bags do not provide restraint to the lower body.
The seat belts should be correctly worn and the
driver and passenger seated upright as far as
practical away from the supplemental side air
bag. Rear seat passengers should be seated as
far away as practical from the door finishers and
side roof rails. The side air bags and curtain
side-impact and rollover air bags inflate quickly
in order to help protect the front and rear
outboard occupants. Because of this, the force
of the side air bag and curtain side-
impact/rollover air bag inflating can increase the
risk of injury if the occupant is too close to, or is
against, these air bag modules during inflation.
The side air bag will deflate quickly after the
collision is over.
The curtain side-impact and rollover air bags will
remain inflated for a while.
The supplemental side air bags and curtain
side-impact and rollover air bags operate
only when the ignition switch is in the ON
or START position.
After turning the ignition switch to the ON
position, the supplemental air bag warning
light illuminates. The supplemental air bag
warning light will turn off after about 7
seconds if the systems are operational.
WARNING
Do not place any objects near the
seatback of the front seats. Also, do
not place any objects (an umbrella,
bag, etc.) between the front door fin-
isher and the front seat. Such objects
may become dangerous projectiles
and cause injury if the supplemental
side air bag inflates.
Right after inflation, several side air
bag and curtain side-impact and roll-
over air bag system components will
be hot. Do not touch them; you may
severely burn yourself.
No unauthorized changes should be
made to any components or wiring of
the side air bag and curtain side-
impact/rollover air bag system. This
is to prevent accidental inflation of
the side air bag and curtain side-
impact/rollover air bag or damage to
the side air bag and curtain side-
impact/rollover air bag system.
Do not make unauthorized changesto your vehicle’s electrical system,
suspension system or side panel.
This could affect proper operation of
the supplemental side air bag and
curtain side-impact/rollover air bag
system.
Tampering with the supplemental
system may result in serious per-
sonal injury. For example, do not
change the front seats by placing
material near the seatback or by in-
stalling additional trim material, such
as seat covers, around the side air
bag.
Work around and on the side air bag
and curtain side-impact/rollover air
bag system should be done by a
NISSAN dealer. Installation of elec-
trical equipment should also be done
by a NISSAN dealer. The SRS wiring
harnesses* should not be modified or
disconnected. Unauthorized electri-
cal test equipment and probing de-
vices should not be used on the side
air bag system.
* The SRS wiring harnesses connec-
Safety — seats, seat belts and supplemental restraint system
1-51
05.8.26/Z50-D/V5.0
Page 65 of 341
tors are yellow or orange for easy
identification.
When selling your vehicle, we request that you
inform the buyer about the side air bag and
curtain side-impact/rollover air bag system and
guide the buyer to the appropriate sections in
this Owner’s Manual.
Pre-tensioner seat belt system (For
front seats)
WARNING
The pre-tensioner seat belt cannot be
reused after activation. It must be
replaced together with the retractor
and buckle as a unit.
If the vehicle becomes involved in a
frontal collision but the pre-tensioner
is not activated, be sure to have the
pre-tensioner system checked and, if
necessary, replaced by a NISSAN
dealer.
No unauthorized changes should bemade to any components or wiring of
the pre-tensioner seat belt system.
This is to prevent accidental activa-
tion of the pre-tensioner seat belt or
damage to the pre-tensioner seat
belt operation. Tampering with the
pre-tensioner seat belt system may
result in serious personal injury.
Work around and on the pre-
tensioner seat belt system should be
done by a NISSAN dealer. Installa-
tion of electrical equipment should
also be done by a NISSAN dealer.
Unauthorized electrical test equip-
ment and probing devices should not
be used on the pre-tensioner seat
belt system.
If you need to dispose of the pre-
tensioner or scrap the vehicle, con-
tact a NISSAN dealer. Correct pre-
tensioner disposal procedures are
set forth in the appropriate NISSAN
Service Manual. Incorrect disposal
procedures could cause personal
injury.The front seat pre-tensioner seat belt system
activates in conjunction with the supplemental
front air bag system. Working with the seat belt
retractor, it helps tighten the seat belt when the
vehicle becomes involved in certain types of
collisions, helping to restrain front seat occu-
pants.
Also, the front seat pre-tensioner seat belt sys-
tem activates in conjunction with the supple-
mental side-impact/rollover air bag system.
Working with the seat belt retractor, it helps
tighten the seat belt when the vehicle becomes
involved in certain types of rollover collisions or
rear rollovers.
The pre-tensioner is encased with the seat belt’s
retractor. These seat belts are used the same as
conventional seat belts.
When the pre-tensioner seat belt activates,
smoke is released and a loud noise may be
heard. The smoke is not harmful and does not
indicate a fire. Care should be taken not to inhale
it as it may cause irritation and choking. Those
with a history of a breathing condition should get
fresh air promptly.
If any abnormality occurs in the pre-tensioner
seat belt system, the supplemental air bag warn-
ing light
will not come on, will flash inter-
mittently or will turn on for 7 seconds and remain
on after the ignition switch has been turned to
1-52
Safety — seats, seat belts and supplemental restraint system
05.8.26/Z50-D/V5.0
Page 66 of 341
the ON or START position. In this case, the
pre-tensioner seat belt may not function prop-
erly. They must be checked and repaired. Take
your vehicle to a NISSAN dealer.
When selling your vehicle, we request that you
inform the buyer about the pre-tensioner seat
belt system and guide the buyer to the appro-
priate sections in this Owner’s Manual.
1
SRS air bag warning labels
The warning labels are located on the surface of
the sun visors.2
SRS side-impact air bag warning
label
The warning label is located on the side of the
passenger’s side center pillar.SUPPLEMENTAL AIR BAG
WARNING LABELSWarning labels about the supplemental front air
bag and supplemental side-impact air bag sys-
tems are placed in the vehicle as shown in theillustration.
SSS0330
Safety — seats, seat belts and supplemental restraint system
1-53
05.8.26/Z50-D/V5.0
Page 67 of 341
SUPPLEMENTAL AIR BAG
WARNING LIGHTThe supplemental air bag warning light, display-
ing
in the instrument panel, monitors the
circuits of the supplemental front air bag,
supplemental side air bag and curtain side-
impact and rollover air bag systems, and pre-
tensioner seat belt systems. The circuits moni-
tored by the supplemental air bag warning light
are the diagnosis sensor unit, satellite sensors,
crash zone sensors, rollover sensors, front air
bag modules, side air bag modules, curtain
side-impact/rollover air bag modules, and pre-
tensioner seat belts and all related wiring.After turning the ignition switch to the ON or
START position, the supplemental air bag warn-
ing light illuminates. The supplemental air bag
warning light will turn off after about 7 seconds
if the system is operational.
If any of the following conditions occur, the
supplemental front air bag, supplemental side air
bag and curtain side-impact/rollover air bag
systems, and pre-tensioner seat belt systems
need servicing:
The supplemental air bag warning light re-
mains on after approximately 7 seconds.
The supplemental air bag warning light
flashes intermittently.
The supplemental air bag warning light does
not come on at all.
Under these conditions, the supplemental front
air bags, supplemental side air bags, curtain
side-impact/rollover air bags and/or pre-
tensioner seat belt may not operate properly. It
must be checked and repaired. Take your vehicle
to a NISSAN dealer.
WARNING
If the supplemental air bag warninglight is on, it could mean that the
supplemental front air bag, supplemen-
tal side air bag, curtain side-impact/
rollover air bag systems and/or pre-
tensioner seat belt systems will not op-
erate in an accident. To help avoid injury
to yourself or others, have your vehicle
checked by a NISSAN dealer as soon as
possible.
Repair and replacement procedureThe supplemental front air bags, supplemental
side air bags, curtain side-impact/rollover air
bags and pre-tensioner seat belt are designed to
activate on a one-time-only basis. As a reminder,
unless it is damaged, the supplemental air bag
warning light will remain illuminated after inflation
has occurred. Repair and replacement of these
systems should be done only by a NISSAN
dealer.
When maintenance work is required on the
vehicle, the supplemental front air bags, side air
bags, curtain side-impact/rollover air bags, re-
lated parts and pre-tensioner seat belt should be
pointed out to the person conducting the main-
tenance. The ignition switch should always be in
the LOCK position when working under the
hood or inside the vehicle.
SPA1097
1-54
Safety — seats, seat belts and supplemental restraint system
05.8.26/Z50-D/V5.0
Page 68 of 341
WARNING
Once a supplemental front air bag,
supplemental side air bag or curtain
side-impact/rollover air bag has in-
flated, the air bag module will not
function again and must be replaced.
Additionally, if any of the supplemen-
tal front air bags inflate, the activated
pre-tensioner seat belts must also be
replaced. The air bag module and
pre-tensioner seat belt system
should be replaced by a NISSAN
dealer. The air bag module and pre-
tensioner seat belt system cannot be
repaired.
The supplemental front air bag, side
air bag and curtain side-
impact/rollover air bag systems and
the pre-tensioner seat belt system
should be inspected by a NISSAN
dealer if there is any damage to the
front end or side portion of the ve-
hicle.
If you need to dispose of these
supplemental systems or scrap thevehicle, contact a NISSAN dealer.
Correct disposal procedures are set
forth in the appropriate NISSAN Ser-
vice Manual. Incorrect disposal pro-
cedures could cause personal injury.
Safety — seats, seat belts and supplemental restraint system
1-55
05.8.26/Z50-D/V5.0
Page 71 of 341
2 Instruments and controlsInstrument panel ..................................................................... 2-2
Meters and gauges ............................................................... 2-3
Speedometer and odometer ......................................... 2-4
Tachometer ........................................................................ 2-4
Engine coolant temperature gauge ............................. 2-5
Fuel gauge ......................................................................... 2-5
Compass display (if so equipped) .................................... 2-6
Warning/indicator lights and audible reminders ............ 2-9
Checking bulbs................................................................. 2-9
Warning lights ................................................................... 2-9
Indicator lights ................................................................ 2-14
Audible reminders.......................................................... 2-16
Security systems.................................................................. 2-17
Vehicle security system (if so equipped) ................ 2-17
NISSAN Vehicle Immobilizer System ....................... 2-18
Windshield wiper and washer switch ........................... 2-20
Rear window wiper and washer switch ....................... 2-21
Rear window and outside mirror defroster switch...... 2-22
Headlight and turn signal switch ................................... 2-22
Xenon headlights (if so equipped) .......................... 2-22
Headlight switch ........................................................... 2-23
Daytime running light system (Canada only) ........ 2-25
Instrument brightness control ..................................... 2-26
Turn signal switch ........................................................ 2-27Fog light switch (if so equipped) .............................. 2-27
Hazard warning flasher switch ......................................... 2-27
Horn ........................................................................................ 2-28
Heated seats (if so equipped) ......................................... 2-28
Vehicle dynamic control (VDC) off switch (if so
equipped) .............................................................................. 2-29
Power outlet.......................................................................... 2-30
Storage .................................................................................. 2-31
Coin box........................................................................... 2-31
Cellular phone holder ................................................... 2-31
Cup holders .................................................................... 2-32
Glove box ........................................................................ 2-33
Console box .................................................................... 2-34
Cargo net (if so equipped) ......................................... 2-35
Tonneau cover (if so equipped)................................. 2-36
Windows................................................................................ 2-36
Power windows.............................................................. 2-36
Sunroof (if so equipped) ................................................... 2-38
Automatic sunroof ......................................................... 2-38
Interior lights ......................................................................... 2-40
Ceiling light ..................................................................... 2-40
Map light .......................................................................... 2-41
Rear personal light ........................................................ 2-41
Luggage light .................................................................. 2-42
05.8.26/Z50-D/V5.0
Page 73 of 341
1. Headlight, fog light* and turn signal switch
2. Trip odometer reset button
3. Instrument brightness control switch
4. Meters/gauges
5. Windshield/rear window wiper and washer
switch
6. Hazard warning flasher switch
7. Center ventilator
8. Audio control
9. Display/clock
10. Rear window defroster and Heated outside
mirror* switch
11. Display screen control and/or Navigation
system*1
12. Passenger supplemental air bag
13. Side ventilator
14. Headlight aiming control switch*
15. VDC (Vehicle dynamic control) off switch*
or Headlight aiming control*
16. Steering switch for audio control*
17. Fuse box cover
18. Tilting steering wheel lock lever
19. Driver supplemental air bag/Horn
20. Cruise control main/set switch
21. Ignition switch/steering lock
22. Heater/air conditioner control
23. Coin box
24. Outside mirror remote control
25. Cellular phone holder
26. AWD lock switch (AWD models)
27. Heated seat switch*
28. Power outlet cover
29. Glove box
*: if so equipped
SSI0176
INSTRUMENT PANEL2-2
Instruments and controls
05.8.26/Z50-D/V5.0
Page 74 of 341
*1: Refer to the separate Navigation System
Owner’s Manual.
1. Tachometer
2. Turn signal indicator/Hazard indicator
3. Speedometer
4. Engine coolant temperature gauge
5. Fuel gauge6. Reset button for trip odometer
7. Warning/Indicator lights
8. Odometer (Total/Twin trip)
9. CVT shift position indicator
SIC3031
METERS AND GAUGES
Instruments and controls
2-3
05.8.26/Z50-D/V5.0
