2005 SUBARU IMPREZA window

19
–
CONTINUED –
„Light control and wiper control levers/switches
12
3
4
5
1
10 9 7
11
2
6
8
UGF064BB
1) Parking light switch (page 3-35)
2) Windshield wiper (page 3-38)
3) Mist (page 3-39)
4) Windshield washer (page 3-39)
5) Rear window wiper and washer
switch (page 3-40)
6) Wiper control lever (page 3-38)
7) Illumination brightness control (page 3-33)
8) Light control lever (page 3-30)
9) Headlight ON/OFF (page 3-30)
10) Headlight flasher High/Low beam change (page 3-30)
11) Turn signal (for lane change) (page 3-32)
12) Turn signal (page 3-32)

1-14
Seat, seatbelt and SRS airbags
T
Infants or small children
Use a child restraint system that is suitable for your ve-
hicle. See information on “Child restraint systems” inthis chapter. T Children
If a child is too big for a child restraint system, the child
should sit in the rear seat and be restrained using the
seatbelts. According to accident statistics, children are
safer when properly restrained in the rear seating po-
sitions than in the front seating positions. Never allow
a child to stand up or kneel on the seat.
If the shoulder portion of the belt crosses the face or
neck, adjust the shoulder belt anchor height (window-
side seating positions only) and then if necessary
move the child closer to the belt buckle to help provide
a good shoulder belt fit. Care must be taken to secure-
ly place the lap belt as low as possible on the hips and
not on the child’s waist. If the shoulder portion of the
belt cannot be properly positioned, a child restraint
system should be used. Never place the shoulder belt
under the child’s arm or behind the child’s back. T
Expectant mothers
Expectant mothers also need to use the seatbelts.
They should consult their doctor for specific recom-
mendations. The lap belt should be worn securely and
as low as possible over the hips, not over the waist. „ Emergency Locking Retractor (ELR)
The driver’s seatbelt has an Emergency Locking Re-
tractor (ELR).
The emergency locking retractor allows normal body
movement but the retractor locks automatically during
a sudden stop, impact or if you pull the belt very quick-
ly out of the retractor.
HS1107AA

1-20
Seat, seatbelt and SRS airbags
4. To make the lap part tight, pull up on the shoulder
belt.
5. Place the lap belt as low as possible on your hips,
not on your waist.
V
Adjusting the rear seat shoulder belt anchor
height (window-side seating positions only)
The shoulder belt anchor height should be adjusted to
the position best suited for you. To adjust the anchor
height, push the release button and slide the anchor
up or down. Pull down on the anchor to make sure that
it is locked in place.
Always adjust the anchor height so that the shoulder
belt passes over the middle of the shoulder without
touching the neck.
4
5
HS1051BC
UG1075BA

1-34
Seat, seatbelt and SRS airbags
„
Where to place a child restraint system
The following are SUBARU’s recommendations on
where to place a child restraint system in your vehicle.
A: Front passenger’s seat
You should not install a child restraint system due to
the hazard to children posed by the passenger’s air-
bag.
B: Rear seat, window-side seating positions
Recommended positions for all types of child restraint
systems.
In these positions, Automatic/Emergency Locking Re-
tractor (A/ELR) seatbelts and lower anchorages (bars)
are provided for installing a child restraint system. C: Rear seat, center seating position
Installing a child restraint system is not recommended,
although the A/ELR seatbelt is provided in this posi- tion.
Some types of child restraints might not be able to be
secured firmly due to projection of the seat cushion.
In this seating position, you should use only a child re-
straint system that has a bottom base that fits snugly
against the contours of the seat cushion and can be
securely retained using the seatbelt.
If it is unavoidable to install a child restraint system in
the rear seat’s center seating position, lower the cen-
ter head restraint to the lowest position and install the
child restraint system by correctly passing the rear
center seatbelt through the belt guide.
Put children aged 12 and under in the rear seat
properly restrained at all times. The SRS airbag
deploys with considerable speed and force and
can injure or even kill children, especially if
they are 12 years of age and under and are not
restrained or improperly restrained. Because
children are lighter and weaker than adults,
their risk of being injured from deployment is
greater.
For that reason, be sure to secure ALL types of
UG1530BA

1-44
Seat, seatbelt and SRS airbags
Some types of child restraint systems can be installed
on the rear seat of your vehicle without use of the seat-
belts. Such child restraint systems are secured to the
designated anchorages provided on the vehicle body.
The lower and tether anchorages are sometimes re-
ferred to as the LATCH system (
Lower Anchors and
T ethers for CHildren).
Your vehicle is equipped with four lower anchorages
(bars) and three upper anchorages (tether anchorag-
es) for accommodating such child restraint systems. The lower anchorages (bars) are used for installing a
child restraint system only on the rear seat window-
side seating positions. For each window-side seating
position, two lower anchorages are provided.
Each lower anchorage is located where the seat cush-
ion meets the seatback.
UG1091BAHS1076BA

1-45
Seat, seatbelt and SRS airbags
– CONTINUED –
The tether anchorages (upper anchorages) are pro-
vided for all the seating positions (middle and both
window-side ones) of the rear seat. You will find marks “ ” at the bottom of the rear
seat seatbacks. These marks indicate the positions of
the lower anchorages (bars).
UG1095BAHS1078BA

1-50
Seat, seatbelt and SRS airbags
There is an anchorage for the center seating position
at the rear edge of the roof, and anchorages for each
of the two window-side seating positions on the rear
wall of the cargo area. T
To hook the top tether
V Sedan
1. Attach the child restraint top tether hook to the ap-
propriate upper anchorage.
2. Tighten the top tether securely.
Please contact your SUBARU dealer if you have any
question regarding the installation of a child restraint
system. V
Wagon
1. Remove the headrest at the window-side seating
position where the child restraint system has been in-
stalled with the lower anchorages or seatbelt; lift up
the headrest while pressing the release button. Store
the headrest in the cargo area. Avoid placing the
headrest in the passenger compartment to prevent it
from being thrown around in the passenger compart-
ment in a sudden stop or a sharp turn.
UG1087BA
HS1081BA

1-51
Seat, seatbelt and SRS airbags
– CONTINUED –
2. (For both window-side seating positions) Remove
the cap from the anchor fitting cover by prying it with a
screwdriver. Center
UG1526BAUG1090BA
