2006 MERCEDES-BENZ R500 Owner's Manual

536 IndexAir recirculation mode 224, 239
Activating 225, 239
Deactivating 226, 240
Air volume
Adjusting 222, 237
AIRMATIC* 269
Alarm
Audible 95, 106
Canceling 106
Visual 104
Alarm system
Anti-theft 104
Alignment bolt (vehicle tool kit) 481, 529
Anticorrosion/antifreeze 527
Antiglare
Automatic 209
Antilock brake system (ABS) 529
Anti-theft alarm system
Arming 105
Canceling alarm 106
Disarming 106
Anti-theft systems
Anti-theft alarm system 104
Immobilizer 104
Tow-away alarm 106Aquaplaning see Hydroplaning
Armrest
Storage compartment in front of 296
Storage compartments 296
Ashtray
Front center console 303
Aspect ratio 385, 529
ATF (automatic transmission fluid) 350
AUDIO menu 170
Selecting radio station 170
Selecting satellite radio* station 171
Audio system
CD mode 171
Automatic antiglare for rear view
mirror 209
Automatic central locking
Activating/deactivating (control
system) 188
Automatic climate control*
Front defroster 238
Residual ventilation 243Automatic climate control* (3-zone) 230
Adjusting air distribution 236
Adjusting air volume 237
Air recirculation mode 239
Rear passenger compartment 244
Residual heat utilization 243
Setting the temperature 236
Automatic headlamp mode 148
Automatic lighting control
Activating 155
Deactivating 155
Automatic locking when driving 130
Automatic shift program
Automatic transmission* 204
Automatic transmission
Accelerator position 203
Emergency operation (Limp Home
Mode) 207
Gear ranges 202
Gear selector lever position 199, 200
Gear shifting malfunctions 207
Kickdown 203
Transmission fluid 350
Automatic transmission*
Automatic shift program 204

537 Index
B
Backup lamps
Replacing bulbs 466
Bar 386, 529
BAS 99, 529
Batteries, SmartKey
Check lamp 113, 119
Batteries, vehicle
Messages in display 430
Battery discharged
Jump starting 496
Battery, SmartKey 463
Battery, vehicle 487
Charging 495
Dis-/reconnecting 489
Removing/installing 489
Bead 386, 529
Bi-Xenon* headlamps 529
Replacing bulbs 466
Block heater (Canada only) 391
Blocking
Rear door window operation 93
Bottle opener 300
Brake assist system (BAS) 529
Brake fluid 523
Message in display 432Brake lamps
Replacing bulbs 466
Brake pads
Message in display 430
Brakes 332
Warning lamp 405
Break-in period 330
Bulbs, replacing 465
Additional turn signal lamps 466
Backup lamps 466
Bi-Xenon* headlamps 466
Brake lamps 466
Front fog lamp 471
Front fog lamps* 466
Front lamps 466
Headlamps 466
License plate lamps 466, 474
Parking lamps 466
Rear fog lamps 472
Rear side marker lamp bulbs 472
Sidemarker lamps 466
Standing lamps 466
Tail lamp assemblies 472
Tail lamps 466
Turn signal lamps 466C
CAC (Customer Assistance Center) 529
California
Important notice 11
Call priority
Tele Aid* 318
Calling up
Range (distance to empty) 193
Service indicator 393
CAN system 529
Capacities
Fuels, coolants, lubricants, etc. 521
Card holder 300
Cargo compartment
Extending 283
Fuse box 504
Lamp 157
Tie-down rings 281
Cargo compartment cover blind* 288
Closing 288
Installing 289
Opening 288
Removing 288
Cargo tie-down rings 281
Carpets, cleaning 402

538 IndexCatalytic converter 340
CD player
Operating 171
CD-changer* 294
Center console 29
Lower part 30
PASS AIR BAG OFF indicator
lamp 414
Upper part 29
Central locking
Automatic 130
Switch 131
Switching on/off (control
system) 188
Unlocking from inside 131
Central locking switch 131
Certification label 510
Changing
SmartKey setting 189
Charging
Vehicle battery 495
CHECK ENGINE malfunction indicator
lamp 407, 408Checking
Coolant level 351
Oil level 346
Tire inflate pressure 344
Vehicle lighting 344
Checking tire pressure electronically with
the Advanced Tire Pressure Monitoring
System* (Advanced TPMS*) 371
Checking tire pressure electronically with
the Tire Pressure Monitoring System
(TPMS) 368
Child safety 82
Air bags 72
Infant and child restraint systems 78,
82
LATCH child seat mounts 92
Child safety switch see Blocking of rear
door window operation
Cigarette lighter
Front center console 303
Cigarette lighter* 305Cleaning
Headlamps 208
Headliner 402
Light alloy wheels 401
Plastic and rubber parts 402
Steering wheel 402
Windows 400
Windshield 60
Cleaning tires 355
Climate control 216
Adjusting 222
Adjusting air volume 222
deactivating 220
Front defroster 223
Rear passenger compartment 228
Setting the temperature 222
Clock 180
Closing
Glove box 294
Hood 346
Panorama sliding/pop-up roof 260
Power tilt/sliding sunroof* 462
Side windows 249
Tailgate 124, 128, 129
Tilt/sliding sunroof* 255
Windows 248

539 Index
Closing the tailgate from the inside
electrically* 124
Closing the tailgate from the outside (vehi-
cles without KEYLESS-GO*) 126
Closing tilt/sliding sunroof*
In an emergency 462
Cockpit 22, 529
Cold tire inflation pressure 386, 529
Collapsible tire 457, 530
Collapsible wheel chock 457
Combination switch
High beam flasher 58
Turn signals 58
Windshield wipers 59
Compass 186, 327
Adjustment 186
Calibration 187
Setting the compass zone 186
Control and operation of radio
transmitters 339Control system 530
AUDIO menu 170
Convenience submenu 189
Display digital speedometer 169
Functions 165
Instrument cluster submenu 178,
180
Lighting submenu 182
Malfunction memory menu 173
Menus 164, 165
Selecting radio system 170
Selecting satellite radio* system 171
Settings menu 174
Standard display menu 168
Submenus 163, 165
TEL* menu 194
Trip computer menu 192
Vehicle submenu 186
Convenience submenu 189
Activating easy-entry/exit
feature* 189Coolant 351, 525
Adding 351
Anticorrosion/antifreeze
quantity 526
Checking level 351
Messages in display 433, 436
Temperature 341
Coolant level
Checking 351
Corner-illuminating front fog lamps* 152
Cruise control 264, 530
Canceling 266
Driving downhill 265
Driving uphill 265
Setting current speed 265
Setting speeds 269
Cruise control lever 264
Cup holder
Front center console 299
In rear center console 301
Cup holders 299
Cleaning 401
Curb weight 386, 530
Customer Assistance Center (CAC) 529

540 IndexD
Daytime running lamp mode 149
Setting 182
Deactivating
Air conditioning 227
Air conditioning (cooling) 242
Air recirculation mode 226, 240
Alarm 106
Anti-theft alarm system 106
Automatic climate control*
(3-zone) 234
Central locking (control system) 188
Climate control system 220
Cruise control 266
Defrost 223, 238
Engine 66
ESP
®
101
Hazard warning flasher 154
Headlamps 65
Immobilizer 104
Interior lighting delayed
switch-off 185Rear passenger compartment ventila-
tion and climate control 245
Rear window defroster 215
Rear window wiper 62
Residual heat 228, 243
Seat heating* 143
Tow-away alarm 107
Deep water see Standing water
Defogging
Windshield 224, 238
Delayed switch-off
Interior lighting 185
Department of Transportation see DOT
Dialing
A number (telephone*) 195
Difficulties
While driving see Problems while driv-
ing
Digital speedometer 168
Direction of rotation (tires) 356Discharged battery
Jump starting 496
Disconnecting
Vehicle battery 489
Display
Selecting 179
Displays
Digital speedometer 169
Maintenance service indicator 392
Messages 347
Selecting 179
Showing malfunctions 173
Distance to empty (range)
Calling up 192
Door control panel 34
Door entry lamps 157
Door handle 34
Door unlock
With Tele Aid* 319
Door windows 248
Automatic closing 250
Automatic opening 250

541 Index
Closing 248
Closing fully (Express-close) 250
Opening 248
Opening fully (Express-open) 250
Stopping 250
Synchronizing 251
Doors
Message in display 436
Opening from inside vehicle 121
Opening from outside 112
DOT 386, 530
Downhill driving
Cruise control 265
Drinking and driving 331
Drive sensibly-save fuel 331
Driving 50, 56
Abroad 339
In winter 337
Problems 62
Safety systems 97
Through standing water 338
Driving abroad 339
Driving off 333Driving safety systems
4-ETS 102
ABS 97
BAS 99
EBP 102
ESP
®
99
Driving systems 264
AIRMATIC* 269
Cruise control 264
Driving safety systems 97
Parktronic* 274
Driving tips 203
Accelerator position 203
Kickdown 203
E
Easy-entry/exit feature* 132
Activating 189
EBP 102
Electrical fuses 503
Electrical system
Technical data 518
Electronic Brake Proportioning see EBP
Electronic Stability Program see ESP
®
Electronic Traction System see 4-ETSEmergency calls
Initiating an emergency call 314
With Tele Aid* 313
Emergency operation (Limp Home
Mode) 207
Emergency operations
Closing tilt/sliding sunroof* 462
Locking the vehicle 460
Opening tilt/sliding sunroof* 462
Remote door unlock 319
Unlocking the vehicle 459
Emergency tensioning device see ETD
Emission control 340
Emission control label 511
Ending
A call (telephone*) 195
Engine
Message in the display 433
Starting 53
Starting with KEYLESS-GO* 54
Technical data 513
Turning off 66
Engine cleaning 397
Engine compartment
Hood 345
Main fuse box 504

542 IndexEngine malfunction indicator lamp 407,
433
Engine malfunction indicator lamp (Cana-
da only) 27
Engine malfunction indicator lamp (USA
only) 27
Engine number 530
Engine oil 346, 523
Adding 349
Additives 523
Checking level 346
Consumption 346
Display messages 437–438
Messages in display 347, 437–438
Viscosity 530
ESP
®
25, 99, 530
Switching off 101
Switching on 102
Warning lamp 409
ETD 530
Safety guidelines 74
ETD (Emergency tensioning device) 80
Extending cargo compartment 283
Exterior mirrors
Folding 211Exterior rear view mirrors
Adjusting 48
Power folding* 211
Synchronizing 211
F
Fastening the seat belts 50
First aid kit 454
Flat tire 478
Lowering the vehicle 485
Preparing the vehicle 479
Spare wheel 457
Flexible Service System PLUS (FSS
PLUS) 530
Floormats* 328
Fluid level
Automatic transmission 350
Fog lamp, rear
Switching on 151
Fog lamps, front*
Messages in display 442
Replacing bulbs 466
Switching on 151
Folding
Exterior mirrors 2114-ETS 102
Front air bags 75
Front defroster 223, 238
Front fog lamps
Indicator lamp 147
Front lamps
Messages in display 442
Replacing bulbs 466, 468
Front seats
Head restraints 44
Front towing eye 501
Front wiper blades
Installing 476, 477
Removing 475
FSS PLUS (Flexible Service System
PLUS) 530
Fuel 343
Additives 525
Fuel reserve warning lamp 409
Gasoline additives 525
Premium unleaded gasoline 343,
524
Requirements 524
Fuel additives 525
Fuel cap
Message in display 439

543 Index
Fuel consumption statistics
After start 192
Since last reset 193
Fuel filler flap
Locking 342
Opening 461
Unlocking 342
Fuel requirements 524
Fuel tank
Filler flap 342
Fuels, coolants, lubricants etc. 521
Functions (control system) 165
Resetting 176
Fuses 503
Fuse box in cargo compartment 504
Fuse box in passenger
compartment 505
Main fuse box 504
G
Garage door opener* 320
Gasoline additives 525
Gasoline see Fuel
GAWR 386, 530Gear range 530
Automatic transmission 202
Limiting 202
Shifting into optimal 207
Gear range limit
Canceling 207
Gear selector lever
Message in the display 421
Position 200
Position (automatic
transmission) 199
Global
Locking 112
Unlocking 112
Global Positioning System (GPS) 531
Glove box 294
Closing 294
Opening 294
Good visibility 208
GPS 531
Gross Axle Weight Rating see GAWR
Gross Trailer Weight see GTW
Gross Vehicle Weight Rating see GVWRGross Vehicle Weight see GVW
GTW 386
GVW 386, 531
GVWR 386, 531
H
Hard plastic trim items, cleaning 402
Hazard warning flasher 153
Switching off 154
Switching on 154
Head restraints
Front seats 44
Rear seats 139
Headlamp cleaning system* 352
Headlamps
Automatic control 148
Bi-Xenon* 529
Cleaning lenses 399
Cleaning system* 208, 352
Refilling washer fluid 352
Replacing bulbs 466
Switching off 65
Switching on 58
Washer fluid 528
Washer system 528
