2006 Peugeot 206 SW Dag Owner's Manual

65
-Audio equipment and telematics
SATELLITE NAVIGATION
SYSTEM
Initialisation
When the navigation is used for the
first time, or if the battery is discon-
nected, the navigation system must
be initialised.
To do this, park the vehicle in the
open so that it can make contact with
a satellite then turn the ignition key
to the
Running position for fifteen
minutes.
Certain functions or services de-
scribed may vary depending on the
version of CD ROM or the country
where the vehicle is sold.
For safety reasons, the
inputting of navigation in-
formation by the driver
must be carried out when
the vehicle is stationary.The CD ROM drive
This is
part of the RT3 GPS audio/
telephone.
1. CD ROM ejection button.
2. CD ROM drive.
This contains all the map data.
It must be inserted in the drive,
printed face upwards.
Use only CD ROMs approved by
PEUGEOT.
The navigation CD ROM
The system uses the following ele-
ments:
- A CD ROM drive.
- A last voice message recall control -
during navigation, a long press on
the end of the lights stalk repeats
the last spoken information.
- Map data in the form of a CD ROM which must be inserted in the drive
printed side up.
- A configuration CD ROM, required in order to change the voice syn-
thesiser voice (female or male) or
the language used by the system.
- A voice synthesiser which utters the manoeuvre instructions during
navigation.
- A screen.
- A GPS aerial.
- Controls on the panel and at the steering wheel.
Introduction
The satellite navigation system
guides you, by means of vocal and
visual instructions (graphics), to
your chosen destination.
The heart of the system lies in the
use of a map database and
GPS
(Global Positioning System) . With
this system you can fix the position
of your vehicle by means of a satel-
lite network.

66 -Audio equipment and telematics
The last voice message recall
control
Pressing for more than two seconds
on the button at the end of the lights
stalk repeats the last voice informa-
tion.
The control keypadRotation of the dial:
This allows you to
move round the
screen and thus select a function.
It also allows you :
- with a "setting" type parameter,
after selection, to increase or de-
crease the value,
- with a "list" type parameter, to
open the list and scroll through
the values,
- with map guidance, to increase the
zoom .
Pressing the dial:
This allows:
- access to the list of controls (con-
textual menu) of the permanent
display, if there is no other display
superimposed,
- confirmation of the selected func-
tion or the modified value,
- selection of a "setting" or "list"
type parameter for modification. "MENU" button:
- brief press: access to the
general
menu ,
-
press for more than two seconds:
displaying of a help menu with the
list of voice commands, a description
of the version of your equipment, a
demonstration mode and the status
of the services.
"MODE" button:
- brief press: modification of perma- nent display (audio system, naviga-
tion/guidance...),
"ESC" button:
- brief press: cancelling of operation
in progress or erasing of last su-
perimposed display,
- pressing for more than two sec- onds: erasing of all superimposed
displays and return to the perma-
nent display.
This lets you select and validate the
functions, controls and programmes
displayed.

67
-Audio equipment and telematics
General notes on the display
During navigation, if the navigation
CD ROM is present, the screen indi-
cates the manoeuvres to be carried
out:
1.
During navigation: manoeuvre
to be carried out or, temporarily,
course to be followed.
2. Next manoeuvre to be carried
out.
3. Next road to be taken and name
of the town.
4. Current road and name of the
town.
5. Symbol concerning the
Traffic Information or the local
services*.
6. Estimated time of arrival at
destination (based on
free-flowing traffic).
7. Distance to final destination.
8. Distance to next manoeuvre. General menu
Switch on the RT3 GPS audio/tele-
phone and insert the navigation CD
ROM.
Press the
"MENU" button to access
the general menu .
Select the Navigation/Traffic Informa-
tion icon using the dial G, then validate
by pressing the dial to access the main
"Navigation - Traffic Info" menu.
Notes:
Depending on the situation of the
vehicle and the reception of GPS
information, this information may
disappear from the screen temporarily.
In Navigation display mode, a long
press of the "Menu" control permits
access to the activation of a demon-
stration of the Navigation function of
your RT3 GPS audio/telephone.
Next, select a destination using the
Navigation Menu. After entering, start
the Navigation to display a simulation
of the movement of your vehicle. The
starting point will be either the cur-
rent location of the vehicle or the last
known location. It is possible to enter
an alternative starting point via the
demonstration menu.
This demonstration may enable you
to visualise a journey that you wish
to make in the near future.
* According to screen.

68 -Audio equipment and telematics
The main "Navigation - Traffic Info"
menu offers various options for acti-
vation or management of guidance:
- "Select a destination".
- "Stages and routes".
- "Guidance options".
- "TMC traffic information".
- "Stop guidance".
Once guidance has been started, a
display warns you about use of the
navigation. If you accept its content,
press G. Observe current road indi-
cations.
Navigation - Traffic Information
The "Select a destination" menu
offers various options for reaching a
destination:
- "Entering an address" .
- Select a "service" available in a
town (restaurant, airport, hotel,
cinema, theatre, etc.).
- Select a destination stored in a "directory" .
- Select one of the twenty "previous
destinations" .
Selecting a destination
The last guidance address is dis-
played.
Select and validate in succession the
entry zones "Town", "Road" , then
"N°" to fill them in.
The "OK" function permits valida-
tion of the address and access to the
guidance activation function.
The "Store" function permits recording
of the address in a directory file.
The "Curr. loc" function permits
display of the current address.
The "GPS" function permits selection
of the GPS coordinates.
Entering an address

69
-Audio equipment and telematics
To enter the name of a town, select
each letter by turning the dial, then
validate each letter by pressing the
dial.
If an error is made entering the let-
ters, the
"Change" function permits
erasing of the last letter entered.
Note: following the validation of a
letter, only those which could make
up a name existing in the database
appear.
As letters are entered, the "List"
function indicates the number of
towns beginning with the same letters.
Activation of this function permits se-
lection of a town from the list.
When the list contains fewer than
six names, these are displayed auto-
matically. Select a town then validate
by pressing the dial.
When the complete name of the town
is displayed, select the "OK" function
then confirm by pressing the dial.
Note: once the town has been
entered, you can confirm by pressing
"OK" . You will then be guided to the
centre of this town automatically.
Entering the name of the town Entering the name of the road
Enter the name of the street in the
same way as the name of the town.
When the full name of the street is
displayed, select the "OK" function
then confirm by pressing the dial.
Note: do not enter the type of road
(road, avenue, etc.).
Enter the number of the street previ-
ously entered.
Select the "OK" function, then
confirm by pressing the dial.
Note: if the number of the street
entered is not available, it is rejected.
You can also select a street from the
"Junctions" function, which avoids
having to enter the street number.
Note: if the street selected does not
have a number, the list of junctions is
displayed automatically.
The full destination is displayed.
Select the "OK" function, then
confirm by pressing the dial to
access the guidance activation
function. Follow the instructions
given by the system.
Entering the number of the road
or junction
Entering the town and road using
the alphanumeric keypad
Press the numeric key which corre-
sponds to the letter required until the
letter appears on the screen, then
confirm by pressing the # key after
each letter.
If you make an inputting error, press
the * button to correct the last letter
entered.

70 -Audio equipment and telematics
The last address entered is dis-
played.
There are 3 options for defining the
location around which you wish to
obtain a service:
• Accept the last address entered by confirming the "OK" function.
• Enter the name of another town then confirm the road (optional).
• Automatically display the name of your current location using the
"Curr. loc" function.
Selecting a service
If you wish to be directed to a service,
select the category of service and
confirm.
The list of services in the category
selected is displayed. Select then
confirm the required service to gain
access to selection of the location.
An indication in the (X/n) band
indicates whether there are several
establishments (n = maximum) offer-
ing the same service within a radius,
as the crow flies, of 30 miles (50 km)
of the chosen location.
Use the functions "<<", ">>" or "<" ,
">" to consult the list offered.
When the establishment of your
choice is displayed, you can select:
- "OK" to activate guidance to this
service.
- "Store" to add to your directory.
- "Contact" to call the service.
Note:
If the service selected is not available
in the programmed location, a mes-
sage will inform you of this.
Following confirmation of the lo-
cation, the service nearest to it is
displayed. The distance indicated is
the distance to it as the crow flies.
The most recent destinations are
shown.
There are three possible methods
of defining the location to which you
wish to travel:
- accept the last details input by means of the "OK" function,
- input the details of your destina- tion,
- automatically input the details of your current location by means of
the "Curr. loc." function.
GPS details

71
-Audio equipment and telematics
Select the
"Directory" function to
access the file in which the address
you are looking for is archived.
Select a description by scrolling down
the list by means of the dial, then
confirm by pressing the dial. The
directory file is then displayed.
Select the "OK" function, then press
the dial to access the guidance
activation function.
Follow the directions given by the
system.
Selecting a destination stored in
the directory
Select the "Previous destinations"
function to access one of the last
twenty addresses stored.
Select a description by scrolling
down the list by means of the dial,
then confirm it by pressing the dial.
The complete address is then dis-
played.
Select the "OK" function, then press
the dial to access the guidance acti-
vation function.
Follow the instructions given by
the system.
Selection of one of the previous
destinations
- "Add a stage" to your route after
starting guidance.
- "Order or delete stages" .
- "Divert route" . You must indicate
the number of miles (kilometres)
that you wish to avoid to permit the
calculation of a new route.
- Select the initial "Chosen destina-
tion" in order to change it.
Note: if a stage is programmed, the
navigation system will always try to
pass via this stage until you have
gone through it or deleted it.
Stages and routes

72 -Audio equipment and telematics
- "Define the calculation criteria"
for your route so that it is the fast-
est, the shortest, takes account of
the traffic information, etc... The
last criteria selected are displayed.
- "Set the voice synthesiser" , set
the volume of the guidance instruc-
tions.
-
"Activate/deactivate road names" ,
set the pronunciation in the spoken
instructions.
- "Description of the CD ROM" , to
display the Navigation CD ROM
information.
- "Delete the previous destina-
tions" .
Guidance options
The last criterion used is displayed.
Select a criterion from the list, then
validate by pressing the dial.
When the criterion of your choice
has been selected, select the "OK"
function then confirm by pressing the
dial.
Calculation criteria Management of the directory
This function enables you to rename
an address stored in the directory.
Select the description corresponding
to the stored address to be changed.
Select the "Rename" function, then
confirm by pressing the dial.
Select the "OK" function, then
confirm by pressing the dial to record
the changes made.
Stopping/Resuming guidance
"Stop guidance"
During guidance, select this function
then validate.
"Resume guidance"
In the absence of guidance, select
this function then validate to activate
guidance to the last destination pro-
grammed.
Note: after re-starting the engine,
a screen appears enabling you to
resume guidance activated before
the ignition was switched off.
