2006 INFINITI G35 light switch

1. Warning/Indicator lights
2. Tachometer
3. Automatic transmission position indi-
cator (AT models)/Manual transmis-
sion up-shift indicator (MT models)
4. Speedometer 5. Engine coolant temperature gauge
6. Trip odometer reset switch
7. Odometer (Total/Twin trip)/Up-shift in-
dicator setting (MT models)
8. Fuel gauge SPEEDOMETER AND ODOMETER
Speedometer The speedometer indicates vehicle speed.
Odometer/Twin trip odometer/
Up-shift indicator setting (MT
models) The odometer
q 1
/twin trip odometer or
up-shift indicator setting (MT models)
q 2
are displayed when the ignition switch is
in the ON position. SSI0075 SIC2559
METERS AND GAUGES
Instruments and controls
2-3
w 06.1.4/V35-D/V5.0
X

If a magnet is located near the driver side
instrument panel (the sensor is located in-
side) or the vehicle is driven where the ter-
restrial magnetism is disturbed, the com-
pass display may not indicate the correct
direction.
O The compass may not display correctly
at the following places:
Ð under a bridge
Ð among buildings
Ð on an iron bridge
Ð inside a tunnel
Ð above a subway
Ð on a railway crossing
Ð in an underground parking lot
Ð near a huge vehicle
Ð near a transformer substation
If you carry out correction procedure
at one of the above places, the proce-
dure may not be completed correctly.
O If air conditioner fan speed is
maximum, the compass display may
shake. This is normal. Reduce the fan
speed to avoid shaking the display. Correction functions of the
compass display If the direction is not shown correctly,
carry out the correction procedure below.
1. Push the COMP switch for about 10
seconds. The direction bar starts
blinking.
2. Turn off electrical equipment such as
lights, hazard indicator, air condi-
tioner, etc. Then drive the vehicle
slowly (less than 3 MPH (5 km/h)) and
turn the vehicle one or more times in
an open and safe area. When the com-
pass displays the direction, the proce-
dure is completed.
2-8 Instruments and controls
w 06.1.4/V35-D/V5.0
X

All-wheel drive (AWD) warning light (AWD
models) Low tire pressure warning light Cruise set switch indicator light
or
Anti-lock brake warning light Low washer fluid warning light Front passenger air bag status light
Automatic transmission check warning
light P position selecting warning light (for
Intelligent Key system) High beam indicator light (Blue)
or Brake warning light Rear Active Steer (RAS) warning light (if
so equipped) Malfunction indicator lamp (MIL)
Charge warning light Seat belt warning light Slip indicator light
Door open warning light Supplemental air bag warning light Snow mode indicator light (if so
equipped)
Engine oil pressure warning light Automatic transmission position indicator
light Turn signal/hazard indicator lights
Intelligent Key warning light (for Intelli-
gent Key system) Cruise main switch indicator light Vehicle Dynamic Control (VDC) off indica-
tor light
Low fuel warning light
CHECKING BULBS Apply the parking brake and turn the igni-
tion key to ON without starting the en-
gine. The following lights will come on:
, or , , ,
The following lights come on briefly and
then go off:
, or , , , , , , ,
If any light fails to come on, it may indi-
cate a burned-out bulb or an open circuit
in the electrical system. Have the system
repaired promptly.
WARNING LIGHTS
All-wheel drive (AWD)
warning light (AWD models) The light comes on when the ignition
switch is turned to ON. It turns off soon
after the engine is started.WARNING/INDICATOR LIGHTS AND
AUDIBLE REMINDERS
Instruments and controls
2-9
w 06.1.4/V35-D/V5.0
X

If the AWD system malfunctions, or the di-
ameter of the front and the rear wheels
are different, the warning light will either
remain illuminated or blink. See ªAll-
wheel drive (AWD) warning lightº in the
ª5. Starting and drivingº section.
CAUTIONO If the warning light comes on while
driving there may be a malfunction in the
AWD system. Reduce the vehicle speed
and have your vehicle checked by an
INFINITI dealer as soon as possible.
O Do not drive on dry, hard surface roads in
the SNOW mode.
O If the AWD warning light blinks on when
you are driving:
· blinks rapidly (about twice a second):
Pull off the road in a safe area, and
idle the engine. The driving mode will
change to 2WD to prevent the AWD
system from malfunctioning.
If the warning light turns off, you can
drive again. · blinks slowly (about once every 2 sec-
onds):
Pull off the road in a safe area, and
idle the engine. Check that all tire
sizes are the same, tire pressure is
correct and tires are not worn.
If the warning light is still on after the above
operations, have your vehicle checked by an
INFINITI dealer as soon as possible.
or Anti-lock brake
warning lightWhen the ignition switch is turned to the
ON position, the anti-lock brake warning
light will illuminate and then turn off. This
indicates the anti-lock brake system (ABS)
is operational.
If the light comes on while the engine is
running, it may indicate the anti-lock
brake system is not functioning properly.
Have the system checked by an INFINITI
dealer.
If a malfunction occurs in the system, the
anti-lock function of the brake will cease
operation but the ordinary brakes will
continue to operate. See ªAnti-lock brake system (ABS)º in the ª5. Starting and
drivingº section for further details.
If the light comes on while you are driving,
contact an INFINITI dealer for repair.
Automatic transmission
check warning light When the ignition switch is turned to the
ON position, the automatic transmission
check warning light comes on and then
turns off. This indicates that the auto-
matic transmission system is operational.
If the light comes on while the engine is
running or while driving, it may indicate
that the automatic transmission system is
not functioning properly. Have an INFINITI
dealer check and repair the transmission.
or Brake warning
light The brake warning light indicates the
parking brake system operation, low
brake fluid level of the brake system and
Anti-lock Brake System (ABS) malfunction.
Parking brake indicator:
When the ignition switch is in the ON po-
sition, the light comes on when the park-
ing brake is applied.
2-10 Instruments and controls
w 06.1.4/V35-D/V5.0
X

Low brake fluid warning light:
The light warns of a low brake fluid level.
If the light comes on while the engine is
running with the parking brake not ap-
plied, stop the vehicle and perform the
following:
1. Check the brake fluid level. Add brake
fluid as necessary. See ªBrake fluidº
in the ª8. Maintenance and do-it-
yourselfº section.
2. If the brake fluid level is correct, have
the warning system checked by an
INFINITI dealer.
Anti-lock Brake System (ABS) warning
indicator:
When the parking brake is released and
the brake fluid level is sufficient, if both
the brake warning light and the anti-lock
brake system warning light illuminate, it
may indicate the anti-lock brake system is
not functioning properly. Have the brake
system checked by an INFINITI dealer. See
ªAnti-lock brake warning lightº earlier in
this section. WARNING O Your brake system may not be working
properly if the warning light is on.
Driving could be dangerous. If you judge
it to be safe, drive carefully to the
nearest service station for repairs. Oth-
erwise, have your vehicle towed because
driving it could be dangerous.
O Pressing the brake pedal with the engine
stopped and/or a low brake fluid level
may increase your stopping distance
and braking will require greater pedal ef-
fort as well as pedal travel.
O If the brake fluid level is below the MINI-
MUM or MIN mark on the brake fluid res-
ervoir, do not drive until the brake
system has been checked by an INFINITI
dealer.
Charge warning light If the light comes on while the engine is
running, it may indicate that the charging
system is not functioning properly. Turn
the engine off and check the alternator belt. If the belt is loose, broken, missing
or if the light remains on, see an INFINITI
dealer immediately.
CAUTION Do not continue driving if the generator belt
is loose, broken or missing.
Door open warning light This light comes on when any of the
doors are not closed securely while the
ignition switch is in the ON position.
Engine oil pressure warning
light This light warns of low engine oil pres-
sure. If the light flickers or comes on dur-
ing normal driving, pull off the road in a
safe area, stop the engine immediately
and call an INFINITI dealer or other autho-
rized repair shop.
The engine oil pressure warning light is
not designed to indicate a low oil level.
Use the dipstick to check the oil level. See
ªEngine oilº in the ª8. Maintenance and
do-it-yourselfº section.
Instruments and controls
2-11
w 06.1.4/V35-D/V5.0
X

CAUTIONRunning the engine with the engine oil pres-
sure warning light on could cause serious
damage to the engine almost immediately.
Turn off the engine as soon as it is safe to do
so.
Intelligent Key warning light
(for Intelligent Key system)This light comes on in green when it is
possible to turn the ignition switch.
When the light comes on in red, it is not
possible to turn the switch.
O The warning light blinks in red when
the Intelligent Key is outside the ve-
hicle with the ignition switch in the
ACC or ON position. Confirm the loca-
tion of the key as soon as possible
when the warning light blinks in red.
Be sure to carry the Intelligent Key
with you while driving the vehicle.
O The warning light goes off about 10
seconds after the Intelligent Key is
brought inside the vehicle. Low fuel warning light This light comes on when the fuel in the
tank is getting low. Refuel as soon as it is
convenient, preferably before the fuel
gauge reaches the E (Empty) position.
There will be a small reserve of fuel re-
maining in the fuel tank when the fuel
gauge needle reaches the E (Empty) posi-
tion.
Low tire pressure warning
light Your vehicle is equipped with a tire pres-
sure monitoring system (TPMS) that moni-
tors the tire pressure of all tires except
the spare.
The low tire pressure warning light warns
of low tire pressure or indicates that the
TPMS is not functioning properly.
After the ignition switch is turned ON, this
light illuminates for about 1 second and
turns off.
Low tire pressure warning:
If the vehicle is being driven with low tire
pressure, the warning light will illuminate.
When the low tire pressure warning light
illuminates, you should stop and adjust the tire pressure to the recommended
COLD tire pressure shown on the Tire and
Loading Information label to turn the light
OFF.
For additional information, see ªTire pres-
sure monitoring system (TPMS)º in the ª5.
Starting and drivingº section and in the
ª6. In case of emergencyº section.
TPMS malfunction:
If the TPMS is not functioning properly,
the low tire pressure warning light will
flash for approximately 1 minute when the
ignition switch is turned ON. The light will
remain on after the 1 minute. Have the
system checked by an INFINITI dealer.
For additional information, see ªTire pres-
sure monitoring system (TPMS)º in the ª5.
Starting and drivingº section.
WARNING O If the light does not illuminate with the
ignition switch turned ON, have the ve-
hicle checked by an INFINITI dealer as
soon as possible.
2-12 Instruments and controls
w 06.1.4/V35-D/V5.0
X

O If the light illuminates while driving,
avoid sudden steering maneuvers or
abrupt braking, reduce vehicle speed,
pull off the road to a safe location and
stop the vehicle as soon as possible. Se-
rious vehicle damage could occur and
may lead to an accident and could result
in serious personal injury. Check the tire
pressure for all four tires. Adjust the tire
pressure to the recommended COLD tire
pressure shown on the Tire and Loading
Information label to turn the low tire
pressure warning light OFF. If the light
still comes on while driving after ad-
justing the tire pressure, a tire may be
flat. If you have a flat tire, replace it with
a spare tire as soon as possible.
O
When a spare tire is mounted or a wheel is
replaced, tire pressure will not be indicated,
the TPMS will not function and the low tire
pressure warning light will flash. Contact
your INFINITI dealer as soon as possible for
tire replacement and/or system resetting.
O Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS. CAUTION O The TPMS is not a substitute for the
regular tire pressure check. Be sure to
check the tire pressure regularly.
O If the vehicle is being driven at speeds of
less than 16 MPH (25 km/h), the TPMS
may not operate correctly.
O Be sure to install the specified size of
tires to the four wheels correctly.
Low washer fluid warning
light This light comes on when the washer tank
fluid is at a low level. Add washer fluid as
necessary. See ªWindow washer fluidº in
the ª8. Maintenance and do-it-yourselfº
section.
P position selecting warning
light (for Intelligent Key
system) The light blinks in red when the selector
lever is not in the P (Park) position and
you are outside the vehicle with the Intel-
ligent Key. When the warning light blinks, move the
selector lever to P position and return the
ignition switch to the LOCK position.
Rear Active Steer (RAS)
warning light (if so
equipped) If the light comes on while the engine is
running, it may indicate that there is a
malfunction with the Rear Active Steer
(RAS) portion of the steering system. Have
the system checked by an INFINITI dealer.
For further information about the RAS sys-
tem, see ªRear Active Steer (RAS) systemº
in the ª5. Starting and drivingº section.
If a malfunction occurs in the system, the
RAS function will cease but driving can be
continued.
If the light comes on while you are driving,
contact an INFINITI dealer for repair.
Seat belt warning light and
chime The light and chime remind you to fasten
the driver's seat belt. The light illuminates
whenever the ignition switch is pushed to
the ON position, and will remain illumi-
nated until the driver's seat belt is fas-
Instruments and controls
2-13
w 06.1.4/V35-D/V5.0
X

tened. At the same time, the chime will
sound for about 6 seconds unless the
driver's seat belt is securely fastened.
The seat belt warning light may also illu-
minate if the front passenger's seat belt
is not fastened when the front passen-
ger's seat is occupied (if so equipped).
For 5 seconds after the ignition switch is
in the ON position, the system does not
activate the warning light for the front
passenger.
If the light blinks or illuminates even if
the driver's and front passenger's seat
belts are fastened, it may indicate that
the pre-crash seat belt system (if so
equipped) has a malfunction. Have an
INFINITI dealer check and repair the
system.
See ªSeat beltsº in the ª1. Safety Ð
Seats, seat belts and supplemental re-
straint systemº section for precautions on
seat belt usage.
Supplemental air bag
warning lightAfter turning the ignition switch to the ON
position, the supplemental air bag
warning light will illuminate. The supple-
mental air bag warning light will turn off after about 7 seconds if the system is op-
erational.
If any of the following conditions occur,
the supplemental front air bag, supple-
mental side air bag and curtain side-
impact air bag systems, and pre-tensioner
seat belt need servicing and your vehicle
must be taken to your an INFINITI dealer.
O The supplemental air bag warning
light remains on after approximately 7
seconds.
O The supplemental air bag warning
light flashes intermittently.
O The supplemental air bag warning
light does not come on at all.
Unless checked and repaired, the Supple-
mental Restraint System and/or the pre-
tensioner seat belt may not function prop-
erly. For additional information, see
ªSupplemental restraint systemº in the
ª1. Safety Ð Seats, restraints and supple-
mental restraint systemº section.
WARNING If the supplemental air bag warning light is
on, it could mean that the supplemental front air bag, supplemental side air bag, cur-
tain side-impact air bag systems and/or pre-
tensioner seat belt systems will not operate
in an accident. To help avoid injury to your-
self or others, have your vehicle checked by
an INFINITI dealer as soon as possible.
INDICATOR LIGHTS
Automatic transmission
position indicator light When the ignition switch is turned to the
ON position, the indicator in the instru-
ment panel shows the automatic trans-
mission selector lever position. See ªDriv-
ing with automatic transmissionº in the
ª5. Starting and drivingº section.
Cruise main switch
indicator light The light comes on when the cruise con-
trol main switch is pushed. The light goes
out when the main switch is pushed
again. When the cruise main switch indi-
cator light comes on, the cruise control
system is operational.
2-14 Instruments and controls
w 06.1.4/V35-D/V5.0
X
