2006 BMW MOTORRAD K 1200 S alarm

ESA Electronic SuspensionAdjustment
Electronic Suspension
Adjustment.
DWA Anti-theft alarm (Diebs-
tahlwarnanlage)
ABS Anti-lock brake system
RDC Tyre pressure control
(ReifenDruck-Control)EquipmentWhen you ordered your BMW
motorcycle, you chose vari-
ous items of custom equip-
ment. This Rider's Manual
describes optional extras (OE)
offered by BMW and selec-
ted optional accessories (OA).
This explains why the manual
may also contain descriptions
of equipment which you have
not ordered. Please note, too,
that your motorcycle might not be exactly as illustrated
in this manual on account of
country-specific differences.
If your BMW was supplied
with equipment not described
in this Rider's Manual, you will
find these features described
in separate manuals.
Technical dataAll dimensions, weights and
power ratings stated in the
Rider's Manual are quoted
to the standards and comply
with the tolerance require-
ments of the Deutsche Institut
für Normung e.V. (DIN). Ver-
sions for individual countries
may differ.CurrencyThe high safety and quality
standards of BMW motor-
cycles are maintained by con-
stant development work on
designs, equipment and ac-cessories. Because of this,
your motorcycle may differ
from the information supplied
in the Rider's Manual. Nor
can errors and omissions be
entirely ruled out. We hope
you will appreciate that no
claims can be entertained on
the basis of the data, illustra-
tions or descriptions in this
manual.
17zGeneral instructions

Instrument cluster1 Rev. counter
2 Speedometer
3 Warning and telltale
lights ( 20)
4 Multifunction display
( 20)
5 Telltale light, anti-theft
alarm (OE) and sensor for
instrument lighting
6 Control, odometer
( 41)
The instrument-cluster
lighting has automatic
day and night switchover.
217zGeneral views

Mode of presentationMeaning
The
LAMPF!
warning appears
on the display.Front light bulb defective ( 27)
Lights up yellow The
LAMPS!
warning appears
on the display. Bulbs defective ( 27)
Appears on the
display Ice warning ( 27)
The
DWALO!
warning appears
on the display. Battery of anti-theft alarm (OE) weak
( 28)
Lights up yellow The
DWA!
warn-
ing appears on
the display. Anti-theft alarm battery flat (OE)
( 28)
323zStatus indicators

The air temperature measured
at the motorcycle is lower
than 3 °C.The ice warning does
not mean that there is
no risk of black ice forming
at measured temperatures
above 3 °C.
Always take extra care and
think well ahead when tem-
peratures are low; remember
that the danger of black ice
is particularly high on bridges
and where the road is in the
shade.
Ride carefully and think well
ahead.
Battery of anti-theft alarm
(OE) weak
The
DWALO!
warning ap-
pears on the display.
This error message
appears only briefly after the pre-ride check
completes.
The integral battery in the
anti-theft alarm has lost a sig-
nificant proportion of its ori-
ginal capacity. There is no
assurance of how long the
anti-theft alarm can remain
operational if the motorcycle's
battery is disconnected.
Seek the advice of a spe-
cialist workshop, preferably
an authorised BMW Motor-
rad dealer.
Anti-theft alarm battery flat
(OE) General warning light
lights up yellow.
The
DWA!
warning appears
on the display.
The integral battery in the
anti-theft alarm has lost its
entire original capacity. There
is no assurance that the anti- theft alarm will be operational
if the motorcycle's battery is
disconnected.
Seek the advice of a spe-
cialist workshop, preferably
an authorised BMW Motor-
rad dealer.
328zStatus indicators

A
Abbreviations and symbols, 6
Anti-theft alarm, 17
B
BatteryCharging battery when
connected, 120
Charging battery when
disconnected, 121
Installation, 121, 122
Removal, 121, 122
Technical data, 141
Warning, battery charge
current, 26
Brake fluid Checking level, front, 94
Checking level, rear, 95
Brake pads Checking front, 92
Checking rear, 93
Brakes Technical data, 140
Breakdown assistance kit, 85 Bulbs
General instructions, 108
Replacing brake-light
bulbs, 113
Replacing front turn
indicator bulbs, 115
Replacing high-beam
headlight bulb, 111
Replacing low-beam
headlight bulb, 109
Replacing parking-light
bulb, 113
Replacing rear light
bulbs, 113
Replacing rear turn indicator
bulbs, 117
Technical data, 142
Warning, bulb failure, 27
C
Case Adapting, 84
Adjusting, 82
Closing, 82
Installing, 84 Opening, 82
Removing, 83
Checklist, 66
Clock, 20 Adjusting, 42
Clutch Fluid reservoir, 11, 13
Technical data, 137
Confirmation of maintenance work, 149
E
Electrics Technical data, 141
Emergency off switch (kill switch), 16, 48
Engine Technical data, 134
Temperature gauge, 20, 21
Warning, engine electron-
ics, 25
Engine oil Checking level, 89
Draining, 91
Technical data, 136
11156zIndex
