The anti-lock brake system (ABS)
helps prevent the brakes from
locking up, and helps you retain
steering control by pumping the
brakes rapidly, much faster than a
person can do it.
The ABS also balances the front-to-
rear braking distribution according
to vehicle loading.
Let the ABS work for you by always
keeping firm, steady pressure on the
brake pedal. This is sometimes
referred to as ‘‘stomp and steer.’’ You
will feel a pulsation in the brake
pedal when the ABS activates, and
you may hear some noise. This is
normal: it is the ABS rapidly
pumpingthebrakes.Ondry
pavement, you will need to press on
thebrakepedalveryhardbeforethe
ABS activates. However, you may
feel the ABS activate immediately if
you are trying to stop on snow or ice. If
this indicator comes on, the anti-
lock function of the braking system
has shut down. The brakes still work
like a conventional system, but
without anti-lock. You should have
your dealer inspect your vehicle as
soon as possible.
You will also see a ‘‘CHECK ABS
SYSTEM’’ message on the multi-
inf ormation display (see page ). 85
You should never pump the brake pedal. On RDX with Technology Package
model
CONT INUED
ABS Indicator
Anti-lock Brakes (ABS)
Driving
307
——
y

y
() y
y

Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving. Al
though your tire pressure is
monito red, you must manually check
thetirepressuresmonthly.
Each tire, including the spare, should
be checked monthly when cold, and
set to the recommended inflation
pressure as specified on the vehicle
placard and in the owner’s manual
(see page ).
Driving on a signifi cantly under-
inflated tire causes the tire to
ov erheat and can lead to tire failure.
Under-infl ation also reduces fuel
efficiency and tire tread life, and may
affect the vehicle’s handling and
stopping ability. When
the low tire pressure indicator
is on, one or more of your tires is
signifi cantly underinflated. You
should stop and check your tires as
soon as possible, and inflate them to
the proper pressure as indicated on
the vehicle’s tire information placard.
Each
tire has its own pressure
sensor. If the air pressure of a tire
becomes significantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure indicator to come on.
With this indicator on, you will see
which tire is losing the pressu re on
the multi-information display along
with a ‘‘CHECK TIRE PRESSU RE’’
message (see page ).
With
this indicator on, you will see
which tire is losing the pressu re on
thetirepressure monitor(seepage
).
373
311
312
CONT INUED
On RDX with Technology Packagemodel
On RDX model
Tire Pressure Monitoring System (TPMS)
Low Tire Pressure
Indicator
Driving
309
——
y

y
() y
y

Each wheel is equipped with a tire
pressure sensor mounted inside the
tire behind the valve stem. You must
use TPMS specific wheels. It is
recommended that you always have
your tires serviced by your dealer or
qualified technician.
Your vehicle has a tire pressure
monitor on the info rmation display. The
tire pressure monitor uses the
same display as the door and tailgate
open monitor. When any of the tires
has low pressure, the low tire
pressure indicator on the instrument
panel comes on, and you will also see
which tire is losing the pressu re on
the tire pressure monitor.
If the TPMS indicator comes on, the
tire pressure monitor does not work
(see page ).
If the low tire pressure indicator and
the low tire position on the low tire
pressure monitor do not go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible. 73
CONT INUED
On RDX model
Tire Pressure Monitoring System (TPMS)
Tire Pressure Monitor
Driving
311
LOW PRESSURE TIRE
——
y

y
() y
y

ÛÝ
To display the tire pressure monitor,
press the INFO ( / ) button until
it appears on the multi-inf ormation
display.
When all tire pressures are normal,
the tire pressure monitor will show a
‘‘TIRE PRESS. OK SYSTEM FUNC
NORMAL’’ message. When any of the tires have low
pressure, the low tire pressure
indicator on the instrument panel
comes on, and the multi-inf ormation
display also interrupts the current
display and shows a ‘‘CHECK TIRE
PRESSURE’’ message. You can see
one or more of the low pressure tire
positions highlighted in the display
along with this message.When any of the tires have low
pressure, the tire pressure monitor
shows a ‘‘TIRE PRESS. ERROR
SYSTEM FUNC NORMAL’’
message.
On RDX with Technology Package
model
Tire Pressure Monitoring System (TPMS)
312
INFO BUTTONS
——
y

y
() y
y

If one or more tires have low
pressure, the low tire pressure
indicator on the instrument panel
also comes on (see page ).
It is possible that the pressures
shown on the multi-inf ormation
display and the pressures you
manually measure are slightly
dif f erent.
If the dif f erence is signif icant or you
cannot make the low tire pressure
indicator and message on the multi-
inf ormation display go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible.
When the TPMS is functioning
normally, you can see the tire
pressure readings of each tire in psi
(U.S. models) or kPa (Canadian
models) by pressing the SEL/
RESET button while the multi-
inf ormation display shows the tire
pressure monitor. If there is a problem with the TPMS,
the multi-information display shows
a ‘‘CHECK TPMS SYSTEM’’
message.
73
CONT INUED
On RDX with Technology Package
model On RDX with Technology Package
model
Tire Pressure Monitoring System (TPMS)
T ire Pressure ReadingsCheck T PMS System Message
Driving
313
U. S.
Canada SEL/RESET BUTTON
——
y
y
() y
y

If the low tire pressure indicator
comes on, or the multi -information
display shows a ‘‘CHECK TPMS
SYSTEM’’ message, the VSA system
automatically turns on even when
the VSA system is turned off by
pressing the VSA OFF switch (see
page ). If this happens, you
cannot turn the VSA system of f by
pressing the VSA OFF switch again.
If you see this message, the tire
pressure monitor shows a ‘‘SYSTEM
FUNCTION ERROR’’ message. The
system may not be able to detect or
signal low tire pressure as intended.
Also, the tire pressure readings will
not be displayed. Have your vehicle
checked by a dealer as soon as
possible. 316As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Tire Pressure Monitoring System (TPMS)
314
——
y
y
() y
y

The VSA system cannot enhance the
vehicle’s driving stability in all
situ ations and does not control your
vehicle’s entire braking system. It is
still your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety.
The
vehicle stability assist (VSA)
system helps to stabilize the vehicle
during cornering if the vehicle turns
more or less than desired. It also
assists you in maintaining traction
while accelerating on loose or
slippery road surfaces. It does this
by regulating the engine’s output and
by selectively applying the brakes.
When VSA activates, you may notice
that the engine does not respond to
the accelerator in the same way it
does at other times. You will also see
the VSA activation indicator blink. When
VSA activates, you will see the
VSA activation indicator blink (see
page ).
If this indicator comes on while
driving, pull to the side of the road
when it is safe, and turn off the
engine. Reset the system by
restarting the engine. If the VSA
system indicator stays on, or comes
back on while driving, have the VSA
system inspected by your deale r.
If the indicator does not come on
when the ignition switch is turned to
the ON (II) position, there may be a
problem with the VSA system. Have
your dealer inspect your vehic le as
soon as possible. You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display (see page ).
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement.
When you put a spare tire on the
wheel, TPMS indicator or ‘‘CHECK
TPMS SYSTEM’’ message
(depending on the models) may
come on. When the indicator or
message is on, you are unable to turn
of f the VSA system with the VSA
OFF switch.
70
85
On RDX with Technology Package
modelVSA A ctivation Indicator
Vehicle Stability Assist
(VSA ) System Indicator
Vehicle Stability Assist (VSA) System
Driving
315
——
y

y
() yy

Avoid driving through deep water. If
you encounter water in your route (a
small stream or large puddle, for
example), evaluate it carefully before
going ahead. Make sure it is shallow,
flowing slowly, and has firm ground
underneath. If you are not sure of
the depth or the ground, turn around
andfindanotherroute.
Driving through deep water can also
damage your vehicle. The water can
get into the transmission and
differential, diluting the lubricant
and causing an eventual failure. It
can also wash the grease out of the
wheel bearings. Avoid
driving on soft sand, deep mud,
or other surfaces where you could
get stuck. If you do happen to get
stuck because of inclement weather
or other conditions, choose a safe
and appropriate course of action.
You should never use a jack to try
getting unstuck. A jack only works
on firm, level ground. Also, your
vehicle could easily slip off the jack
and hurt you or someone else. If
you spin the wheels excessive ly
trying to get unstuck, you may
overheat the components of the SH-
AWD system. The SH-AWD
indicator on the instrument panel will
blink to indicate the rear dif f erential
temperature is too high.
You will also see an ‘‘SH-AWD DIFF
TEMP HIGH’’ message on the multi-
inf ormation display (see page ).
If this happens, stop and allow
everything to cool down. The SH-
AWD indicator goes off after the
rear dif f erential temperature drops. 85
On RDX with Technology Package
model
If You Get Stuck
Crossing a Stream
Of f -Highway Driving Guidelines
