2006 LEXUS RX330 four wheel drive

GAUGES, METERS AND SERVICE REMINDER INDICATORS
83
(l) “VSC” Warning Light
This light warns that there is a problem somewhere in the
vehicle stability control system or traction control system.
The light will come on when the ignition key is turned to the
“ON” position and will go off after a few seconds.
If the light comes on while driving, the vehicle stability control
system and traction control system do not work. However, as
conventional braking operates when applied, there is no
problem to continue your driving.
In the following cases, contact your Lexus dealer:
 The warning light does not come on after the ignition key is
turned to the “ON” position.
 The warning light remains on after the ignition key is turned
to the “ON” position.
 The warning light comes on while driving.
Tw o −wheel drive models only — The “TRAC OFF” indicator
light will come on when the “VSC” warning light comes on even
if the “TRAC OFF” switch is not pushed.
(m) Automatic Transmission Fluid Temperature Warning Light
(fourwheel drive models only)
This light warns that the automatic transmission fluid
temperature is too high.
If this light comes on while you are driving, slow down and pull
off the road. Stop the vehicle at a safe place and put the
selector lever in “P” and leave the engine idling until the light
goes off. If the light goes off, you can start the vehicle again.
If the light does not go off, call a Lexus dealer or qualified repair
shop for assistance.
NOTICE
Continued driving with the warning light on may
damage the automatic transmission.
(n) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
nearly empty. Fill the tank as soon as possible.

SECTION 3 – 1
381
STARTING AND DRIVING
Starting and driving
Three−way catalytic converters382
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust caution 384
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before starting the engine 385
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch 385
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Parking brake 387
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
How to start the engine 388
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission (standard type) 389
. . . . . . . . . . . . . . . . . . . . .
Automatic transmission (multi −mode type) 398
. . . . . . . . . . . . . . . . . . .
Rear view monitor system 408
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise control 412
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Dynamic laser cruise control 416
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electronically modulated air suspension 437
. . . . . . . . . . . . . . . . . . . . .
Traction control system (two− wheel drive models) 449
. . . . . . . . . . . .
Traction control system (four −wheel drive models) 453
. . . . . . . . . . . .
Vehicle stability control system 455
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 458
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Tire pressure warning system 462
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pad wear limit indicators 465
. . . . . . . . . . . . . . . . . . . . . . . . . . . .

STARTING AND DRIVING
453
TRACTION CONTROL SYSTEM
(fourwheel drive modes)
The traction control system automatically helps prevent
the spinning of 4 wheels when the vehicle is started or
accelerated on slippery road surfaces.
When the ignition key is turned to “ON”, the system
automatically turns on.
CAUTION
Under certain slippery road conditions, full traction of
the vehicle and power against 4 wheels cannot be
maintained, even though the traction control system is
in operation. Do not drive the vehicle under any speed
or maneuvering conditions which may cause the
vehicle to lose traction control. In situations where the
road surface is covered with ice or snow, your vehicle
should be fitted with snow tires or tire chains. Always
drive at an appropriate and cautious speed for the
present road conditions.
Normal driving mode
 Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds just after the vehicle begins to move. This means that
the traction control system is in the self− check mode, but does
not indicate a malfunction.

DRIVING TIPS
485
Trailer towing tips
When towing a trailer, your vehicle will handle differently
than when not towing. The three main causes of
vehicletrailer accidents are driver error, excessive speed
and improper trailer loading. Keep these in mind when
towing:
 Before starting out, check the operation of the lights and all
vehicle −trailer connections. After driving a short distance,
stop and recheck the lights and connections. Practice
turning, stopping and backing with a trailer in an area away
from traffic until you learn the feel.
 Backing with a trailer is difficult and requires practice. Grip
the bottom of the steering wheel and move your hand to the
left to move the trailer to the left. Move your hand to the right
to move the trailer to the right. (This procedure is generally
opposite to that when backing without a trailer.) Also, just
turn the steering wheel a little at a time, avoiding sharp or
prolonged turning. Have someone guide you when backing
to reduce the risk of an accident.
 Because stopping distance may be increased,
vehicle −to−vehicle distance should be increased when
towing a trailer. For each 16 km/h (10 mph) of speed, allow
at least one vehicle and trailer length between you and the
vehicle ahead. Avoid sudden braking as you may skid,
resulting in jackknifing and loss of control. This is especially
true on wet or slippery surfaces.
Avoid jerky starts or sudden acceleration.
 Avoid jerky steering and sharp turns. The trailer could hit
your vehicle in a tight turn. Slow down before making a turn
to avoid the need of sudden braking.
 Remember that when making a turn, the trailer wheels will
be closer than the vehicle wheels to the inside of the turn.
Therefore, compensate for this by making a larger than
normal turning radius with your vehicle.
 Crosswinds and rough roads will adversely affect handling
of your vehicle and trailer, causing sway. Pay attention to
the rear from time to time to prepare yourself for being
passed by large trucks or buses, which may cause your
vehicle and trailer to sway. If swaying happens, firmly grip
the steering wheel and reduce speed immediately but
gradually. Never increase speed. If it is necessary to
reduce speed, brake slowly. Steer straight ahead. If you
make no extreme correction with the steering or brakes,
your vehicle and trailer will stabilize.
 Be careful when passing other vehicles. Passing requires
considerable distance. After passing a vehicle, do not forget
the length of your trailer and be sure you have plenty of room
before changing lanes.
 In order to maintain efficient engine braking and electrical
charging performance, do not use overdrive. Transmission
must be “4” position (with standard type) or the shift range
position must be “4” (fourth range) in “S” mode (with
multi−mode type).

IN CASE OF AN EMERGENCY
517
Fourwheel drive models
Use a towing dolly under the rear wheels.
NOTICE
Never tow from the front with rear wheels on the ground,
as this may cause serious damage to the transmission.
 From rear
Use a towing dolly under the front wheels.
NOTICE
Never tow from the rear with front wheels on the ground,
as this may cause serious damage to the transmission.

IN CASE OF AN EMERGENCY
521
NOTICE
Only use specified towing eyelet; otherwise your
vehicle may be damaged.
 Never tow a vehicle from the rear with four wheels on
the ground. This may cause serious damage to the
transmission.
A driver must be in the vehicle to steer it and operate the
brakes.
Towing in this manner may be done only on hard −surfaced
roads for a short distance and at low speeds. Also, the wheels,
axles, drive train, steering and brakes must all be in good
condition.
CAUTION
Use extreme caution when towing the vehicle. Avoid
sudden starts or erratic driving maneuvers which would
place excessive stress on the emergency towing eyelet
and towing cable or chain. The eyelet and towing cable
or chain may break and cause serious injury or damage.
NOTICE
Use only a cable or chain specifically intended for use
in towing vehicles. Securely fasten the cable or chain
to the towing eyelet provided.
Before towing, release the parking brake and put the
transmission in “N”. The ignition key must be in “ACC” (engine
off) or “ON” (engine running).
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work so steering and
braking will be much harder than usual.

INTRODUCTION
545
Rear (Fourwheel drive models)
When jacking up your vehicle with the jack, position the
jack correctly as shown in the illustrations.
CAUTION
When jacking, be sure to observe the following to
reduce the possibility of personal injury:
 Follow jacking instructions.
 Do not put any part of your body under the vehicle
supported by the jack. Otherwise, personal injury
may occur.
 Do not start or run the engine while your vehicle is
supported by the jack.
 Stop the vehicle on a level firm ground, firmly set the
parking brake and put the transmission in “P”. Block
the wheels on the opposite side of the jack up point
if necessary.
 Make sure to set the jack properly in the jack point.
Raising the vehicle with jack improperly positioned
will damage the vehicle or may allow the vehicle to fall
off the jack and cause personal injury.
 Never get under the vehicle when the vehicle is
supported by the jack alone; use vehicle support
stands.
 Do not raise the vehicle with someone in the vehicle.

CHASSIS
586
This applies also to the spare tire and tires stored
for future use.
Tire selection
When replacing a tire, use a tire of the same size
and construction, and the same or greater
maximum load as the originally installed tires.
Also, on fourwheel drive models, all the tires
must be the same brand and have the same tread
patterns.
Using any other size or type of tire may seriously
affect handling, ride, speedometer/odometer
calibration, ground clearance, and clearance between
the body and tires or snow chains.
Check that the maximum load of the replaced tire is
greater than 1/2 of the Gross Axle Weight Ratings
(GAWR) of either the front axle or the rear axle,
whichever is greater. As for the maximum load of
the tire, see the load limit at maximum cold tire
inflation pressure mentioned on the sidewall of the tire,
and as for the Gross Axle Weight Ratings (GAWR),
see the Certification Label. For details about
Certification Label and sidewall of the tire, see pages
536 and 573.
CAUTION
Observe the following instructions. Otherwise,
an accident may occur resulting in death or
serious injuries.
Do not mix radial, bias belted, or biasply tires
on your vehicle, as this may cause dangerous
handling characteristics resulting in loss of
control.
 Do not use tires other than the manufacturer’s
recommended size, as this may cause
dangerous handling characteristics resulting
in loss of control.
 Fourwheel drive models:
Do not use tires of different brands, sizes,
construction or tread patterns, as this may
cause dangerous handling characteristics
resulting in loss of control.
