the person performing work for you
is qualied to do so.
The airbag system does not need regular
maintenance.
82
