TRANSMISSION CONTROL
MANUAL TRANSMISSION22-4
TRANSMISSION CONTROL
GENERAL INFORMATIONM2222000100242
Due to the addition of vehicles with M/T, the following
transmission control has been established.
CONSTRUCTION DIAGRAM
AC600701
Gearshift knob
AB
Select cable
Gearshift lever assembly
Gearshift cable or
Select cable assembly
Gearshift cable
TECHNICAL FEATURES
GENERAL00-10
TRANSMISSION
M2000021000594
MANUAL TRANSMISSION
Due to the addition of vehicles with M/T, a
"GETRAG" F5MGA type <4A9 engine>, F5MGB
type<4G1 engine> transmission has been adopted.
SPECIFICATIONS
Transmission modelF5MGAF5MGB
Engine model4A914G15
Transmission type5-speed, floor-shift
Transmission gear ratio1st3.3083.538
2nd1.9131.913
3rd1.2581.344
4th0.9431.027
5th0.7630.833
Reverse3.2313.357
Final reduction ratio4.1583.737
GEARSHIFT CONTROL
AC600701
Gearshift knob
AB
Select cable
Gearshift lever assembly
Gearshift cable or
Select cable assembly
Gearshift cable
The cable type of gea r shift contro l is adop ted.
