2006 Lexus ES330 Basic Functions In Frequent Use / OWNER'S MANUAL (OM33703U)

OCCUPANT RESTRAINT SYSTEM
clxxi

SECTION 1 – 7
clxxii
INSTRUMENTS AND CONTROLS
Steering wheel and mirrors
Tilt steering columnclxxiii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power adjustable pedals clxxiii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirrors clxxiv
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside rear view mirror clxxvii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vanity mirrors clxxxii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .

STEERING WHEEL AND MIRRORS
clxxiii
TILT STEERING COLUMN
To change the steering wheel angle, hold the steering
wheel, pull up the lock release lever, tilt the steering wheel
to the desired angle and release the lever.
When the steering wheel is in a low position, it will spring up as
you release the lock release lever.
CAUTION
 Do not adjust the steering wheel while the vehicle is
moving. Doing so may cause the driver to mishandle
the vehicle and an accident may occur resulting in
death or serious injuries.
 After adjusting the steering wheel, try moving it up
and down to make sure it is locked in position.
POWER ADJUSTABLE PEDALS
To adjust the position of the accelerator and brake pedals,
push the switch.
The ignition key must be in the “ON” position with the automatic
transmission selector lever in the “P” position.
To move the pedals toward the front of the vehicle: Push the
“
” side of the switch.
To move the pedals back toward you: Push the “
” side of the
switch.
The accelerator and brake pedals will move simultaneously.

STEERING WHEEL AND MIRRORS
clxxivWhen you set your driving position:
1. Set the parking brake firmly.
2. Move the accelerator and brake pedals to the front most
position.
3. Adjust the seat position and steering wheel angle properly.
(See pages cviii and clxxiii.)
4. Move the pedals toward you
until you can fully depress the
brake pedal.
5. After adjusting, depress the pedals a few times to get used
to the feel.
CAUTION
 Never put your foot on the accelerator pedal while the
pedals are moving. It may cause racing of the engine
or sudden acceleration.
 Make sure that you can fully depress the brake pedal
before driving. Otherwise, you may not be able to
hold down the brake pedal firmly in an emergency
stop.
OUTSIDE REAR VIEW MIRRORS
Adjust the mirror so that you can just see the side of your
vehicle in the mirror.
Be careful when judging the size or distance of any object seen
in the outside rear view mirror on the passenger’s side
because it is a convex mirror. Any object seen in a convex
mirror will look smaller and farther away than if seen in a normal
flat mirror.
When the inside rear view mirror darkens in AUTO mode, the
outside rear view mirrors also darken to reduce the reflection
of the headlights of the following vehicle. For details, see
“Inside rear view mirror” on page clxxvii.

STEERING WHEEL AND MIRRORS
clxxv
When you push the rear window and outside rear view mirror
defogger switch, the heater panels in the outside rear view
mirrors
will quickly clear the mirror surface. (See “Rear window
and outside rear view mirror defogger switch” on page xliv.)
CAUTION
 Do not adjust the mirror while the vehicle is moving.
Doing so may cause the driver to mishandle the
vehicle and an accident may occur resulting in death
or serious injuries.
 Since the mirror surfaces can get hot, do not touch
them when the rear window and outside rear view
mirror defogger switch is on.
Power rear view mirror control
1Control switch2Master switch
To adjust the power rear view mirror, first place the master
switch at “L” (left) or “R” (right), and push the contro\
l
switch on the desired side.
The power rear view mirror can be adjusted when the key is in
the “ACC” or “ON” position.

STEERING WHEEL AND MIRRORS
clxxviVehicles with driving position memory system —
When
the automatic transmission selector lever is shifted
into the “R” position with the master switch in the “L” or
“R” position, the rear view mirrors automatically down to
help backing up.
The mirrors return to the previous position in the following
operations.
 Shift the transmission lever out of the “R” position.
 Place the master switch in the neutral position.
NOTICE
If ice should jam the mirror, do not operate the control
or scrape the mirror face. Use a spray deicer to free the
mirror.
Folding rear view mirrors
To fold the rear view mirror, push backward.
The rear view mirrors can be folded backward for parking in
compact areas.
CAUTION
Do not drive with the mirrors folded backward. Both the
driver and passenger side rear view mirrors must be
extended and properly adjusted before driving.

STEERING WHEEL AND MIRRORS
clxxvii
INSIDE REAR VIEW MIRROR
Adjust the mirror so that you can just see the rear of your
vehicle in the mirror.
Pushing the “MIRROR” switch changes the mode
between AUTO and DAY.
The indicator comes on when the AUTO mode is selected.
DAY mode: The mirror surface is normal.
AUTO mode: If the mirror detects light from the headlights
of the vehicle behind you, the mirror surface darkens
slightly to reduce the reflected light.
When the inside rear view mirror surface changes, the outside
rear view mirror surfaces will also become darker.
When the ignition key is inserted and turned on, the inside rear
view mirror always turns on in the AUTO mode. When the outside air temperature is low, it may take a little
longer for the mirror to darken in response to the detection of
headlights.
CAUTION
Do not adjust the mirror while the vehicle is moving.
Doing so may cause the
driver to mishandle the vehicle
and an accident may occur resulting in death or serious
injuries.
To ensure correct functioning of antiglare mirror sensors
located on both sides of the mirror, do not touch or cover
the sensors with your finger or a piece of cloth, etc.

STEERING WHEEL AND MIRRORS
clxxviii
Compass
The compass indicates the direction in which the vehicle
is heading. The illustration shown above indicates the
vehicle is heading north.
Push the “COMP” switch to turn the compass system on
and off.
If the ignition switch was turned off with the system on, the
system will automatically turn back on when the ignition switch
is turned on. Displays
Directions
N
NE E
SE S
SW W
NWNorth
Northeast East
Southeast South
Southwest West
Northwest
The compass may not show the correct direction in the
following conditions:
 The vehicle is stopped immediately after turning.
The compass does not adjust while the vehicle is stopped.
 The ignition switch is turned off immediately after turning.
 The vehicle is on an inclined surface.
 The vehicle is in a place where the earth’s magnetic field is
subject to interference by artificial magnetic fields
(underground parking, under a steel tower, between
buildings, roof parking, near a crossing, near a large vehicle,
etc.).
 The vehicle is magnetized. (There is a magnet or a metal
object on or near the inside rear view mirror.)
 The battery has been disconnected.
