2007 Acura RL Owner's Manual

For security purposes, newer garage
door opening systems use a ‘‘rolling’’
or variable code. Information from
the remote control and the garage
door opener is needed bef ore
HomeLink can operate the garage
door opener.Find the ‘‘training’’ button on your
garage door opener unit. The
location will vary, depending on
the manufacturer. Make sure you have properly
completed the ‘‘Training
HomeLink’’ procedure. Press the HomeLink button again
f or about 1 second. It should
operate the garage door.
The ‘‘Training HomeLink’’
procedure trains HomeLink to the
proper garage door opener code.
The f ollowing procedure
synchronizes HomeLink to the
garage door opener so it sends and
receives the correct codes. Press the training button on the
garage door opener unit until the
indicator next to the button comes
on. The indicator may blink, or
comeonandstayon.Youthen
have approximately 30 seconds to
complete the f ollowing steps.Press and hold the button on
HomeLink f or 3 to 4 seconds.
Press and hold the HomeLink
button again f or 3 to 4 seconds.
This should turn of f the training
indicator on the garage door
opener unit. (Some systems may
require you to press the button up
to three times.)
6.
2. 4.
5.
1. 3.
T raining With a Rolling Code
System
HomeL ink Universal Transceiver
Features
295
TRAINING BUTTON
——
y
y
(yy

Youshoulderaseallthreecodes
before selling the vehicl e.
Toerasethecodesstoredinallthree
buttons,
press and hold the two
outside buttons until the red
indicator begins to flash, then
release the buttons.
If you want to retrain a programmed
button for a new device, you do not
have to erase all button memory.
You can replace the existing memory
code using this procedure: If
a standard transmitter was
programmed, the indicator will
stay on for about 25 seconds.
HomeLink
is a registered
trademark of Johnson Controls, Inc.
If
you have problems with training
the HomeLink Universal Transceiver,
or would like information on home
products that can be operated by
HomeLink, call (800) 355-3515. On
the Internet, go to
www.homelink.com. Once
the HomeLink indicator
begins to flash slowly, continue to
hold the HomeLink button, and
f ollow steps 3 thru 6 under
‘‘Training HomeLink’’ (see page ).
If a rolling code transmitter was
previously programmed, the
indicator will f lash rapidly f or 2
seconds, and then stay on f or
about 23 seconds.
Press and hold the HomeLink
button to be trained until the
HomeLink indicator begins to
flash slowly.
1. 2.
293
As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.Erasing Codes
Retraining a Button Customer Assistance
HomeL ink Universal Transceiver
296
——
y

y
(y
y

Most AcuraLink f unctions are
controlled by the interf ace dial. The
interface dial has two parts, a knob
and a selector.
The knob turns lef t and right. Use it
to make selections or adjustments to
a list or menu on the screen.The selector can be pushed lef t,
right, up, down, and in. Use the
selector to scroll through lists, to
select menus, and to highlight menu
items. When you make a selection,
push the center of the selector
(ENTER)togotothatselection.
AcuraLink enhances your ownership
experience by providing a direct
communication link between your
vehicleandtheAcuraServer.
Working through the XM radio
satellite, AcuraLink works in
conjunction with the navigation
system, HandsFreeLink (HFL), and
audio system in your vehicle. It
displays and receives several kinds
of messages, including:
Operating tips and inf ormation on
your vehicle’s f eatures.
Important recall and safety
inf ormation.
Maintenance inf ormation to keep
your vehicle in top condition.
Diagnostic inf ormation to provide
inf ormation about any problems
with your vehicle.
RL Technology Package and RL CMBS/PAX modelsInterf ace Dial
AcuraLink
Features
297
ENTER
SELECTOR
KNOB
——
y
y
(yy

If you have new messages, an
envelope icon appears in the top
right corner of the navigation screen.
To open a message:
Press ENTER on the interface
selector, then select New Message
from the navigation system map
menu. If there is more than one
message, stored in the system,
you will see a list of message titles. Unread
messages have a closed
en velope icon next to them. The icon
disappears when it has already been
read.
Only diagnostic info
messa ges overlay the screen while
driving. They indicate if your vehicle
has a problem that may need
immediate attention (see page ).
Afterpurchasingyourvehicle,
messages may not appear
immediately.
Your dealer has to register the
vehicle identif ication bef ore you can
receive messages. This can take
several days to process.
Scroll up or down, and select the
message you want to read by
pressing ENTER on the interf ace
selector.
To view previously read messages,
press the INFO button, select
MESSAGES, then select the
category you want to review. 304
Reading Messages
AcuraLink
298
NOTE:
——
y
y
(yy

Diagnostic inf o and recall/
campaign messages can only be
deleted by your dealer.
To delete a single message: Press the INFO button to bring up
the Information screen.
Scroll to the Messages option,
then select it by pressing ENTER
on the interf ace selector.
When you open a message, you can
read a summary of it, and then
choose one of several options. If an
option is not available f or a message,
that button will not be highlighted.
Scroll to the category with the
messages you want to delete, and
selectthecategorybypressing
ENTER on the interf ace selector. Scroll to the Delete Messages
option, and select it by pressing
ENTER on the interf ace selector. Usetheinterfaceknobtoscrollto
the AcuraLink/Messages button,
and select it by pressing ENTER
on the interf ace selector. Select MORE by pushing the
interface selector to the right. Press the SETUP button to view
the setup screen. The Delete All Messages
command does not apply to Recall or
Diagnostic Inf o messages. These
messages must be deleted by your
dealer. To delete all messages:
Usetheinterfaceknobtoscrollup
or down to the message title you
want to delete, and select it by
pressing ENTER on the interf ace
selector. Select the message category f or
the message you want to delete.
Scroll to Delete with the interface
knob, and select it by pressing
ENTER on the interf ace selector.
CONT INUED
Deleting Messages Message Options
AcuraLink
Features
299
NOTE:NOTE:
——
y

y
(yy

µ
µ
µ
µ µ
µ To
set your AcuraLink preferences
(thetypesofmessagesyouwantto
receive, if any), visit the Owner Link
website at
www.owners.acura.com,
and choose what you would like to
receive. If you do not have internet
access, call Acura Client Services at
(800) 382-2238; they can set your
message preferences for you.
Select
this button to
delete the current message.
Select this button to hear a
voice read the entire message. This
gives you more information than the
screen can display at one time. When
you select the Voice button, it
changes to a Stop Reading button.
Select the button again to stop the
voice.
Select this button to call a
phone number embedded in the
message. When you select , the
HandsFreeLink (HFL) dials the
number for you.
To make a call, your Bluetooth
compatible phone must be pai red to
your vehicle’s HandsFreeLink
system, have its power on, and be
inside the vehicle (see page ).
Select this button to f ind the nearest
Acura dealer using the navigation system.
Select
this button to call the Acura dealer
you purchased your vehicle f rom.
AcuraLink also directs you to this
dealer so you can schedule a
maintenance appointment or receive
inf ormation about a message. If your
assigned servicing dealer changes,
AcuraLink will be updated to call
that dealer.
Select this button to
get more inf ormation about the
current diagnostic message. To use
this option, your cell phone must be
paired to the HFL. In addition, the
paired phone must have a compatible
data service and be set up with the
AcuraLink system to make a data
connection. Access the
handsf reelink.com website to f ind
out which data services are currently
compatible with AcuraLink.
306 Message Pref erences
Delete
Voice
Call
Call
Find Nearest Acura Dealer Call Your A cura Dealer
More Inf o
AcuraLink
300
——
y

y
(yy

µµ µ
µ
To access the f ollowing f unctions,
press the SETUP button, push the
interf ace selector to the right to
select MORE, then rotate the
interf ace knob to select AcuraLink/
Messages.
Select this
button to delete all stored messages
within a category, except f or
diagnostic info and recall campaign
messages. These messages can only
be deleted by a certif ied technician
af ter the recall is done or the
problem is corrected, or through a
broadcast message f rom Acura.
Select ON if you want to be notif ied
of new messages (envelope icon
appears on the navigation screen).
Select OFF if you do not want to be
notif ied of new messages (envelope
icon does not appear on the
navigation screen). Messages can still be accessed using
the INFO menu. If you would like to
stop receiving messages, visit the
OwnerLink website at
to change your messaging
pref erences.
Select ON to have
the system automatically read each
message to you. Select OFF to
manually select the Voice button
when you want a message read to
you.
Select
this button to begin the process
required to connect to Acura. This is
used to access the most recent
diagnostic inf ormation when a
problem occurs.
www.owners.
acura.com
CONT INUED
AcuraL ink/Message Screen
Delete Messages
New Message Notif icationAuto Reading
Phone-Data Connection
AcuraLink
Features
301
——
y
y
(yy

µThere are six message categories in
AcuraLink: Quick Tips, Feature
Guides, Maintenance Minders,
Recalls/Campaigns, Diagnostic Inf o,
and Dealer Appointment Reminders.
The system can store up to 256
messages.
Message categories can be added,
revised, or deleted through
broadcast messages f rom Acura.
For the Phone Data
Connection button to be active, you
need a Bluetooth
compatible and
enabled cellphone paired to the
HandsFreeLink (HFL). To complete
the date connection setup, the paired
phone must have a compatible data
service.
The def ault setting is prompt. When
a diagnostic inf o message appears,
and you select the Check Now
button, the system will prompt you
bef ore connecting to the Acura
server. If you do not wish to connect
at that time, select No at the prompt,
and you will see the inf ormation
from the onboard database. The
‘‘Auto’’ setting will remove the
prompt when you select the Check
Now button and will automatically
connect to the Acura server. This
setting only applies when you have a
Bluetooth
enabled phone that is
paired with the HFL and you have
completed the Phone-Data
Connection setup.
AcuraLink
Message Categories
Connect to the Acura Server
302
NOTE:
——
y
y
(yy
