Seat, seatbelt and SRS airbags
Window-side
3. Attach the child restraint top tether hook to the ap-
propriate upper anchorage.
4. Tighten the top tether securely.
Please contact your SUBARU dealer if you have any
question regarding the installation of a child restraint
system.
Always remove the headrest when mounting a
child restraint system with a top tether. Other-
wise, the top tether cannot be fastened tightly.
UG1097BA

1-67
Seat, seatbelt and SRS airbags
– CONTINUED –
Never allow a child to kneel on the front pas-
senger’s seat facing the side window or to wrap
his/her arms around the front seatback. In the
event of an accident, the force of the SRS side
airbag deployment could injure the child seri-
ously because his/her head or arms or other
body parts are too close to the SRS side airbag.
Since your vehicle is also equipped with a pas-
senger’s SRS frontal airbag, children aged 12
and under should be placed in the rear seat
anyway and should be properly restrained at all
times.
Do not attach accessories to the door trim or
near either SRS side airbags and do not place
objects near the SRS side airbags. In the event
of the SRS side airbag deployment, they could
be propelled dangerously toward the vehicle’s
occupants and cause injuries.
HS1096BA

2-1
2
Keys and doors
Keys ............................................................... 2-2 Key number ....................................................... 2-3
Immobilizer (WRX-STi) ................................. 2-3 Security ID plate ................................................ 2-4
Security indicator light ..................................... 2-5
Key replacement ............................................... 2-5
Door locks ..................................................... 2-6 Locking and unlocking from the outside ........ 2-6
Locking and unlocking from the inside .......... 2-7
Power door locking switches ...................... 2-8
Remote keyless entry system ..................... 2-9 Locking the doors ............................................. 2-10
Unlocking the doors ......................................... 2-10
Illuminated entry ............................................... 2-11
Vehicle finder function ..................................... 2-11
Sounding a panic alarm ................................... 2-11
Selecting audible signal operation .................. 2-11
Replacing the battery ....................................... 2-11
Replacing lost transmitters .............................. 2-13
Security system (if equipped) ..................... 2-17 System operation .............................................. 2-17
Arming the system ............................................ 2-17
Disarming the system ....................................... 2-19
Valet mode ......................................................... 2-20
Passive arming .................................................. 2-20
Child safety locks ......................................... 2-23
Windows ........................................................ 2-24 Power windows ................................................. 2-24
Trunk lid (Sedan) .......................................... 2-27 To open and close the trunk lid from
outside ............................................................ 2-27
To open the trunk lid from inside .................... 2-28
To cancel the trunk lid release ........................ 2-28
Internal trunk lid release handle ...................... 2-28
Rear gate (Wagon) ........................................ 2-31
Moonroof (if equipped) ................................. 2-33 Tilt function ....................................................... 2-33
Sliding function ................................................. 2-33
Sun shades ........................................................ 2-35

2-4
Keys and doors
y
Never leave your vehicle unattended with its
keys inside. y Before leaving your vehicle, close all windows
and lock the doors and rear gate.y Do not leave spare keys or any record of your
key number in the vehicle.
y Do not place the key under direct sunlight or
anywhere it may become hot. y Do not get the key wet. If the key gets wet,
wipe it dry with a cloth immediately. „
Security ID plate
A) Key number plate
B) Security ID plate
The security ID is stamped on the metal plate attached
to the key set. Write down the security ID and keep it
in another safe place, not in the vehicle. This number
is needed to make a replacement key if you lose your
key or lock it inside the vehicle.
This number is also needed for replacement or repair
of the engine control unit, immobilizer control unit.A B
UB2534BB

2-17
Keys and doors
– CONTINUED –
Security system (if equipped)
The security system helps to protect your vehicle and
valuables from theft. The horn sounds and the turn
signal lights flash if someone attempts to break into
your vehicle. The starter motor is also interrupted to
prevent starting the vehicle without a key.
The system can be armed and disarmed with the re-
mote transmitter.
The system does not operate when the key is inserted
into the ignition switch. „System operation
The security system will give the following alarm indi-
cations when triggered: y The turn signal lights will flash and the horn will
sound intermittently. In addition, the starter motor will
not operate. y The alarm automatically resets after 30 seconds;
however, the alarm will reactivate if the vehicle is tam-
pered with again. The alarm will continue for six times
if any sensor continues to be activated.
The alarm is triggered by: y Opening a door, the rear gate or trunk lid.
y Application of physical shock to the vehicle (e.g. forced entry). Note that there are two alarm levels for
shock: warning and alarm. In warning mode, the alarm
detects lower level vibrations and triggers 2 warning
chirps on the horn and two flashes on the lights as a
deterrent to would be vandals. In alarm mode, higher
levels of shock are detected and the system will go into full alarm. y
Ignition switch being turned on while in armed state.
NOTE
With the valet mode selected, the security system
does not operate when the remote transmitter is
used for locking and unlocking. The security indi-
cator light in the combination meter flashes twice
per second to show that the valet mode is select-
ed. For details, refer to “Valet mode” in this sec- tion. „ Arming the system
T To arm the system using remote transmitter
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk lid)
are locked.
5. Close all doors (and the rear gate on the Wagon).

2-19
Keys and doors
– CONTINUED –
properly closed. When you close the door, the system
will automatically arm and doors will automaticallylock. TTo arm the system using power door locking
switches
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk lid)
are locked.
5. Close the doors (and the rear gate on the Wagon)
but leave only the driver’s door or the front passen-
ger’s door open. 6. Push the front side (“LOCK” side) of the power door
locking switch to set the door locks.
7. Close the door. An electronic chirp will sound once,
the turn signal lights will flash once and the security in-
dicator light will flash as follows:
All models except WRX-STi: once every approximate-
ly two seconds
WRX-STi: twice every approximately two seconds
NOTE
The system can be armed even if the engine hood
and/or the windows are opened. Always make
sure that they are fully closed before arming the
system. „
Disarming the system
Briefly press the “ ” button (for less than two sec-
onds) on the remote transmitter. The driver’s door will
unlock, an electronic chirp will sound twice, the turn
signal lights will flash twice and the security indicator
light will go off.
NOTE (WRX-STi)
If your vehicle is equipped with an immobilizer, the
immobilizer’s function will cause the security indi-
cator light to flash (once every approximately
three seconds) even after the system is disarmed.
6
7
UG2038BB

2-24
Keys and doors
Windows „
Power windows
To avoid serious personal injury caused by en-
trapment, you must do the following.yWhen operating the power windows, be ex-
tremely careful to prevent anyone’s fingers,
arms, neck or head from being caught in the
window. y Always lock the passengers’ windows using
the lock switch when children are riding in the
vehicle. y Before leaving the vehicle, always remove
the key from the ignition switch for safety and
never allow an unattended child to remain in
the vehicle. Failure to follow this procedure
could result in injury to a child operating the
power window.
The power windows operate only when the ignition
switch is in the “ON” position. T
Driver’s side switches
1) Lock switch
2) For driver’s window (with one-touch auto down fea- ture)
3) For front passenger’s window
4) For rear left window
5) For rear right window
All door windows can be controlled by the power win-
dow switch cluster at the driver side door.
1
2
4 5 3
UG2045BB

2-25
Keys and doors
– CONTINUED –
VOperating the driver’s window
1) Open
2) Automatically open
3) Close
To open:
Push the switch down lightly and hold it. The window
will open as long as the switch is held.
This switch also has a one-touch auto down feature
that allows the window to be opened fully without hold-
ing the switch.
Push the switch down until it clicks and release it, and
the window will fully open. To stop the window half-
way, pull the switch up lightly. To close:
Pull the switch up lightly and hold it. The window will
close as long as the switch is held. V
Operating the passengers’ windows
To open the passengers’ windows, push the appropri-
ate switch down and hold it until the window reaches
the desired position.
To close the window, pull the switch up and hold it until
it reaches the desired position.
3 1
2
HS2027BB
HS2027CA
