2006 CHEVROLET COLORADO window

(D) Construction Code:A letter code is used to
indicate the type of ply construction in the tire. The
letter R means radial ply construction; the letter D means
diagonal or bias ply construction; and the letter B means
belted-bias ply construction.
(E) Rim Diameter:Diameter of the wheel in inches.
(F) Service Description:These characters represent
the load range and speed rating of the tire. The load
index represents the load carry capacity a tire is certied
to carry. The load index can range from 1 to 279. The
speed rating is the maximum speed a tire is certied
to carry a load. Speed ratings range from A to Z.
Tire Terminology and Denitions
Air Pressure:The amount of air inside the tire pressing
outward on each square inch of the tire. Air pressure
is expressed in pounds per square inch (psi) or
kilopascal (kPa).
Accessory Weight:This means the combined weight
of optional accessories. Some examples of optional
accessories are, automatic transmission, power steering,
power brakes, power windows, power seats, and air
conditioning.
Aspect Ratio:The relationship of a tire’s height to
its width.Belt:A rubber coated layer of cords that is located
between the plies and the tread. Cords may be made
from steel or other reinforcing materials.
Bead:The tire bead contains steel wires wrapped by
steel cords that hold the tire onto the rim.
Bias Ply Tire:A pneumatic tire in which the plies are
laid at alternate angles less than 90 degrees to the
centerline of the tread.
Cold Ination Pressure:The amount of air pressure
in a tire, measured in pounds per square inch (psi) or
kilopascals (kPa) before a tire has built up heat from
driving. SeeInation - Tire Pressure on page 5-58.
Curb Weight:This means the weight of a motor vehicle
with standard and optional equipment including the
maximum capacity of fuel, oil, and coolant, but without
passengers and cargo.
DOT Markings:A code molded into the sidewall of a
tire signifying that the tire is in compliance with the U.S.
Department of Transportation (DOT) motor vehicle safety
standards. The DOT code includes the Tire Identication
Number (TIN), an alphanumeric designator which can
also identify the tire manufacturer, production plant,
brand, and date of production.
GVWR:Gross Vehicle Weight Rating, seeLoading
Your Vehicle on page 4-44.
5-56

Appearance Care
Cleaning the Inside of Your Vehicle
Your vehicle’s interior will continue to look its best if
it is cleaned often. Although not always visible, dust and
dirt can accumulate on your upholstery. Dirt can
damage carpet, fabric, leather, and plastic surfaces.
Regular vacuuming is recommended to remove particles
from your upholstery. It is important to keep your
upholstery from becoming and remaining heavily soiled.
Soils should be removed as quickly as possible. Your
vehicle’s interior may experience extremes of heat
that could cause stains to set rapidly.
Lighter colored interiors may require more frequent
cleaning. Use care because newspapers and garments
that transfer color to your home furnishings may also
transfer color to your vehicle’s interior.
When cleaning your vehicle’s interior, only use cleaners
specically designed for the surfaces being cleaned.
Permanent damage may result from using cleaners on
surfaces for which they were not intended. Use glass
cleaner only on glass. Remove any accidental over-spray
from other surfaces immediately. To prevent over-spray,
apply cleaner directly to the cleaning cloth.Notice:If you use abrasive cleaners when cleaning
glass surfaces on your vehicle, you could scratch
the glass. When cleaning the glass on your vehicle,
use only a soft cloth and glass cleaner.
Many cleaners contain solvents that may become
concentrated in your vehicle’s breathing space. Before
using cleaners, read and adhere to all safety
instructions on the label. While cleaning your vehicle’s
interior, maintain adequate ventilation by opening
your vehicle’s doors and windows.
Dust may be removed from small buttons and knobs
using a small brush with soft bristles.
Your GM dealer has a product for cleaning your
vehicle’s glass. Should it become necessary, you can
also obtain a product from your GM dealer to remove
odors from your vehicle’s upholstery.
5-89

Fuses Usage
PWR/SEATPower Seat Circuit Breaker
(If Equipped)
RT HDLP Passenger’s Side Headlamp
LT HDLP Driver’s Side Headlamp
AUX PWR 2 Accessory Power 2
FOG/LAMP Fog Lamps (If Equipped)
A/C CMPRSR Air Conditioning Compressor
WSW Wiper/Washer Switch
PWR/WNDW Power Windows (If Equipped)
FUEL/PUMP Fuel Pump
STRTR Starter Solenoid Relay
WPR Wiper
ABS 2Anti-lock Brake System 2
(ABS Pump)
DR/LCK Power Door Locks (If Equipped)
ETC Electronic Throttle Control (ETC)
02 SNSR Oxygen Sensors
CRUISECruise Control Switch, Inside
Rearview Mirror, Transfer Case
Control Module, Brake Switch,
Clutch Disable
HTD/SEAT Heated Seat (If Equipped)
AIRBAGSupplemental Inatable Restraint
System, Sensing and Diagnostic
ModuleFuses Usage
ABSAnti-lock Brake System (ABS), ABS
module, Four-Wheel Drive, Gravity
Sensor
BCK/UP Back-up Lights
FRT/AXLE Front Axle Actuator
TRN/HAZRD
REARRear Turn/Hazard Lights
ERLS Map Sensor, Can Purge Solenoid
PCMI Powertrain Control Module (PCM)
TRANS Transmission Solenoid
IGNIgnition, Clutch Starter Switch,
Neutral Safety Back-Up Switch,
Ignition Coils 1-5, Air Conditioning
Relay
INJ Injectors
ABS 1Anti-lock Brake System 1
(ABS Logic)
FRT PRK
LAMPFront Park/Turn Lamps, Driver and
Passenger’s Side Power Window
Switches Lighting
REAR PRK
LAMPRear Parking Lamp 1, Passenger’s
Side Taillamp, License Plate Lamps
REAR PRK
LAMP2Driver’s Side Rear Taillamp,
Passenger Side Airbag Indicator
Lighting, Instrument Panel Dimming
Power (2WD/4WD switch lighting)
5-101

Fuses Usage
CLSTR Cluster
TRN/HAZRD
FRTTurn/Hazard/Courtesy/Cargo
Lamps/Mirrors
TCCM Transfer Case Control Module
HORN Horn
TBC Truck Body Controller
IGN TRNSD Ignition Transducers
RDO Radio
ONSTAR OnStar
®
CNSTR VENT Fuel Canister Vent Solenoid
PCM B Powertrain Control Module (PCM) B
Relays Usage
DRL Daylight Running Lamps
BEAM SEL Beam Selection
IGN 3 HVACIgnition 3, Climate Control,
Climate Control Head Fuse,
Power Seat Fuse
RAPRetained Accessory Power
(Power Window Fuse,
Wiper/Washer Switch Fuse),
Sunroof Fuse
Relays Usage
PRK/LAMPFront Parking Lamp Fuse, Rear
Parking Lamps
HDLP Headlamps
FOG/LAMP Fog Lamps (If Equipped)
FUEL/PUMP Fuel Pump, Fuel Pump Fuse
A/C CMPRSR Air Conditioning Compressor
RUN/CRNKRun/Crank, Airbag System Fuse,
Cruise Control Fuse, Ignition Fuse,
Back-Up Lamps, ABS Fuse, Front
Axle, PCM-1, Injectors Fuse,
Transmission Fuse
PWR/TRNPowertrain, Electronic Throttle
Control Fuse, Oxygen Sensor Fuse
HORN Horn
WPR 2 Wiper 2 (High/Low)
WPR Wipers (On/Off)
STRTR Starter Relay (PCM Relay)
Miscellaneous Usage
WPR Diode — Wiper
A/C CLTCH Diode — Air Conditioning, Clutch
MEGA FUSE Mega Fuse
5-102

Manual Windows............................................2-12
Message
DIC Warnings and Messages........................3-41
Mirrors
Automatic Dimming Rearview with
Compass and Temperature Display.............2-37
Manual Rearview Mirror................................2-36
Manual Rearview Mirror with OnStar
®.............2-37
Outside Convex Mirror.................................2-40
Outside Manual Mirrors................................2-39
Outside Power Mirrors..................................2-40
MyGMLink.com................................................ 7-4
N
New Vehicle Break-In......................................2-17
Normal Maintenance Replacement Parts............6-14
O
Odometer......................................................3-24
Odometer, Trip...............................................3-24
Off-Road Driving.............................................4-15
Off-Road Recovery..........................................4-12
Oil
Engine.......................................................5-13
Pressure Light.............................................3-35
Oil, Engine Oil Life System..............................5-16
Older Children, Restraints................................1-35
Online Owner Center........................................ 7-4
OnStar
®System, see OnStar®Manual...............2-41
Other Warning Devices...................................... 3-6
Outlet Adjustment............................................3-21
Outlet(s), Accessory Power...............................3-18
Outside
Convex Mirror.............................................2-40
Manual Mirrors............................................2-39
Power Mirrors.............................................2-40
Owner Checks and Services.............................. 6-8
Owners, Canadian............................................... ii
9

P
Paint, Damage...............................................5-95
Park (P)
Shifting Into................................................2-31
Shifting Out of............................................2-33
Parking
Brake........................................................2-30
Over Things That Burn.................................2-34
Parking Your Vehicle.......................................2-33
Passenger Airbag Status Indicator.....................3-27
Passenger Sensing System..............................1-74
Passing.........................................................4-12
Passlock
®......................................................2-16
Pickup Conversion to Chassis Cab....................4-49
Power
Accessory Outlet(s)......................................3-18
Door Locks.................................................. 2-8
Lumbar Controls........................................... 1-4
Retained Accessory (RAP)............................2-18
Seat ............................................................ 1-3
Steering Fluid.............................................5-33
Windows....................................................2-13
Pretensioners, Safety Belt................................1-34
Programmable Automatic Door Locks.................. 2-8
Q
Questions and Answers About Safety Belts.........1-17
R
Radiator Pressure Cap....................................5-26
Radios..........................................................3-45
AM-FM Radio.............................................3-47
Care of Your CD Player...............................3-77
Care of Your CDs ........................................3-77
Radio with CD............................................3-50
Radio with Six-Disc CD................................3-65
Setting the Time for Radios with
Radio Data Systems (RDS).......................3-47
Setting the Time for Radios without
Radio Data Systems (RDS).......................3-46
Theft-Deterrent............................................3-76
Understanding Reception..............................3-76
Rear Axle......................................................5-44
Rear Door Security Locks.................................. 2-9
Rear Doors...................................................... 2-9
Rear Safety Belt Comfort Guides......................1-31
Rear Seat Operation...............................1-10, 1-12
Rear Seat Passengers, Safety Belts..................1-28
Rear Storage Area..........................................2-44
Rearview Mirror, Automatic Dimming with
Compass and Temperature Display................2-37
Rearview Mirror with OnStar
®...........................2-37
Rearview Mirrors.............................................2-36
Reclining Seatbacks.......................................... 1-5
Recommended Fluids and Lubricants.................6-12
Recovery Hooks.............................................4-43
Recreational Vehicle Towing.............................4-50
10

Scheduled Maintenance..................................... 6-4
Seatback Latches............................................. 1-9
Seats
Head Restraints............................................ 1-8
Heated Seats............................................... 1-4
Manual........................................................ 1-2
Manual Lumbar............................................. 1-3
Power Lumbar .............................................. 1-4
Power Seats................................................. 1-3
Rear Seat Operation............................1-10, 1-12
Reclining Seatbacks...................................... 1-5
Seatback Latches.......................................... 1-9
Secondary Latch System.................................5-81
Securing a Child Restraint
Center Front Seat Position............................1-61
Rear Seat Position......................................1-58
Right Front Seat Position..............................1-61
Security Light.................................................3-36
Service........................................................... 5-3
Accessories and Modications......................... 5-3
Adding Equipment to the
Outside of Your Vehicle.............................. 5-5
California Proposition 65 Warning.................... 5-3
Doing Your Own Work................................... 5-4
Engine Soon Light.......................................3-32
Publications Ordering Information...................7-15Servicing Your Airbag-Equipped Vehicle..............1-79
Setting the Time
Radios with Radio Data Systems (RDS).........3-47
Radios without Radio Data Systems (RDS).....3-46
Sheet Metal Damage.......................................5-95
Shifting Into Park (P).......................................2-31
Shifting Out of Park (P)...................................2-33
Signals, Turn and Lane-Change.......................... 3-8
Sliding Rear Windows.....................................2-14
Spare Tire.....................................................5-87
Installing....................................................5-73
Removing...................................................5-70
Storing.......................................................5-84
Specications, Capacities...............................5-103
Speedometer..................................................3-24
Starting Your Engine.......................................2-19
Steering........................................................4-10
Steering Wheel, Tilt Wheel................................. 3-7
Storage Areas
Cupholder(s)...............................................2-42
Front Armrest Storage Area...........................2-43
Glove Box..................................................2-42
Rear Storage Area.......................................2-44
Stuck in Sand, Mud, Ice, or Snow.....................4-42
Sun Visors.....................................................2-14
Sunroof.........................................................2-45
12

V
Vehicle
Control........................................................ 4-5
Damage Warnings........................................... iv
Loading......................................................4-44
Parking Your...............................................2-33
Symbols......................................................... iv
Vehicle Data Collection and
Event Data Recorders..................................7-10
Vehicle Identication
Number (VIN).............................................5-97
Service Parts Identication Label...................5-97
Ventilation Adjustment......................................3-21
Visors...........................................................2-14
W
Warning Lights, Gages and Indicators................3-22
Warnings
DIC Warnings and Messages........................3-41
Hazard Warning Flashers............................... 3-6
Other Warning Devices.................................. 3-6
Safety and Symbols......................................... iii
Vehicle Damage.............................................. ivWheels
Alignment and Tire Balance..........................5-65
Different Size..............................................5-63
Replacement...............................................5-65
Where to Put the Restraint...............................1-45
Windows.......................................................2-12
Manual......................................................2-12
Power ........................................................2-13
Sliding Rear................................................2-14
Windshield
Washer......................................................3-10
Washer Fluid..............................................5-34
Wiper Blade Replacement.............................5-50
Wiper Blades, Cleaning................................5-93
Wiper Fuses...............................................5-98
Wipers......................................................... 3-9
Winter Driving................................................4-38X
XM™ Satellite Radio Antenna System................3-78
Y
Your Vehicle and the Environment....................... 6-2
14
