163 Controls in detail
Automatic transmission
Steering wheel gearshift control
one-touch gearshifting
The steering wheel gearshift control pro-
vides an alternative method for changing
the gears manually and limiting or extend-
ing the gear range for automatic shifting
with the gear selector lever in positionD
and driving in the automatic program
modeC orS.The steering wheel gearshift buttons are
located to the left and right of the steering
wheel.
1Left button: downshift
2Right button: upshift
i
For information on using the steering
wheel gearshift control in manual pro-
gram modeM, see “Manual shift pro-
gram” (
page 165).
i
To avoid overrevving the engine when
downshifting with steering wheel
gearshift buttons, the transmission will
not shift to a lower gear if the engine’s
max. speed would be exceeded.
!
Allow engine to warm up under low
load use. Do not place full load on the
engine until the operating temperature
has been reached.
Shift into reverse gearR or parking
positionP only when the vehicle is
stopped.
Avoid spinning of a drive wheel for an
extended period when driving off on
slippery road surfaces. This may cause
serious damage to the drivetrain which
is not covered by the Mercedes-Benz
Limited Warranty.
i
You cannot shift with the steering
wheel gearshift buttons when the gear
selector lever is in positionP,N orR.
The last selected program
mode (CorS) is switched on when the
engine is restarted in the automatic
program mode.

167 Controls in detail
Automatic transmission
Briefly press the gear selector lever to
the right in theD+direction.
or
Briefly press button2 on the right
side of the steering wheel
(
page 163).
The transmission shifts to the next
higher gear.
If, instead of the manual program mode
symbol
M, thep symbol appears in the
multifunction display (
page 156), shift to
the next higher gear. The fuel supply will
otherwise be interrupted to prevent the
engine from overrevving.Downshifting
Briefly press the gear selector lever to
the left in theD-direction.
or
Briefly press button1 on the left side
of the steering wheel (
page 163).
The transmission shifts to the next
lower gear.Kickdown
Using the kickdown when driving in the
manual program modeM is not possible.
Deactivating manual shift program
Press the program mode selector
switch (
page 165) repeatedly
until
CorS appears in the multifunction
display.
or
Restart the engine.
The transmission will go to the
automatic program mode (C orS).
The manual program modeM is not
stored.
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced
vehicle control. Your vehicle’s ABS will not
prevent this type of loss of control.
i
When you brake or stop, the transmis-
sion shifts down to a gear from which
you can easily accelerate or take off.

178 Controls in detail
Climate control
Setting the temperature
Use temperature controls2 and3
(
page 175) to separately adjust the air
temperature on each side of the passenger
compartment. You should raise or lower
the temperature setting in small incre-
ments, preferably starting at 72°F (22°C).
The climate control will adjust to the set
temperature as fast as possible.
Increasing
Turn temperature control2 and/or
3 (
page 175) slightly clockwise.
The climate control system will corre-
spondingly adjust the interior air tem-
perature.Decreasing
Turn temperature control2 and/or
3 (
page 175) slightly counterclock-
wise.
The climate control system will corre-
spondingly adjust the interior air tem-
perature.
Adjusting air distribution and volume
Use air distribution control4
(
page 175) to adjust the air distribution.
The following symbols are located on the
controls:
Press buttonU (page 175).
The indicator lamp on the button goes
out. The automatic air distribution is
switched off. The air distribution is
controlled according to the selected
control setting.i
If you turn the temperature control
clockwise until it stops for one side of
the vehicle, you increase the tempera-
ture for the other side at the same
time.
i
If you turn the temperature control
counterclockwise until it stops for one
side of the vehicle, you decrease the
temperature for the other side at the
same time.
SymbolFunction
aDirects air through the center,
side and rear passenger
compartment air vents
ZDirects air to the windshield
and the side defroster vents
bDirects air into the entire
vehicle interior
YDirects air to the footwells

207 Controls in detail
Audio system
Manual tuning
Select desired waveband.
Press S or Tbutton for approx.
3 seconds.
Press button repeatedly until desired
frequency has been reached.
Step-by-step station tuning takes place
in ascending or descending order. Each
time the button is pressed, the radio
tunes further by 0.2 MHz. During
manual tuning, the radio is muted.
Automatic seek tuning
Select desired waveband.
Press S or T button briefly.
The radio will tune to the next highest
or next lowest receivable frequency.Scan search

Starting scan search
Select desired waveband.
Press SC soft key.
SC will appear in the display. The
radio briefly tunes in all receivable
stations on the waveband selected.

Ending scan search
Press SC soft key or S or T.
The station last played will be
selected and
SC disappears from
the display.Station memory
You can store ten AM and ten FM stations
in the memory.

Storing stations
Tune in desired station.
Press and hold desired station
button1 to R until a brief
signal tone is heard.
The frequency is stored on the
selected station button.

Calling up stations
Press desired station button1
to R briefly.
i
If no station is received after two
consecutive scans of the complete
frequency range, then the scan stops
at the frequency from which it began.

209 Controls in detail
Audio system
Search
Press S or T button to tune in
the next receivable weather band
station.Scan search
Starting scan search
Press SC soft key.
SC will appear in the display. The
radio briefly tunes in all receivable
weather band stations.

Ending scan search
Press SC soft key or S or T.
The weather band station last
played will be selected and
SC
disappears from the display.Introduction to satellite radio*
(USA only)
SIRIUS satellite radio provides 100 chan-
nels of digital-quality radio, among others
music, sports, news, and entertainment,
free of commercials. SIRIUS satellite radio
uses a fleet of high-power satellites to
broadcast 24 hours per day, coast to
coast, in the contiguous U.S.
This diverse, satellite-delivered program-
ming is available for a monthly subscrip-
tion fee.
For more information and service
availability, call the SIRIUS Service
Center (
page 210), or contact
www.siriusradio.com
i
If no weather band station is received
after three consecutive scans of the
complete frequency range, then the
scan stops at the channel with which it
began and
NO WB FOUND appears in the
display.
If this happens, switch back to
standard radio mode.

213 Controls in detail
Audio system
The system will automatically switch to
a station of the selected category if the
currently selected station is not of the
selected category. Otherwise, the
currently selected station remains
tuned.

Tuning a station within the selected
category
The channels identified for the
currently selected category are
arranged numerically. Only one entry is
visible at a time.
Press S or T button briefly.
The next station within the category
is started.
or
Press and hold S or T
button for approx. 3 seconds until
desired station has been reached.Tuning via scan search
Scan search is characterized as follows:

Scan search plays a channel for
approx. 8 seconds and then skips to
the next channel within the current cat-
egory.

Scan search can be terminated
manually.
Press SC soft key.
The search starts.
SC appears in the
display.
Press SC soft key again.
The search stops.Obtaining additional text information
Additional text information (artist, title)
related to the current channel can be
displayed.
Press INF soft key.
The title being played is displayed.
Press INF soft key again.
The name of the artist performing the
title being played is displayed.
i
If a button is not pressed within
4 seconds, the radio will return to the
standard display.

238 Controls in detail
Power windows
Opening and closing the windows
The side windows are opened and closed
electrically. The switches for all the side
windows are on the driver’s door. The
switches for the respective windows are
on the front passenger door and the rear
doors.
1Left front window
2Right front window
3Right rear window
4Left rear window
5Rear window override switch
(
page 80)
Warning!G
When closing the power windows, make
sure there is no danger of anyone being
harmed by the closing procedure.
The closing of the door windows can be im-
mediately halted by releasing the switch or,
if switch was pulled past the resistance
point and released, by either pressing or
pulling the respective switch.
If the window encounters an obstruction
t h a t b l o c k s i t s p a t h i n a c i r c u m s t a n c e w h e r e
you pulled the switch past the resistance
point and released it to close the window,
the automatic reversal function will stop the
window and open it slightly.
If the window encounters an obstruction
that blocks its path in a circumstance where
you are closing the window by pulling and
holding the switch, by pressing and holding
button‹ on the SmartKey, or by press-
ing and holding button, ore on the
automatic climate control panel, the auto-
matic reversal function will not operate.
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Unsuper-
vised use of vehicle equipment can cause an
accident and/or serious personal injury.

386 Practical hints
Unlocking/locking in an emergency
Unlocking the vehicle
If you are unable to unlock the vehicle with
the SmartKey, open the driver’s door and
the trunk using the mechanical key. Removing the mechanical key
1Mechanical key locking tab
2Mechanical key
Move locking tab1 in direction of
arrow.
Slide mechanical key2 out of the
housing.Unlocking the driver’s door
1Unlocking
Insert the mechanical key into the
driver’s door lock until it stops.
Turn the mechanical key counterclock-
wise to position1.
The driver’s door is unlocked.
i
Unlocking and opening the driver’s
door and/or the trunk with the me-
chanical key will trigger the anti-theft
alarm system*.
To cancel the alarm, do one of the
following:

Press buttonŒ or‹ on the
SmartKey.

Insert the SmartKey in the starter
switch.
