2006 CHEVROLET AVALANCHE Owners Manual

A. Low-Beam Headlamp
B. High-Beam Headlamp
4. Unplug the electrical connector.
5. Turn the old bulb counterclockwise and remove it
from the headlamp assembly.
6. Put the new bulb into the assembly and turn it
clockwise until it is tight.
7. Plug in the electrical connector.
8. Reinstall the headlamp assembly.
9. Install the pin and turn it into the locking feature.
Front Turn Signal, Sidemarker and
Parking Lamps
Vehicles with Body-Side Cladding
To replace a front turn signal, sidemarker, or parking
lamp bulb, do the following:
1. Open the hood. SeeHood Release on page 5-12
for more information.
2. Remove the turn
signal/parking lamp
assembly by pressing
the release clip on the
outboard side of the
assembly and pulling
the outboard end of the
assembly toward you.
3. Pull the inboard side of the assembly out from the
vehicle.
5-57

A. Sidemarker Lamp
B. Front Turn Signal/Parking Lamp4. Press the locking release lever (the sidemarker
lamp does not have a locking release lever), turn
the bulb socket counterclockwise and remove it from
the turn signal/parking lamp assembly.
5. Remove the old bulb from the bulb socket.
6. Put the new bulb into the bulb socket.
7. Put the bulb socket into the turn signal assembly
and turn it clockwise until it locks (the sidemarker
lamp does not lock into place).
8. Place the inboard end of the turn signal/parking
lamp assembly into the pocket.
9. Push the outboard side of the assembly in until the
release clip snaps into place.
5-58

Front Turn Signal, Sidemarker and
Daytime Running Lamps
Vehicles without Body-Side Cladding
To replace a front turn signal, sidemarker, or DRL bulb,
do the following:
1. Remove the headlamp assembly as mentioned
previously. SeeHeadlamps on page 5-55for
more information.2. Press the retainer clip (arrow), located behind the
turn signal assembly, towards the outside of the
vehicle.
3. Pull the turn signal assembly out from the vehicle.
5-59

A. Daytime Running Lamp (DRL)
B. Front Turn Signal/Parking Lamp
C. Sidemarker Lamp4. Press the locking release lever (the sidemarker
lamp does not have a locking release lever), turn
the bulb socket counterclockwise and remove it
from the turn signal assembly.
5. Remove the old bulb from the bulb socket.
6. Install a new bulb into the bulb socket.
7. Reinstall the bulb socket into the turn signal
assembly and turn it clockwise until it locks
(the sidemarker lamps does not lock into place).
8. Reinstall the turn signal assembly back onto the
vehicle placing the hook and posts on the inner
side into the alignment holes rst and then the outer
side into the retainer bracket. Push until you hear
a click.
9. Reinstall the headlamp assembly back into the
vehicle.
5-60

Daytime Running Lamps (DRL)
Vehicles with Body-Side Cladding
The daytime running lamps (DRL) are located in the
front fascia near the fog lamps. They can be identied by
their square shape. To change a bulb, do the following:
1. Reach under the front fascia and locate the
DRL assembly. Be sure you are not picking the fog
lamp assembly, which is near the DRLs.
2. Turn the bulb socket
counterclockwise and
remove it from the DRL
assembly.
3. Pull out the old bulb from the socket.
4. Install a new bulb.
5. Reinstall the bulb socket back into the DRL
assembly and turn it clockwise until it is tight.
Taillamps, Turn Signal, Stoplamps
and Back-up Lamps
To replace one of these bulbs, do the following:
1. Open the tailgate. SeeTailgate on page 2-20for
more information.
2. Remove the two rear
lamp assembly screws
near the tailgate
latch and pull out the
lamp assembly.
5-61

3. Locate the bulb you wish to change.
A. Stoplamp/Taillamp
B. Turn Signal Lamp
C. Back-up Lamp
4. Press the release tab
and turn the bulb socket
counterclockwise to
remove it from the
taillamp assembly.5. Pull the old bulb straight out from the socket.
6. Press a new bulb into the socket and turn the socket
clockwise into the taillamp assembly until it clicks.
7. Reinstall the taillamp assembly and tighten the
screws.
License Plate Lamp
To replace one of these bulbs, do the following:
1. Reach under the rear bumper for the bulb socket.
2. Twist the bulb socket counterclockwise and pull the
bulb socket out of the connector.
5-62

3. Pull the old bulb from the bulb socket, keeping the
bulb straight as you pull it out.
4. Install the new bulb.
5. Reverse steps 1–3 to reinstall the license
plate lamp.
Replacement Bulbs
Exterior Lamp Bulb Number
Back-up Lamp 3157
Daytime Running Lamps (DRL) 4114K
Front Parking and Turn
Signal Lamp3157A or 3457NA
Headlamps
High-Beam *9011 or 9005
Low-Beam 9006
Stoplamp, Taillamp and Turn
Signal Lamp3157
Sidemarker Lamp 194
*Vehicles with Body-Side Cladding
For replacement bulbs not listed here, contact
your dealer.
Windshield Wiper Blade
Replacement
Windshield wiper blades should be inspected for wear
and cracking. SeeScheduled Maintenance on page 6-4
for more information.
Replacement blades come in different types and are
removed in different ways. For proper type and length, see
Normal Maintenance Replacement Parts on page 6-14.
To replace the windshield wiper blade assembly do the
following:
1. Lift the wiper arm away from the windshield.
5-63

2. Push the release lever (B) to disengage the hook
and push the wiper arm (A) out of the blade (C).
3. Pushthe new wiper blade securely on the wiper arm
until you hear the release lever click into place.
Tires
Your new vehicle comes with high-quality tires made by
a leading tire manufacturer. If you ever have questions
about your tire warranty and where to obtain service,
see your GM Warranty booklet for details. For additional
information refer to the tire manufacturer’s booklet
included with your vehicle.
{CAUTION:
Poorly maintained and improperly used tires
are dangerous.
Overloading your tires can cause
overheating as a result of too much
friction. You could have an air-out and a
serious accident. SeeLoading Your
Vehicle on page 4-46.
Underinated tires pose the same danger
as overloaded tires. The resulting accident
could cause serious injury. Check all tires
frequently to maintain the recommended
pressure. Tire pressure should be checked
when your tires are cold. SeeInflation - Tire
Pressure on page 5-71.
Overinated tires are more likely to be
cut, punctured, or broken by a sudden
impact — such as when you hit a pothole.
Keep tires at the recommended pressure.
Worn, old tires can cause accidents. If your
tread is badly worn, or if your tires have
been damaged, replace them.
5-64
