2005 SUBARU IMPREZA window

2-26
Keys and doors
V
Locking the passengers’ windows
1) Lock
2) Unlock
To lock the passengers’ windows, push the lock
switch. When the lock switch is in the “LOCK” position,
the passengers’ windows cannot be opened or closed. T Passengers’ side switches
To open the window, push the switch down and hold it
until the window reaches the desired position.
To close the window, pull the switch up and hold it until
the window reaches the desired position.
When the lock switch on the power window switch cluster, located on the driver’s side door, is in the
“LOCK” position, the passengers’ windows cannot be
operated with the passengers’ switches.
1
2
HS2028BB

2-27
Keys and doors
– CONTINUED –
Trunk lid (Sedan)
yTo prevent dangerous exhaust gas from en-
tering the vehicle, always keep the trunk lid
closed while driving. y Help prevent young children from locking
themselves in the trunk. When leaving the vehi-
cle, either close all windows and lock all doors
or cancel the inside trunk lid release. Also make
certain that the trunk is closed.
On hot or sunny days, the temperature in the
trunk could quickly become high enough to
cause death or serious heat-related injuries in-
cluding brain damage, particularly for small
children. „
To open and close the trunk lid from
outside
To open the trunk lid from outside, insert the key and
turn it clockwise.
To close the trunk lid, lightly press the trunk lid down
until the latch engages.
UG2047BA

3-2
Instruments and controls
High/low beam change (dimmer) .................... 3-31
Headlight flasher .............................................. 3-31
Daytime running light system (except U.S.-spec. WRX-STi) ......................... 3-32
Turn signal lever ........................................... 3-32
Illumination brightness control ................... 3-33
Illumination brightness control (WRX-STi) .................................................. 3-34
Headlight beam leveler (U.S.-spec. WRX-STi) ................................ 3-34
Parking light switch ..................................... 3-35
Fog light button (if equipped) ..................... 3-36
Wiper and washer ......................................... 3-36 Windshield wiper and washer switches ......... 3-38
Rear window wiper and washer switch – Wagon .......................................................... 3-40
Rear window defogger button ..................... 3-41
Windshield wiper deicer (if equipped) ........ 3-43
Intercooler water spray switch (WRX-STi) .................................................. 3-44
Mirrors ........................................................... 3-45 Inside mirror ...................................................... 3-45
Outside mirrors ................................................. 3-48
Tilt steering wheel ........................................ 3-50
Horn ............................................................... 3-51

3-4
Instruments and controls
The key can be turned from “ACC” to “LOCK” only
when the selector lever is in the “P” position. T
Manual transmission vehicles
The key can be turned from “ACC” to “LOCK” only
when the key is pushed in while turning it.
y Never turn the ignition switch to “LOCK”
while the vehicle is being driven or towed be-
cause that will lock the steering wheel, prevent-
ing steering control. And when the engine is
turned off, it takes a much greater effort than usual to steer.y
Before leaving the vehicle, always remove
the key from the ignition switch for safety and
never allow an unattended child to remain in
the vehicle. Failure to follow this procedure
could result in injury to a child or others. They
could operate the power windows, the sunroof
or other controls or even make the vehicle
move.
„ ACC
In this position the electrical accessories (radio, ciga-
rette lighter, etc.) can be used. „ ON
This is the normal operating position after the engine
is started. „ START
The engine is started in this position. The starter
cranks the engine to start it. When the key is released
(after the engine has started), the key automatically
returns to the “ON” position.
HS2020DA

3-36
Instruments and controls
Fog light button (if equipped)
The fog lights operate only when the headlights are on
low beam. Push the fog light button to turn the fog
lights on.
Press the button again to turn them off.
The indicator light located on the button will illuminate
when the fog lights are on.Wiper and washer
In freezing weather, do not use the windshield
washer until the windshield is sufficiently
warmed by the defroster.
Otherwise the washer fluid can freeze on the
windshield, blocking your view.
y
Do not operate the washer continuously for
more than ten seconds, or when the washer flu-
id tank is empty. This may cause overheating of
the washer motor. Check the washer fluid level
frequently, such as at fuel stops. y Do not operate the wipers when the wind-
shield or rear window is dry. This may scratch
the glass, damage the wiper blades and cause
the wiper motor to burn out. Before operating
the wiper on a dry windshield or rear window,
always use the windshield washer.y In freezing weather, be sure that the wiper
blades are not frozen to the windshield or rear
window before switching on the wipers. At-UG3512BA

3-37
Instruments and controls
– CONTINUED –
tempting to operate the wiper with the blades
frozen to the window glass could cause not
only the wiper blades to be damaged but also
the wiper motor to burn out. If the wiper blade
is frozen to the window glass, be sure to oper-
ate the defroster, windshield wiper deicer (if
equipped) or rear window defogger before turn-
ing on the wiper.yIf the wipers stop during operation because
of ice or some other obstruction on the window,
the wiper motor could burn out even if the wiper
switch is turned off. If this occurs, promptly
stop the vehicle in a safe place, turn the ignition
switch to the “LOCK” position and clean the
window glass to allow proper wiper operation. y Use clean water if windshield washer fluid is
unavailable. In areas where water freezes in
winter, use SUBARU Windshield Washer Fluid
or the equivalent. (See the “Windshield washer
fluid” section in chapter 11.)
Also, when driving the vehicle when there are
freezing temperatures, use non-freezing type
wiper blades.y Do not clean the wiper blades with gasoline
or a solvent, such as paint thinner or benzene.
This will cause deterioration of the wiperblades.
NOTE y The wiper operates only when the ignition
switch is in the “ON” or “ACC” position. y Clean your wiper blades and window glass peri-
odically with a washer solution to prevent streak-
ing, and to remove accumulations of road salt or
road film. Keep the washer button depressed at
least for 1 second so that washer solution will be
sprinkled all over the windshield or rear window. y Grease, wax, insects or other material on the
windshield or the wiper blade results in jerky wip-
er operation and streaking on the glass. If you can-
not remove those streaks after operating the
washer or if the wiper operation is jerky, clean the
outer surface of the windshield or rear window
and the wiper blades using a sponge or soft cloth
with a neutral detergent or mild-abrasive cleaner.
After cleaning, rinse the window glass and wiper
blades with clean water. The glass is clean if no
beads form on the glass when you rinse with wa-ter. y If you cannot eliminate the streaking even after
following this procedure, replace the wiper blades
with new ones. Refer to the “Replacement of wiper

3-40
Instruments and controls
„
Rear window wiper and washer switch
– Wagon
1) Rear wiper
2) Washer
T Rear wiper
The rear wiper offers intermittent operation only.
To turn the rear wiper on, turn the knob on the end of
the wiper control lever to the “ON” position.
To turn the wiper off, return the knob on the end of the
lever to the “OFF” position. T Washer
To wash the rear window while the rear wiper is oper- ating, turn the knob on the end of the wiper control le-
ver counterclockwise to the “ ” position. The
washer fluid sprays until you release the knob.
To wash the rear window when the rear wiper is not in
use, turn the knob on the end of the wiper control lever
clockwise to the “ ” position. The washer fluid
sprays and the wiper operates until you release the
knob.
1
2
2
UG3514BB

3-41
Instruments and controls
– CONTINUED –
Rear window defogger button
The rear window defogger operates only when the ig-
nition switch is in the “ON” position.
The rear window defogger button is located on the cli-
mate control panel.
The defogger will automatically shut off after about 15
minutes. If the window clears before that time, push
the button to turn it off. It also turns off when the igni-
tion switch is turned to the “ACC” or “LOCK” position.
If defrosting or defogging is desired when you restart
your vehicle, you have to push the button to turn it on
again.
Manual climate control system
UG3508BA
