2006 LEXUS LX470 change

OCCUPANT RESTRAINT SYSTEMS
106
Adjusting seat cushion angle and height
16X004d
Move the control switch in the desired direction.
Releasing the switch will stop the seat cushion in that position.
Adjusting lumbar support
16X005c
Push the control switch on either side.
The amount of lumbar support will change while the switch is
pushed.

OCCUPANT RESTRAINT SYSTEMS
132
CAUTION
Do not modify, remove, strike or open the seat belt
pretensioner assemblies, airbag sensor or
surrounding area or wiring. Failure to follow these
instructions may prevent the seat belt pretensioners
from activating correctly, cause sudden operation of
the system or disable the system, which could result
in death or serious injury.
 Do not use tires or wheels other than the
manufacturer’s recommended size. Such a use may
cause the curtain shield airbags and seat belt
pretensioners to inflate accidentally, resulting in
death or serious injury. For details, see “Checking
and replacing tires” on page 438.
 Do not place luggage heavier than specified on the
roof luggage carrier. Such luggage may cause the
curtain shield airbags and seat belt pretensioners to
inflate accidentally, resulting in death or serious
injury. For details, see “Roof luggage carrier” on
page 88.
 Do not modify or change the suspension system.
Such changes may cause the curtain shield airbags
to inflate accidentally, resulting in death or serious
injury.
Failure to follow these instructions can result in death
or serious injury. Consult your Lexus dealer before
performing any repair and modification.
NOTICE
Do not perform any of the following changes without
consulting your Lexus dealer. Such changes can
interfere with proper operation of the seat belt
pretensioners in some cases.
 Installation of electronic devices such as a mobile
twoway radio, cassette tape player or CD player.
 Repairs on or near the seat belt retractor assemblies.
 Modification of the front end structure.
 Attachment of a grille guard (bull bar, kangaroo bar,
etc.), snowplow, winches or any other equipment to
the front end.
 Repairs made on or near the front fenders, front end
structure or console.

OCCUPANT RESTRAINT SYSTEMS
141
16X655a
Do not put anything or any parts of your body on or
in front of the dashboard or steering wheel pad that
houses the driver and front passenger airbag
system. They might restrict inflation or cause death
or serious injury as they are projected rearward by
the force of the deploying airbags. Likewise, the
driver and front passenger should not hold objects in
their arms or on their knees.
 Do not modify or remove any wiring. Do not modify,
remove, strike or open any components, such as the
steering wheel pad, steering wheel, column cover,
dashboard near the front passenger airbag, front
passenger airbag cover, front passenger airbag or
airbag sensor assembly. Doing so may prevent the
front airbag system from activating correctly, cause
sudden activation of the system or disable the
system, which could result in death or serious injury.
 Do not use seat accessory, such as a cushion or seat
cover, that covers the front seat, or do not modify or
replace the upholstery of the front seat. Such
accessories or changes may prevent the front
passenger airbag system from activating correctly,
disable the system or cause the front passenger
airbag to inflate accidentally, resulting in death or
serious injury.
Failure to follow these instructions can result in death
or serious injury. Consult your Lexus dealer about any
repair and modification.
If you wish to modify your vehicle for a person with a
physical disability, consult y our Lexus dealer. It may
dangerously interfere with the SRS side airbags and
curtain shield airbags operation.

OCCUPANT RESTRAINT SYSTEMS
142
NOTICE
Do not perform any of the following changes without
consulting your Lexus dealer. Such changes can
interfere with proper operation of the SRS front airbag
system in some cases.
Installation of electronic devices such as a mobile
twoway radio, cassette tape player or CD player.
 Modification of the front end structure.
 Attachment of a grille guard (bull bar, kangaroo bar,
etc.), snowplow, winches or any other equipment to
the front end.
 Repairs made on or near the front fenders, front end
structure, console, steering column, steering wheel,
dashboard near the front passenger airbag or front
seats.
16x502a
This indicator comes on when the ignition key is turned to
the “ON” position. It goes off after about 6 seconds. This
means the SRS front airbags are operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver’s seat position sensor, driver’s seat belt buckle switch,
front passenger occupant classification system and indicator
light, front passenger’s seat belt buckle switch, seat belt
pretensioner assemblies, inflators, roll sensing of curtain
shield airbags off indicator light, interconnecting wiring and
power sources. (For details, see “Service reminder indicators
and warning buzzers” on page 52.)

OCCUPANT RESTRAINT SYSTEMS
154
16x512a
Do not attach a microphone or any other device or
object around the area where the curtain shield
airbag activates such as on the windshield glass,
side door glass, front, center and roof side garnish,
roof interior or assist grips. When the curtain shield
airbag inflates, the microphone or other device or
object will be thrown away with great force or the
curtain shield airbag may not activate correctly,
resulting in death or serious injury.
 Do not hook a hanger , heavy or sharp pointed objects
on the coat hook. If the curtain shield airbag inflates,
those items will be hurled away with great force or the
curtain shield airbag may not activate correctly,
which could result in death or serious injury. When
you hang clothes, hang them on the coat hook
directly.
 Do not use seat accessories which cover the parts
where the side airbags inflate. Su ch accessories may
prevent the side airbags from activating correctly,
causing death or serious injury.
 Do not modify or replace the seats or upholstery of
the seats with side airbags. Such changes may
prevent the side airbag system from activating
correctly disable the system or cause the side
airbags to inflate accidentally, resulting in death or
serious injury.
 Do not disassemble or repair the front and rear pillars
and roof side rail containing the curtain shield
airbags. Such changes may disable the system or
cause the curtain shield airbags to inflate
accidentally, resulting in death or serious injury.
 Do not modify or change the suspension system.
Such changes may cause the curtain shield airbags
to inflate accidentally, which could result in death or
serious injury.
 Do not use tires or wheels other than the
manufacturer’s recommended size. Such a use may
cause the curtain shield airbags to inflate
accidentally, which could result in death or serious
injury. For details, see “Checking and replacing
tires” on page 438.
 Do not place luggage heavier than specified on the
roof luggage carrier. Such luggage may cause the
curtain shield airbags to inflate accidentally, which
could cause in death or serious injury. For details,
see “Roof luggage carrier” on page 88.

OCCUPANT RESTRAINT SYSTEMS
155
Failure to follow these instructions can result in death
or serious injury. Consult your Lexus dealer about any
repair and modification.
If you wish to modify your vehicle for a person with a
physical disability, consult your Lexus dealer. It may
dangerously interfere with the SRS side airbags and
curtain shield airbags operation.
NOTICE
Do not perform any of the following changes without
consulting your Lexus dealer. Such changes can
interfere with proper operation of the SRS side airbag
and curtain shield airbag system in some cases.
Installation of electronic devices such as a mobile
twoway radio, cassette tape player or CD player.
 Modification of the side structure of the passenger
compartment.
 Repairs made on or near the console, or front seats.
16x502a
This indicator comes on when the ignition switch is turned
to the “ON” position. It goes off after about 6 seconds.
This means the SRS side airbags and curtain shield
airbags are operating properly.
This warning light system monitors the airbag sensor
assembly, front airba g sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver’s seat position sensor, driver’s seat belt buckle switch,
front passenger occupant classification system and indicator
light, front passenger’s seat belt buckle switch, seat belt
pretensioner assemblies, inflators, roll sensing of curtain
shield airbags off indicator light, interconnecting wiring and
power sources. (For details, see “Service reminder indicators
and warning buzzers” on page 52.)

OCCUPANT RESTRAINT SYSTEMS
189
DRIVING POSITION MEMORYSYSTEM
A microcomputer will memorize the position of the driver’s
seat, and the positions of the tilt and telescopic steering, and
outside rear view mirrors. Two different driving position
profiles can be entered into the computer’s memory.
Recording the driving position in the computer’s memory can
only be done when the ignition key is in the “ON” position and
the selector lever is in the “P” position.
Setting the driving position
16X162
1. Adjust the driver’s seat, tilt and telescopic steering and
outside rear view mirrors to the desired position.
2. While pushing the “SET” button, push button “1” or “2”
until the signal beeps. The beep sound means that the positions are recorded in the
computer’s memory.
By repeating these two steps
and pressing the remaining
button, the driving position for another driver can be recorded.
To set a new memorized position, select the desired position
and perform step 2. The previous memory will be erased and
the new position will be set.
To make only slight changes to an already memorized position,
the easiest way is to first activate the memorized position, then
make the desired changes and perform step 2 above.
Recalling the memorized position
16X163
When you push button “1” or “2”, the driving position will
be automatically adjusted to the position recorded for that
button.

STEERING WHEEL AND MIRRORS
196
INSIDE REAR VIEW MIRROR
16X016e
Adjust the mirror so that you can just see the rear of your
vehicle in the mirror.
Pushing the switch changes the mode between “AUTO”
and “DAY”.
The indicator comes on when the “AUTO” mode is selected.
“DAY” mode: The mirror surface is normal.
“AUTO” mode: If the mirror detects light from the
headlights of the vehicle behind you, the mirror surface
darkens slightly to reduce the reflected light.
When the inside rear view mirror surface changes, the outside
rear view mirror surfaces will also become darker.
When the ignition key is inserted and turned on, the inside rear
view mirror always turns on in the “AUTO” mode. When
the inside air temperature is low, it may take a little longer
for the mirror to darken in response to the detection of
headlights.
CAUTION
Do not adjust the mirror while the vehicle is moving.
Doing so may cause the driver to mishandle the vehicle
and an accident may occur resulting in death or serious
injuries.
16x658b
To ensure correct functioning of antiglare mirror sensors
located on both sides of the mirror, do not touch or cover
the sensors with your finger or a piece of cloth, etc.
