2006 INFINITI M35 display

LAN-24
[CAN]
TROUBLE DIAGNOSES WORK FLOW
Revision: 2006 January2006 M35/M45
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN
FOR LDW CAMERA UNIT
Display Results (Present)
OK: Normal
UNKWN: The diagnosed unit does not transmit or receive the applicable data normally.
–: There is no received unit or the unit is not in the condition that reception diagnosis is performed.
Display Results (Past)
OK: Normal
0: There is malfunction now.
1 ~ 39: Displays when it is normal at present and finds malfunction in the past. It increases like 012...3839 after returning to the
normal condition whenever IGN OFF
ON. If it is over 39, it is fixed to 39 until the self-diagnostic results are erased. It returns to 0
when malfunction is detected again in the process.
–: Undiagnosed
PKIB5965E
“SELECT SYSTEM”
screen“CAN DIAG SUPPORT
MNTR” screenDescription Present Past
LDWTRANSMIT DIAG TRANSMIT DIAG is not diagnosed. –
OK/0/1~39/– ECM Make sure of normal reception from ECM. OK/UNKWN/–
VDC/TCS/ABSMake sure of normal reception from ABS actuator
and electric unit (control unit).OK/UNKWN/–
BCM/SEC Make sure of normal reception from BCM. OK/UNKWN/–
TCM Make sure of normal reception from TCM. OK/UNKWN/–

TROUBLE DIAGNOSES WORK FLOW
LAN-25
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: 2006 January2006 M35/M45
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN
FOR LOW TIRE PRESSURE WARNING CONTROL UNIT
Display Results (Present)
OK: Normal
UNKWN: The diagnosed unit does not transmit or receive the applicable data normally.
–: There is no received unit or the unit is not in the condition that reception diagnosis is performed.
Display Results (Past)
OK: Normal
0: There is malfunction now.
1 ~ 39: Displays when it is normal at present and finds malfunction in the past. It increases like 012...3839 after returning to the
normal condition whenever IGN OFF
ON. If it is over 39, it is fixed to 39 until the self-diagnostic results are erased. It returns to 0
when malfunction is detected again in the process.
–: Undiagnosed
PKIB9797E
“SELECT SYSTEM”
screen“CAN DIAG SUP-
PORT MNTR”
screenDescription Present Past
AIR PRESSURE
MONITORTRANSMIT DIAG Make sure of normal transmission. OK/UNKWN/–
OK/0/1~39/– ECM Make sure of normal reception from ECM. OK/UNKWN/–
VDC/TCS/ABSMake sure of normal reception from ABS actuator and
electric unit (control unit).OK/UNKWN/–

LAN-26
[CAN]
TROUBLE DIAGNOSES WORK FLOW
Revision: 2006 January2006 M35/M45
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN
FOR INTELLIGENT KEY UNIT
Display Results (Present)
OK: Normal
UNKWN: The diagnosed unit does not transmit or receive the applicable data normally.
–: There is no received unit or the unit is not in the condition that reception diagnosis is performed.
Display Results (Past)
OK: Normal
0: There is malfunction now.
1 ~ 39: Displays when it is normal at present and finds malfunction in the past. It increases like 012...3839 after returning to the
normal condition whenever IGN OFF
ON. If it is over 39, it is fixed to 39 until the self-diagnostic results are erased. It returns to 0
when malfunction is detected again in the process.
–: Undiagnosed
PKIB9796E
“SELECT SYSTEM”
screen“CAN DIAG SUP-
PORT MNTR”
screenDescription Present Past
INTELLIGENT KEYTRANSMIT DIAG Make sure of normal transmission. OK/UNKWN/–
OK/0/1~39/– ECM Make sure of normal reception from ECM. OK/UNKWN/–
ABSMake sure of normal reception from ABS actuator and
electric unit (control unit).OK/UNKWN/–
METER/M&AMake sure of normal reception from unified meter and A/C
amp.OK/UNKWN/–
BCM/SEC Make sure of normal reception from BCM. OK/UNKWN/–
TCM Make sure of normal reception from TCM. OK/UNKWN/–
IPDM E/R Make sure of normal reception from IPDM E/R. OK/UNKWN/–

TROUBLE DIAGNOSES WORK FLOW
LAN-27
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: 2006 January2006 M35/M45
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN FOR UNIFIED METER AND A/C
AMP.
Display Results (Present)
OK: Normal
UNKWN: The diagnosed unit does not transmit or receive the applicable data normally.
–: There is no received unit or the unit is not in the condition that reception diagnosis is performed.
Display Results (Past)
OK: Normal
0: There is malfunction now.
1 ~ 39: Displays when it is normal at present and finds malfunction in the past. It increases like 012...3839 after returning to the
normal condition whenever IGN OFF
ON. If it is over 39, it is fixed to 39 until the self-diagnostic results are erased. It returns to 0
when malfunction is detected again in the process.
–: Undiagnosed
PKIB9798E
“SELECT SYSTEM”
screen“CAN DIAG SUPPORT
MNTR” screenDescription Present Past
METER A/C AMPTRANSMIT DIAG Make sure of normal transmission. OK/UNKWN/–
OK/0/1~39/– ECM Make sure of normal reception from ECM. OK/UNKWN/–
TCM Make sure of normal reception from TCM. OK/UNKWN/–
BCM/SEC Make sure of normal reception from BCM. OK/UNKWN/–
VDC/TCS/ABSMake sure of normal reception from ABS actuator
and electric unit (control unit).OK/UNKWN/–
IPDM E/R IPDM E/R is not diagnosed. –
MULTI AVMake sure of normal reception from AV(NAVI) con-
trol unit.OK/UNKWN/–
I-KEYMake sure of normal reception from Intelligent Key
unit.OK/UNKWN/–
EPS EPS is not diagnosed. –
AWD/4WDMake sure of normal reception from AWD control
unit.OK/UNKWN/–
e4WD e4WD is not diagnosed. –
ICCMake sure of normal reception from ICC sensor
integrated unit.OK/UNKWN/–
LANE KEEP LANE KEEP is not diagnosed. –
TIRE-PMake sure of normal reception from low tire pres-
sure warning control unit.OK/UNKWN/–
AFSMake sure of normal reception from AFS control
unit.OK/UNKWN/–

LAN-28
[CAN]
TROUBLE DIAGNOSES WORK FLOW
Revision: 2006 January2006 M35/M45
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN
F O R AV ( N AV I ) C O N T R O L U N I T
Display Results (Present)
OK: Normal
UNKWN: The diagnosed unit does not transmit or receive the applicable data normally.
–: There is no received unit or the unit is not in the condition that reception diagnosis is performed.
Display Results (Past)
OK: Normal
0: There is malfunction now.
1 ~ 39: Displays when it is normal at present and finds malfunction in the past. It increases like 012...3839 after returning to the
normal condition whenever IGN OFF
ON. If it is over 39, it is fixed to 39 until the self-diagnostic results are erased. It returns to 0
when malfunction is detected again in the process.
–: Undiagnosed
PKIB9802E
“SELECT SYSTEM”
screen“CAN DIAG SUP-
PORT MNTR”
screenDescription Present Past
MULTI AVTRANSMIT DIAG Make sure of normal transmission. OK/UNKWN/–
OK/0/1~39/– ECM Make sure of normal reception from ECM. OK/UNKWN/–
METER/M&AMake sure of normal reception from unified meter and A/C
amp.OK/UNKWN/–
BCM/SEC Make sure of normal reception from BCM. OK/UNKWN/–
HVACMake sure of normal reception from unified meter and A/C
amp.OK/UNKWN/–
IPDM E/R Make sure of normal reception from IPDM E/R. OK/UNKWN/–
TIRE-PMake sure of normal reception from low tire pressure
warning control unit.OK/UNKWN/–

TROUBLE DIAGNOSES WORK FLOW
LAN-29
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: 2006 January2006 M35/M45
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN
FOR RAS CONTROL UNIT
Display Results (Present)
OK: Normal
UNKWN: The diagnosed unit does not transmit or receive the applicable data normally.
–: There is no received unit or the unit is not in the condition that reception diagnosis is performed.
Display Results (Past)
OK: Normal
0: There is malfunction now.
1 ~ 39: Displays when it is normal at present and finds malfunction in the past. It increases like 012...3839 after returning to the
normal condition whenever IGN OFF
ON. If it is over 39, it is fixed to 39 until the self-diagnostic results are erased. It returns to 0
when malfunction is detected again in the process.
–: Undiagnosed
PKIB9803E
“SELECT SYSTEM”
screen“CAN DIAG SUP-
PORT MNTR”
screenDescription Present Past
RAS/HICASTRANSMIT DIAG Make sure of normal transmission. OK/UNKWN/–
OK/0/1~39/– ECM Make sure of normal reception from ECM. OK/UNKWN/–
VDC/TCS/ABSMake sure of normal reception from ABS actuator and
electric unit (control unit).OK/UNKWN/–
STRG Make sure of normal reception from steering angle sensor. OK/UNKWN/–

LAN-30
[CAN]
TROUBLE DIAGNOSES WORK FLOW
Revision: 2006 January2006 M35/M45
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN
FOR PRE-CRASH SEAT BELT CONTROL UNIT
Display Results (Present)
OK: Normal
UNKWN: The diagnosed unit does not transmit or receive the applicable data normally.
–: There is no received unit or the unit is not in the condition that reception diagnosis is performed.
Display Results (Past)
OK: Normal
0: There is malfunction now.
1 ~ 39: Displays when it is normal at present and finds malfunction in the past. It increases like 012...3839 after returning to the
normal condition whenever IGN OFF
ON. If it is over 39, it is fixed to 39 until the self-diagnostic results are erased. It returns to 0
when malfunction is detected again in the process.
–: Undiagnosed
PKIB9799E
“SELECT SYSTEM”
screen“CAN DIAG SUP-
PORT MNTR”
screenDescription Present Past
PRECRASH
SEATBELTTRANSMIT DIAG Make sure of normal transmission. OK/UNKWN/–
OK/0/1~39/– ECM Make sure of normal reception from ECM. OK/UNKWN/–
METER/M&AMake sure of normal reception from unified meter and A/C
amp.OK/UNKWN/–
ICC ICC is not diagnosed. –
TCM Make sure of normal reception from TCM. OK/UNKWN/–

TROUBLE DIAGNOSES WORK FLOW
LAN-31
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: 2006 January2006 M35/M45
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN
FOR DRIVER SEAT CONTROL UNIT
Display Results (Present)
OK: Normal
NG: Malfunction
UNKWN: The diagnosed unit does not transmit or receive the applicable data normally.
DESCRIPTION OF “CAN DIAG SUPPORT MNTR” SCREEN
FOR ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)
Display Results (Present)
OK: Normal
NG: Malfunction
UNKWN: The diagnosed unit does not transmit or receive the applicable data normally.
SKIB2360E
“SELECT SYSTEM”
screen“CAN DIAG SUPPORT
MNTR” screenDescription Present
AUTO DRIVE POS.INITIAL DIAG Make sure that microcomputer in ECU works normally.OK/NG
TRANSMIT DIAG TRANSMIT DIAG is not diagnosed. OK
BCM/SEC Make sure of normal reception from BCM. OK/UNKWN
METER/M&A Make sure of normal reception from unified meter and A/C amp. OK/UNKWN
TCM Make sure of normal reception from TCM. OK/UNKWN
PKIB9794E
“SELECT SYSTEM”
screen“CAN DIAG SUPPORT
MNTR” screenDescription Present
ABSINITIAL DIAG Make sure that microcomputer in ECU works normally.OK/NG
TRANSMIT DIAG Make sure of normal transmission. OK/UNKWN
ECM Make sure of normal reception from ECM. OK/UNKWN
TCM Make sure of normal reception from TCM. OK/UNKWN
METER/M&A METER/M&A is not diagnosed. UNKWN
STRG Make sure of normal reception from steering angle sensor. OK/UNKWN
ICC Make sure of normal reception from ICC sensor integrated unit. OK/UNKWN
AWD/4WD Make sure of normal reception from AWD control unit. OK/UNKWN
RAS Make sure of normal reception from RAS control unit. OK/UNKWN
