2005 MERCEDES-BENZ CLK-Class key

34 AudioRadio operation

Radio operationIn chapter “Audio” you will find detailed
information regarding
radio operation

CD operation (CD drive, CD changer*)

AUX operation
If you have not done so already, please fa-
miliarize yourself with these functions by
reading chapter “At a glance”.

Press A.
Audio menu
If an audio submenu is displayed, press
the
Back
soft key until the Audio menu
is displayed.
or

Press A again.

In the Audio menu, press the soft key
for the desired audio source.
Switching On

Press J.
The system mutes the active audio
source and theß symbol is displayed
in the status bar. The soft keys on the
left side are greyed out in some
submenus.
Switching off

Press J again.
or

Turn the rotary control at the e key to
adjust the volume.
or

Press g or h.
The soft keys on the left side are
selectable again.
Warning
G
In order to avoid distraction which could
lead to an accident, the driver should enter
system settings with the vehicle at a stand-
still and operate the audio system only if
permitted by road, weather and traffic con-
ditions.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is co-
vering a distance of 44 feet (approximately
14 m) every second.
Opening the Audio menuiThe
CD
soft key is available if a CD
changer* is connected to the
COMAND.
Selecting an audio sourceMuting

35 Audio
Radio operation

In the Audio menu, press the
Radio

soft key.
The Radio main menu will appear. The
station last tuned to will begin to play.
Radio main menu1Soft key assignment
2Main area
3Status bar
Switching back to the Audio menu
Press the
Back
soft key.You can select between FM-, AM- and WB-
Band.
AM Band

In the FM Radio main menu, press the FM/AM
soft key until “AM” is displayed
in the status bar.The AM station last tuned to will begin to
play. The frequency will appear in the
display.
Switching back to FM band

Press the
FM/AM
soft key.
The station last tuned to will begin to
play.
Switching to radio operation
iThe
Sound
soft key is available if
COMAND is equipped with a sound
amplifier*.
Changing the Radio band
Frequency band
Frequency range
FM
AM
87.7 - 107.9 MHz
530 - 1710 kHz

36 AudioRadio operationWeather Band WB
In the FM or AM Radio main menu,
press the
WB
soft key.
An automatic scan is starting and the
COMAND plays and displays the
channel of the first strong WB station.
Switching back to FM or AM band

Press the
FM/AM
soft key.
or

Press the
WB
soft key
The station last tuned to will begin to
play.
Switching back to the Audio menu

Press the
Back
soft key.
The Weather Band WB station will con-
tinue to play.You can use the following functions:

Automatic seek tuning (
page 37)

Manual tuning (
page 37)

Station selection from the preset menu
(page 38)

Station selection via direct frequency
entry (FM, AM) (
page 37)

Automatic station scan (FM, AM)
(page 38)

Station selection from the FM/AM
Autostore presets (
page 43)
iWith the number keys 1 - 7 it is pos-
sible to choose a channel.
The message
No channel
will appear
if the system could not detect a chan-
nel.
Selecting a station

37 Audio
Radio operation
Automatic seek tuning
Press g or h.
or

Push the joystick to gor G.
FM- and AM-Bands, Weather Band WB
The radio will tune in to the next receivable
station (FM, AM) or channel (WB) with de-
scending/ascending frequency depending
on the direction of seek.
WB
Alternatively, you can select the channel
directly:

Press a number key 1 through 7.Manual tuning (FM, AM)

Activate the desired wave band
(page 35).

Press g or h longer than 2 se-
conds.
The function is active.

Press g or h repeatedly to
change the frequency step by step.
or

Push the joystick to H or h.
Each handling will change the
frequency by one step.
FM Band
The frequency displayed will change in in-
crements of 0.2 MHz.
AM Band
Tuning will take place in increments of
10 kHz.Station selection via direct frequency
entry (FM, AM)
E.g.: 102.7 MHz in the FM band

Activating the desired wave band
(page 35).

Press *.
An input line will appear.
iThe selected channel is not shown in
the status line.

38 AudioRadio operation
Enter the desired frequency with the
number keys within 8 seconds, e.g.
1027 for 102.7 MHz.
The station you have selected will
begin to play.
FM, AM band
Entries outside the frequency range are
not accepted. The message
Please
observe frequency range 87.7 -
107.9 MHz
will appear briefly.Station selection via number keypad
(presets)
FM- and AM-Bands

Press one of the number keys, such as
2 briefly.
The radio will tune to the frequency as-
signed to that memory location. If none
has been set by you, the radio will not
change the station.Automatic station scan (FM, AM)
The stations on same band (FM, AM) can
be scanned one after the other for 8 se-
conds each.
Start scan function

Activate the desired wave band
(page 35).

Press the
Scan
soft key.
Frequency band
Frequency range
FM
AM
87.7 - 107.9 MHz
530 - 1710 kHz
iIf you do not make another entry within
8 seconds, the function will be canceled
and you will continue listening to the
station last tuned to.
iFM and AM presets are independent
and can only be accessed while in the
corresponding band.
Saving stations for FM and AM
(page 40).
iIn the AM band, two search runs take
place. During the first run, stations with
good reception are played. During the
second run, stations with weaker
reception are played.

39 Audio
Radio operation
The scan function will begin.End scan function and play a station

Press the
Scan
soft key again if you
hear the desired station.
or
The scan function stops automatically
when the first station received has been
scanned twice.

40 AudioRadio operationYou can use the following functions:
Saving stations manually (FM, AM)

Saving stations automatically FM, AM
(page 42)

Selecting a station from the FM/AM
preset menu (
page 43)

Selecting a station from the FM/AM
Auto presets (
page 43)Saving stations manually (FM, AM)
In the Radio main menu

Activate the desired wave band
(page 35).

Press one of the number keys, e.g. 2,
longer than 2 seconds.
You will hear a verification beep if the
beep tones option was activated in the
system settings (
page 162).
The radio saves the current station at
the memory preset selected. The me-
mory preset selected will appear in the
status bar, e.g.
FM2
.On the memory list

Activate the desired wave band
(page 35).

Press the
Presets
soft key.
The memory Preset menu will appear.

Push the joystick to H, h or g,
G to highlight the desired memory
preset.
Memory functions
iThere are 10 presets available (1 -
9, 0).
An existing entry is overwritten in the
memory list when a new input is given.

41 Audio
Radio operation

Press E
longer than 2 seconds.
You will hear a verification beep if the
beep tones option was activated in the
system settings (
page 162).
The current station will be saved at the
memory preset selected.You will see the Radio main menu

automatically after 8 seconds

if you press the
Back
soft key.
iThere are 2 presets for each of the FM
and AM waveband
standard FM/AM presets (saving
stations manually) and

Auto presets (saving stations
automatically).
The standard FM/AM presets are not
affected by the Auto presets. This is a
second option for storing a station ran-
ge you are currently receiving.
