2005 MERCEDES-BENZ S55AMG Owner's Manual

207 Controls in detail
Power windows
Power windows
Opening and closing the power windows
The side windows are opened and closed
electrically. The switches for all side win-
dows are on the driver’s door. The switch-
es for the respective windows are on the
front passenger door and the rear doors.
1Left front window
2Right front window
3Right rear window
4Left rear window
5Rear window override switch
(
page 78)
Warning!
G
When closing the windows, make sure that
there is no danger of anyone being harmed
by the closing procedure.
The closing of the door windows can be im-
mediately halted by releasing the switch or,
if the switch was pressed past the resis-
tance point and released, by pressing the re-
spective switch.
The door windows are equipped with the ex-
press-close and automatic reversal func-
tion. If the window encounters an
obstruction that blocks its path in a circum-
stance where you pressed the switch past
the resistance point and released it to close
the window, the automatic reversal function
will stop the window and open it slightly.
If the window encounters an obstruction
that blocks its path in a circumstance where
you are closing the window by pressing and
holding the switch, by pressing and holding
button ‹ on the SmartKey, or by press-
ing and holding the lock button (vehicles
with KEYLESS-GO*) on the door handle, the
automatic reversal function will not operate.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.iYou can also open or close the win-
dows using the SmartKey, see “Sum-
mer opening feature” (
page 209) and
“Convenience closing feature”
(
page 210).
You can close and reopen the windows
using the air recirculation button,
or the charcoal filter buttone in the
climate control panel (
page 194).

208 Controls in detailPower windows
Switch on ignition (
page 34).
Opening the windows

Press switch1 to 4 at the
symbolk to the resistance point.
The corresponding window will move
downwards until you release the
switch.Closing the windows

Press switch1 to 4 at the
symbolj to the resistance point.
The corresponding window will move
upwards until you release the switch.
Fully opening the windows
(Express-open)

Press switch1 to 4 at the
symbolk past the resistance point
and release.
The corresponding window opens com-
pletely.Fully closing the windows
(Express-close)

Press switch1 to 4 at the
symbolj past the resistance point
and release.
The corresponding window closes com-
pletely.
iOperating the windows from the rear is
not possible if you activate the override
switch (
page 78).
iWith the SmartKey in starter switch po-
sition 0 or removed from the starter
switch, the power windows can be op-
erated:

until you open the driver’s or front
passenger door


for at least five minutes.
Warning
G
If you press and hold the switch up when
closing the window, and upward movement
of the window is blocked by some obstruc-
tion including but not limited to arms, hands,
fingers, etc., the automatic reversal will not
operate.
Warning!
G
Driver's door only:
If within five seconds you again press the
switch past the resistance point and re-
lease, the automatic reversal will not func-
tion.

209 Controls in detail
Power windows
Stopping windows during Express-op-
eration
Briefly press the respective power win-
dow switch again.
Synchronizing the power windows
The power windows must be synchronized

after the battery has been disconnect-
ed


if the power windows cannot be fully
opened (Express-open) or closed
(Express-close)
Each power window must be synchronized.

Close all doors.

Switch on ignition (
page 34).

Press and hold switch1 to 4 at the
symbolj until the windows are
completely closed.

Hold on to switches1 to 4 for ap-
proximately one second.
The power windows are synchronized.
Summer opening feature
If the weather is warm, you can ventilate
the vehicle before driving off by simulta-
neously:

opening the side windows


opening the tilt/sliding sunroof


turning on the seat ventilation* for the
driver’s seat
!If the upward movement of the window
is blocked during the closing proce-
dure, the window will stop and open
slightly.Remove the obstruction, press
the respective power window switch at
the symbolj again past the resis-
tance point and release.If the window
still does not close when there is no ob-
struction, press and hold the respec-
tive power window switch at the
symbolj. The side window will
then close without the obstruction sen-
sor function.
iThe seat ventilation* for the driver’s
seat is automatically set to the highest
level if activated via summer opening
feature.

210 Controls in detailPower windows
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle.

Press and hold button Πuntil the
windows and tilt/sliding sunroof have
reached the desired position.

Release button Πto interrupt pro-
cedure.
Convenience closing feature
When you lock the vehicle, you can close
the windows and tilt/sliding sunroof simul-
taneously.
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(page 210).

Press and hold button ‹ until the
windows and tilt/sliding sunroof are
completely closed.

Release button ‹ to interrupt pro-
cedure.
Vehicles with KEYLESS-GO*:

Press and hold button ‹ or the lock
button at the outside door handle
(page 58) until the side windows and
the tilt/sliding sunroof are completely
closed.

Release button Πor the lock button
at the outside door handle to interrupt
procedure.
Warning!
G
When closing the windows and the tilt/slid-
ing sunroof, make sure that there is no dan-
ger of anyone being harmed by the closing
procedure.
If potential danger exists, proceed as fol-
lows:

Release button
‹
to reverse direc-
tion of movement, press button
Œ

for opening or button
‹
for closing.
Vehicles with KEYLESS-GO*:


Pull on the door handle and hold firmly.
The side windows and the tilt/sliding
sunroof will open for as long as the door
handle is held but the door is not
opened.

211 Controls in detail
Power tilt/sliding sunroof
Power tilt/sliding sunroof
Opening and closing the power tilt/sliding sunroof
The tilt/sliding sunroof can be opened and
closed electrically. The switch for the
tilt/sliding sunroof is on the overhead con-
trol panel.
1Push up to raise sunroof at rear
2Pull down to lower sunroof at rear
3Push forward to slide sunroof closed
4Push back to slide sunroof openWith the sunroof closed or tilted open, a
screen can be slid into the roof opening to
guard against sun rays. When sliding the
sunroof open, the screen will also retract.
Warning!
G
When closing the tilt/sliding sunroof, make
sure that there is no danger of anyone being
harmed by the closing procedure.
The closing procedure of the tilt/sliding sun-
roof can be immediately halted by releasing
the switch or, if the switch was moved past
the resistance point and released, by mov-
ing the switch in any direction.
The tilt/sliding sunroof is made out of glass.
In the event of an accident, the glass may
shatter. This may result in an opening in the
roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts
properly as entire body parts or portions of
them may protrude from the passenger
compartment.


212 Controls in detailPower tilt/sliding sunroof

Switch on ignition (
page 34).
Opening and closing the power
tilt/sliding sunroof

To open, close, raise or lower the
tilt/sliding sunroof, move the switch to
resistance point in the required
direction1to4.

Release the sunroof switch when the
tilt/sliding sunroof has reached the de-
sired position.
Fully opening (Express-open) and clos-
ing (Express-close) the power the
tilt/sliding sunroof

To open, close, raise or lower the
tilt/sliding sunroof, move the switch
past the resistance point in the re-
quired direction1to4 and release.
The tilt/sliding sunroof opens or closes
completely.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment can cause an accident
and/or serious personal injury.!To avoid damaging the seals, do not
transport any objects with sharp edges
which can stick out of the tilt/sliding
sunroof.
Do not open the tilt/sliding sunroof if
there is snow or ice on the roof, as this
could result in malfunctions.
The tilt/sliding sunroof can be opened
or closed manually should an electrical
malfunction occur (
page 386).
iYou can also open or close the tilt/slid-
ing sunroof using the SmartKey, see
“Summer opening feature”
(page 209) and “Convenience clos-
ing feature” (
page 210).
You can close and reopen the tilt/slid-
ing sunroof using the air recirculation
button, or the charcoal filter
buttone in the climate control pan-
el (
page 194).
iWith the SmartKey in starter switch po-
sition 0 or removed from the starter
switch, the tilt/sliding sunroof can be
operated

until you open the driver’s or pas-
senger door


for up to approximately five min-
utes.


213 Controls in detail
Power tilt/sliding sunroof
Stopping the power tilt/sliding sunroof
during Express-operation
Move the switch in any direction.
Synchronizing the power tilt/sliding
sunroof
The tilt/sliding sunroof must be synchro-
nized

after the battery has been
disconnected or discharged


after the tilt/sliding sunroof has been
closed manually (
page 386)


the tilt/sliding sunroof does not open
smoothly


after a malfunction

Switch on ignition (
page 34).

Press and hold the sunroof switch in di-
rection of arrow1 until the tilt/sliding
sunroof is fully raised at the rear.
Keep holding the sunroof switch in the
direction of arrow1 for approximately
one second.

Check the Express-open feature
(page 212).
If the tilt/sliding sunroof opens com-
pletely, the sunroof is synchronized.
Otherwise repeat the above steps.
iThe selecting a tilt/sliding sunroof
opening position feature is activated
for Canada vehicles, but deactivated
for U.S. vehicles at the factory. If you
wish to have it activated, contact an au-
thorized Mercedes-Benz Center.
To select a tilt/sliding sunroof opening
position, press the sunroof switch to
the resistance point and release it
when the tilt/sliding sunroof has
reached the desired position. The
tilt/sliding sunroof now opens to the
position set when the sunroof switch is
pressed past the resistance point in the
“open” direction.
iIf the movement of the tilt/sliding sun-
roof is blocked during the closing pro-
cedure, the sunroof will stop and
reopen slightly.

214 Controls in detailDriving systemsThe driving systems of your vehicle are de-
scribed on the following pages:

Cruise control and Distronic*, with
which the vehicle can maintain a preset
speed.


Airmatic adjusts the vehicle suspen-
sion characteristics automatically and
controls the vehicle level.


ABC* with vehicle level control system,
with which you can change vehicle sus-
pension characteristics.


Parktronic*, which serves as a parking
assistant.
For information on the BAS, ABS, and ESP
driving systems, see “Driving safety sys-
tems” (
page 80).
Cruise control
Cruise control automatically maintains the
speed you set for your vehicle.
Use of cruise control is recommended for
driving at a constant speed for extended
periods of time. You can set or resume
cruise control at any speed over 20 mph
(30 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever on the left-hand side of the steering
column (
page 22).
Warning!
G
Cruise control is a convenience system de-
signed to assist the driver during vehicle op-
eration. The driver is and must remain at all
times responsible for the vehicle speed and
for safe brake operation.
Only use cruise control if the road, traffic
and weather conditions make it advisable to
travel at a steady speed.

The use of cruise control can be danger-
ous on winding roads or in heavy traffic
because conditions do not allow safe
driving at a steady speed.


The use of cruise control can be danger-
ous on slippery roads. Rapid changes in
tire traction can result in wheel spin and
loss of control.


Deactivate cruise control when driving
in fog.
The “Resume” function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.
