2005 NISSAN X-TRAIL Combination meter

IP-12
INSTRUMENT PANEL ASSEMBLY

[ ]: The number shows the removal order.
REMOVAL
Front Speaker Grille (LH/RH)
1. Insert a remover into front speaker grille door side edge, and
then disengage pawls and clips.
2. Pull forward and remove.
Cluster Lid A
Disengage clips by pulling cluster lid A frontward to remove.
CAUTION:
During removal or installation, use shop cloth to protect sur-
rounding area from damage.
Combination Meter
1. Remove screw.
2. Disconnect connector on back and remove combination meter.
CAUTION:
During removal or installation, use shop cloth to protect
surrounding area from damage.
Instrument panelIP-18[25]
Side ventilator grille (LH/RH)ATC-138
[26]
Cup holderIP-18
[27] Components Parts Location Refer toInstrument
panelCombination
meterDisplay unit Audio Console
PIIA9899E
PIIA7393E
PIIA7394JPIIA7394E

SE-6
SQUEAK AND RATTLE TROUBLE DIAGNOSES

FELT CLOTHTAPE
Used to insulate where movement does not occur. Ideal for instrument panel applications.
68370-4B000: 15 × 25 mm (0.59 × 0.98 in) pad/68239-13E00: 5 mm (0.20 in) wide tape roll
The following materials, not available through NISSAN Parts Department, can also be used to repair
squeaks and rattles.
UHMW(TEFLON) TAPE
Insulates where slight movement is present. Ideal for instrument panel applications.
SILICONE GREASE
Used in of UHMW tape that will be visible or not fit.
Note: Will only last a few months.
SILICONE SPRAY
Use when grease cannot be applied.
DUCT TAPE
Use to eliminate movement.
CONFIRM THE REPAIR
Confirm that the cause of a noise is repaired by test driving the vehicle. Operate the vehicle under the same
conditions as when the noise originally occurred. Refer to the notes on the Diagnostic Worksheet.
Generic Squeak and Rattle TroubleshootingEIS008O2
Refer to Table of Contents for specific component removal and installation information.
INSTRUMENT PANEL
Most incidents are caused by contact and movement between:
1. Cluster lid A and instrument panel
2. Acrylic lens and combination meter housing
3. Instrument panel to front pillar garnish
4. Instrument panel to windshield
5. Instrument panel mounting pins
6. Wiring harnesses behind the combination meter
7. A/C defroster duct and duct joint
These incidents can usually be located by tapping or moving the components to duplicate the noise or by
pressing on the components while driving to stop the noise. Most of these incidents can be repaired by apply-
ing felt cloth tape or silicon spray (in hard to reach areas). Urethane pads can be used to insulate wiring har-
ness.
CAUTION:
Do not use silicone spray to isolate a squeak or rattle. If you saturate the area with silicone, you will
not be able to recheck the repair.
CENTER CONSOLE
Components to pay attention to include:
1. Shifter assembly cover to finisher
2. A/C control unit and cluster lid C
3. Wiring harnesses behind audio and A/C control unit
The instrument panel repair and isolation procedures also apply to the center console.
DOORS
Pay attention to the:
1. Finisher and inner panel making a slapping noise
2. Inside handle escutcheon to door finisher
3. Wiring harnesses tapping
4. Door striker out of alignment causing a popping noise on starts and stops
Tapping or moving the components or pressing on them while driving to duplicate the conditions can isolate
many of these incidents. You can usually insulate the areas with felt cloth tape or insulator foam blocks to
repair the noise.

CHARGING SYSTEM
SC-13
C
D
E
F
G
H
I
J
L
MA
B
SC

CHARGING SYSTEM PFP:00011
System Description EKS00316
The alternator provides DC voltage to operate the vehicle's electrical system and to keep the battery charged.
The voltage output is controlled by the IC regulator.
Power is supplied at all times

through 10A fuse (No. 34, located in the fuse and fusible link box)

to alternator terminal 4 (“S” terminal).
“B” terminal supplies power to charge the battery and operate the vehicle's electrical system. Output voltage is
controlled by the IC regulator at terminal 4 (“S” terminal) detecting the input voltage. The charging circuit is
protected by the 120A (Gasoline engine models) or 100A (Diesel engine models) fusible link (letter A, located
in the fuse and fusible link box).
The alternator is grounded to the engine block.
With the ignition switch in the ON or START position, power is supplied

through 10A fuse [No. 11, located in the fuse block (J/B)]

to combination meter terminal 2 for the charge warning lamp.
Ground is supplied with power and ground supplied

to terminal 5 of the combination meter

through alternator terminal 3 (“L” terminal)

to alternator terminal E (Gasoline engine models) or through body ground (Diesel engine models)

through ground E30 (Gasoline engine models).
The charge warning lamp will illuminate. When the alternator is providing sufficient voltage with the engine
running, the ground is opened and the charge warning lamp will go off.
If the charge warning lamp illuminates with the engine running, a malfunction is indicated.

HEADLAMP - XENON TYPE -
LT-5
C
D
E
F
G
H
I
J
L
MA
B
LT

HEADLAMP - XENON TYPE -PFP:26010
System Description EKS00N4V
DESCRIPTION
The headlamps are controlled by the lighting switch which is built in the combination switch.
Power is supplied at all times

through 15A fuse (No. 40, located in fuse and fusible link box)

to lighting switch terminal 8,

through 15A fuse (No. 41, located in fuse and fusible link box)

to lighting switch terminal 5,

through 30A fusible link (letter M, located in fuse and fusible link box)

through 20A fuse (No. 52, located in fuse block)

to HID relay LH terminal 5, and

through 20A fuse (No. 51, located in fuse block)

to HID relay RH terminal 5,

through 15A fuse (No. 38, located in fuse and fusible link box)

to driving lamp relay-1 terminal 3.
LOW BEAM OPERATION
When the lighting switch is turned to the 2ND position, power is supplied

through lighting switch terminal 10

to HID relay LH terminal 1,

through lighting switch terminal 7

to HID relay RH terminal 1,

through HID relay LH and RH terminal 3

to headlamp LH and RH terminal 2.
Ground is supplied

to HID relay LH and RH terminal 2

through grounds E24 and E50,

to headlamp LH and RH terminal 4

through grounds E24 and E50.
With power and ground supplied, low beam headlamps illuminate.
HIGH BEAM OPERATION/FLASH-TO-PASS OPERATION
When the lighting switch is turned to the 2ND position and placed in HIGH BEAM position or PASSING posi-
tion, power is supplied

through lighting switch terminal 9

to headlamp LH terminal 1

to HID relay LH terminal 1, and

to combination meter terminal 20,

through lighting switch terminal 6

to headlamp RH terminal 1, and

to HID relay RH terminal 1,

through HID relay LH and RH terminal 3

to headlamp LH and RH terminal 2.
Ground is supplied

to HID relay LH and RH terminal 2

through grounds E24 and E50,

to headlamp LH and RH terminal 3, and

to headlamp LH and RH terminal 4

through grounds E24 and E50,

LT-6
HEADLAMP - XENON TYPE -


to combination meter terminal 19

through grounds M27and M70.
With power and ground supplied, low beam and high beam headlamps, and HIGH BEAM indicator illuminate.
DRIVING LAMP OPERATION
To illuminate the driving lamp, push the driving lamp switch when the lighting switch is turned to the 2ND posi-
tion and placed in HIGH BEAM position or PASSING position, power is supplied

through lighting switch terminal 9

to headlamp LH terminal 1

to HID relay LH terminal 1

to combination meter terminal 20

to driving lamp relay-1 terminal 1

to driving lamp switch terminal 7, and

to driving lamp relay-2 terminal 5,

through driving lamp relay-2 terminal 3

to driving lamp switch terminal 6,

through driving lamp relay-1 terminal 5

to driving lamp LH and RH terminal 2,

through lighting switch terminal 6

to headlamp RH terminal 1, and

to HID relay RH terminal 1,

through HID relay LH and RH terminal 3

to headlamp LH and RH terminal 2.
Ground is supplied

to driving lamp relay-1 terminal 2

through driving lamp relay-2 terminal 7

through driving lamp relay-2 terminal 6

through grounds E24 and E50,

to driving lamp switch terminal 4

through driving lamp relay-2 terminal 1

through driving lamp relay-2 terminal 2

through grounds E24 and E50,

to driving lamp LH terminal 1

through ground R8,

to driving lamp RH terminals 1 and 3

through ground R8,

to HID relay LH and RH terminal 2

through grounds E24 and E50,

to headlamp LH and RH terminal 3, and

to headlamp LH and RH terminal 4

through grounds E24 and E50,

to combination meter terminal 19

through grounds M27 and M70.
With power and ground supplied, low beam and high beam headlamps, driving lamp and HIGH BEAM indica-
tor illuminate.

LT-18
HEADLAMP - XENON TYPE -

Aiming Adjustment of HeadlampEKS00N4Z
PREPARATION BEFORE ADJUSTING
For Details, Refer To The Regulations In Your Own Country.
Before performing aiming adjustment, check the following.
1. Keep all tires inflated to correct pressures.
2. Place vehicle on flat surface.
3. Set that there is no-load in vehicle other than the driver (or equivalent weight placed in driver's position).
Coolant, engine oil filled up to correct level and full fuel tank.
LOW BEAM
1. Turn headlamp low beam ON.
2. Use adjusting screws to perform aiming adjustment.
RH high beam does not operate, but
RH low beam operates.1. Bulb
2. Open in high beam RH circuit
3. Lighting switch
4. Headlamp RH ground circuit1. Check bulb.
2. Check the following.–Harness between headlamp RH and lighting switch for
open circuit.
3. Check lighting switch.
4. Check harness between headlamp RH and ground.
RH low beam does not operate, but
RH high beam operates.1. 20A fuse
2. HID relay RH
3. Open in RH low beam circuit
4. RH low beam ground circuit
5. Xenon bulb
6. HID control unit1. Check 20A fuse (No.51, located in fuse and fusible link
box). Verify battery positive voltage is present at terminal
5 of headlamp RH relay.
2. Check HID relay RH.
3. Check harness between HID relay RH terminal 3 and
headlamp RH terminal 2 for an open circuit.
4. Check harness between headlamp RH and ground.
5. Replace xenon bulb with other side bulb or new one. (If
headlamps illuminate correctly, replace bulb.)
6. Replace HID control unit with other side control unit or
new one. (If headlamps illuminate correctly, replace con-
trol unit.)
High beam indicator does not work.1. Bulb
2. Open in high beam circuit1. Check bulb in combination meter.
2. Check the harness circuit. Symptom Possible cause Repair order
PKIC0981E

HEADLAMP - CONVENTIONAL TYPE -
LT-25
C
D
E
F
G
H
I
J
L
MA
B
LT

HEADLAMP - CONVENTIONAL TYPE -PFP:26010
System Description EKS00N57
DESCRIPTION
The headlamps are controlled by the lighting switch which is built in the combination switch.
Power is supplied at all times

through 15A fuse (No. 40, located in fuse and fusible link box)

to lighting switch terminal 8,

through 15A fuse (No. 41, located in fuse and fusible link box)

to lighting switch terminal 5,

through 15A fuse (No. 38, located in fuse and fusible link box)

to driving lamp relay-1 terminal 3.
LOW BEAM OPERATION
When the lighting switch is turned to the 2ND position, power is supplied

through lighting switch terminal 10

to headlamp LH terminal 3,

through lighting switch terminal 7

to headlamp RH terminal 3.
Ground is supplied

to headlamp LH and RH terminal 2

through grounds E24 and E50.
With power and ground supplied, low beam headlamps illuminate.
HIGH BEAM OPERATION/FLASH-TO-PASS OPERATION
When the lighting switch is turned to the 2ND position and placed in HIGH BEAM position or PASSING posi-
tion, power is supplied

through lighting switch terminal 9

to headlamp LH terminal 1, and

to combination meter terminal 20,

through lighting switch terminal 6

to headlamp RH terminal 1.
Ground is supplied

to headlamp LH and RH terminal 2

through grounds E24 and E50,

to combination meter terminal 19

through grounds M27 and M70.
With power and ground supplied, high beam headlamps and HIGH BEAM indicator illuminate.
DRIVING LAMP OPERATION
To illuminate the driving lamp, push the driving lamp switch when the lighting switch is turned to the 2ND posi-
tion and placed in HIGH BEAM position or PASSING position, power is supplied

through lighting switch terminal 9

to headlamp LH terminal 1

to combination meter terminal 20

to driving lamp relay-1 terminal 1

to driving lamp switch terminal 7, and

to driving lamp relay-2 terminal 5,

through driving lamp relay-2 terminal 3

to driving lamp switch terminal 6,

through driving lamp relay-1 terminal 5

to driving lamp LH and RH terminal 2,

LT-26
HEADLAMP - CONVENTIONAL TYPE -


through lighting switch terminal 6

to headlamp RH terminal 1.
Ground is supplied

to driving lamp relay-1 terminal 2

through driving lamp relay-2 terminal 7

through driving lamp relay-2 terminal 6

through grounds E24 and E50,

to driving lamp switch terminal 4

through driving lamp relay-2 terminal 1

through driving lamp relay-2 terminal 2

through grounds E24 and E50,

to driving lamp LH terminal 1

through ground R8,

to driving lamp RH terminals 1 and 3

through ground R8,

to headlamp LH and RH terminal 2

through grounds E24 and E50,

to combination meter terminal 19

through grounds M27 and M70.
With power and ground supplied, high beams headlamp, driving lamp and the HIGH BEAM indicator illumi-
nate.
