2007 Alfa Romeo GT Owner handbook (in English)

CAR MAINTENANCE
239
Do not keep aerosol cans
in the car. There is the risk
they might explode. Aerosol
cans must never be exposed to a
temperature above 50°C. The tem-
perature inside the car might go well
beyond that figure when exposed
to the sun’s rays.
INTERIOR PLASTIC PARTS
For routine cleaning of interior plastic parts
use a soft cloth moistened with water and
neutral soap. Remove grease or persisting
stains using appropriate solvent-free prod-
ucts designed to preserve appearance and
colour of plastic components.
IMPORTANTNever use spirit or petro-
leum to clean the glass of the instrument
panel or other plastic components.
STEERING WHEEL/GEAR LEVER
KNOB WITH GENUINE LEATHER
COVERING
These components shall only be cleaned
with water and neutral soap. Never use spir-
it or alcohol-based products.
Before using special products for cleaning
interiors, read carefully label instructions and
indications to make sure they are free from
spirit and/or alcohol-based substances. If
when cleaning the windscreen with special
glass products, some drops fall on the
leather covering of the steering wheel/gear
lever knob remove them immediately and
then clean with water and neutral soap.
IMPORTANTTake the utmost care
when engaging the steering lock to prevent
scratching the leather covering.
CLEANING LEATHER SEATS
– Remove dried on dirt with a lightly
moistened chamois leather or cloth with-
out pressing too hard.
– Remove liquid and grease stains with
a dry absorbent cloth without rubbing. Then
wipe with a soft cloth or chamois leather
with water and neutral soap. If the stain per-
sists, use specific products, carefully follow-
ing the instructions for use.
IMPORTANTNever use spirit or alco-
holbased products, even in small percentage.
Fabric upholstery of your
car is purpose-made to
withstand common wear
resulting from normal use of the
car. It is however absolutely nec-
essary to prevent hard and/or pro-
longed scratching/scraping caused
by clothing accessories like metal-
lic buckles, studs, “Velcro” fixings,
etc. that stressing locally the fabric
could break yarns and damage the
upholstery as a consequence.

TECHNICAL SPECIFICATIONS
240
IDENTIFICATION LABEL
This (fig. 2) is to be found on the front
crossmember of the engine compartment.
It contains the following information:
(A)Space for details of national ho-
mologation
(B)Space for punching the consecutive
chassis number
(C)Space available for maximum
weights authorised by various na-
tional regulations
(D)Space for version and any supple-
mentary indications to those specified(E)Space for smoke coefficient (JTD ver-
sions)
(F)Space for punching manufacturer’s
name.
BODYWORK LABEL
This is located in the engine bay, to one
side of the upper right shock absorber (fig.
3) and contains:
– Type of vehicle: ZAR 937.000
– Manufacturer’s serial number (chassis
number).
IDENTIFICATION DATA
You are advised to note the identification
codes. The identification datastamped and
given on the labels and their position are
the following (fig. 1):
1- Identification label
2- Body label
3- Bodywork paint identification label
4- Engine label.
T T
E E
C C
H H
N N
I I
C C
A A
L L
S S
P P
E E
C C
I I
F F
I I
C C
A A
T T
I I
O O
N N
S S
fig. 1
A0A0654b
fig. 2
A0A0246b
fig. 3
A0A0247b

TECHNICAL SPECIFICATIONS
241
BODYWORK PAINT
IDENTIFICATION LABEL
The label (fig. 4) is on the inner left edge
of the tailgate. It contains the following in-
formation:
A. Paint manufacturer.
B. Name of colour.
C. Colour code.
D.Indication on the type of product to be
used for touching-up.
ENGINE STAMP
Theengine marking is stamped on the
gearbox side of the crankcase, in corre-
spondence with the exhaust manifold.
ENGINE CODES - BODY VERSIONS
fig. 4
A0A0651b
Engine code Body versions
1.8 T SPARKAR32205 937CXR1A 26
2.0 JTS937A1000 937CXH1A 22
2.0 JTS
932A2000 937CXT1A 29
(for special markets)
2.0 JTS Selespeed937A1000 937CXH11 23
3.2V6936A000 937CXP1B 25
JTD16V937A5000 937CXN1B 24D

2.0 JTS
2.0 JTS
Selespeed
937A1000
Otto
4 in line
83 x 91
1970
11.5 : 1
121
165
6400
206
21
3250
NGK PFR6B
NGK BKR6EKPA
Unleaded
petrol
95 RON2.0 JTS (**)
932A2000
Otto
4 in line
83 x 91
1970
11.5 : 1
119
163
6400
201
20
3250
NGK PFR6B
NGK BKR6EKPA
Unleaded
petrol
95 RONJTD16V
937A5000
Diesel
4 in line
82 x 90.4
1910
17.5 : 1
110
150
4000
305
31
2000
Diesel fuel for motor
vehicles
(Specification EN 590) 3.2
V6
936A000
Otto
6 in 60° V
93 x 78
3179
10 : 1
176,5
240
6200
300
30.6
4800
NGK PFR6B
Unleaded
petrol
95 RON 1.8 T. SPARK
AR32205
Otto
4 in line
82.7
1747
11.5 : 1
103
140
6500
163
16.6
3900
NGK PFR6B+
NGK PMR7A
NGK BKR6EKPA+
NGK PMR7A
Unleaded
petrol
95 RON
TECHNICAL SPECIFICATIONS
242
ENGINE
(*) There are two different spark plugs for each cylinder, one per type (**) For versions/markets where applicable
To change plugs contact Alfa Romeo Authorized Services.
Code type
Cycle
Number and position of cylinders
Piston bore and stroke mm
Total displacement cm3
Compression ratio
Maximum horsepower (EEC):
kW
HP
at rpm
Maximum torque (EEC):
Nm
kgm
at rpm
Spark plugs (*)
Fuel

TECHNICAL SPECIFICATIONS
243
FUEL SUPPLY
Alterations or repairs to the fuel supply system carried out incorrectly and without taking account of
the technical features of the system, may cause operating faults with the risk of fire.
TRANSMISSION
Supply
2.0 JTS
Direct electronic injection
Gearbox
Clutch
Drive
2.0 JTS
Five forward gears plus
reverse with
synchronisers for forward
speeds
Dry single disk with
hydraulic control
Front
JTD16V
Six forward gears plus
reverse
all synchronised
Dry single disk with
hydraulic control
Front
JTD16V
Common Rail direct injection
with supercharging
3.2V6
Direct electronic injection
3.2V6
Six forward gears plus
reverse all synchronised
Dry single disk with
hydraulic control
Front
2.0 JTS Selespeed
Five forward gears and
reverse with electronic
control system
Dry single disk with
electrohydraulic control
Front
1.8 T. SPARK
Multipoint electronic injection
1.8 T. SPARK
Five forward gears plus
reverse with
synchronisers for
forward speeds
Dry single disk with
hydraulic control
Front

TECHNICAL SPECIFICATIONS
244
FRONT WHEEL DRIVE WITH
SELF-LOCKING DIFFERENTIAL
(upon request for versions/
markets where applicable)
Alfa Q2characteristics are such as to
guarantee top performance with whatever
road condition.Alfa Q2features front wheel drive with
front mechanical self-locking differential LSD
(Limited Slip Differential). Torque level be-
tween right and left wheel is modulated ac-
cording to the TORSEN Bfront differen-
tial grip. Mechanical modulation is continu-
ous and gradual thus optimizing drive under
whatever running condition and guarantee-
ing smooth drive, high stability and keeping
top comfort conditions.This type of differential enables to exploit
the tyre-road grip at the best even under
poor grip conditions: the driver is however
charged with observing common safety rules
since road safety is always the driver's re-
sponsibility.

TECHNICAL SPECIFICATIONS
245
Service brakes:– front
– rear
Parking brake
BRAKES
Front
Rear
Type
Turning radius
(between pavements) m
1.8 T. SPARK - 2.0 JTS - 3.2 V6 - JTD16V
rack and pinion with hydraulic power steering
11.5
SUSPENSION
STEERING SYSTEM
1.8 T. SPARK - 2.0 JTS - 3.2 V6- JTD16V
Disk
Disk
Controlled by hand lever, acting on the rear brakes
1.8 T. SPARK - 2.0 JTS - 3.2 V6 - JTD16V
quadrilateral system with stabiliser bar
Mc Pherson type

WHEELS
RIMS AND TYRES
Pressed steel or alloy rims.
Radial tubeless tyres.
The log book shows all the homologated
tyres.
IMPORTANTIn the event of any dis-
crepancies between this Handbook and the
vehicle Log Book, only the latter should be
considered.
While the specified dimensions remain the
same, for driving safety, the vehicle must be
fitted with tyres of the same brand and type
on all wheels.
IMPORTANTDo not use inner tubes
with Tubeless tyres.
COMPACT SPARE WHEEL
Pressed steel rim.
WHEEL GEOMETRY
Front wheel toe-in measured from rim to
rim: –1 ±0.6
The values refer to the vehicle travelling.
Example:
205/55 R 16 91 W
or
205/55 ZR 16
CORRECT TYRE READING
(fig. 5)
Below, please find the instructions need-
ed to understand the meaning of the code
stamped on the tyre.
The code may be in one of the ways giv-
en in the example.
205= Nominal width (S, distance in
mm between sides).
55= Percentage height/width (H/S)
ratio.
R= Radial tyre.
ZR= Radial tyre, with speed over 240
km/h.
16= Rim diameter in inches (Ø).
91= Load index (capacity), e.g. 91 =
615 kg. Not present in ZR tyres.
W,Z= Maximum speed index. In ZR
tyres the speed index Z is before
the R.
fig. 5
A0A0465b
