MA-8
PERIODIC MAINTENANCE
Revision: November 20092006 QX56
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace drive belts if da maged.
(2) If operating mainly in dusty conditions, more frequent maintenance may be required.
(3) Maintenance-free item. For service procedures, go to the FL section.
(4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(5) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with “ *” are recommended by NISSAN for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and inter vals are
required.
CHASSIS AND BODY MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate. [ ]: At the mileage intervals only.
MAINTENANCE OPERATION
MAINTENANCE INTERVAL
Reference
Section -
Page or -
Content Title
Perform at number of miles, kilo-
meters or months, whichever
comes first. Miles x 1,000
(km x 1,000) Months 33.75
(54)27 37.5
(60) 30 41.25
(66)33 45
(72) 36 48.75
(78)39 52.5
(84) 42 56.25
(90)45 60
(96) 48
Drive belts NOTE (1) I*MA-13
Air cleaner filter NOTE (2) [R]MA-16
EVAP vapor lines I*MA-20
Fuel lines I*MA-16
Fuel filter NOTE (3) —
Engine coolant NOTE (4) R*MA-13
Engine oil R R R R R R R R MA-17
Engine oil filterR R R R R R R R MA-17
Spark plugs (double PLATINUM-
TIPPED type)Replace every 105,000 miles (169,000 km).
MA-18
Intake and exhaust valve clear-
ance*NOTE (5)
EM-105
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
Section- Page
or
- Content Title
Perform at number of miles, kilometers or
months, whichever comes first. Miles x
1,000(km x
1,000)
Months 3.75
(6)
3 7.5
(12)
6 11 . 2 5
(18)
9 15
(24)
12 18.75
(30)
15 22.5
(36)
18 26.25
(42)
21 30
(48)
24
Brake lines and cables IIMA-28
Brake pads and rotors II IIMA-28
Automatic transmission fluid NOTE (1)IIMA-22
Transfer fluid and front final drive oil NOTE (1)IIMA-25,
MA-25
Rear final drive oil NOTE (1)IIMA-25,
MA-25
Steering gear and linkage, axle and suspen-
sion parts IIII
MA-29,
MA-30
Tire Rotation NOTE (2) MA-28
Drive shaft boots and propeller shaft (4WD)II IIMA-25
Exhaust system II IIMA-22
In-cabin microfilter RRMA-21

PERIODIC MAINTENANCEMA-9
C
DE
F
G H
I
J
K
M A
B
MA
Revision: November 2009 2006 QX56
(1) If towing a trailer, or using a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles
(48,000 km) or 24 months.
(2) Refer to “ Tire rotation” under the “General maintenance ” heading earlier in this section.
Schedule 2ELS001BM
EMISSION CONTROL SYSTEM MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace drive belts if da maged.
(2) Maintenance-free item. For service procedures, go to FL section.
(3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(4) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with “* ” are recommended by NISSAN for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and inter vals are
required. MAINTENANCE OPERATION
MAINTENANCE INTERVAL
Reference
Section- Page or
- Content Title
Perform at number of miles, kilometers or
months, whichever comes first. Miles x
1,000(km x
1,000)
Months 33.75
(54)27 37.5
(60) 30 41.25
(66)33 45
(72) 36 48.75
(78)39 52.5
(84) 42 56.25
(90)45 60
(96) 48
Brake lines and cables IIMA-28
Brake pads and rotors IIIIMA-28
Automatic transmission fluid NOTE (1)IIMA-22
Transfer fluid and front final drive oil NOTE (1)IIMA-25,
MA-25
Rear final drive oil NOTE (1)IIMA-25,
MA-25
Steering gear and linkage, axle and suspen-
sion parts IIIIMA-29,
MA-30
Tire Rotation NOTE (2) MA-28
Drive shaft boots and propeller shaft (4WD)IIIIMA-25
Exhaust system IIIIMA-22
In-cabin microfilter RRMA-21
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Reference
Section - Page
or - Content Title
Perform at number of miles, kilome-
ters or months, whichever comes first. Miles x 1,000
(km x 1,000)
Months 7.5
(12)
6 15
(24)
12 22.5
(36)
18 30
(48)
24 37.5
(60)
30 45
(72)
36 52.5
(84)
42 60
(96)
48
Drive belts NOTE (1) I*MA-13
Air cleaner filter [R][R]MA-16
EVAP vapor lines I*I*MA-20
Fuel lines I*I*MA-16
Fuel filter NOTE (2) —
Engine coolant NOTE (3) R*MA-13
Engine oil R R R R R R R R MA-17
Engine oil filterR R R R R R R R MA-17
Spark plugs (PLATINUM-TIPPED
type) Replace every 105,000 miles (169,000 km).
MA-18
Intake and exhaust valve clearance* NOTE (4) EM-105

MA-10
PERIODIC MAINTENANCE
Revision: November 20092006 QX56
CHASSIS AND BODY MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate. [ ]: At the mileage interval only.
(1) Refer to “ Tire rotation” under the “ General maintenance ” heading earlier in this section.
MAINTENANCE OPERATION
MAINTENANCE INTERVALReference
Section
- Page or
- Content
Title
Perform at number of miles, kilometers or
months, whichever comes first.
Miles x 1,000
(km x 1,000) Months 7.5
(12) 6 15
(24) 12 22.5
(36) 18 30
(48) 24 37.5
(60) 30 45
(72) 36 52.
5
(84)
42 60
(96) 48
Brake lines and cables IIIIMA-28
Brake pads and rotors IIIIMA-28
Automatic transmission fluid IIIIMA-22
Transfer fluid and front final drive oil IIIIMA-25,
MA-25
Rear final drive oil IIIIMA-25,
MA-25
Steering gear and linkage, axle and suspen-
sion parts. IIMA-29,
MA-30
Tire rotation NOTE (1) MA-28
Drive shaft boots and propeller shaft
(4WD)IIII
MA-25
Exhaust system IIMA-22
In-cabin microfilter RRRRMA-21

RECOMMENDED FLUIDS AND LUBRICANTSMA-11
C
DE
F
G H
I
J
K
M A
B
MA
Revision: November 2009 2006 QX56
RECOMMENDED FLUIDS AND LUBRICANTSPFP:00000
Fluids and LubricantsELS001BN
*1: For further details, refer to MA-12, "SAE Viscosity Number" .
*2: Using automatic transmission fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic
transmission durability, and may damage the automatic transmission, which is not covered by the NISSAN new vehicle limited warr anty.
*3: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRON
TM III or MERCONTM or equivalent ATF may also be used.
*4: Available in mainland U.S.A. through your NISSAN dealer.
*5: For further details, see “Air conditioner specification label ”.
*6: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 0 ° C (32° F).
*7: DEXRON
TM III, MERCONTM or equivalent may also be used. Outside the continental United States and Alaska contact a NISSAN
dealership for more information regarding suitable fluids, including recommended brand(s) of DEXRONTM III or MERCONTM Automatic
Transmission Fluid.
*8: For improved vehicle performance, NISSAN recommends the use of unleaded premium gasoline with an octane rating of at least 91
AKI (RON 96). For further details, refer to GI-5, "
Precautions for Fuel (Unleaded Premium Gasoline Required)" .
*9: See your INFINITI dealer for service for synthetic oil. Description
Capacity (Approximate)
Recommended Fluids/Lubricants
Metric US measure Imp measure
Fuel 105.8 28 gal 23 1/4 gal Unleaded gasoline with octane rating of
at least 87 AKI (RON 91) *8
Engine oil
Drain and refill With oil filter
change
6.2
6 1/2 qt 5 1/2 qt

API Certification Mark *1

API grade SG, Energy Conserving II or
API grade SH, SJ or SL *1

ILSAC grade GF-II and GF-III *1
Without oil filter
change
5.9
6 1/4 qt 5 1/4 qt
Dry engine (engine overhaul) 7.6 8 qt
6 3/4 qt
Cooling system With reservoir
at MAX level
14.4
3 3/4 gal 3 1/8 gal Genuine NISSAN Long Life Anti-freeze
coolant or equivalent
Automatic transmission fluid (ATF) 10.6 11 1/4 qt 9 3/8 qt Genuine NISSAN Matic J ATF *2
Rear final drive oil 1.75 3 3/4 pt 3 1/8 pt API GL-5 Synthetic 75W-90 Gear Oil
(Part No. 999MP-DF200p) or equivalent
*9
Transfer fluid 3.0 3 1/8 qt 2 5/8 qt Genuine NISSAN Matic D ATF (Conti-
nental U.S and Alaska) or Canada NIS-
SAN Automatic Transmission Fluid *7
Front final drive oil 1.6 3 3/8 pt 2 7/8 pt API GL-5 Viscosity SAE 80W-90 *6
Power steering fluid (PSF) 1.0 2 1/8 pt 1 3/4 pt Genuine NISSAN PSF or equivalent *3
Brake fluid ——— Genuine NISSAN Super Heavy Duty
Brake Fluid or equivalent,
DOT 3 (US FMVSS No. 116) *4
Brake grease ——— PBC (poly butyl cuprysil) grease or
equivalent
Multi-purpose grease ——— NLGI No. 2 (lithium soap base)
Windshield washer fluid 4.5 1 1/4 gal 1 gal Genuine NISSAN Windshield Washer
Concentrate Cleaner & Anti-freeze or
equivalent
Air conditioning system refrigerant 1.08 ± 0.05 kg 2.38 ± 0.11 lb 2.38 ± 0.11 lb HFC-134a (R-134a) *5
Air conditioning system oil 290 m9.8 fl oz 10.2 fl oz NISSAN A/C System Oil Type S or
equivalent *5

CHASSIS AND BODY MAINTENANCEMA-29
C
DE
F
G H
I
J
K
M A
B
MA
Revision: November 2009 2006 QX56
CALIPER
Check the caliper for any leaks, repair as necessary.
PA D
Check the pads for wear or damage. Refer to BR-32, "Front Disc
Brake" , BR-33, "Rear Disc Brake" .
Checking Steering Gear and LinkageELS001CD
STEERING GEAR

Check the steering gear housing for looseness, damage and oil
leakage as shown.

Check the steering column connections for looseness.
STEERING LINKAGE

Check the ball joint, dust cover and other component parts for looseness, wear, damage, and grease leak-
age.
Checking Power Steering Fluid and LinesELS001CE
CHECKING FLUID LEVEL

Check the power steering fluid level with the engine off.

Check fluid level on reservoir. Use “HOT ” range at fluid tempera-
tures of 50 ° to 80 °C (122 ° to 176 °F). Use “COLD” range at fluid
temperatures of 0 ° to 30 °C (32 ° to 86 °F).
CAUTION:

Do not overfill.

Refer to MA-11, "Fluids and Lubricants" .
SMA922A
LMA051
SGIA0506E
LGIA0021E

PS-1
POWER STEERING SYSTEM
G STEERING
CONTENTS
C
DE
F
H I
J
K L
M
SECTION
A
B
PS
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 2
Precautions for Steering System ......................... ..... 2
PREPARATION ...................................................... ..... 3
Special Service Tools (SST) ................................ ..... 3
Commercial Service Tools ................................... ..... 4
NOISE, VIBRATION, AND HARSHNESS (NVH)
TROUBLESHOOTING ........................................... ..... 5
NVH Troubleshooting Chart ................................ ..... 5
POWER STEERING FLUID ................................... ..... 6
Checking Fluid Level ........................................... ..... 6
Checking Fluid Leakage ...................................... ..... 6
Air Bleeding Hydraulic System ............................ ..... 6
STEERING WHEEL .................................................... 7 On-Vehicle Inspection and Service ..................... ..... 7
CHECKING CONDITION OF INSTALLATION . ..... 7
CHECKING STEERING WHEEL PLAY ........... ..... 7
CHECKING NEUTRAL POSITION ON STEER-
ING WHEEL ..................................................... ..... 7
CHECKING STEERING WHEEL TURNING
FORCE ............................................................. ..... 7
CHECKING FRONT WHEEL TURNING ANGLE ..... 8
Removal and Installation ..................................... ..... 8
REMOVAL ........................................................ ..... 8
INSTALLATION ................................................ ..... 8
TILT SYSTEM ............................................................. 9 Removal and Installation ..................................... ..... 9
TILT MOTOR AND TILT SENSOR ................... ..... 9
STEERING COLUMN ............................................ ... 10
Removal and Installation ..................................... ... 10
REMOVAL ........................................................ ... 10
INSPECTION AFTER REMOVAL .................... .... 11
INSTALLATION ................................................ .... 11INSPECTION AFTER INSTALLATION .............
... 12
Disassembly and Assembly ................................. ... 13
DISASSEMBLY ................................................ ... 13
ASSEMBLY ...................................................... ... 14
INSPECTION AFTER ASSEMBLY ................... ... 14
POWER STEERING GEAR AND LINKAGE ......... ... 15
Removal and Installation ..................................... ... 15
REMOVAL ........................................................ ... 15
INSTALLATION ................................................ ... 16
INSPECTION AFTER INSTALLATION ............. ... 17
Disassembly and Assembly ................................. ... 17
DISASSEMBLY ................................................ ... 17
INSPECTION AFTER DISASSEMBLY ............. ... 18
ASSEMBLY ...................................................... ... 19
POWER STEERING OIL PUMP ............................ ... 21
On-Vehicle Inspection and Service ...................... ... 21
CHECKING RELIEF OIL PRESSURE ............. ... 21
Removal and Installation ..................................... ... 21
REMOVAL ........................................................ ... 21
INSTALLATION ................................................ ... 21
Disassembly and Assembly ................................. ... 22
INSPECTION BEFORE DISASSEMBLY .......... ... 22
DISASSEMBLY ................................................ ... 22
INSPECTION AFTER DISASSEMBLY ............. ... 22
ASSEMBLY ...................................................... ... 22
HYDRAULIC LINE ................................................. ... 23
Removal and Installation ..................................... ... 23
SERVICE DATA AND SPECIFICATIONS (SDS) ... ... 25
Steering Wheel .................................................... ... 25
Steering Column .................................................. ... 25
Steering Outer Socket and Inner Socket ............. ... 26
Steering Gear ...................................................... ... 27
Oil Pump ................................................................. 27
Steering Fluid .......................................................... 27

NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTINGPS-5
C
DE
F
H I
J
K L
M A
B
PS
Revision: November 2009 2006 QX56
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartEGS000U8
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference page
PS-6PS-6PS-18PS-18PS-18PS-6PS-7PS-7
EM-13, "
Checking Drive Belts
"
PS-7PS-13PS-15PS-11PS-10PS-15

PR-3, "
NVH Troubleshooting Chart
"
FFD-6, "
NVH Troubleshooting Chart
"
FAX-4, "
NVH Troubleshooting Chart
"
FSU-4, "
NVH Troubleshooting Chart
"
WT-4, "
NVH Troubleshooting Chart
"
WT-4, "
NVH Troubleshooting Chart
"
FAX-4, "
NVH Troubleshooting Chart
"
BR-5, "
NVH Troubleshooting Chart
"
Possible cause and sus-
pected parts
Fluid level
Air in hydraulic system
Outer socket ball joint swinging force
Outer socket ball joint rotating torque
Outer socket ball joint end play
Steering fluid leakage
Steering wheel play
Steering gear rack sliding force
Drive belt looseness
Improper steering wheel
Improper installation or looseness of tilt lock lever
Mounting rubber deterioration
Steering column deformation or damage
Improper installation or looseness of steering column
Steering linkage looseness
PROPELLER SHAFT
FRONT FINAL DRIVE
WHEEL HUB
SUSPENSION
TIRES
ROAD WHEEL
DRIVE SHAFT
BRAKES
Symptom Noise
× × ××××× × × ××××××× ×
Shake ×××× ××××× ×
Vibration ××××× × ××× ×
Shimmy ××× × ×××× ×
Shudder × × ×××× ×

PS-6
POWER STEERING FLUID
Revision: November 20092006 QX56
POWER STEERING FLUIDPFP:KLF20
Checking Fluid LevelEGS000U9
Check power steering fluid level with engine off, referring to the scale
on reservoir tank.
Use HOT range for fluid temperatures of 50° – 80 °C (122 ° – 176° F).
Use COLD range for fluid temperatures of 0 ° – 30° C (32 ° – 86 °F).
CAUTION:

Do not overfill.

Do not reuse any used power steering fluid.

Recommended fluid is Genuine NISSAN PSF or equivalent.
Refer to MA-11, "
RECOMMENDED FLUIDS AND LUBRI-
CANTS" .
Checking Fluid LeakageEGS000UA
Check the hydraulic piping lines for improper attachment and for
leaks, cracks, damage, loose connections, chafing or deterioration.
1. Run engine until fluid temperature reaches 50 ° – 80 °C (122 ° –
176° F) in reservoir tank. Keep engine speed idle.
2. Turn steering wheel right-to-left several times.
3. Hold steering wheel at each “lock” position for five seconds to
check fluid leakage.
CAUTION:
Do not hold steering wheel in a locked position for more
than 10 seconds. (There is the possibility that oil pump may
be damaged.)
4. If fluid leakage at connections is noticed, then loosen flare nut and then retighten. Do not over tighten con- nector as this can damage O-ring, washer and connector.
5. If fluid leakage from oil pump is noticed, check oil pump. Refer to PS-21, "
POWER STEERING OIL
PUMP" .
6. Check steering gear boots for accumulation of fluid indicating a leak from the steering gear.
Air Bleeding Hydraulic SystemEGS000UB
Incomplete air bleeding causes the following. When this happens, bleed air again.

Air bubbles in reservoir tank.

Clicking noise in oil pump.

Excessive buzzing in oil pump.
NOTE:
When vehicle is stationary or while steering wheel is being turned slowly, some noise may be heard from
oil pump or gear. This noise is normal and does not affect any system.
1. Stop engine, and then turn steering wheel fully to right and left several times. CAUTION:
Do not allow steering fluid reservoir tank to go below the MIN level line. Check tank frequently and
add fluid as needed.
2. Run engine at idle speed. Turn steering wheel fully right and then fully left, hold for about three seconds. Then check for fluid leakage.
3. Repeat step 2 several times at about three second intervals. CAUTION:
Do not hold steering wheel in the locked position for more than 10 seconds. (There is the possibil-
ity that oil pump may be damaged.)
4. Check for air bubbles or cloudy fluid.
5. If air bubbles or cloudiness still exists, stop engine, perform steps 2 and 3 again until air bubbles or cloud- iness does not exist.
6. Stop engine, check fluid level.
LGIA0021E
SGIA0506E
