O Waste oil must be disposed of prop-
erly.
O Check your local regulations.
4. Loosen the oil filter with an oil filter
wrench
q B
. Remove the oil filter by
turning it by hand.
5. Wipe the engine oil filter mounting
surface with a clean rag.
Be sure to remove any old rubber
gasket remaining on the mounting sur-
face of the engine.
6. Coat the gasket on the new filter with
clean engine oil.
7. Screw in the oil filter clockwise until a
slight resistance is felt, then tighten
additionally more than 2/3 turn.
Oil filter tightening torque:
11 to 15 ft-lb
(14.7 to 20.5 N z m)
8. Clean and re-install the drain plug
with a new washer. Securely tighten
the drain plug with a wrench.
Drain plug tightening torque:
22 to 29 ft-lb
(29 to 39 N z m)
Do not use excessive force. 9. Refill engine with recommended oil
and install the cap securely.
CAUTION The dipstick must be inserted in place to pre-
vent oil spillage from the dipstick hole while
filling the engine with oil.
See ªCapacities and recommended
fuel/lubricantsº in the ª9. Technical
and consumer informationº section for
drain and refill capacity. The drain and
refill capacity depends on the oil tem-
perature and drain time. Use these
specifications for reference only. Al-
ways use the dipstick to determine the
proper amount of oil in the engine.
CAUTION When filling oil, do not pull out the dipstick.
10. Start the engine and check for
leakage around the drain plug and
the oil filter. Correct as required. 11. Turn the engine off and wait more
than 10 minutes. Check the oil level
with the dipstick. Add engine oil if
necessary.
After the operation 1. Install the engine undercover into po-
sition as the following steps.
a. Pull the center of the small plastic
clip out.
b. Hold the engine undercover into
position.
c. Insert the clip through the under-
cover into the hole in the frame,
then push the center of the clip in
to lock the clip in place.
d. Install the other bolts that hold the
undercover in place. Be careful not
to strip the bolts or over-tighten
them.
2. Lower the vehicle carefully to the
ground.
3. Dispose of waste oil and filter prop-
erly.
8-12 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

9 Technical and consumer information Capacities and recommended fuel/lubricants ... 9-2
Fuel recommendation .................................. 9-3
Engine oil and oil filter recommendation ..... 9-5
Recommended SAE viscosity number .......... 9-6
Air conditioning system refrigerant and
lubricant recommendations ......................... 9-7
Specifications................................................... 9-8
Engine......................................................... 9-8
Wheels and tires ......................................... 9-9
Dimensions and weights ............................. 9-9
When traveling or registering your vehicle in
another country .............................................. 9-10
Vehicle identification ...................................... 9-10
Vehicle identification number (VIN) plate ... 9-10
Vehicle identification number (Chassis
number) ..................................................... 9-10
Engine serial number ................................. 9-11
F.M.V.S.S./C.M.V.S.S. certification label ..... 9-11
Emission control information label ............. 9-12
Tire and loading information label ............. 9-12
Air conditioner specification label .............. 9-13 Installing front license plate............................ 9-13
Vehicle loading information ............................ 9-14
Terms ........................................................ 9-14
Vehicle load capacity ................................. 9-15
Loading tips ............................................... 9-17
Measurements of weights .......................... 9-17
Towing a trailer ............................................... 9-18
Maximum load limits ................................. 9-18
Towing load/specification chart ................. 9-19
Towing safety ............................................ 9-19
Flat towing ................................................ 9-22
Uniform tire quality grading............................ 9-23
Emission control system warranty .................. 9-24
Reporting safety defects (US only) .................. 9-24
Readiness for inspection/maintenance (I/M)
test (US only).................................................. 9-25
Event data recorders ...................................... 9-26
Owner's Manual/Service Manual order
information ................................................... 9-26
In the event of a collision.......................... 9-27
w 06.1.4/V35-D/V5.0
X

The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedure in-
structed in the ª8. Maintenance and do-it-yourselfº section to determine the proper refill capacity. Capacity (Approximate)
Recommended
specificationsUS
measure Imp
measure Liter
Fuel*1 20 gal 16-5/8 gal 76
Engine oil (Drain and refill)*8
With oil filter change 5 qt 4-1/8 qt 4.7 O API Certification Mark*2, *3
O API grade SG/SH, Energy Conservin gI&IIorAPI grade SJ or SL, Energy Conserving*2, *3
O ILSAC grade GF-I, GF-II & GF-III*2, *3Without oil filter change 4-5/8 qt 3-7/8 qt 4.4
Cooling system
With reservoir 9-1/4 qt 7-5/8 qt 8.7
Genuine NISSAN Long Life Antifreeze/Coolant or equivalent
Reservoir 7/8 qt 3/5 qt 0.8
Automatic transmission fluid Ð Ð Ð Genuine NISSAN Matic J ATF*4
Manual transmission gear oil Ð Ð Ð Genuine NISSAN Manual Transmission Fluid (MTF)
HQ Multi 75W-85 or API GL-4, Viscosity SAE 75W-85 or 75W-90
Differential gear oil Ð Ð Ð API GL-5, Viscosity SAE 80W-90*5
Transfer fluid Ð Ð Ð Genuine NISSAN Matic D ATF (Continental U.S. and Alaska) or CANADA NISSAN Automatic Trans-
mission Fluid*6
Power steering fluid (PSF) Refill to the proper fluid level according to the in-
structions in the ª8. Maintenance and do-it-yourselfº
section. Genuine NISSAN PSF or equivalent*10
Brake and clutch fluid Genuine NISSAN Super Heavy Duty Brake Fluid*7 or equivalent DOT 3
Multi-purpose grease Ð Ð Ð NLGI No. 2 (Lithium soap base)
Air conditioning system refrigerant Ð Ð Ð HFC-134a (R-134a)*9
Air conditioning system lubricants Ð Ð Ð NISSAN A/C System Oil Type S or exact equivalent
Windshield washer fluid Ð Ð Ð Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent
*1: For additional information, see ªFuel recommendationº later in this section.
*2: For additional information, see ªEngine oil and oil filter recommendationº later in this section.
*3: For additional information, see ªRecommended SAE viscosity numberº later in this section.
*4: Using automatic transmission fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is not
covered by the INFINITI new vehicle limited warranty.
*5: For hot climates, viscosity SAE 90 is suitable for ambient temperatures always above 32ÉF (0ÉC).
*6: DEXRON TM
III/MERCON TM
or equivalent may also be used. Outside the continental United States and Alaska contact an INFINITI dealer for more information regarding suitable fluids, including recommended
brand(s) of DEXRON TM
III/MERCON TM
automatic transmission fluid.
*7: Available in mainland US through an INFINITI dealer.
*8: For additional information, see ªEngine oilº in the ª8. Maintenance and do-it-yourselfº section for changing engine oil.
*9: For additional information, see ªVehicle identificationº later in this section for air conditioner specification label.
*10: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRON TM
III/MERCON TM
or equivalent ATF may also be used.CAPACITIES AND RECOMMENDED
FUEL/LUBRICANTS
9-2 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

FUEL RECOMMENDATION
Sedan Ð Automatic transmission
models Use unleaded regular gasoline with an oc-
tane rating of at least 87 AKI (Anti-Knock In-
dex) number (Research octane number 91).
For improved vehicle performance,
INFINITI recommends the use of unleaded
premium gasoline with an octane rating of
at least 91 AKI number (Research octane
number 96).
Sedan Ð Manual transmission
and Coupe models Use unleaded premium gasoline with an
octane rating of at least 91 AKI (Anti-
Knock Index) number (Research octane
number 96).
If premium gasoline is not available, un-
leaded regular gasoline with an octane
rating of 87 AKI number (Research octane
number 91) may be temporarily used, but
only under the following precautions:
O Have the fuel tank filled only partially
with unleaded regular gasoline, and
fill up with unleaded premium gaso-
line as soon as possible. O Avoid full throttle driving and abrupt
acceleration.
However, for maximum vehicle perfor-
mance, the use of unleaded premium gaso-
line is recommended.
CAUTION O Using a fuel other than that specified
could adversely affect the emission con-
trol system, and may also affect the war-
ranty coverage.
O Under no circumstances should a leaded
gasoline be used, because this will dam-
age the three-way catalyst.
O Do not use E-85 fuel in your vehicle. Your
vehicle is not designed to run on E-85
fuel. Using E-85 fuel can damage the fuel
system components and is not covered
by the INFINITI vehicle limited warranty.
Gasoline specifications INFINITI recommends using gasoline that
meets the World-Wide Fuel Charter
(WWFC) specifications where it is avail- able. Many of the automobile manufactur-
ers developed this specification to im-
prove emission control system and ve-
hicle performance. Ask your service
station manager if the gasoline meets the
WWFC specifications.
Reformulated gasoline Some fuel suppliers are now producing
reformulated gasolines. These gasolines
are specially designed to reduce vehicle
emissions. INFINITI supports efforts to-
wards cleaner air and suggests that you
use reformulated gasoline when avail-
able.
Gasoline containing oxygenates Some fuel suppliers sell gasoline contain-
ing oxygenates such as ethanol, MTBE
and methanol with or without advertising
their presence. INFINITI does not recom-
mend the use of fuels of which the oxy-
genate content and the fuel compatibility
for your INFINITI cannot be readily deter-
mined. If in doubt, ask your service sta-
tion manager.
If you use oxygenate-blend gasoline,
please take the following precautions as
the usage of such fuels may cause vehicle
Technical and consumer information
9-3
w 06.1.4/V35-D/V5.0
X

ENGINE Model VQ35DE
Type Gasoline, 4-cycle
Cylinder arrangement 6-cylinder, V-slanted at 60É
Bore x Stroke in (mm) 3.760 x 3.205 (95.5 x 81.4)
Displacement cu in (cm 3
) 213.45 (3,498)
Firing order 1-2-3-4-5-6*
Idle speed rpm
See the emission control label on
the underside of the hood.Ignition timing (B.T.D.C.) degree/rpm
CO percentage at idle speed [No air] %
Spark plug Standard PLFR5A-11
Service option PLFR4A-11, PLFR6A-11
Spark plug gap (Normal) in (mm) 0.043 (1.1)
Camshaft operation Timing chain The spark ignition system of this vehicle
meets all requirements of the Canadian
Interference-Causing Equipment Regula-
tions. TI0001-A
SPECIFICATIONS
9-8 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

When planning to travel in another
country, you should first find out if the
fuel available is suitable for your vehicle's
engine.
Using fuel with too low an octane rating
may cause engine damage. All gasoline
vehicles must be operated with unleaded
engine gasoline. Therefore, avoid taking
your vehicle to areas where appropriate
fuel is not available.
When transferring the registration of your
vehicle to another country, state, province
or district, it may be necessary to modify
the vehicle to meet local laws and regula-
tions.
The laws and regulations for motor ve-
hicle emission control and safety stan-
dards vary according to the country,
state, province or district; therefore, ve-
hicle specifications may differ.
When any vehicle is to be taken into an-
other country, state, province or district
and registered, its modifications, trans-
portation, and registration are the respon-
sibility of the user. INFINITI is not respon-
sible for any inconvenience that may re-
sult. VEHICLE IDENTIFICATION NUMBER
(VIN) PLATE The vehicle identification number plate is
attached as shown. This number is the
identification for your vehicle and is used
in the vehicle registration.
VEHICLE IDENTIFICATION NUMBER
(Chassis number) The number is stamped as shown. STI0038 STI0302
WHEN TRAVELING OR REGISTERING YOUR
VEHICLE IN ANOTHER COUNTRY VEHICLE IDENTIFICATION
9-10 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

model year and prior, see an INFINITI
dealer, or contact:
Resolve Corporation
20770 Westwood Road
Strongsville, OH 44136
1-800-247-5321
In Canada:
To purchase a copy of a genuine INFINITI
Service Manual or Owner's Manual please
contact an INFINITI dealer. For the phone
number and location of an INFINITI dealer
in your area call the INFINITI Satisfaction
Center at 1-800-361-4792 and a bilingual
INFINITI representative will assist you.
Also available are genuine INFINITI Ser-
vice and Owner's Manuals for older
INFINITI models.
IN THE EVENT OF A COLLISION Unfortunately, accidents do occur. In this
unlikely event, there is some important
information you should know. Many insur-
ance companies routinely authorize the
use of non-genuine collision parts in
order to cut costs, among other reasons. Insist on the use of Genuine
INFINITI Collision Parts! If you want your vehicle to be restored
using parts made to INFINITI's original ex-
acting specifications Ð if you want to
help it to last and hold its resale value,
the solution is simple. Tell your insurance
agent and your repair shop to only use
Genuine INFINITI Collision Parts. INFINITI
does not warrant non-INFINITI parts, nor
does INFINITI's warranty apply to damage
caused by a non-genuine parts.
Using Genuine INFINITI Parts can help pro-
tect your personal safety, preserve your
warranty protection and maintain the re-
sale value of your vehicle. And if your ve-
hicle was leased, using Genuine INFINITI
Parts may prevent or limit unnecessary
excess wear and tear expenses at the end
of your lease.
INFINITI designs its hoods with crumple
zones to minimize the risk that the hood
will penetrate the windshield of your ve-
hicle in an accident. Non-genuine (imita-
tion) parts may not provide such built-in
safety features. Also, non-genuine parts
often show premature wear, rust and cor-
rosion. Why should you take a chance? In over 40 states, the law says you must
be advised if non-genuine parts are used
to repair your vehicle. And some
states/provinces have enacted laws that
restrict insurance companies from autho-
rizing the use of non-genuine collision
parts during the new vehicle warranty.
These laws help protect you, so you can
take action to protect yourself.
It's your right! If you should need further information
visit us at:
www.infiniti.com (for U.S. customers) or
www.infiniti.ca (for Canadian customers)
Technical and consumer information
9-27
w 06.1.5/V35-D/V5.0
X
