2005 SUBARU BAJA clock

9-22
In case of emergency
Confirm that the cooling fan is turning. If the fan is not
turning, immediately turn the engine off and contact
your authorized dealer for repair.
3. After the engine coolant temperature has dropped,
turn off the engine.
If the temperature gauge stays at the overheated
zone, turn the engine off.
4. After the engine has fully cooled down, check the
coolant level in the reserve tank.
If the coolant level is below the “MIN” mark, add cool-
ant up to the “MAX” mark.
5. If there is no coolant in the reserve tank, add cool-
ant to the reserve tank. Then remove the radiator cap
and fill the radiator with coolant.
If you remove the radiator cap from a hot radiator, first
wrap a thick cloth around the radiator cap, then turn
the cap counterclockwise slowly without pressing
down until it stops. Release the pressure from the ra-
diator. After the pressure has been fully released, re-
move the cap by pressing down and turning it.Towing
Never tow AWD vehicles (both AT and MT) with
the front wheels raised off the ground while the
rear wheels are on the ground, or with the rear
wheels raised off the ground while the front
wheels are on the ground. This will cause the
vehicle to spin away due to the operation or de-
terioration of the center differential.
If towing is necessary, it is best done by your SUBARU
UB9064BA

9-29
In case of emergency
– CONTINUED –
1) Screws
2. Remove the map light lens by prying the edge of
the lens with a flat-head screwdriver, then remove the
switch body retaining screws and take off the moon- roof switch. 3. Insert the wrench in the end of the motor shaft. y
To lower the moonroof, turn the wrench clockwise.
y To close the moonroof, turn the wrench counter-
clockwise.
Have your vehicle checked by an authorized SUBARU
dealer.
1UB9007BBUB9008BA

10-4
Appearance care
sion components. „
Cleaning aluminum wheels
y Promptly wipe the aluminum wheels clean of any
kind of grime or agent. If dirt is left on too long, it may
be difficult to clean off. y Do not use soap containing grit to clean the wheels.
Be sure to use a neutral cleaning agent, and later rinse
thoroughly with water. Do not clean the wheels with a
stiff brush or expose them to a high-speed washing
device.y Clean the vehicle (including the aluminum wheels)
with water as soon as possible when it has been
splashed with sea water, exposed to sea breezes, or
driven on roads treated with salt or other agents. „ Cleaning fog light lens
1. Stop the vehicle in a safe place.
2. Stop the engine and turn off the fog lights. 1) Counter-clockwise
2) Light lens horizontal center line
3. Check that the fog lights are not hot. Then, grasp
the protector and turn it approximately 10 ° counter-
clockwise.
4. Pull the protector off the fog light.
5. Wash the lens with water.
6. Apply the protector to the lens at an angle of ap-
proximately 10 ° from the fog light’s horizontal center
line. Then, turn the protector clockwise until it stops.
Finally, check that the protector’s horizontal bars are
parallel with the fog light’s horizontal center line.
1
2 10
UBA017BB

11 -6 5
Maintenance and service
– CONTINUED –
TBAJA-Sport
1) Electrical connector
2) Push
1. Disconnect the electrical connector while pressing
the lock release tab. 2. Remove the bulb holder from the headlight assem-
bly by turning it counterclockwise.
3. Remove the bulb from the headlight assembly.
4. Install the new bulb.
5. Install the bulb holder in the headlight assembly by
turning it clockwise until it locks.
6. Remove the electrical connector.
1
2
UBB045BB
UBB046BA

11 - 6 6
Maintenance and service
T
BAJA, BAJA-Turbo
1) Low beam light bulb
2) High beam light bulb
Remove the headlight bulb cover, by turning it coun-
terclockwise.
UBB039BA
1
2UBB040BB

11 - 6 8
Maintenance and service
T
High beam light bulbs0
1) Push
1. Disconnect the electrical connector from the bulb.
2. Remove the bulb from the headlight assembly by
turning it counterclockwise.
3. Replace the bulb with new one.
4. Reconnect the electrical connector. At this time,
use care not to touch the bulb surface.
5. To install the bulb to the headlight assembly, turn it
clockwise until it clicks.
6. Install the headlight bulb cover. „ Front fog light
It may be difficult to replace the bulbs. Have yourUBB043BA
1
UBB044BB

11 -6 9
Maintenance and service
– CONTINUED –
SUBARU dealer replace the bulbs if necessary. „Front turn signal light, parking light
and side marker light
The headlight assembly must be removed before the
front turn signal light and parking light bulbs can be re-
placed. When the headlight assembly has been re-
moved and then reinstalled, it may become necessary
to make a headlight aiming adjustment. After a bulb
has been replaced, it is recommended that the head-
light aiming adjustment be made at a SUBARU dealer.
1. Remove the headlight assembly mounting screws
located at the top of and the front of the headlight as- sembly using a Phillips screwdriver or an open-end
wrench.
2. Move the headlight assembly forward.
1) Front turn signal light bulb
2) Front turn signal light bulb/parking and front side marker light bulb
3. Remove the bulb socket from the headlight assem-
bly by turning it counterclockwise.
UBB016BA
1
2
UBB039CB

11 - 7 0
Maintenance and service
4. Remove the bulb from the socket by pushing it and
turning counterclockwise. Install a new bulb in the socket.
5. Set the bulb socket into the headlight assembly and
turn it clockwise until it locks.
6. Set the headlight assembly into the vehicle body.
Tighten the mounting screws. „
Rear combination lights
Rear combination lights are composed of the rear turn
signal/brake/tail light and back up lights. T Rear turn signal/Brake/Tail and Back up lights
The rear turn signal/brake/tail light is one bulb with two filament types.
If any one of them malfunctions, replace the bulb with
a new one.
1. Open the tailgate.
2. Pry the cover from the side of the rear combination
light.
UBB020BA
