2006 MERCEDES-BENZ C55AMG engine

33 Getting started
Unlocking
Starter switch positions SmartKey
Starter switch
0For removing SmartKey
The steering is locked when the
SmartKey is removed from the starter
switch.
1Power supply for some electrical
consumers, such as seat adjustment2Ignition (power supply for all electrical
consumers) and driving position.
All lamps (except low beam headlamp
indicator lamp, high beam headlamp in-
dicator lamp, and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary. If
a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in instrument cluster” (page 350).
3Starting position
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Unsuper-
vised use of vehicle equipment may cause
an accident and/or serious personal injury.

34 Getting started
Unlocking
i
When you switch on ignition, the
indicator and warning lamps (except
low beam headlamp indicator lamp,
high beam headlamp indicator lamp,
and turn signal indicator lamps unless
activated) in the instrument cluster
come on. The indicator and warning
lamps (except low beam headlamp in-
dicator lamp, high beam headlamp indi-
cator lamp, and turn signal indicator
lamps if activated) will go out when the
engine is running. This indicates that
the respective systems are operational.
i
The SmartKey can only be removed
from the starter switch with the gear
selector lever in positionP.
!
If the SmartKey cannot be turned in the
starter switch, the battery may not be
sufficiently charged.

Check the battery and charge it if
necessary (
page 411).

Get a jump start (page 415).
To prevent accelerated vehicle battery
discharge or a completely discharged
battery, always remove the SmartKey
from the starter switch when the en-
gine is not in operation.

39 Getting started
Adjusting
Easy-entry/exit feature
This feature allows for easier entry into and
exit from the vehicle. When entering and
exiting the vehicle, the steering wheel is in
its uppermost position.
The easy-entry/exit feature can be activat-
ed or deactivated in the
Convenience sub-
menu of the control system (
page 148).With the easy-entry/exit feature activated,
the steering wheel will return to its last set
position when you:

close the driver’s door with the ignition
switched on,
or

insert the SmartKey into the starter
switch with the driver’s door closed. With the easy-entry/exit feature activated,
the steering wheel tilts upwards when you:

remove the SmartKey from the starter
switch,
or

open the driver’s door with the
SmartKey in starter switch position0
or1.
Warning!G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To cancel steering wheel movement, do one
of the following:

Move steering column stalk
(
page 38).

Press memory position switch
(
page 112).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
i
The last set steering wheel position is
stored when

the ignition is switched off

the position is stored in memory
(
page 112)
i
If the current position for the steering
wheel is in the uppermost tilt position,
the steering wheel will no longer be
able to move upward when the
easy-entry/exit feature is activated.
The adjustment procedure is briefly in-
terrupted when the engine is started.

45 Getting started
Driving
Starting the engine Automatic transmission
Gearshift pattern for automatic
transmission
PPark position with gear selector lever
lock
RReverse gear
NNeutral position
DDrive position
For more information, see “Automatic
transmission” (
page 155).
Warning!G
Do not pass belts over sharp edges. They
could tear.
Do not allow the belt to get caught in the
door or in the seat adjustment mechanism.
This could damage the belt.
Never attempt to make modifications to
seat belts. This could impair the effective-
ness of the belts.
Do not bleach or dye seat belts as this may
severely weaken them. In a crash, they may
not be able to provide adequate protection.
Damaged seat belts or belts that were highly
stressed in an accident must be replaced.
Contact an authorized Mercedes-Benz
Center.Warning!G
Inhalation of exhaust gas is hazardous to
your health. All exhaust gas contains carbon
monoxide (CO), and inhaling it can cause un-
consciousness and possible death.
Do not run the engine in confined areas
(such as garage) which are not properly ven-
tilated. If you think that exhaust gas fumes
are entering the vehicle while driving, have
the cause determined and corrected imme-
diately. If you must drive under these condi-
tions, drive only with at least one window
fully open.

46 Getting started
Driving
Starting
Place the gear selector lever in
positionP.
Do not depress the accelerator.
Turn the SmartKey in the starter switch
to position3 (
page 33) and release it
again immediately. The engine then
starts automatically.
For information on turning off the engine,
see “Turning off engine” (
page 56).Starting difficulties
If the engine does not start as described,
carry out the following steps:
Turn the SmartKey in starter switch to
position0 and repeat the starting
procedure (
page 45).
Remember that extended starting
attempts can drain the vehicle battery.
Get a jump start (page 415).
If the engine does not start after several
starting attempts, there could be a mal-
function in the engine electronics or in the
fuel supply system.
Notify an authorized Mercedes-Benz
Center.
Parking brake
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Children
could release the parking brake, which
could result in an accident and/or serious
injury.

47 Getting started
Driving
1Release handle
2Parking brake pedal
Release parking brake by pulling on
handle1.
The warning lamp; (USA only)
or3 (Canada only) in the
instrument cluster goes out.
Driving
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of loss of control.
!
If you hear a warning signal and the
message
Release parking brake ap-
pears in the multifunction display when
driving off, you have forgotten to re-
lease the parking brake.
!
Simultaneously depressing the acceler-
ator pedal and applying the brake re-
duces engine performance and causes
premature brake and drivetrain wear.
i
Once the vehicle is in motion, the auto-
matic central locking system engages
and the locking knobs drop down.
For more information, see “Automatic
central locking” (
page 103).
!
Do not run cold engine at high engine
speeds. Running a cold engine at high
engine speeds may shorten the service
life of the engine.

48 Getting started
Driving
Automatic transmission
Depress the brake pedal.
Move gear selector lever to positionD
to drive forward, or to positionR to
drive rearward.
Release the brake pedal.
Carefully depress the accelerator
pedal.
Switching on headlamps
Low beam headlamps
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.
Exterior lamp switch
1Off
2Low beam headlamps on
Turn exterior lamp switch to
positionB.
The low beam headlamp indicator
lampB in the instrument cluster
comes on (
page 24).
!
Wait for the gear selection process to
complete before setting the vehicle in
motion.
!
Place the gear selector lever in
positionP orR only when the vehicle is
stopped in order to avoid damaging the
transmission.
Warning!G
It is dangerous to shift the gear selector le-
ver out ofP orN if the engine speed is high-
er than idle speed. If your foot is not firmly
on the brake pedal, the vehicle could accel-
erate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and when
your right foot is firmly on the brake pedal.

52 Getting started
Driving
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.

The engine electronics may not be op-
erating properly.

Unburned gasoline may have entered
the catalytic converter and damaged it.
Give very little gas.
Have the problem repaired by an au-
thorized Mercedes-Benz Center as
soon as possible.The coolant temperature is
above 248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.
Stop the vehicle in a safe location as
soon as possible and turn off the en-
gine. Allow engine and coolant to cool.
Check the coolant level and add
coolant if necessary (
page 301).
!
If anything blocks the windshield
wipers (leaves, snow, etc.), switch
them off immediately.

For safety reasons, stop the vehicle
in a safe location and remove
SmartKey from starter switch
before attempting to remove any
blockage.

Remove blockage.

Turn the windshield wipers on
again.
If the windshield wipers fail to function
at all with combination switch in
positionI,

set the combination switch to the
next higher wiper speed

have the windshield wipers
checked at the nearest authorized
Mercedes-Benz Center
