2005 PEUGEOT 206 SW DAG Owners Manual

54 -Audio equipment and telematics
01-10-2005
55
-Audio equipment and telematics
01-10-2005
COMPACT DISC CHANGER
Selecting CD changer mode
Press the
"SOURCE" button several
times. Selecting a track
Press button
M to select the following
track.
Press button N to return to the start
of the current track or to select the
previous track.
Press several times in succession to
skip several tracks. Contextual menu
By pressing knob
G, the contextual
menu permits you to switch the
following functions on or off:
- playing of the start of the track ("Introscan"),
- random play ("Random"),
- programming of the track playing order,
- list of tracks.
Selecting a disc
Press one of the buttons "1" to "5"
on the audio/telephone to select the
appropriate disc. Accelerated play
Press and hold button
M or N for
forwards or backwards accelerated
play.
Accelerated play stops as soon as
the button is released.
Buttons
H and I allow
you to select respec-
tively the previous or
following disc in the
changer.
Playing of the irst
track on the disc
begins automatically.
Following each change of source, on
returning to CD changer mode, play
will resume where it stopped.

54 -Audio equipment and telematics
01-10-2005
55
-Audio equipment and telematics
01-10-2005
TELEPHONE
This function is a
GSM dual-band
telephone (900 and 1 800 MHz)
incorporated in the RT3 GPS audio/
telephone system.
It is a "hands free" telephone. This
function is provided by a microphone
located next to the front courtesy
light, the speakers, a steering
column control and voice commands
which allow access to most of the
functions (the audio/telephone
control panel buttons allow access to
all the functions).
Display of the principal "mobile" type
functions, as well as consultation of
the indexes, is provided by the multi-
function display.
This function is active , whatever
position the ignition key is in even
after thirty minutes, when the
message "Economy mode active"
appears on the multi-
function
display. "Telephone and telematic
services" menu
Press the
MENU button then, using
the knob G, select the "Telephone
and telematic services" application
and conirm to gain access to the
following options:
- "Call" .
- "Service" , permits access to the
PEUGEOT services.
- "Telephone functions" , permits
setting of all of the telephone
functions.
- "Text messages (SMS)" , permits
management of all of the functions
for the text messages (SMS). Contextual menu
Press button
D to display the
telephone contextual menu.
This menu enables you to gain
access to the following functions:
- "List of calls" .
- "Enter number" .
- "Access to directory" .
- "Access to your voice mail"
(message service of your GSM
operator).
Note:
Do not allow yourself to become
distracted when you are behind
the wheel and comply with current
national legislation. The driver is
advised to stop in order to hold a
telephone conversation or carry out
certain actions (manual dialling of a
number, for example).

56 -Audio equipment and telematics
01-10-2005
57
-Audio equipment and telematics
01-10-2005
Within each menu:
Move around and se-
lect a function by turn-
ing the G button then
validate by pressing
the button. Using the alphanumeric keypad
For a given button, to input a character
in the second or subsequent rows
press until you obtain the character
required.
Buttons Associated characters
[1]
1 or space
[2] 2 or A B C 2 or a b c 2
[3] 3 or D E F 3 or d e f 3
[4] 4 or G H I 4 or g h i 4
[5] 5 or J K L 5 or j k l 5
[6] 6 or M N O 6 or m n o 6
[7] 7 or P Q R S 7 or p q r s 7
[8] 8 or T U V 8 or t u v 8
[9] 9 or W X Y Z 9 or w x y z 9
[0] 0 or + (long press)
[#] # or validation
[*] * or erasing of last character
input (long press)
Cancel an operation using the
"ESC"
button.
Using the menus, example
"Telephone functions"
Press the
"MENU" button to
display the general menu . Select
the "Telephone and telematic
services" application, validate
"Telephone functions" to access
the principal telephone functions,
then the various menus, in order to
reach the one required.
This menu allows you to access the
following functions:
- "Network": allows you to select
the network search mode and to
see the networks available.
- "Duration of calls": allows you
to consult the duration recorder of
calls made and zero re-set.
- "Process the PIN code": allows
you to use or modify the PIN code.
- "Call options": allows you to
conigure the calls with entering of
my number, automatic answering
after X rings, speciication of ring
options and allows you to conigure
the diversion number for the text
messages and clear the list of calls
and the text messages.

56 -Audio equipment and telematics
01-10-2005
57
-Audio equipment and telematics
01-10-2005
Installing the SIM card
Open lap L
by pressing the point
of a pencil on the circular opening
above the lap.
Insert your SIM card, available from
a mobile telephone operator, as
indicated in the graphics, then close
the lap.
Note: removal or insertion of the
SIM card must only be carried out
after the RT3 audio/telephone has
been switched off (key in position S
(ignition switch) and screen off).
If you have a duplicate card, when
carrying out the irst installation or to
update your directory you must insert
your mobile telephone’s SIM card
then transfer its information to the
RT3 audio/telephone directory - refer
to the Directory main menu. Input your PIN code using the
alphanumeric keypad and validate
by pressing button G
or button #
to access the network. Connection
to the network is validated by the
appearance of a symbol on the
screen.
Warning: if you make three errors in
succession when inputting your PIN
code, your SIM card will be blocked.
To unblock it, you will need to input
the PUK code. The PUK code will be
supplied to you by the person selling
your SIM card (input of the PUK code
allows for 10 errors in succession;
after this the SIM card becomes
permanently unusable).
Note: the PIN code is required
each time the ignition is switched
on, unless the PIN code has been
stored in the memory or protection
by PIN code is not activated on the
SIM card.
Inputting the PIN codeCancelling of PIN code request
In the menu "Telephone functions"
select "Process the PIN code" , then
validate the "Cancel" function.
Warning: in this case, do not lose
your SIM card. Losing it would mean
anyone who inds it would be able to
make unlimited calls.

58 -Audio equipment and telematics
01-10-2005
59
-Audio equipment and telematics
01-10-2005
Telephone function screens
Not in use
This screen indicates the presence
of voice messages or text messages
(SMS) not listened to/read, the
cumulative time in use since the last
zero reset and the status of your
telephone.
In use
This screen indicates the time elapsed
since the start of the conversation, as
well as the number* or name of the
person to whom you are speaking (if
recorded in the index) and the status
of your telephone.
* If this option and service are
available.
Making a call
Press button D to display the
contextual menu of the telephone.
Entering a number
Select the function "Call"
then "Enter number"
then enter the number
of the person you wish
to speak to using the
alphanumeric keypad.
Press button D to make the call. Making a call from a directory
Select the
"Call" function then
"Directory" to access all the iles
containing a telephone number or
the "List of calls" function to access
the list of the last twenty incoming (if
the number display option is active)
or outgoing calls.
Note: there are two directories, the
RT3 audio/telephone directory and
the SIM card directory.
Receiving a call
When a ringing sounds to
let you know that a call is
waiting, you can choose
either to accept it by
pressing button D or the
end of the steering wheel
remote control or not to accept it by
pressing the button Q or by selecting
and validating the "NO" button on
the "Answer?" screen.
If you accept the call, to end your
communication, press button Q.
If you do not accept the call, it is
transferred to your voice mail or to a
call diversion number.

58 -Audio equipment and telematics
01-10-2005
59
-Audio equipment and telematics
01-10-2005
Text messages (SMS)
Receiving text messages
When the buzzer sounds (if the
SMS text messages buzzer option is
active) and a superimposed screen
announces
"Do you wish to read
the new text message (SMS)?" ,
you can choose to read the text
message received by selecting
and validating "YES" or postpone
reading it by selecting and validating
"NO" , by pressing the "ESC" button
or by waiting until the announcement
disappears. The message is read by
the voice synthesiser, if it is active.
Note: the old text messages stored
and the new text messages, the
reading of which you wished to
postpone, can be consulted. Press
the "MENU" button then validate
the "Telematic" icon, select "Text
messages (SMS)" and validate
the function "Reading of SMS
received" by pressing button G.
Then scroll through the list by turning
the button and press the button to
select the text message to be read (if
the voice synthesiser is active). Sending a text message
In the menu
"Text messages
(SMS)" validate the function "Typing
of an SMS" . Type your text message
using the alphanumeric keypad and
validate it using the "OK" button to
store it or validate the "Send" button
to send it. Validation of the "Send"
button enables you to enter the
number of your recipient or select it
from the directory or from the list of
calls and send the message.
"Duration of calls" menu
Select the "Duration of calls"
function from the "Telephone
functions"
menu to consult the
duration counters for the calls made.
The partial counter totals the duration
of the calls since the last zero reset
carried out using the "Zero reset"
button.
"Telephone options" menu
Select the "Call options" function
from the "Telephone functions"
menu to access the functions:
- "Conigure the calls" which
permits activation and deactivation
of the "show my number" and
"automatic answering after X rings"
functions
- "Ringing options" which permits
adjustment of the ringing volume
for voice calls, activation of the text
messages (SMS) receipt buzzer
and selection of a ring tone from
the ive offered
- "Voice call diversion number"
which permits recording of the call
diversion number chosen by the
customer, otherwise the call will be
transferred to the voice mail if the
call diversion box is ticked.
Replying to a text message
After reading atext message, you
can:
Reply directly to the sender by
selecting
"Reply". A screen appears
automatically to enable you to enter
your message.
Record the number of the sender
of the text message in your current
directory by selecting "Record".

60 -Audio equipment and telematics
01-10-2005
61
-Audio equipment and telematics
01-10-2005
Services*
Press button
E to dis-
play the "Services"
menu and select one
of the following serv-
ices:
Emergency call*
In an emergency , press
button V until a signal is
heard and a call validation /
deletion screen is displayed
(delay of 6 seconds) or enter
112 directly.
Make an emergency call
if you are involved in a
situation which leads you to fear
serious consequences (injuries, ...)
for those who are exposed to it (if you
witness or are involved in an accident
resulting in injuries, an attack, ...).
Before making a call of this kind,
the audio/telephone must detect a
cellular network.
If you have not signed the speciic
PEUGEOT contract, the parameters
of the SOS button are set so that
a call is made to 112 - unique
number made available by the
worldwide GSM network, reserved
for emergency calls.
No security mode is required and,
depending on the network or country,
you do not need to insert your SIM
card or enter your PIN.
If you have signed the speciic
PEUGEOT contract, your call will be
located and you will be put in contact
with a PEUGEOT assistance team.
For further details, refer to the
general conditions of your contract. "PEUGEOT Assistance" /
Emergency call
During a connection to "PEUGOT
Assistance" or an emergency call,
it is not possible to send or receive
calls or SMS text messages; these
will be transferred to your voice
mail.
In this case, a green diode lashes
on the RT3 GPS audio/telephone
panel, when the emergency call
or "PEUGEOT Assistance" call
procedure begins, then lights
continuously when the call is taken
by the services concerned.
* If option and service available.
"Customer Contact Centre"
which enables you to contact the
PEUGEOT Customer Contact
Centre
directly and access the
services offered (this type of call
is suspended if an emergency or
breakown call is made).
"PEUGEOT Assistance" which
enables you to contact the call
centre which controls the PEUGEOT
breakdown service directly and
receive rapid assistance (you have
6 seconds within which to cancel
the call when it is made). During
the breakdown call phase it is not
possible to make any other calls
with the exception of emergency
calls. If you have signed the speciic
PEUGEOT contract, your call will be
located.
"Operator services" which gives
access to the list of services speciic
to your operator (e.g.: customer
service, consumption monitoring,
news, stock market, weather, travel,
games, etc) if they are available.

60 -Audio equipment and telematics
01-10-2005
61
-Audio equipment and telematics
01-10-2005
The Directory
General
The directory can contain up to
396 iles divided into 4 independent
sub-directories (
"User 1", "User 2" ,
"User 3" and "User 4" ).
When the system is delivered, the
default current directory is "User 4".
A ile can contain:
- an address,
- 5 telephone numbers,
- 5 e-mails,
- a note,
- a voice description which can be used for a voice command.
The address is entered by indicating
the town and the street.
Note: if you enter the address in
the absence of the navigation CD
ROM, you will not be able to use this
address for navigation. To modify an existing ile, select it
using the
"Consult or modify a ile"
function of the "Management of
directory iles" menu then make the
modiications.
Note: when the address is entered,
the navigation CD-Rom must be
present in order to obtain guidance
to this destination.
"Directory" menu
Press the
MENU button then, using
the knob G, select the "Directory"
application and conirm to gain
access to the following options:
- "Management of directory iles"
with:
• "Consult or modify a ile" .
• "Add a ile" , enter the
description of the new ile then
select on the ile the section to
be completed then conirm and
enter the information.
• "Delete a ile" .
• "Delete all iles" in a directory.
- "Directory coniguration" with:
• "Select a directory" .
• "Name a directory" .
• "Select the starting directory"
(current directory).
- "File transfer" , with:
• "Exchange by infrared" of the
iles to portable equipment and
vice versa.
• "Exchange with the SIM card"
of the information entered in the
RT3 GPS audio/telephone. "Consult or modify a ile"
