2005 PEUGEOT 206 SW DAG Owners Manual

46 -Audio equipment and telematics
01-10-2005
47
-Audio equipment and telematics
01-10-2005
Sound ambience
This function permits
the selection of a
"None", "Rock",
"Classical", "Jazz",
"Vocal" or "Techno"
sound ambience.
Turn button G to select the sound
ambience.
Selecting "None" permits access
to all of the settings deined below.
Selecting another ambience sets the
bass and treble automatically.
Bass setting
When
"Bass" is displayed, turn
button G to vary the setting.
- "-9" for minimum bass setting,
- "0" for normal setting,
- "+9" for maximum bass setting. Treble setting
When
"Treble"
is displayed, turn
button G to vary the setting.
- "-9" for minimum treble setting,
- "0" for normal setting,
- "+9" for maximum treble setting.
Adjusting the loudness
This function automatically empha-
sises bass and treble tones when the
volume is low.
Rotate button G
to switch the function
on or off.
Setting the front/rear sound
distribution (Fader)
When
"Fader" is displayed:
- Turn button
G clockwise to increase
the volume in the front.
- Turn button
G anti-clockwise to
increase the volume in the rear. Setting the right/left sound
distribution (Balance)
When
"Balance" is displayed:
- Turn button G clockwise to increase
the volume on the right.
- Turn button G anti-clockwise to
increase the volume on the left.
Automatic volume adjustment
This function allows the volume to
be adjusted automatically depending
on the level of noise produced by the
speed of the vehicle.
Press button G to switch the function
on or off.

48 -Audio equipment and telematics
01-10-2005
49
-Audio equipment and telematics
01-10-2005
RADIO
Notes on radio reception
Car radio/telephone receivers are
subject to phenomena which do
not affect domestic radio sets. Both
MW/LW and FM are subject to
various forms of interference. This is
not a relection on the quality of the
equipment, but is due to the nature of
the signals and the way in which they
are transmitted.
On MW/LW interference may be
noticed when passing under high
voltage power lines or bridges, or in
tunnels.
On FM, interference may be the
result of the increasing distance
from the transmitter, delection of
the signals by obstacles (mountains,
hills, buildings, etc.) or of being in
an area which is not covered by a
transmitter. Selecting the radio
Press
"SOURCE" several times. Automatic station search
Briely press button
M or N to search
for the station immediately above or
below.
The search stops at the irst station
found.
If the TA trafic programme is select-
ed, only the most powerful stations
broadcasting this type of programme
are selected.
Selecting a waveband
Briely press button "BAND/AST" to
select the FM1, FM2, FMast and AM
wavebands. Search sensitivity
It is possible to carry out automatic
searches at two levels of sensitivity:
- To tune in to the most powerful
transmitters, select the local search
mode "LO" (default option).
- To tune in to the weakest or most distant transmitters, select the
sensitive search mode "DX".
The station search is carried out irst
in "LO" (local) sensitivity, then in
"DX" (distant) sensitivity.
To make a direct search in "DX"
(distant) sensitivity, press button M
or N twice in succession.

48 -Audio equipment and telematics
01-10-2005
49
-Audio equipment and telematics
01-10-2005
Automatic storing of FM stations
in the memory (autostore)
Recalling stations stored in the
memory
For each waveband, briely press
the buttons
"1" to "6" to recall the
corresponding stored station.
In the case of an RDS station, the
frequency appears for a few seconds
before its name.
Recalling an RDS station may result
in a search for the frequency which
corresponds to the region through
which you are travelling.
Press the
"BAND/AST" button for
more than two seconds.
Your audio/telephone automatically
stores the 6 stations with the strong-
est signal in FM. These stations are
stored in the FMast waveband.
If it is not possible to ind 6 stations,
the remaining memories are empty.
Manual station search
Briely press button H or I
to increase or decrease the
frequency displayed.
By continuing to press
the button in the direction
selected, you will obtain
continuous scrolling of the
frequency.
Scrolling stops when you
release the button.
Manual station storing
Select the station required.
Press one of the buttons "1" to "6"
for more than two seconds.
A window appears on the screen, the
station is stored when it is displayed
on the memory number that you
have allocated to it.

50 -Audio equipment and telematics
01-10-2005
51
-Audio equipment and telematics
01-10-2005
RDS SYSTEM
Using the RDS (Radio Data
System) function on FM
Most FM radio stations use the RDS
system.
This system allows you to continue
listening to the same station,
whatever frequency it is using for the
region you are going through.
This screen indicates
the name of the sta-
tion selected. The
audio/telephone con-
tinuously searches for the transmit-
ter which transmits the same pro-
gramme with the best reception. This
search may cause slight interference
with the transmission.
The function can be switched on
or off via the "RDS" button or the
"AUDIO FUNCTIONS" main menu.
The screen will show:
- "RDS" if the function is active and
available for the station selected.
- "RDS" crossed out or "RDS"
greyed out on the screen* if the
function is active but is not available
on the station.
If the station to which you are
listening does not have several
frequencies in the region through
which you are travelling, you can
switch off the automatic frequency
following. Trafic information programme
Press the "TA/PTY"
button to switch the
function on or off.
The multifunction screen will show: - TA if the function is selected,
- TA crossed out or greyed out*
if the function is selected but not
available.
Any trafic information lash will be
given priority, whatever source you
are listening to (radio, CD or CD
changer).
If you wish to interrupt the
broadcasting of a message, press
the "TA/PTY" button.
Notes: the volume of the trafic
information is independent of the
volume of normal audio/telephone
listening.
You can adjust it by using the volume
button. The setting will be stored and
will be used when the next messages
are broadcast.
You must be on the FM waveband.
During station search or automatic
storing phases, if the "TA" function
is selected, transmitters which are
compatible with the broadcasting of
these messages will be tuned to or
stored irst.
The station being listened to must
indicate via the RDS system that it
broadcasts trafic information. Stations which are organised in
a network (EON) have regional
transmitters which broadcast their
own programmes: you can listen to
one of these stations and switch to
the network station which broadcasts
the trafic information messages.
RDS station following Regional following mode (REG)
When they are part of a network,
certain stations broadcast regional
programmes in the various areas
they serve. With regional following
mode you can keep listening to the
same programme.
You can choose to follow:
• Either a regional station only.
• Or the entire network, with the
possibility of listening to a different
programme.
The function can be switched on or
off via the "AUDIO FUNCTIONS"
main menu or by pressing the "RDS"
button for more than 2 seconds.
The multifunction screen will show:
- REG if the function is active,
- REG crossed out or greyed out*
if the function is active but not
available.
* According to screen

50 -Audio equipment and telematics
01-10-2005
51
-Audio equipment and telematics
01-10-2005
PTY function
This allows you to listen to stations
broadcasting a speciic type of
programme, selected from the list of
available types below:
NEWS SCIENCE
AFFAIRS VARIED
INFO POP M
SPORT ROCK M
EDUCATE EASY M
FICTION LIGHT M
CULTURE OTHER M
WEATHER LEISURE
FINANCE JAZZ
CHILDREN COUNTRY
SOCIAL NATION M
RELIGION OLDIES
PHONE IN FOLK M
TRAVEL DOCUMENT
When FM is selected, press button
"TA/PTY"
for more than two seconds
to switch the function on or off. To ind a
PTY programme:
- select the PTY button,
- turn button G to scroll down the
different types of programmes
offered, then conirm your choice,
when the programme of your choice
is displayed press button M or N
to carry out an automatic search
(after an automatic search the PTY
function is switched off if no station
has been found).
In PTY mode the different types
of programmes can be stored in
the memory. To do this, press the
preselection buttons "1" to "6" for
more than two seconds. To recall
the type of programme stored
in the memory, briely press the
corrresponding button. EON system
This system connects stations
which are part of the same network.
It enables the broadcast of trafic
information or a
PTY programme,
by a station that is part of the same
network as the station to which you
are listening.
The service is available when
you have selected the TA trafic
information programme or the PTY
function.
Audio functions menu
Select the "Audio functions" menu
from the general menu to:
- "Activate/Deactivate RDS
frequency following" ,
- "Activate/Deactivate regional
mode" ,
- "Activate/deactivate Radio
Text display" , broadcast by the
radio station if available ("RT" is
displayed at the bottom of the
screen).
- "Activate/deactivate CD details
display" , also permits MP3
display.

52 -Audio equipment and telematics
01-10-2005
53
-Audio equipment and telematics
01-10-2005
Contextual menu
By pressing knob
G, the contextual
menu allows you to access the
following functions:
- "Inputting a frequency" ,
- "List of stations" to access
the 30 stations picked up locally
directly,
- "Refresh list" to update this list,
- "Display Radio Text" broadcast
by the radio station if it is available
("RT" is displayed at the bottom of
the screen).
When you are in radio mode,
pressing knob G enables you to
call up the Radio contextual menu
to select "Read Radio Text"
(information broadcast by the station
concerning the programme to which
you are listening) (example: name of
singer, title of the song...).COMPACT DISC
Selecting CD mode
After inserting a disc, printed face
upwards, the CD drive starts auto-
matically.
If a disc has already been inserted,
press the "SOURCE" button to
select CD mode. Selecting a track
Press button
M to select the following
track.
Press button N to return to the start
of the current track or to select the
previous track.
Press several times in succession to
skip several tracks.
Press button B to
eject the disc from the
drive.
If the CD is not
removed within 10 to 15 seconds
following ejection, it is re-inserted
into the drive automatically but is not
played.
Ejecting a disc Accelerated play
Press and hold button M or N for
forwards or backwards accelerated
play.
Accelerated play stops as soon as
the button is released.
Notes:
• Before inserting a CD, press
button B to check that the drive
does not already contain a CD.
• When the navigation CD is in the drive, it is not possible to listen to a
CD in CD mode .

52 -Audio equipment and telematics
01-10-2005
53
-Audio equipment and telematics
01-10-2005
Contextual menu
By pressing knob
G, the contextual
menu allows you to access the
following functions:
- "Inputting a frequency" ,
- "List of stations" to access
the 30 stations picked up locally
directly,
- "Refresh list" to update this list,
- "Display Radio Text" broadcast
by the radio station if it is available
("RT" is displayed at the bottom of
the screen).
When you are in radio mode,
pressing knob G enables you to
call up the Radio contextual menu
to select "Read Radio Text"
(information broadcast by the station
concerning the programme to which
you are listening) (example: name of
singer, title of the song...).COMPACT DISC
Selecting CD mode
After inserting a disc, printed face
upwards, the CD drive starts auto-
matically.
If a disc has already been inserted,
press the "SOURCE" button to
select CD mode. Selecting a track
Press button
M to select the following
track.
Press button N to return to the start
of the current track or to select the
previous track.
Press several times in succession to
skip several tracks.
Press button B to
eject the disc from the
drive.
If the CD is not
removed within 10 to 15 seconds
following ejection, it is re-inserted
into the drive automatically but is not
played.
Ejecting a disc Accelerated play
Press and hold button M or N for
forwards or backwards accelerated
play.
Accelerated play stops as soon as
the button is released.
Notes:
• Before inserting a CD, press
button B to check that the drive
does not already contain a CD.
• When the navigation CD is in the drive, it is not possible to listen to a
CD in CD mode .

52 -Audio equipment and telematics
01-10-2005
53
-Audio equipment and telematics
01-10-2005
Contextual menu
By pressing knob
G, the contextual
menu permits you to switch the
following functions on or off:
- playing of the start of a track ("Introscan"),
- random play ("Random"),
- programming of the track playing order,
- list of tracks.
Do not use copied CDs as
these could damage your
player.
Insert circular compact
discs only. Playing MP3 CDs
Following the insertion of an MP3
CD, playing of the irst song of the
irst MP3 directory begins. You can
select the track to be played using
buttons
M or N or the MP3 directory
using buttons H or I.
Note: when the navigation CD is in
the drive, it is not possible to listen to
an MP3 CD in CD mode . MP3 contextual menu
Selecting a track
To display the list of MP3 directories,
press the MODE button to enter MP3
mode. When the knob G is pressed,
the contextual menu permits
displaying of the "list of tracks".In MP3 mode, pressing the knob
G
enables you to switch the following
functions on or off:
- Playing of the start of each track on the CD ("Introscan").
- Random play ("Random").
- Repeating of the tracks in the current MP3 directory.
- List of MP3 tracks.
This equipment enables you to listen
to music which is usually protected
by copyright in accordance with
current national and international
regulations.
Please refer to these regulations and
comply with them.
The playing and displaying of an
MP3 compilation may depend on the
recording programme and / or the
parameters used.
We recommend use of the ISO 9660
recording standard.
Using buttons
H or I,
select the MP3 direc-
tory to be played.
To open an MP3 di-
rectory, press knob G.
Using buttons M or N, select the
track to be played.
Conirm by pressing knob G.
