2005 RENAULT MEGANE ESP

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G1-FRA.qxd 10/11/05 15:53 Page 1.35
1.35
To avoid any risk to your safety, we recommend that you use
RENAULT approved accessories because they are suitable for your
vehicle and are the only accessories for which RENAULT will
provide a warranty.
CHILD SAFETY (continued)
The right choice
Your vehicle is fitted with the Isofix
system, approved in accordance with
the ECE 14 and ECE 16 regulations.
The safety of your children is also
your responsibility.
To ensure that your child has the
maximum possible protection, we
recommend that you use Isofix seats
approved by the RENAULT
Network.
Refer to the information on the
Isofix system for securing child seats
in Section 1.
Restraint systems for all the
categories are available. These
systems have been developed in
consultation with the manufacturers
and have been tested in RENAULT
vehicles.
Contact your RENAULT Dealer and
ask him to help you install it.
Categories 0 and 0+ (from 0 to
13 kg)
A child’s neck is very susceptible to
injury up to the age of two. It is
preferable to put your child into a
rear-facing enclosing shell seat. This
position enhances safety.
Category 1 (from 9 kg to 18 kg)
Between the ages of 2 and 4, a
child’s pelvis is not fully developed.
Restraints using the vehicle’s seat
belts are not adequate and there is a
risk that the child will sustain
abdominal injuries in the event of a
frontal impact. Use a seat which
restrains the child by means of a
harness.
Place the back of the child seat
firmly against the vehicle seatback.
Adjust the height of the head
restraint or remove it if necessary.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.35 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.51
1.51
INSTRUMENT PANEL (continued)
The presence and operation of the indicator lights described below depen\
d on the vehicle equipment and country.
1 Rev counter
(scale × 1000)
üElectronic Stability
Program (ESP) and
traction control system
(ASR) warning light.
There are several reasons for the
warning light coming on: see
Electronic Stability Program
(ESP) and Traction control system
(ASR) in Section 2.
äFume filter system
warning light
For vehicles equipped
with this option, the light comes
on when the ignition is switched
on then goes out.
 If it lights up continuously, contact your RENAULT Dealer
as soon as possible;
 If it flashes, reduce the engine speed until the light stops
flashing.
Consult your RENAULT Dealer
as soon as possible.
Refer to the information on
emission control, fuel economy
and driving in Section 2. 1
cLeft-hand direction
indicator light
xAnti-lock braking system
(ABS) indicator light
This comes on when the
engine is started then goes out.
If it comes on when you are
driving, it indicates a fault in the
anti-lock braking system (ABS).
Braking will then be as normal,
without the ABS system.
Contact your RENAULT Dealer as
soon as possible. 1
åAirbag warning light
This lights up when the
engine is started and goes
out after a few seconds.
If it does not light up when the
ignition is switched on, or comes
on when the engine is running,
there is a fault in the system.
Consult your RENAULT Dealer as
soon as possible.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.51 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.59
1.59
INSTRUMENT PANEL (continued)
The presence and operation of the indicator lights described below depen\
d on the vehicle equipment and country.
1 Rev counter
(scale × 1000)
xAnti-lock braking system
(ABS) indicator light
This comes on when the
engine is started then goes out.
If it comes on when you are
driving, it indicates a fault in the
anti-lock braking system (ABS).
Braking will then be as normal,
without the ABS system.
Contact your RENAULT Dealer as
soon as possible.
åAirbag warning light
This lights up when the
engine is started and goes
out after a few seconds.
If it does not light up when the
ignition is switched on, or comes
on when the engine is running,
there is a fault in the system.
Consult your RENAULT Dealer as
soon as possible. 1
äToxic Fume Filter
System Warning Light
For vehicles equipped
with this option, the light comes
on when the ignition is switched
on then goes out.
 If it lights up continuously, contact your RENAULT Dealer
as soon as possible;
 If it flashes, reduce the engine speed until the light stops
flashing.
Consult your RENAULT Dealer
as soon as possible.
Refer to the information on
emission control, fuel economy
and driving in Section 2.
cLeft-hand direction
indicator light 1
üElectronic Stability
Program (ESP) and
traction control system
(ASR) indicator light.
There are several reasons for the
warning light coming on: see
Electronic Stability Program
(ESP) and Traction control system
(ASR) in Section 2.
îSpeed limiter and cruise
control indicator light
To understand how this
operates, see the information on
the Cruise control and Speed
limiter in Section 2.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.59 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23511

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.74
1.74
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of fault messages
Message Display
Instrument panel variant 2 Interpretation of messages
"ESP/ASR deactivated"
ASR traction control deactivated (see information on traction control \
in
section 2) and ESP, electronic stability program (see “electronic stability
program: ESP with understeer control” paragraph in section 2).
"No tyre sensor" or "Tyre sensor out of order"
Sensor fault on the missing wheel in zone Aof the display: this is displayed, for
example, when the emergency spare wheel is fitted on the vehicle (see T\
yre
pressure monitor in Section 2).
"Check tyre pressure"
Wheel inflation fault (underinflation) indicated on the multifunction \
display or
in zone Aon the information display; adjust the pressure as soon as possible.
"Bleed diesel filter" or "Check diesel filter"
Indicates that there is water present in the diesel fuel.
Consult your RENAULT Dealer as soon as possible.
Message Display
Instrument panel variant 1
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.74 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.01
2.01
Section 2: Driving
(Advice on use relating to fuel economy and the environment)
Running in ........................................................................\
.................................................................................................2.02
Starting and stopping the engine
........................................................................\
.............................................2.03 ➟2.05
Special features of petrol versions
........................................................................\
....................................................... .2.06
Special features of diesel versions
........................................................................\
....................................................... .2.07
Special features of diesel versions with particle filter
........................................................................\
.....................2.08
Gear lever
........................................................................\
....................................................... ............................................2.09
Handbrake
........................................................................\
....................................................... ...........................................2.10
Power assisted steering
........................................................................\
....................................................... .....................2.10
Advice on emission control and fuel economy
........................................................................\
....................2.11 ➟2.13
Environment
........................................................................\
....................................................... ....................................... 2.14
Tyre pressure monitor
........................................................................\
....................................................... .........2.15 ➟2.18
Electronic Stability Program: ESP
........................................................................\
....................................................... ..2.19
Traction control: ASR
........................................................................\
....................................................... ............2.20 - 2.21
Anti-lock Braking System: ABS
........................................................................\
.................................................2.22 - 2.23
Emergency brake assist
........................................................................\
....................................................... .....................2.24
Speed Limiter
........................................................................\
....................................................... ........................2.25 ➟2.27
Cruise control
........................................................................\
....................................................... ........................2.28 ➟2.31
Parking proximity sensor
........................................................................\
....................................................... ......2.32 - 2.33
Automatic transmission
........................................................................\
....................................................... ......2.34 ➟2.37
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.01 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.07
SPECIAL FEATURES OF DIESEL VERSIONS
Precautions to be taken in winter
To avoid any faults in icy weather:
fully charged,
full to avoid water vapour
condensing and accumulating at
the bottom of the tank.
Diesel engine speed
Diesel engines are fitted with
injection equipment
which prevents
the engine speed from being
exceeded irrespective of the gear
selected.
Running out of fuel
If the fuel tank has been drained
completely , you may start the
engine normally after refilling the
fuel tank provided that the battery is
well charged.
However, if after a few seconds and
several attempts the engine fails to
start, contact a RENAULT Dealer.
2.07
Do not park the vehicle or
run the engine in locations
where combustible
substances or materials such
as grass or leaves can come into
contact with the hot exhaust system.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.07 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
1

1

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.08
2.08
SPECIAL FEATURES OF DIESEL VEHICLES FITTED WITH AN EXHAUST PARTICLE FILT\
ER
When driving, depending on the
grade of fuel used, it is possible that
white smoke may be emitted.
This is due to the exhaust particle
filter being cleaned automatically,
and does not affect the way the
vehicle runs.
Diesel engine speed
Diesel engines are fitted with
injection equipment which prevents
the engine from over-revving,
irrespective of the gear engaged.
Precautions to be taken in winter
To avoid any faults in icy weather:
- ensure that the battery is always fully charged;
- always keep the fuel tank relatively full to avoid water vapour
condensing in it and accumulating
at the bottom of the tank.
Do not park the vehicle or
run the engine in locations
where combustible
substances or materials
such as grass or leaves can come
into contact with the hot exhaust
system.
The warning light comes on
to indicate a filter saturation risk.
To clean the particle filter, we
recommend that you drive the
vehicle as soon as possible until the
warning light goes out, at an average
speed of 48 mph (80 km/h) provided
that traffic conditions and the speed
limit allow it.
As an indication, cleaning should
last about 20 minutes in this case.
If the message “Check emission
control” or “Regenerate particle
filter” is displayed alongside the
warning light, refer to your
RENAULT dealer as soon as possible.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.08 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.11
ADVICE ON FUEL ECONOMY AND DRIVING
Maintenance
It should be noted that failure to
respect anti-pollution standards
may lead to legal action being taken
against the vehicle owner. In
addition, replacing engine, fuel
supply system and exhaust
components with parts other than
those originally recommended by
the manufacturer may alter your
vehicle so that it no longer complies
with anti-pollution standards.
Have your vehicle checked and
adjusted by your RENAULT Dealer
in accordance with the instructions
in the vehicle’s Warranty and
Services booklet.
Your RENAULT Dealer has all the
equipment necessary for ensuring
that your vehicle is maintained to its
original standard.
Engine adjustments
• ignition: this does not require
adjustment.
plugs: for optimum fuel
economy, efficiency and
performance the specifications laid
down by our Design Department
must be strictly applied.
If the spark plugs have to be
changed, use the make, type and
gap specified for your vehicle’s
engine. Contact your Renault
Dealer for this information.
this does not require
adjustment.
A clogged
cartridge hinders performance and
must be replaced.
RENAULT is actively striving to
reduce pollutant exhaust gas
emissions and to save energy.
By virtue of its design, moderate fuel
consumption and initial settings,
your RENAULT conforms to current
anti-pollution standards. Technical
design, however, cannot achieve all.
The fuel consumption of your
vehicle and the level of pollutant
exhaust gas emissions are also your
responsibility. Make sure that your
vehicle is maintained and used
correctly.
2.11
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.11 (Black/Process Black\
plate)
