2007 Acura RDX display

µµ
In MP3/WMA mode
The folder scan
f unction samples the f irst f ile of each
f older in the current disc in the order
they are compressed in MP3/WMA.
To activate this feature, press the
SCAN button twice. The f irst f ile of
each f older plays f or about 10
seconds. You will see ‘‘FOLDER
SCAN’’ next to disc number on the
audio control display. You will also
see ‘‘SCAN’’ and the f older number
blinking on the upper display. To
hear the rest of the f ile in the f older
currently scanning, press and hold
the SCAN button for more than 2
seconds. If you don’t, the system advances to
the next f older, plays about 10
seconds of it, and continues through
the rest of the f olders the same way.
When the system f inishes scanning
all the f olders of the current disc, the
system returns to the f older it
started scanning with, f older scan is
canceled and the system begins to
play that folder normally. The disc scan
f unction samples the f irst track/f ile
(in MP3/WMA mode) of each disc
within the changer in numerical
order. To activate this f eature, press
the SCAN button twice. In the MP3/
WMA mode, press the SCAN button
three times. The f irst track/f ile of
each disc plays f or about 10 seconds.
You will see ‘‘SCAN’’ next to the
DISC icon on the audio control
display. You will also see ‘‘SCAN’’
and the disc number blinking on the
upper display. To hear the rest of the
track/f ile in the disc currently
scanning, press and hold the SCAN
button for more than 2 seconds.
CONT INUED
FOLDER SCAN DISC SCAN
Audio System
Features
217
FOLDER SCAN INDICATOR
——
y


y
() yy

µ
If you don’t, the system advances to
the next disc, plays about 10 seconds
of it, and continues through the rest
of thediscsthesameway.Whenthe
system f inishes scanning all the
discs, disc scan is canceled and the
system begins to play the f irst track/
f ile of that disc normally. You will see ‘‘RANDOM’’ next to the
TRACK/FILE icon on the audio
display. To turn of f this f eature,
select random, then press ENTER
again.
Each time you press and release the
SCAN button, the mode changes
f rom scan to f older scan, disc scan
then to normal playing.
This f eature plays the
tracks (all f iles in each f older in
MP3/WMA mode) within a disc in
random order. To activate random
play, press the AUDIO button to
view the audio control display, then
push down the selector on the
interface dial. Rotate the interface
dial to select random. Press ENTER
on the selector to enter your
selection.
Audio System
RANDOM (Random within a
disc)
218
SCAN INDICATOR RANDOM INDICATOR
TRACK RANDOM ICON
DISC SCAN ICON
——
y

y
() yy

µ
In MP3/WMA mode
This
f eature plays the f iles within a f older
in random order, rather than in the
order they are compressed in MP3/
WMA. To activate folder random
play, press the AUDIO button to
view the audio control display, then
push down the selector on the
interface dial. Rotate the interface
dial to select the f older random.
Press ENTER on the selector to
enter your selection. You will see ‘‘FOLDER RANDOM’’
on the audio control display. To turn
of f this f eature, select the f older
random then, press ENTER again.You can play a DVD-A disc in the CD
changer. The disc controls are same
as previously described.
To pause a disc, press the
corresponding number of the
current disc on the preset buttons.
To play the disc again, press the
preset button again.
You can also pause a disc on the
audio control display. Press the
AUDIO button to view the display,
select a corresponding number of
the current disc on the preset icons
by rotating the interf ace dial, then
press ENTER on the interf ace
selector. To play the disc again,
select the preset icon, then press
ENTER again.
FOLDER RANDOM
Playing a DVD-A Disc
To Pause a Disc
Audio System
Features
219
FOLDER RANDOM INDICATOR
FOLDER RANDOM ICON
——
y
y
() yy

If you turn the system off while a CD
is playing, either with the PWR/VOL
knob or by turning off the ignition
switch, the disc will stay in the drive.
When you turn the system back on,
the CD will begin playing where it
left off.
To take the system out of CD mode,
press the AM/FM, or DISC/AUX, or
button to switch to the radio,
or satellite radio (U.S. models only),
or auxiliary input while a CD is
playing. When you return to CD
mode by pressing the DISC/AUX
button, play will continue at the same
point that it left off. To
remove the disc that is currently
playing, press and release the eject
( ) button. You will see
‘‘EJECT’’ on the upper display. When
you remove the disc from the slot,
the system begins the load sequence
so you can load another disc in that
position. If you do not load another
disc within 10 seconds, the system
selects the previous mode [AM, FM1,
FM2, or XM Radio (U.S. models)].
If you do not remove the disc from
the slot, the system will reload the
disc after 10 seconds and put the CD
changer in pause mode. To begin
playing the disc, press the DISC/
AUX button.
To remove a different CD from the
changer, select it with the
appropriate preset button, or icon on
the audio control display. When that
disc begins playing, press the eject
button. Press
and hold the eject button until
you hear a beep to remove all the
discs from the changer.
You can also eject discs when the
ignition switch is off by pressing the
eject button. The disc that was last
selected is ejected first. You can
eject the rest of the discs one at a
time.
For information on how to handle
and protect compact discs, see page
.
For information, see page .
For
information, see page .
233
234227
To Stop Playing a Disc
Removing CDs f rom the Changer
Protecting Discs
Adjusting the Sound CD Changer Error Messages
Audio System
220
——
y
y
() yy

µµ
Your vehicle is capable of receiving
XM
Satellite Radio anywhere in the
United States, except Hawaii and
Alaska.
XM
is a registered trade mark of
XM Satellite Radio, Inc.
XM Satellite Radio receives signals
f rom two satellites to produce clear,
high-quality digital reception. It
of f ers many channels in several
categories. Along with a large
selection of dif f erent types of music,
XM Satellite Radio also allows you to
view channel and category selections
in the upper display and the audio
control display. To listen to the XM satellite Radio,
turn the ignition switch to the
ACCESSORY (I) or ON (II) position.
Push the PWR/VOL knob to turn on
the audio system, and press the
button. To view the audio
control display, press the AUDIO
button. Adjust the volume turning
the PWR/VOL knob. The last
channel you listened to will show on
the upper display.
Each time you press and
release the DISP/MODE button, the
upper display changes in the
f ollowing sequence: Channel name,
category, artist name, and music title. To switch between the
category mode and channel mode,
press and hold the DISP/MODE
button until the mode changes.
appears ‘‘CH’’ or ‘‘CAT’’ mode
indicator appears on the upper
display.
CONT INUED
Audio System
Operating the XM Radio
DISP MODE
Features
223
——
y
y
() yy

µ
µ You can also change channel
selections on the audio control
display. Press the AUDIO button to
view the display, then push down the
selector on the interf ace dial. Rotate
the interf ace dial to select the tune.
Press ENTER on the selector to
enter your selection. Rotate the
interf ace knob to the desired
channel. In the category mode, you
can only select channels within that
category. Press either side of the SEEK/SKIP
(CATEGORY) bar ( or )
to select another category.
You can also change the category on
the audio control display. Press the
AUDIO button to view the display,
then push the selector on the
interf ace dial to the right side or lef t
side to select another category.
When in the satellite radio mode,
you can use any of f our methods to
f ind channels: TUNE, SEEK/SKIP
(CATEGORY), SCAN, and the
preset icons.
You can also switch between the
category mode and channel mode,
on the audio control display. Press
the AUDIO button to view the
display, then push down the selector
on the interf ace dial. Rotate the
interf ace dial to select the mode.
Press ENTER on the selector to
enter your selection.
Press the TUNE/
FOLDER bar to change channel
selections. Press the side of the
bar to tune to higher numbered
channels, and the side of the
bar to tune to lower numbered
channels. In the category mode, you
can only select channels within that
category.
Audio System
SEEK /SK IP (CA T EGORY)
T o Select a Channel
TUNE
224
TUNE ICON
SEEK/SKIP (CATEGORY) ICON
——
yy
() yy

µµ
The scan f unction gives
you a sampling of all channels while
in the channel mode. In the category
mode, only the channels within that
category are scanned. To activate
scan, press the SCAN button. The
system plays each channel in
numerical order f or a f ew seconds,
then selects the next channel. When
you hear a channel you want to
continue listening to, press the
button again. Youcanstoreupto12
preset channels using the preset
buttons/icons. Each button/icon
stores one channel f rom the XM1
band and one channel f rom the XM2
band.
To store a channel:
You can also scan the channels on
the audio control display. Press the
AUDIO button to view the display,
then push down the selector on the
interf ace dial. Push the selector to
the right to activate scan feature. In category mode, only channels within that category can be selected.
In channel mode, all channels can be
selected.Usethetune,seek,orscan
function to tune to a desired
channel. Press the button. To view
the audio control display, press the
AUDIO button. Either XM1 or XM
2 will be shown on the display.
1.
2.
CONT INUED
Audio System
SCAN
Preset
Features
225
SCAN ICON
SCAN INDICATOR
——
y


y
() yy

CONT INUED
BASS, TREBLE, BALANCE, and
FADER are each adjustable. You can
also adjust the strength of the sound
coming from the center and
subwoof er speakers. In addition, you
can set the Dolby PL (Prologic) II
and Speed-sensitive volume
compensation (SVC).
To adjust each mode, press the
AUDIO button to view the audio
control display, push the interf ace
selector down, and turn the interf ace
dial to SOUND. Then press ENTER
on the selector.
Selectthemodeyouwanttoadjust
by pushing the interf ace selector up
or down, or by turning the interf ace
dial.
On RDX with Technology Packagemodel
Audio System
Adjusting the Sound
Features
227
SOUND ICON
——
