2005 MERCEDES-BENZ C CLASS COUPE mirror controls

ContentsSafety and Security........................... 59
Occupant safety................................... 60 Air bags .......................................... 61
Seat belts ....................................... 66
Children in the vehicle .................... 70
Panic alarm* ........................................ 80 Activating ....................................... 80
Deactivating ................................... 80
Driving safety systems ......................... 81 ABS ................................................ 81
BAS ................................................ 82
ESP ................................................. 83
Anti-theft systems................................ 86 Immobilizer..................................... 86
Anti-theft alarm system* ................ 86
Tow-away alarm* ........................... 87
Controls in detail ............................... 89
Locking and unlocking ......................... 90 SmartKey ....................................... 90
Opening the doors from the inside . 94
Opening the trunk lid ..................... 95
Closing the trunk lid ....................... 95
Trunk lid emergency release .......... 96
Automatic central locking .............. 97
Locking and unlocking from the
inside ............................................. 98
Seats ................................................. 100 Easy-entry/exit feature* .............. 100
Removing and installing front seat
head restraints ............................. 102
Rear seat head restraints ............. 103
Seat heating* ............................... 106
Memory function* ............................. 107 Storing positions into memory ..... 108
Recalling positions from memory . 108
Storing exterior rear view mirror
parking position ........................... 109 Lighting ............................................. 110
Exterior lamp switch .................... 110
Combination switch ..................... 114
Cornering fog lamps*................... 114
Hazard warning flasher ................ 116
Interior lighting ............................ 117
Instrument cluster ............................. 119 Instrument cluster illumination .... 119
Coolant temperature gauge ......... 120
Trip odometer .............................. 121
Tachometer .................................. 121
Outside temperature indicator ..... 121
Control system .................................. 123 Multifunction display.................... 123
Multifunction steering wheel........ 124
Menus .......................................... 126
Standard display menu ................ 128
AUDIO menu ................................ 129
NAV* menu .................................. 131
Vehicle status message memory
menu............................................ 132
Settings menu .............................. 133
Trip computer menu..................... 151
TEL menu* ................................... 153

38 Getting startedAdjustingPower seat* adjustment
The seat adjustment switches are located
in each door.1 Head restraint height
2 Seat height
3 Seat cushion tilt
4 Seat fore and aft adjustment
5 Backrest tilt
Switch on the ignition (
page 33).
or

Open the respective door. Seat fore and aft adjustment

Press the switch forward or backward
in the direction of arrow
4.
Adjust seat to a comfortable seating
position that still allows you to reach
the accelerator / brake pedal safely.
The position should be as far to the rear
as possible, consistent with ability to
properly operate controls. Seat cushion tilt

Press the switch up or down in the
direction of arrow
3 until your upper
legs are lightly supported.
Seat backrest tilt

Press the switch forward or backward
in the direction of arrow 5 until your
arms are slightly angled when holding
the steering wheel.
Seat height

Press the switch up or down in the
direction of arrow 2.
Head restraint height

Press the switch up or down in the di-
rection of arrow 1.
!W h e n m o v i n g t h e s e a t s , m a k e s u r e t h a t
there are no items in the footwell or
behind the seats. Otherwise you could
damage the seats.iThe memory function* (
page 107)
lets you store the settings for the seat
position together with the setting for
the steering wheel and the exterior rear
view mirrors.
iAdjust the head restraint in such a way
that it is as close to the head as possi-
ble.

107
Controls in detail
Memory function*
 Memory function*
You can store up to three different settings
per SmartKey.
The following settings are saved for each
stored position:

Driver’s seat, backrest and head
restraint position


Steering wheel position


Exterior rear view mirror positions
These key-dependent memory settings
can be deactivated if desired. For informa-
tion on key-dependent memory settings,
see “Setting key-dependency”
(
page 149). The following settings are not
key-dependent. They are stored when
using the buttons on the passenger door:


Front passenger seat, backrest and
head restraint position.
!Prior to operating the vehicle, the driv-
er should check and adjust the seat
height, seat position fore and aft, and
seat backrest angle if necessary, to en-
sure adequate control, reach and com-
fort. The head restraint should also be
adjusted for proper height. See also the
section on air bags (
page 61) for
proper seat positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, opera-
tion and comfort. Both the interior and
exterior rear view mirrors should be ad-
justed for adequate rear vision.
Fasten seat belts. Infants and small
children should be seated in a properly
secured restraint system that complies
with U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and Canadian
Motor Vehicle Safety Standards 213
and 210.2.
Warning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.

108 Controls in detailMemory function*The memory button and memory position
switch are located on the door.1 Memory button
2 Memory position switch
Switch on the ignition (
page 33).
or

Open the respective door and insert
the SmartKey in the starter switch.
Storing positions into memory
Adjust the seats, steering wheel and
exterior rear view mirrors to the
desired position (
page 35).

Turn memory position switch 2 to
selected memory position.

Press memory button 1.

Release memory button 1 and press
memory position switch 2 within
three seconds.
All settings are stored at the selected
position.
Recalling positions from memory
Turn memory position switch 2 to
selected memory position.

Press and hold memory position
switch 2 until the seat, steering wheel
and exterior rear view mirrors have
completely moved to the stored
positions.!Do not operate the power seats using
the memory button if the seat backrest
is in an excessively reclined position.
Doing so could cause damage to front
or rear seats.iReleasing the memory position switch
stops movement to the stored posi-
tions immediately.

109
Controls in detail
Memory function*
Storing exterior rear view mirror parking position
For easier parking, you can adjust the pas-
senger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gear
R.
For information on activating the parking
position, see “Activating exterior rear view
mirror parking position” (
page 169). 1Adjustment button
2 Passenger-side exterior rear view
mirror button
3 Memory button

Stop the vehicle.

Switch on the ignition (
page 33).

Press button 2.
The passenger-side exterior rear view
mirror is selected.

Adjust the exterior rear view mirror
with button 1 so that you see the rear
wheel and the road curb.

Press memory button 3 on the door.

Within three seconds, press bottom of
adjustment button 1.
The parking position is stored if the
mirror does not move.
iYou can store a parking position for the
passenger-side exterior rear view mir-
ror for each SmartKey.
iIf the mirror does move, repeat the
above steps. After the setting is stored
you can move the mirror again.

136 Controls in detailControl systemThe table below shows what settings can
be changed within the various menus.
Detailed instructions on making individual
settings can be found on the following
pages.Instrument cluster
Time/Date
Lighting
Vehicle
Convenience
Selecting temperature
display mode
Time synchronization with
head unit*
Setting daytime running
lamp mode (USA only)
Setting automatic
locking
Activating
easy-entry/exit feature
Selecting speedometer
display mode
Setting the time (hours)
Setting locator lighting
Setting key-dependency
Selecting language
Setting the time (minutes)
Setting night security
illumination
Setting parking position
for exterior rear view
mirror
Selecting display (speed
display or outside tempera-
ture) for status indicator
Selecting time display mode
Setting interior lighting
delayed shut-off
Selecting automatic time
change (Daylight Saving
Time (DST) summer/winter)Setting the date (month)Setting the date (day)Setting the date (year)

148 Controls in detailControl systemVehicle submenu
Access the
Vehicle
submenu via the
Settings
menu. Use the
Vehicle
submenu
to make general vehicle settings.
The following function is available:
Setting automatic locking
Use this function to activate or deactivate
the automatic central locking. With the
automatic central locking system
activated, the vehicle is centrally locked at
vehicle speeds of approximately 9 mph
(15 km/h).

Move the selection marker with
button æ orç to the
Vehicle

submenu.

Press button j ork repeatedly
until the message
Automatic door lk.

appears in the multifunction display. The selection marker is on the current
setting.

Press button
æ orç to switch
the automatic central locking
On or
Off
. Convenience submenu
Access the
Convenience
submenu via the
Settings
menu. Use the
Convenience

submenu to change the settings for a
number of convenience features.
The following functions are available:
Activating easy-entry/exit feature*
Use this function to activate and deacti-
vate the easy-entry/exit feature
(
page 100).
Function
Page
Set automatic locking
148
Function
Page
Activate easy-entry/exit
feature*
148
Setting key-dependency
149
Setting parking position for exte-
rior rear view mirror
150

149
Controls in detail
Control system

Move the selection marker with
button
æ orç to the Convenience
submenu.

Press button j ork repeatedly
until the message
Easy-entry feature

appears in the multifunction display.
The selection marker is on the current
setting.

Press æ orç to change the
easy-entry/exit setting. The following settings are available for
the easy-entry/exit feature:
Setting key-dependency
Use this function to set whether the
memory settings for the seats, the steering
wheel and the mirrors should be stored
separately for each SmartKey
(
page 107).

Move the selection marker with
button æ orç to the Convenience
submenu.

Press button j ork repeatedly
until the message
Key dependency

appears in the multifunction display.
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the easy-en-
try/exit feature is activated.
To cancel seat/steering wheel movement,
do one of the following:

Press seat adjustment switch*
(page 38).


Move steering column stalk*
(page 41).


Press the memory position switch*
(page 108).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
Off
The easy-entry/exit
feature is
deactivated
Steer. Column
Only the steering
column is moved
St.col.+seat
Both the steering
column and the seat
are moved
